EMTEST UCS 500Nx Series User manual

M a n u a l
F o r O p e r a t i o n
UCS 500Nx
The ultra-compact simulator
and its system modules
UCS 500 N5
UCS 500 N7
Modules for Telecom surge
Tsurge5 / Tsurge7
CNT 508 / CNT 516
V 4780 / V4780 S1
UCS500Nx - designed as a modular system - is the most
intelligent solution offering exactly what you need for full-
compliant immunity tests against transient and power fail
phenomena. The distinct operation features, convenient DUT
connection facilities, a clearly arranged menu structure and
display philosophy as well as the pre-programmed standard test
routines make testing easy, reliable and safe. Extendable by a
variety of test accessories the UCS 500Nx is a universal
equipment for abroad range of recommendations even for three-
phase applications up to 100A
EN/IEC 61000-4-4
EN/IEC 61000-4-5
EN/IEC 61000-4-8
EN/IEC 61000-4-9
EN/IEC 61000-4-11
EN/IEC 61000-4-12
EN/IEC 61000-4-29
EN 61000-6-1
EN 61000-6-2
Version:
5.40 / 13.12.2016
the benchmark for emc
Replaces:
5.39 / 03.08.2016
Filename:
UserManual-UCS 500N5-7-E-V5.40.doc
Printdate:
13.12.16

EM TEST UCS 500 Series
Operating Manual V 5.40 2 / 99
EM Test (Switzerland) GmbH
Sternenhofstrasse 15
4153 Reinach BL1
Switzerland
Phone : [phone]
Fax : [phone]
URL : http://www.emtest.com
Copyright © 2016 EM Test (Switzerland) GmbH
All right reserved.
Information in earlier versions. Specifications subject to change

EM TEST UCS 500 Series
Operating Manual V 5.40 3 / 99
Contents
1. Model Overview...............................................................................................................6
1.1. UCS Models........................................................................................................................................6
1.2. Standards covered by UCS N Series.................................................................................................8
2. Safety information...........................................................................................................9
2.1. Protected Earth PE.............................................................................................................................9
2.2. FI Fault current protection ..................................................................................................................9
3. Operating Functions .....................................................................................................10
3.1. Front view.........................................................................................................................................10
3.2. Rear view..........................................................................................................................................12
4. Operation .......................................................................................................................15
4.1. Description of the menus..................................................................................................................15
4.2. Menu structure..................................................................................................................................15
4.3. Main Menu........................................................................................................................................16
4.4. Service..............................................................................................................................................17
4.5. Setup ................................................................................................................................................19
4.6. Setup procedure for Set voltage.......................................................................................................21
5. Test Equipment UCS 500N ...........................................................................................22
5.1. UCS 500 N5......................................................................................................................................22
5.2. UCS 500 N7......................................................................................................................................23
6. Technical data ...............................................................................................................24
6.1. EFT Electrical Fast Transients Burst as per IEC 61000-4-4...............................................................24
6.2. SURGE Immunity requirements as per IEC 61000-4-5 ...................................................................25
6.3. Power Fail Generator as per IEC 61000-4-11..................................................................................26
6.4. RINGWAVE Immunity requirements as per IEC 61000-4-12...........................................................27
6.5. Telecom Surge Generator as per IEC 61000-4-5 (TSurge module)................................................28
6.6. EUT Supply Specifications ...............................................................................................................29
6.7. General Specifications......................................................................................................................30
6.8. Environmental conditions .................................................................................................................30
6.9. Technical data of special generators................................................................................................31
6.9.1. UCS 500N5.2T .................................................................................................................................31
6.9.2. UCS 500N5.5 and UCS 500N5.6 and UCS 500N5.9 for Railways application................................32
6.9.3. UCS 500N5.11 .................................................................................................................................33
6.9.4. UCS 500N6.5....................................................................................................................................34
6.9.5. UCS 500N6.7....................................................................................................................................34
6.9.6. UCS 500N7.1....................................................................................................................................35
6.9.7.UCS 500N7.4....................................................................................................................................35
7. Maintenance setup and service ...................................................................................36
7.1. General.............................................................................................................................................36
7.2. Test set- up.......................................................................................................................................36
7.3. Fuse for the EUT power supply........................................................................................................36
7.4. Insulating- or external transformer for EUT power supply................................................................36
7.5. Calibration and verification...............................................................................................................37
7.5.1. Factory calibration ............................................................................................................................37
7.5.2. Guideline to determine the calibration period of EM Test instrumentation ......................................37
7.5.3. Calibration of Accessories made by passive components only: ......................................................37
7.5.4. Periodically In-house verification......................................................................................................37
8. Delivery Groups.............................................................................................................38
8.1. Basic equipment...............................................................................................................................38
8.2. Accessories and options...................................................................................................................38

EM TEST UCS 500 Series
Operating Manual V 5.40 4 / 99
9. EFT Burst as per IEC 61000-4-4 ..................................................................................40
9.1. Operation..........................................................................................................................................40
9.1.1. Quick Start........................................................................................................................................41
9.1.2. Standard test routines .....................................................................................................................42
9.1.3. User Test Routines...........................................................................................................................43
9.2. Burst generation ...............................................................................................................................45
9.3. Test level with Burst as per IEC 61000-4-4 Ed.2. ............................................................................45
9.4. Coupling/decoupling network ...........................................................................................................46
9.4.1. Coupling/decoupling network for ac/dc power lines.........................................................................46
9.4.2. Capacitive coupling clamp................................................................................................................46
9.5. Burst Test Setup...............................................................................................................................46
9.5.1. Test setup with capacitive coupling clamp.......................................................................................47
10. Surge Immunity as per IEC 61000-4-5 .........................................................................48
10.1. Operation..........................................................................................................................................48
10.1.1. Quick Start........................................................................................................................................49
10.1.2. Standard test Routine.......................................................................................................................50
10.1.3. User Test Routines...........................................................................................................................52
10.1.4. Phase synchronization in 3-phase system.......................................................................................54
10.1.5. Pulsed magnetic field as per IEC 61000-4-9....................................................................................56
10.1.6. Setup current limiter for surge current..............................................................................................57
10.1.7. Charging time for surge....................................................................................................................58
10.2. Surge pulse generation ....................................................................................................................59
10.3. Coupling/decoupling network ...........................................................................................................59
10.3.1. Coupling to ac/dc power supply lines...............................................................................................59
10.3.2. Coupling to I / O lines .......................................................................................................................60
10.4. Test set-up........................................................................................................................................60
11. Voltage Dips as per IEC 61000-4-11.............................................................................61
11.1. Test setup for DIPS and Interruption tests.......................................................................................61
11.2. Operation..........................................................................................................................................61
11.2.1. Quick Start........................................................................................................................................62
11.2.2. Standard Test Routines....................................................................................................................63
11.2.3. User Test Routines...........................................................................................................................67
11.3. The Power Fail Test .........................................................................................................................68
11.4. Overcurrent.......................................................................................................................................69
11.5. The Power Fail Test .........................................................................................................................70
11.5.1. Voltage Interruptions ........................................................................................................................70
11.5.2. Voltage dips, voltage variations........................................................................................................71
11.6. DC Power networks..........................................................................................................................71
11.7. Test setup and accessories..............................................................................................................72
11.7.1. Transformer type V4780...................................................................................................................72
11.7.2. Motor variac type MV 2616...............................................................................................................74
11.8. 50/60Hz Magnetic Field as per IEC 61000-4-8................................................................................76
12. Ringwave Immunity as per IEC 61000-4-12.................................................................78
12.1. Operation..........................................................................................................................................78
12.1.1. Quick Start........................................................................................................................................78
12.2. Ring wave pulse generation.............................................................................................................80
12.3. Coupling/decoupling network ...........................................................................................................80
12.3.1. Coupling to ac/dc power supply lines...............................................................................................80
12.4. Test set-up........................................................................................................................................80
13. Telecom Surge...............................................................................................................81
13.1. UCS 500N5T with Telecom Surge Module ......................................................................................81
13.2. TSurge7 Module...............................................................................................................................81
13.3. TSurge7 Module...............................................................................................................................81
13.4. TSurge Menu....................................................................................................................................82
13.4.1. Quick Start........................................................................................................................................82
13.5. Coupling Network .............................................................................................................................83
13.6. Test Setup ........................................................................................................................................84
13.7. Test pulses TSurge Modules............................................................................................................84
13.7.1. Waveshape Definitions according IEC 61000-4-5 Ed 3.0................................................................84
13.7.2. Pulse 10 / 700s as per IEC 61000-4-5...........................................................................................85
13.7.3. Pulse 9 / 720s as per FCC .............................................................................................................85

EM TEST UCS 500 Series
Operating Manual V 5.40 5 / 99
14. Appendix........................................................................................................................86
14.1. Declaration of CE-Conformity...........................................................................................................86
14.1.1. Declaration of Conformity UCS 500N5.............................................................................................86
14.1.2. Declaration of Conformity UCS 500N7.............................................................................................87
14.1.3. Declaration of Conformity UCS 500N5x models for one phenomenon............................................88
14.1.4. Declaration of Conformity UCS 500N5x models..............................................................................89
14.1.5. Declaration of Conformity TSurge 7 Module for UCS 500N7...........................................................90
14.1.6. Declaration of Conformity CNT 516..................................................................................................91
14.1.7. Declaration of Conformity Tapped Transformer...............................................................................92
14.2. UCS 500N - General Diagram..........................................................................................................93
14.3. Main diagram control connection......................................................................................................93
14.4. Main diagram high voltage connection.............................................................................................94
14.5. CNT 508N.........................................................................................................................................95
14.6. CNT 516 ...........................................................................................................................................97
14.7. USB interface....................................................................................................................................99

EM TEST UCS 500 Series
Operating Manual V 5.40 6 / 99
1.
Model Overview
The following manual is based on the following or later firmware:
- UCS 500N5 : V 5.00xx
- UCS 500N7 : V 8.00xx
- UCS 500N7 : V 9.00xx Supports ANSI A/B coupling method. Requires iec.control V 5.2.3.0 or higher
Devices with the Firmware
- UCS 500N5 : V 4.40uxx
- UCS 500N7 : V 7.40uxx
Have a reduced PFS function of the PFS module. For UCS generators with this firmware version exist a separate
manual with the version 5.09. This manual can be ordered at EM TEST if required.
1.1.
UCS Models
Standard models
Model
U pulse
CDN
Remarks
UCS 500N5
5.5kV
300V 16A 1- ph
UCS 500N5.1
5.5 kV
300V 32A 1- ph
Optional + Tsurge 6HU
UCS 500N5T
5.5 kV
300V 16A 1- ph
EFT, Surge, PFS, TSurge 6HU
UCS 500N5.1T
5.5 kV
300V 32A 1- ph
EFT, Surge, PFS, TSurge 6HU
UCS 500N7
7kV
300V 16A 1- ph
DC 300V / 16A ANSI
UCS 500N7.1
7kV
300V 32A 1- ph
DC 300V / 32A ANSI 9HU
Additional extensions
TSurge5
4kV
Built-in 10/700us pulse module up to 5kV, ITU K22 & IEC 61000-4-5
TSurge7
6kV
External 10/700us pulse module up to 7kV, ITU K22 & IEC 61000-4-5
UCS500N with one built in module
The device includes only one module Surge, Burst or Power Fail. The technical data are identical with the
standard UCS500N5. An extension with additional modules is not possible.
UCS500N5V
5kV
UCS500 with Surge Module
UCS500N5E
5.5kV
UCS500 with EFT Burst Module
UCS500N5P
--
UCS500 with Power Fail Module
Module for UCS500N7
Module
Remarks
EFT/N7
Built-in 5.5kV BURST MODULE
VCS/N7
Built-in 7.0kV SURGE MODULE
PFS/N7
Built-in POWER FAIL MODULE 300 volts/ 16 amps. Mandatory for EUT power switch off
RWG/N7
Built-in Ring Wave Module 6 kV / 100 kHz, Ri =12/30 Ωas per ANSI
(not available for UCS 500N7.1 or UCS 500N7.2)
RWG/N7.1
Built-in Ring Wave Module 6 kV / 100 kHz, Ri =12/30/50 Ωas per ANSI / UL 1741,
No peak current measurement (display indicates = ---).
(not available for UCS 500N7.1 or UCS 500N7.2)
TSurge7
External 10/700us pulse module up to 7.0kV, ITU K22 & IEC 61000-4-5

EM TEST UCS 500 Series
Operating Manual V 5.40 7 / 99
Special models
Model
V
Pulse
CDN
Remarks
UCS 500N5.2
5.5kV
400V 16A 1- ph
UCS 500N5.2T
5.5kV
300V 16A 1- ph
UCS 500 with VCS/5 and Telecom Surge module
UCS 500N5.3
5.5 kV
400V 32A 1- ph
UCS 500N5.3-PFS
5.5 kV
400V 32A 1- ph
UCS500 with Power Fail module 400V AC 32A (L-N)
UCS 500N5.4
5.5kV
300V 16A 1- ph
DC 300V 16A
UCS 500N5.5
5.5 kV
300V 32A 1- ph
EFT/5 and VCS/5
10/40for supply lines EN 50121-3-2:2007 (Railway)
UCS 500N5.6
5.5 kV
300V 32A 1- ph
EFT/5 VCS/5 and PFS/5
10/40for supply lines EN 50121-3-2:2007 (Railway)
UCS 500N5.7
5.5kV
300V 16A 1- ph
EFT/5 and VCS/5
UCS 500N5.8
5.5kV
300V 16A 1- ph
EFT/5 and PFS/5; 1ph CDN 300V/16A
UCS 500N5.9
5.5 kV
300V 16A 1- ph
10/40for supply lines EN 55121 (Railway)
UCS 500N5.10
5.5kV
690V 16A 1- ph
VCS/5 without built-in coupler
UCS 500N5.11
5.5kV
690V 16A 1- ph
EFT/5, VCS/5 / Tsurge
UCS 500N7.2
7kV
400V 16A 1- ph
EFT/N7, VCS/N7, PFS/N7 (ANSI)
UCS 500N7.3
7kV
300V 16A 1- ph
EFT/N7, VCS/N7, PFS/N7 (ANSI), RWG/N7.x
UCS 500N7.4
7kV
400V 16A 1- ph
EFT/N7, VCS/N7, PFS/N7, (ANSI), RWG/N7.x
UCS 500N7.6
7kV
690V 16A 1- ph
EFT/N7, VCS/N7.x, RWG/N7, without built-in coupler! AC Voltage 690V
UCS 500N7.7
7kV
690V
EFT/N7, VCS/N7.x, without built-in coupler! AC Voltage 690V(p-p)
UCS 500N7.8
7kV
400V 16A 1- ph
EFT/N7, RWG/N7.x (output impedance 12 and 25 ohm); (ANSI)
UCS 500N7.9
7kV
690V
EFT/N7, VCS/N7, RWG/7.x (Ri 12Ω & 50Ω), no built-in coupler, 690V(p-p)
UCS 500N7.10
7kV
690V
VCS/7, no built-in coupler! Application Voltage 690V(p-p)
Other models up to 2009
Model
Name up to 2008
Pulse voltage
CDN
UCS 500 N4.1
UCS 500 M4 S1
4kV
250V 32A single phase
UCS 500 N6
UCS 500 M6B
6kV
250V 16A single phase
UCS 500 N6.1
--
6kV
250V 32A single phase
UCS 500 N6.3
--
6kV
480V 32A single phase
Models up to 2008
Model Pulse voltage
CDN
UCS 500 4kV
250V 16A single phase
upgrade version
UCS 500 M4 4kV
250V 16A single phase
UCS 500 M6 6kV
250V 16A single phase
UCS 500 M6A 6kV
250V 16A single phase

EM TEST UCS 500 Series
Operating Manual V 5.40 8 / 99
Special models
Special models have the index UCS500Nx Sx. The difference to the standard models are: Voltage- and current
ranges. The operation is the same as by the standard UCS equipment’s.
Model Pulse voltage
CDN
UCS 500 M4 S1 4kV
250V 32A single phase
UCS 500 M4 S2 4kV
690V 16A single phase
UCS 500 M4 S3 4kV
690V 32A single phase
UCS 500 M4 S5 4kV
280V 16A single phase
UCS 500 M6 S2 6kV
690V 16A single phase
ANSI
Model
Pulse EUT
Modules
UCS 500 M6B S1
6kV 250V 32A
EFT/6, VCS/6 and PFS/6; 1ph CDN 250V / 32A (ANSI)
module RWG/6 not available
UCS 500 M6B S2
6kV 690V 16A
EFT/6, VCS/6 and PFS/6; 1ph CDN 690V / 16A (ANSI) 480V dc
module RWG/6 not available
1.2.
Standards covered by UCS N Series
A fully equipped UCS 500N covers the following standards
UCS 500
N5
N7
- IEC 61000-4-4
Burst
X
X
- IEC 61000-4-5
Surge
X
X
- IEC 61000-4-8
50/60Hz Magnetic Field
X
X
- IEC 61000-4-9
Pulse Magnetic Field
X
X
- IEC 61000-4-11
Voltage Dips
Voltage Interruptions
Voltage Variations for ac power mains supply
X
X
- IEC 61000-4-12
Ringwave
X
- IEC 61000-4-29
Voltage Interruptions
Voltage Dips for dc power supply systems
X
X
- ANSI
Surge with 2coupling
X
- ITU and ETS
Telecom Surge
(X)
(X)
- FCC
Part 68
(X)
(X)

EM TEST UCS 500 Series
Operating Manual V 5.40 9 / 99
2.
Safety information
Attention
Before using this equipment, read the operating manual and the
separate delivered safety manual carefully
2.1.
Protected Earth PE
The protective conductor connection is established via the attached power cord and must not be interrupted
under any circumstances.
DANGER
Check before connecting the power supply to the unit that the grounding of the building supply is
installed according to regulations.
In the absence of an earth connection can the frame can be get in the event of a fault, to the mains
voltage potential.
The generator must be properly grounded before connecting on-the EUT supply voltage to the
generator.
2.2.
FI Fault current protection
The standards recommend decoupling and filter capacitors to PE for decoupling surge pulses. This is the reason
for tripping fault current protection relays interrupt the mains to the EUT supply. For eliminate the circumstance
use one of the following options:
Remove the fault current protection
This solution does not limit the current to PE. The surge test as other EMC tests with higher currents to PE are
possible. The user must take care to the circuit with no fault current protection. Only trained professional people
are allowed to perform such tests.
Using of insulating transformers
An insulating transformer separates the circuit from the test circuit. The Fault current detector cannot detect the
earth current in the EUT circuit. The synchronization works between line and PE and therefore a connection
between neutral and PE is necessary. Without this N-PE connection the stray capacitance defines the phase
sync.
The fault current safety detection function in the generator circuit is disabled. The user must respect
this circumstance. For a safe operation he must follow the electrical rulers.
Behind the insulating transformer the neutral and PE must be connected for a proper phase synchronization of
the generator. In case of a 3-phase system the user must perform similar.

EM TEST UCS 500 Series
Operating Manual V 5.40 10 / 99
3.
Operating Functions
3.1.
Front view
1Display
2Function keys "F1..F7
3"Test On"
4Knob (Inc. / Dec
5Cursor keys "" and ""
6Exit
7Escape
8CRO U (surge)
9 CRO I (surge)
10 CRO Trigger output 5V
11 HV pulse Burst output 50 
12 Ground reference
13 Coupling (Burst, Surge and EFT)
14 Channel PF1 and PF2
15 EUT test supply
1 Display
All functions and parameters are displayed (8 lines with max. 40 characters).
2 Function keys "F1 .. F7”
Parameters and functions, displayed in the lowest line, can be selected with the related function key.
3 Test On
By pressing the key "Test On" follows the functions:
- Activate the high voltage power unit; HV is ready to start.
- Switches ON the supplyto the EUT test supply (only with built in PFS module).
- The LED indicates the trigger of a burst event.
4 Knob (Inc. / Dec
The knob increments or decrements test parameters with a numeric value or selects from a list of parameters.
5 Cursor keys
Parameters and functions can be changed on-line. The selection of these parameters is realized with the cursor
moving to the left or to the right.
6 Exit
Pressing of the Exit function will cause a reset of the firmware. This is only possible if no test routine is running.
7 ESC
When pressing the ESC button the user moves back one page in the menu.
8 CRO U (surge)
At the BNC output the voltage pulse (surge) of the generator can be measured galvanic separated.
- Impedance measuring instrument: >1MΩ.
- Max. output voltage: 10V 10% at 5 kV / 7kV impulse voltage.
9 CRO I (surge)
At the BNC output the current pulse (surge) of the generator can be measured galvanic separated.
- Impedance measuring instrument: >1MΩ.
- Max. output voltage: 10V 10% at 2.5 kA / 3.5kA output current.
10 BNC - CRO Trigger
At the BNC output the generator trigger can be checked, e.g. the burst duration, the burst repetition rate and the
spike frequency (+5 V rectangular). This output can be generally used as oscilloscope trigger output and is
synchronous to the following events.
- Burst and surge release
- Voltage dip or interruption, start of the event

EM TEST UCS 500 Series
Operating Manual V 5.40 11 / 99
1Display
2Function keys "F1..F7
3"Test On"
4Knob (Inc. / Dec
5Cursor keys "" and ""
6Exit
7Escape
8CRO U (surge)
9 CRO I (surge)
10 CRO Trigger output 5V
11 HV pulse Burst output 50 
12 Ground reference
13 Coupling (Burst, Surge and EFT)
14 Channel PF1 and PF2
15 EUT test supply
11 HV pulse burst output 50 
External coupling devices such as the capacitive coupling clamp and the 3-phase coupling network are
connected to the coaxial 50 ohm output. Also the calibration of the generator is handled at this output.
Note: The burst signal is present on this output at every coupling mode.
12 Ground reference
During test or calibration procedure the burst generator must be grounded to the reference ground plane
13 Coupling mode
The actual coupling mode is indicated by LED
14 Channel PF1/PF2
This LED indicates the channel mode during the power fail test.
15 EUT test supply
For single-phase EUT the coupling/decoupling network is part of the generator. The EUT is powered via the
safetybanana plugs at the front panel of the simulator.

EM TEST UCS 500 Series
Operating Manual V 5.40 12 / 99
3.2.
Rear view
1Test supply input; channel PF1 together with
the red lamp for phase indication
2Test supply input; channel PF2 together with
the red lamp for phase indication
3 Test supply input neutral
4 Test supply input PE
5 Sync input
1 Test supply PF1
The phase of the power supply for the EUT is connected to the banana connector PF1. The phase L is
conducted to the EUT voltage supply via PF1 if channel PF1 is selected in the set-up menu.
To guarantee a correct function of the synchronization the phase shall be connected to this input. The red lamp
than shall be alighted.
2 Test supply PF2
This input is generallyused for the reduced dip voltage for testing as per IEC 61000-4-11. At this PF2 input a
variac transformer is connected with a reduced voltage, e.g., 0-250V. A motor driven variac transformer can be
controlled via a 0-10V analogue control output.
To guarantee a correct function of the synchronization the phase shall be connected to this input. The red lamp
than shall be alighted.
3 Test supply neutral (PF1/PF2)
The neutral line of the power supplyfor the EUT is connected to the banana connector N.
4 Test supply PE (PF1/PF2)
The protective earth line of the power supply for the EUT is connected to the banana connector PE.
5 SYNC input
An ac voltage to which the events shall be synchronized is connected to this input. If no voltage is available the
tests are started automatically in asynchronous mode. Normally this input shall be connected directly to L of the
channel PF1. Umax. Sync = Umax. EUT
Connection EUT supply
AC Supply
The EUT power supply is normally connected to
the UCS plugs PF1, N and PE
A tap of a motor variac transformer or adapting
transformer for power fail testing is connected to
the connection PF2.
The phase synchronization SYNC must be
connected to PF1. By missing this connection all
tests runs in asynchronous mode with no phase
angle adjust for pulse release.
DC Supply
DC+ to PF1, and PF2 for DIPS
DC- to N
additional PE (depends application)
Earth bolt
The earth bolt must be connected to the ground
reference.

EM TEST UCS 500 Series
Operating Manual V 5.40 13 / 99
6Reference Earth connection
7HV output for Surge pulse
8Common output for Surge pulse
9 Ventilation
10 Warning lamp
11 External trigger
12 BNC connector MON U
13 BNC connector MON I
6 Reference earth connection
The generator has to be connected to the reference earth plane of the test set up. The connection at the rear
part of the generator is an alternative to the grounding point at the front panel
7 HV output
The coax plug is the HV HIGH output of the simulator. It is used for external coupling/decoupling networks.
8 COM output
The Com output is the HV LOW output of the simulator. The output is floating
Attention
The direct output of the surge generator is located at the rear panel of the instrument, HV and
COM. It is not allowed to connect these outputs to anyother coupling/decoupling network than
manufactured byEM TEST, e.g. the types CNV and CNI. Before to connect any external
networks to this output the operator must contact the manufacturer. Any damages due to this
matter are not covered by warranty.
The direct pulse output shall also not be used to connect the generator directly to any power
conducting lines
The wave shape measured at the direct pulse output must not be within the tolerances specified in
IEC 61000-4-5. The pulse shape shall be verified at the CDN output directly, no matter whether it
is an internal or external CDN.
9 Ventilation
After long term duration tests the generator should keep on running for some minutes to cool down the system.
10 Warning lamp
A voltage free contact is available for external warning indications (warning lamp). The signal is generated after
pressing TEST ON.
11 External trigger
One single event, burst, surge, voltage dip or ESD can be released. Trigger level 5V positive going.
12 BNC connector MON U
At this BNC connector the output power supply voltage for the EUT can be measured. Ratio 100:1 5%.
Impedance measuring instrument: 1M.
13 BNC connector MON I
At this BNC connector the output current for the EUT can be measured, e.g. the nominal current or the peak
inrush current. The rating is 10mV/A 5%. Maximum current = 1000A
Impedance measuring instrument: 1M.

EM TEST UCS 500 Series
Operating Manual V 5.40 14 / 99
14 Control output 0-10V
15 Security circuit
16 Mains selector 115V / 230V
17 Power on switch
18 Fuse of the high voltage power supply
19 Serial interface USB
20 Parallel interface IEEE
21 Remote control connector
22 FAIL 1
23 FAIL 2
14 Control output 0-10V
The voltage is used to control external power sources. The source is normally connected to the channel PF2
(normally a motor driven variac transformer). The voltage level is selectable via the operating facilities of the
UCS 500N. The voltage level can also be selected within the service menu under the function „setup.
This output is not mounted on UCS500N5E and UCS500N5V.
15 Safety circuit
The test can only be started if the security circuit is closed. If the circuit is opened during a running test the
simulator will be switched off immediately.
14 Mains selector
Selection of 115V / 230V
17 Power on switch
The switch is part of the mains filter. Mains fuses are part of the filter. (230V / 2 A and 115V / 4 A)
18 Fuse of the high voltage power supply
The high voltage power supply is protected by this fuse „F3“. In case that no high voltage is generated but the
control unit works properly this fuse shall be checked.
19 USB interface
USB interface “USB B” connector. For data-transfer a USB interface is available. The internal RS 232 interface
is converted to USB standard. Therefore the user must set the same baud-rate in the device and control
software.
Using the USB interface may cause EMC problems during burst tests at the computer or notebook side of
the communication line. Therefore a high quality USB cable (USB 2.0 standard) shall be used.
20 Parallel interface GPIB / IEEE 488
IEEE 488 interface with IEEE connector
21 Remote control connector CN
External coupling devices are controlled via this remote control connector.
22 Fail detection FAIL 1 EUT control (TEST STOP
Grounding this input will cause a complete stop of the running test procedure. (+15V to ground) The test must
be completely restarted.
23 Fail detection FAIL 2 EUT control (TEST PAUSE
Grounding this input will cause a break for the running test procedure (+15V to ground).The test will be
continued when the input is no more connected to ground.

EM TEST UCS 500 Series
Operating Manual V 5.40 15 / 99
4.
Operation
4.1.
Description of the menus
The simulator is operated by an easy menu control system. Seven function
keys are available to select parameters and functions. All functions are
indicated on the display; max. 8 lines and 40 characters.
The selected parameter is blinking and can be changed by turning the knob (inc./dec.).
 : The digit for change can be selected with the cursor ( ).
- Selected values are direct indicated on the screen.
- Status on the bottom lines shows the desired status after pressing the function key.
ESC : ESC will take you back to the previous level in the menu and set the displayed
values. The latest settings are stored automatically and will be recalled when the
menu is selected again.
EXIT : The firmware will reset to the main screen.
EM TEST
UCS 500 N5
Ultra Compact Simulator
V 5.00a02
Burst
Surge
Power Fail
SWN: 001234
The serial number and the version number SWN are
used for traceability reasons. These numbers are listed
in the test reports and calibration certificates. These
numbers also are listed within the test reports
generated by the iec.control software.
Start-up display example UCS 500N5. The models type is displayed after startup.
4.2.
Menu structure
Level 0...4
Level 0
Level 1
Level 2
Level 3
Level 4
MAIN MENU
F1 BURST IEC 61000-4-4
F2 SURGE IEC 61000-4-5/9
F3 PFS IEC 61000-4-11/8/29
F7 SERVICE
Burst IEC 61000-4-4
F1 Quick Start
F2 Standard routines
F3 User test routines
Quick Start
F1 Start
F2 Change
F3 Continue
Start
Start the test routine
Change
Select all parameters
Continue
Continue the test routine
Surge IEC 61000-4-5/9
Standard routines
Preprogrammed test routines as
per standard requirements
Standard routines
F1 : F4 IEC 61000-4-4 Level 1-4
F5 Generic Standard EN 61000-6-1
F6 Generic standard EN 61000-6-2
F7 Manual standard routine
Standard routines F1..F3
F1 Start
F2 Change
F3 Continue
Power Fail IEC 61000-4-8/11/29
User test routines
Preprogrammed test routines for
evaluation and design support
F1 Synchronous to the mains
F2 Random burst release
F3 Change V after T by U
F4 Frequency sweep I
F5 Frequency sweep II
F6 Frequency sweep III
F7 Change polarity after T
User test routines F1..F3
F1 Start
F2 Change
F3 Continue
Service
F1 Addresses
F3 Setup
F4 Change standard levels
Setup
F1 Change language
F2 LCD backlighting
F3 Interfaces
F4 ESD/keyboard beeper
F5 Running time clock
F6 Set voltage
F7 Magnetic field factors
Change language Gern or English
LCD backlighting On, Off or Auto
Interfaces Select all parameters
ESD/keyboard beeper (on, off)
Running time clock
Display of the TEST ON time
Set voltage (ext. motor variac)
Magnetic field factors
Correction factors for magnetic field
antenna and current transformer
Change standard level
Change standard level
F1 All parameters to standard level
F2 IEC 61000-4
F3 EN 61000-6-1
F4 EN 61000-6-2
Change standard levels
F1 IEC 61000-4-4 Burst
F2 IEC 61000-4-5 Surge
...

EM TEST UCS 500 Series
Operating Manual V 5.40 16 / 99
4.3.
Main Menu
MAIN MENU
F1 : Burst IEC 61000-4-4
F2 : Surge IEC 61000-4-5/9
F3 : Power Fail IEC 61000-4-11/8/29
F4 : Ringwave IEC 61000-12
F5 : TSurge
F7 : Service
F1
F2
F3
F4
F5
F6
F7
F1 Burst test
With function key F1 the user can select Burst Test as per IEC 61000-4-4. The test pulses are fast transients with
a pulse shape of 5/50ns.
Attention: The generator covers the new specifications given in the draft revision IEC 61000-4-4 edition 2. This means a new spike
frequency which is selectable between 5 kHz and 100 kHz. The burst duration is automatically matched between 15ms
and 0.75ms. The common mode coupling is new with all couplings at the same time.
F2 Surge test
With function key F2 the user can select Surge Test as per IEC 61000-4-5. The test pulses are high energy pulse
with a voltage shape of 1,2/50s and a short circuit current shape of 8/20s.
In addition the test procedure for Pulse Magnetic Field testing as per IEC 61000-4-9 is included in this menu.
F3 Power Fail test
With function key F3 the user can select the Power Fail Test as per IEC 61000-4-11.
The simulator will generate voltage dips and voltage variations with preselectable parameters. IEC 61000-4-11 is
valid for ac power supply systems. For dc supply system in future IEC 61000-4-29 shall be recommended.
In addition the test procedure for 50/60Hz Magnetic Field Testing as per IEC 61000-4-8 is included within the
menu.
The Power fail menu includes a Voltage Variation test as per IEC 61000-4-11 as test procedure. The simulator
will generate voltage variations in the second range.
Attention: The generator covers already the new specifications given in FDIS IEC 61000-4-11: 2004. This means the introduction of
a new 80% test level as well as a new function for the Voltage Variation test.
F4 Ringwave as per IEC 61000-4-12 (UCS500 N7)
With function key F4 the user can select the Ring Wave Test as per IEC 61000-4-12 or ANSI/IEEE. The test
pulses are single-shot with an oscillating and decaying waveshape.
F5 Telecom Surge Test
With the Option TSurge a Telecom Surge pulse 10/700s as per IEC 61000-4-5, ITU, ETS or FCC part 68 Pulse
B is available.
F7 Service
Setup and servicing routines are available.

EM TEST UCS 500 Series
Operating Manual V 5.40 17 / 99
4.4.
Service
SERVICE
F1 : Addresses
F3 : Set-up
F4 : Change standard levels
F7 : Status
F1
F2
F3
F4
F5
F6
F7
F1 Addresses
The addresses of the EM TEST (Switzerland) GmbH
and the EM TEST GmbH are shown. The addresses
of all EM TEST sales agencies are listed on the web
site of EM Test under :
www.emtest.com
F3 Set-up
The software will clearly explain the set-up procedure.
F4 Change standard levels
The stored standard test levels can be changed within this menu.
SERVICE Change standard levels
F1 : Reset all standard levels
F2 : IEC 61000-4
F3 : EN 61000-6-1
F4 : EN 61000-6-2
F1
F2
F3
F4
F5
F6
F7
The user can change the stored standard levels
F1: Set all parameters acc. to standard. The stored standard test levels can be changed within this menu.
The settings are actualized to the standards dated in summer 2004.
F2: IEC 61000-4
F1: IEC 61000-4-4 Burst
F2: IEC 61000-4-5 Surge
F3: IEC 61000-4-8 Magnetic field AC
F4: IEC 61000-4-9 Magnetic field Surge
F5: IEC 61000-4-11 Power Fail AC
F6: IEC 61000-4-29 Power Fail DC
F3: EN 61000-6-1 Generic
F1: EN 61000-6-1 Generic Burst
F2: EN 61000-6-1 Generic Surge
F3: EN 61000-6-1 Generic Power Fail
F4: EN 61000-6-2 Generic
F1: EN 61000-6-1 Generic Burst
F2: EN 61000-6-1 Generic Surge
F3: EN 61000-6-1 Generic Power Fail

EM TEST UCS 500 Series
Operating Manual V 5.40 18 / 99
F7 Status
Status information of the equipment.
UCS500N5 UCS500N7
Page 1
UCS500N5
V5.00
005000
Built in
Modules
Model
Version
SW Number
Burst
Surge
Power Fail
Ringwave
Int. 1Ph
Operating
00000035.53 hrs
Test time
00000015.53 hrs
DI-Status 0000
SCR-Status 0000
Information of
operating
Status information
Page 2
Keyboard Beep
Countdown Beep
Backlighting
off
off
5 min
RS 232
IEEE
19200
15
Setup information
Interface information
DAC adjust
+0, +0
+0, +0
+0, +0
Voltage
V 264
Vn 230
CH PF1
H-field
Af
Tf
If
DAC Adjust
Parameter
Set voltage
H-filed
parameter

EM TEST UCS 500 Series
Operating Manual V 5.40 19 / 99
4.5.
Setup
Firmware V 6.01ax (UCS 500N5) V9.04ax (N7x)
SETUP
SETUP
F1 : Change language / Sprache ändern
F1 : Change language / Sprache ändern
F2 : LCD backlighting
F2 : LCD backlighting
F3 : Interfaces
F3 : Interfaces
F4 : Beep
F4 : Beep
F5 : Timer
F5 : Timer
F6 : Set voltage
F6 : Set voltage low / high
F7 : Magnetic field correction factors
F7 : Magnetic field correction factors
F1
F2
F3
F4
F5
F6
F7
F1
F2
F3
F4
F5
F6
F7
F1 Change language
The user can chose between two languages, German and English.
F2 LCD backlighting
With the use of F2 the backlighting can be switched on or off.
Additionally the Auto Off function can be programmed to switch off the backlighting after a defined time that the
equipment has not been in operation (1 - 30minBecause of the limited lifetime of LCD displays, approx. 10,000h
this function should always be activated.
F3 Interfaces
This menu will help the user to define the status of the integrated serial and parallel interfaces, e.g. the baud rate
of the RS 232 or the address of the IEEE interface.
F4 Beep
F1 is the selector for the keyboard beeper ON/OFF mode. (Short beep at every keyboard hit)
F3 is the selector for the countdown-beeper ON/OFF mode. (Short beep before surge pulse releasing )
To indicate that a running test is finished the beeper sounds always 3 times (not changeable).
F5 Operating time
Pressing of F5 will show the different operating time and status of the test equipment.
Operating time: Total time where the UCS is powered on.
Testing Time: Total time during a running test.
DI –Status: Service information about internal digital inputs.
SCR –Status: Service information about surge switch operation
F6 Set voltage low/high Firmware V 6.01ax (UCS 500N5) V9.04ax (N7x)
This Firmware version offers two separate voltage settings for user that needs to test equipment for 115 V and
230V mains supply. Thanks to the two settings, the user can keep the Motorvariac in the 230V position
Using a MV 2616 with voltage selector switch:
- Set the voltage selector to the 230V position for low and high mains voltage supply.
- Use the Firmware with low and high settings and use the MV 2616 for any supply in the 230 V position.
The operator can specify the following parameters:
F1: Setup Main Voltage to low 115 V. Motorvariac parameter settings for lower main voltage. (115 V)
F2: Setup Main Voltage to high 230 V Motorvariac parameters for higher main voltage. (230 V)
F3: Motorvariac high (low) Selection and indicate of the active “Main Voltage” setting. The
selected setting is used in the power Fail tests for motorvariac
control
The procedure for low and high parameters voltage setting is the same as described in F6 Set Voltage below.
F6 Set voltage
For control of an external power supply source an analogue control voltage can be programmed (0-10V dc).
The operator can specify the following parameters:
F1: Max. variac voltage V [ V ] Maximal output voltage at 100% position of the external motor variac or dc
controlled voltage source. The analogue reference value for the max. voltage is 10 V.
F2: Mains supply voltage V [ V ] of the device under test. This voltage shall be specified by the operator and
depends on the type of equipment under test. The variac normally is automatically set to this output voltage.
F3: Default channel. The operator select the default channel PF1 or PF2 from which the EUT is powered.

EM TEST UCS 500 Series
Operating Manual V 5.40 20 / 99
F7 Magnetic field correction factors
F1: Coil factor Af A/mRange [0.200...9.99 step 0.01 ]
F2: Transformer factor Tf A/VRange [0.020...9.999 step 0.001 ]
F3: Impedance factor If A/VRange [0.200...1.00 step 0.01 ]
These values are delivered together with the necessary options to conducted magnetic field testing.
-Coil factor depends on the type of antenna which is used for the test.
-Transformer factor depends on the type of transformer which is used for the test.
-Impedance factor depends on the type of surge generator which is used for the test. A generator with a
source impedance of 2needs an impedance factor of approx. If = 0.5
