olympia electronics RF-52/A/D User manual

Page 1 from 4
TECHNICAL CHARACTERISTICS
Operation voltage
Degrees of cover protection
Produced in accordance with
Operation temperature range
Relative humidity
Construction material
External dimensions
Typical weight
Guarantee 2 years
Up to 95%
ο
0 to 50 C
IP 65
ABS/PC
110 x 70 x 30 mm
120 gr
EN 60335-1
RF-52/Α/D
Waterproof RFID card switch with display
Powered by RF-54/Α
930052003_09_001
Dimensions of RF-52/Α/D in mm
70
70
110
30
DESCRIPTION
The RF-52/A/D is a device that operates with
RFID technology. It reads the RFID cards and
cooperates with the RF-54/A device. The
system RF-52/A/D with RF-54/A is used to
control an electric door lock and room lighting or
A/C in hotels or rent rooms.
The RF-52/A/D is powered by the RF-54/A
device and communicates with it to transfer the
code of each RFID card that it reads.
The cards are supplied by request, printed with
the customer’s logo (RF-50/T) or plain (RF-50).
The RF-52/A/D has an orange LED to indicate
the existence of an RFID card. It is off when a
card is in the slot. The device has also two
indication LED’s (green and red), and a buzzer.
The LED’s states are:
GREEN:
ΟΝ: The card is appropriate (follows a sound
signal).
RED:
ΟΝ: There is a customer inside the room.
Blinks: The card is recognized but is not
registered to the memory of RF-54/A.
INSTALLATION
The device’s installation is done externally on a
wall or recess mounted with recess base (A-42)
as shown on page 3.
The device is pre-adjusted to be used as an
external card reader.
Thank you for your trust in our products
Olympia Electronics - European manufacturer
Page 4 from 4 930052003_09_001
WARRANTY
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of
warranty is specified in the official catalogue of Olympia Electronics and also in the technical leaflet,
which accompanies each product. This warranty ceases to exist if the buyer does not follow the
technical instructions included in official documents given by Olympia Electronics or if the buyer
modifies the goods provided or has any repairs or re-setting done by a third party, unless Olympia
Electronics has fully agreed to them in writing. Products that have been damaged can be returned to
the premises of our company for repair or replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge
the buyer depending on the reason of defection. Olympia Electronics reserves the right to charge or not
the buyer the transportation cost.
HEAD OFFICE
72nd km. O.N.R. Thessaloniki-Katerini
P.C. 60300 P.O. Box 06 Εginio Pierias Greece
www.olympia-electronics.gr
[email protected]

Page 3 from 4
Page 2 from 4
Dimension of Α-42 in mm
130 112
Figure 2
ATTENTION!!!
The RF-52/Α/D operates with radio frequencies so it is required to have a
minimum distance > 30 cm between 2 devices in horizontal or vertical axis.
Wall side view
Wall bottom view
Wall bottom view
>30cm
>30cm
>30cm
Installation Instruction
1. Lift the front plastic cover and with a flat blade screwdriver unlock the plastic hooks to remove it.
2. Install the 6 mm diameter cable connection seal ring.
3. Use the plastic plugs and the long screws to mount the device to the wall or the short ones to
mount it with A-42 recess mounting base. In each mounting screw firstly pass the washer and
then the black plastic ring included in the package (Figure 3). Then fasten the 2 mounting
screws to secure the device.
4. Connect the cable ( the wiring of the device is described in the user manual of RF-54/A).
5. ATTENTION!! To ensure the IP65 rating protection, place the sealing ring around (Figure 4).
6. Room number setting. Firstly you have to power on the system. There is no risk of electric shock
(power voltage is 12V DC).
Selecting the room number is done by using the buttons 1, 2, 3 and 4 of figure 2. Each button sets the
indication to the screen above it. Each press of the button increases the screen content by 1. The
value options are: blank, -,1,2,3,4,5,6,7,8,9. The room number 47, e.g., can be shown as: or
or etc.
The final selection is permenantly saved in the memory of the device and is not affected by netwirk
interruptions. It can be changed at any time in the same manner as described above.
7.Replace carefully the plastic face to secure it. Then device is secure ready to operate.
Buttons for
room
number
selection
Figure 4
Figure 1
1
2
3
1
Sealing Ring
Figure 3
90
70
37
930052003_09_001930052003_09_001
Installation instruction on the recessed base A-42
1. Drill a knock-out opening to cross the connection cable, and pass it cable.
2. Open the wall for mounting the base 120x80 in.
3. Attach the A-42 recessed mount to the wall with the appropriate mounting material.
4. Once the fastener is dry, follow all the steps of the installation process on page 2.
