OneConnect™
OCe14000-series Adapters
Installation Manual

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
2
Copyright © 2013 Emulex. All rights reserved worldwide. No part of this document may be reproduced by any means
or translated to any electronic medium without the prior written consent of Emulex.
Information furnished by Emulex is believed to be accurate and reliable. However, no responsibility is assumed by
Emulex for its use; or for any infringements of patents or other rights of third parties which may result from its use. No
license is granted by implication or otherwise under any patent, copyright or related rights of Emulex.
Emulex, the Emulex logo, AutoPilot Installer, AutoPilot Manager, BlockGuard, Connectivity Continuum,
Convergenomics, Emulex Connect, Emulex Secure, EZPilot, FibreSpy, HBAnyware, InSpeed, LightPulse, MultiPulse,
OneCommand, OneConnect, One Network. One Company., SBOD, SLI, and VEngine are trademarks of Emulex. All
other brand or product names referenced herein are trademarks or registered trademarks of their respective
companies or organizations.
Emulex provides this manual "as is" without any warranty of any kind, either expressed or implied, including but not
limited to the implied warranties of merchantability or fitness for a particular purpose. Emulex may make
improvements and changes to the product described in this manual at any time and without any notice. Emulex
assumes no responsibility for its use, nor for any infringements of patents or other rights of third parties that may
result. Periodic changes are made to information contained herein; although these changes will be incorporated into
new editions of this manual, Emulex disclaims any undertaking to give notice of such changes.
Emulex, 3333 Susan Street
Costa Mesa, CA 92626

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
Table of Contents 3
Table of Contents
List of Figures ......................................................................................4
List of Tables .......................................................................................5
1. Introduction .....................................................................................6
Major Features......................................................................................... 7
Prerequisites ........................................................................................... 8
Adapter Identification................................................................................ 9
2. Installation..................................................................................... 10
Preparing the Adapter for Installation .......................................................... 10
Installing the Adapter .............................................................................. 12
Attaching Devices ................................................................................... 12
Emulex OneConnect Accessories ..............................................................15
Applying Power ...................................................................................... 16
Viewing the LEDs .................................................................................... 16
3. References .................................................................................... 18
Specifications ........................................................................................ 18
FCC and Regulatory Notices....................................................................... 20
Declarations of Conformity........................................................................ 22
Laser Safety Notice ................................................................................. 24

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
List of Figures 4
List of Figures
Figure 1-1 Emulex OCe14102 Adapter ............................................................... 6
Figure 1-2 Emulex OCe14401 Adapter ............................................................... 7
Figure 2-1 Typical Optical Transceiver .............................................................10
Figure 2-2 Releasing the Latch on an Optical Transceiver.......................................11
Figure 2-3 Removing the Bracket ....................................................................11
Figure 2-4 Installing an Optical Transceiver .......................................................14
Figure 2-5 Connecting a Fiber Optic Cable.........................................................14
Figure 2-6 Connecting a DAC Cable..................................................................15
Figure 2-7 Optical and DAC Adapter LED Indicators ..............................................17

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
List of Tables 5
List of Tables
Table 2-1 Cable and Connector Specifications....................................................13
Table 2-2 Emulex OneConnect Accessories........................................................15
Table 3-1 OCe14000-series Adapter Specifications ..............................................18

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
1. Introduction 6
1. Introduction
This manual describes the Emulex®OneConnect™ OCe14000-series of multi-protocol
PCI-Express adapters for 10 and 40 Gigabit/sec (Gb/s) Enhanced Ethernet (EE) fabric.
Emulex adapters provide ethernet networking and iSCSI functionality, as well as Fibre
Channel over Ethernet (FCoE) functionality for convergence of Fibre Channel (FC)
traffic onto 10 Gigabit EE fabric.
The OCe14000-series adapters include single port (OCe14101) and dual port
(OCe14102) 10 Gigabit Ethernet (GbE) to PCI Express adapters and a single port, 40GbE
to PCI Express adapter (OCe14401).
The single port 10 Gb/s OCe14101 and 40 Gb/s OCe14401 adapters support Ethernet
networking functionality only.
The OCe14102 is available with ethernet networking functionality, or as a full-featured
universal converged network adapter (UCNA) that supports NIC, iSCSI, and FCoE.
All Emulex adapters support NIC single root I/O virtualization (SR-IOV) and are full3y
compliant to the PCI Express CEM Specification Rev. 3.0/2.0/1.1. UCNAs combine two
major functional components: a 10 Gigabit networking MAC and an FC IOC to
interface with a unified lossless Ethernet switch. Adapters serve as a common interface
for both storage and IP traffic retaining familiar FC and networking software stacks, OS
drivers, and management. The supported PCIe connector is an x8.
Illustrations in this manual are only examples. The actual hardware may vary.
Figure 1-1 Emulex OCe14102 Adapter

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
1. Introduction
Major Features 7
Figure 1-2 Emulex OCe14401 Adapter
Major Features
Eight PCIe functions, individually configurable to NIC, iSCSI, or FCoE
personalities with offload features
Eight-lane (x8) Generation 3 PCIe interface at 8GT/s, 5GT/s, or 2.5GT/s
(auto-negotiated with system)
Low-profile PCIe form factor PCBA: 6.600 inches by 2.713 inches
Comes with full height I/O bracket installed for low profile cards; optional low
profile I/O bracket is included
Support for 40GbE link speeds (OCe14401 adapters only)
Optical 10GBASE-SR network interface LC connectors
Support for 10 GbE SFP+ optical or Direct-Attach Copper (DAC) connectors
SFF-8431 Enhanced Small Form Factor Pluggable Module SFP+ compliant
QSFP+ (Quad Small Form Factor Pluggable) interface supporting optics and
direct attach cables (OCe14401 adapters only)
External volatile memory: 2Gb/4Gb DDR3 SDRAM technology
On-board flash memory: The flash is 128Mbit with a SPI interface. The flash
contains the vital product data (VPD) and Boot BIOS images. You can update
the flash with Emulex utilities.
Interoperates with existing FC SAN infrastructures – switches, arrays, SRM
tools (including Emulex utilities), SAN practices, and so forth
Unified Ethernet-to-FC SAN connectivity provided by an FCoE switch
Host Interface support provided through Emulex standard drivers
Comprehensive array of NIC, iSCSI and FCoE operating system drivers,
including support for Windows, Linux, and VMware

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
1. Introduction
Prerequisites 8
Parts and construction compliant to the European Union Directive of Restriction
of Hazardous Substances (RoHS), and similar regulatory requirements for other
countries.
Protocol-specific capabilities
NIC capabilities include:
NDIS 5.2, 6.0, and 6.2-compliant Ethernet functionality
IPv4/IPv6 TCP, UDP checksum offload
IPv4/IPv6 Receive Side Scaling (RSS)
IPv4/IPv6 Large Receive Offload (LRO)
IPv4/IPv6 Large Send Offload (LSO)
Programmable MAC addresses
Up to 128 MAC/VLAN addresses
Support for hash-based multicast MAC address filters
Support for hash-based broadcast frame filters per port
VLAN insertion and extraction
Jumbo packet support up to 9200 bytes
iSCSI capabilities include:
Full iSCSI protocol offload
Header, data digest (CRC) and PDU
Direct data placement of SCSI data
Up to 4K outstanding commands (iSCSI CNA only mode)
Up to 512 offloaded iSCSI connections (iSCSI CNA only)
iSCSI initiator and concurrent initiator/target modes
Support for multipath I/O
T10 PI support for end-to-end data integrity (for target mode drivers)
FCoE capabilities include:
Hardware offloads of Ethernet TCP/IP and concurrent iSCSI and FCoE
ANSI T11 FC-BB-5 support
Programmable World Wide Name (WWN)
Support for FIP and FCoE Ether Types
Concurrent logins (RPI): up to 8K per ASIC (FCoE CNA only mode)
Open exchanges (XRI): up to 4K per ASIC (FCoE CNA only mode)
FCoE initiator and target modes
Supports up to 255 NPIV interfaces
Prerequisites
PCI Express 3.0/2.0/1.1 compliant systems: x8 lane at up to 8 Gb/s per lane.

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
1. Introduction
Adapter Identification 9
Adapter Identification
Each adapter ships with several numbers clearly marked on the board. Emulex
recommends recording these numbers before installation.
IEEE address – a unique 64-bit identifier used for system configuration
World Wide Name (WWN) – derived from the IEEE address; the FC industry
uses the WWN for FC connectivity.
Serial number – assigned by Emulex and used when communicating with
Emulex
Note: If the adapter has two ports, it has two IEEE addresses and two WWNs, one for
each port.

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
2. Installation
Preparing the Adapter for Installation 10
2. Installation
The standard OCe14000-series adapter can be connected to fiber optic cables (used with
embedded optical transceivers) or DAC cables. Additional information for these cable
connections and other installation procedures are described in the following sections.
Preparing the Adapter for Installation
Before installing the adapter, you should perform the following steps:
1. Turn off the computer and unplug it.
2. Remove the computer case.
Note: The adapter comes with a standard PCIe bracket installed. A low-profile
bracket is included in the box with the adapter. The low-profile mounting
bracket is shorter than the standard bracket; approximately 3.11 in. (7.9 cm)
compared to 4.75 in. (12.06 cm) long.
3. For the standard OCe14000-series adapter, if you want to change the bracket to a
low profile version, follow steps 4–12; otherwise, proceed to “Installing the
Adapter” on page 12.
4. Some standard OCe14000-series adapters come with optical transceivers embedded
in their cage assemblies. These optical transceivers must be removed before the
bracket can be removed. If the adapter contains optical transceivers, continue with
the following steps; otherwise, proceed to step 7.
Caution: This is a delicate operation–take care not to damage the optical
transceiver.
The adapter uses different types of optical transceivers. Figure 2-1 shows an
example of one type with the bail (handle) extended.
Figure 2-1 Typical Optical Transceiver
5. To remove a transceiver, pull the bail (handle) out and down to release the latch
and gently pull the transceiver out. Do not force it. After the latch is released, the
transceiver slides out easily.
Figure 2-2 shows a transceiver with the latch released (bail extended) and another
transceiver latched in place.

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
2. Installation
Preparing the Adapter for Installation 11
Figure 2-2 Releasing the Latch on an Optical Transceiver
6. Observing Electrostatic Discharge (ESD) precautions, store the transceiver in an
ESD-safe place.
7. Remove the mounting bracket screws from the top of the adapter. Figure 2-3 shows
the screws that are removed from the bracket.
Figure 2-3 Removing the Bracket
8. Remove the bracket and store it for future use.
9. Align the new mounting bracket tabs with the holes in the adapter.
Note: Be careful not to push the bracket past the transceiver or RJ-45 housing's
grounding tabs. Ensure the light emitting diodes (LEDs) are properly
aligned with the holes in the bracket.

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
2. Installation
Installing the Adapter 12
10. Re-install the screws that attach the adapter to the bracket.
11. Re-install the transceiver by sliding it into the housing. When the latch engages, it
clicks.
12. Push the bail back into place.
Installing the Adapter
To install the adapter:
1. Turn off and unplug the computer.
2. Remove the computer case.
3. Remove the blank panel from an empty PCIe bus slot. See “Preparing the Adapter
for Installation” on page 10 to change the brackets if needed. Otherwise, proceed to
“Attaching Devices” on page 12.
Note: Place the adapter into an empty PCIe x8 or x16 slot. Make sure that the
adapter is in an appropriate PCIe slot that does not interfere with other
components or case to prevent damage to the adapter.
4. Insert the adapter into the empty x8 or x16 PCIe bus slot. Press firmly until the
adapter is seated.
5. Secure the adapter's mounting bracket to the case with a panel screw or clip.
6. Replace the computer case and tighten the case screws.
The adapter is now installed in the server and is ready for device attachment.
Attaching Devices
There are two types of cables that can be connected to the adapter:
Fibre optic cable
DAC cable
An adapter does not allow normal data transmission on either optical or copper links,
unless it is connected to a compatible optical or copper interface connection. The cable
and connector specifications are listed in Table 2-1, Cable and Connector Specifications.
Note: Use Short Range (SR), Direct-connecting Receptacle (DCR) multimode fiber, or
1 to 5 meter SFP+ 10GbE copper cable for interface connections to a network
that adheres to the specifications listed in Table 2-1, Cable and Connector
Specifications.

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
2. Installation
Attaching Devices 13
Table 2-1 Cable and Connector Specifications
Cable Type
Maximum Length
(meters)
Minimum
Length (meters) Connector
Fiber Optic Cable for the OCe14101 and
OCe14102
Short Range, LC-LC Multimode
LC
OM3 – Multimode 50/125 micron fiber (2000
MHz*km bandwidth cable) with LC connectors:
1 Gbps (Not specified by IEEE 802.3)
10 Gbps
550
300
2
2
OM2 - Multimode 50/125 micron fiber (500
MHz*km bandwidth cable) with LC connectors:
1 Gbps
10 Gbps
550
82
2
2
OM1 - Multimode 62.5/125 micron fiber (200
MHz*km bandwidth cable) with LC connectors:
1 Gbps
10 Gbps
275
26
2
2
Fiber Optic Cable for the OCe14401
Short Range, MPO–MPO Multimode
MPO
OM4 - Multimode 50/125 micron fiber (4700
MHz*km bandwidth cable) with MPO connectors:
40 Gbps 150 2
OM3 - Multimode 50/125 micron fiber (2000
MHz*km bandwidth cable) with MPO connectors:
140 Gbps 100 2
10GbE Passive DAC Cable 5 0.5 Direct Attach
Copper
10GbE Active DAC Cable 10 0.5
Direct Attach
Copper

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
2. Installation
Attaching Devices 14
To attach devices to the adapter:
1. Connect the appropriate cable to the adapter.
When connecting an optical cable, ensure the cages have optical transceivers
installed in them (see Figure 2-4).
Figure 2-4 Installing an Optical Transceiver
Once the optical transceivers are installed, insert the optical cable into the LC
connectors on the adapter (see Figure 2-5).
Figure 2-5 Connecting a Fiber Optic Cable
When connecting a DAC cable, ensure the SFP+ cages do not have optical
transceivers installed in them. To remove optical transceivers, see step 5 on page 10.
After confirming there are no optical transceivers installed, insert the DAC
transceiver into the SFP+ cage on the adapter (see Figure 2-6).

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
2. Installation
Applying Power 15
.
Figure 2-6 Connecting a DAC Cable
2. After the appropriate cable is connected to the adapter, connect the other end of the
cable to a suitable device, such as a Top of Rack (TOR) EE switch.
After the device is connected to the adapter, you are ready to apply power to the
computer. See “Applying Power” on page 16.
Emulex OneConnect Accessories
Table 2-2 provides model number, name, interface and required quantities if you want
to order additional or replacement transceivers, or cables.
Applying Power
To apply power:
1. Verify that the adapter is securely installed in the computer.
2. Verify that the correct device is attached.
3. Plug in and turn on the computer.
4. Observe the boot banner for Power On Self Test (POST) results.
Table 2-2 Emulex OneConnect Accessories
Model Number Model Name Quantity Interface
OC10-SR-OPT-1 Emulex OneConnect 10Base-SR
Optical SFP+ Transceiver
1 pc 10Gbase-SR Optical
OC10-SR-OPT-2 Emulex OneConnect 10Base-SR
Optical SFP+ Transceivers (2 pcs)
2 pcs 10Gbase-SR Optical
OC10-LR-OPT-1 Emulex OneConnect 10Base-LR
Optical SFP+ Transceiver
1 pc 10Gbase-SR Optical
OC40-SR4-OPT-1 Emulex OneConnect 40Base-SR4
Optical QSFP+ Transceiver
1 pc 40Gbase-SR4 Optical

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
2. Installation
Viewing the LEDs 16
Viewing the LEDs
Each port connector has two LEDs: an amber LED and a green LED.
Amber LED (Link)
On (constantly) = Link up
Off = Link down
Green LED (Ethernet Activity)
Blink = Activity on the Ethernet link
Off = No activity on the Ethernet link
Figure 2-7 Optical and DAC Adapter LED Indicators

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
3. References
Specifications 18
3. References
Specifications
Table 3-1 OCe14000-series Adapter Specifications
Parameter Range
Physical Dimensions Low-profile form factor, 6.600 inches by 2.713 inches, and
accommodates both the full-height and low-profile bracket.
Power Requirements Standard OCe14101 and OCe14102 adapters:
3.3V DC: 0.018 Watts (typical optical,10GbE and typical with
passive 10GbE direct-attach cable)
12V DC: 9.143 Watts (typical optical, 10GbE)
8.153 Watts (typical passive 10GbE direct-attach cable)
3.3V AUX: 0.018 Watts (typical optical,10GbE and typical with
passive 10GbE direct-attach cable)
OCe14401 adapter:
12V DC: 9.964 Watts (typical optical, 40GbE)
8.626 Watts (typical passive 40GbE direct-attach cable)
Airflow 200 lf/min (minimum)
Temperature 0°C to 55°C (operating)
-40°C to 70°C (non-operating)
Note: Operating the adapter in higher temperatures and/or lower air
flow may result in premature failures.
Humidity Operating: 10% to 90% RH, non-condensing, 22°C wet bulb
Non-operating: 5% to 95% RH, non-condensing, 22°C wet bulb
Agency Approvals for
OCe14000-series adapters
• Class 1 Laser Product per DHHS 21CFR (J) & EN60825-1 when
equipped with approved optical devices
• UL recognized to UL60950-1 2nd Edition
• cUR recognized to CSA 22.2, No. 60950-1-07
• TUV certified to EN60950-1:2006 +A11 +A1 +A12
• FCC Rules, Part 15, Subpart B, Class A
• Industry Canada, ICES-003, Class A
• EMC Directive 2004/108/EC (CE Mark)
EN55022:2010, Class A
EN55024:2010
• Australian EMC Framework (C-Tick Mark)
AS/NZS CISPR22:2009 +A1, Class A
• Japan VCCI, Class A
• Taiwan BSMI, Class A
• Korea MSIP, Class A (KN22 /KN24) referencing latest MSIP and RRL
notices
• BSMI Class A, consisting of CNS 13438:2006 (complete edition)
• RoHS Compliant (Directive 2011/65/EU)
• China RoHS compliant

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
3. References
Specifications 19
Vibration, peak acceleration 0.25g (5 Hz to 500 Hz)
(Sweep Rate = 1 octave/min.)
Table 3-1 OCe14000-series Adapter Specifications
Parameter Range

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
3. References
FCC and Regulatory Notices 20
FCC and Regulatory Notices
OCe14000-series Adapters
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Responsible Party:
Jeff Benck, President and Chief Executive Officer
Emulex Corporation [phone]
3333 Susan St. Costa Mesa, CA. 92626 USA
Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
The reader is cautioned that changes or modifications made to the equipment not
expressly approved by Emulex could void the user's authority to operate this
equipment. The above statement applies to products marketed in the USA.
This class A digital apparatus meets all requirements of the Industry Canada (IC)
Interference - Causing Equipment Standard (ICES-003).
Cet appareil numérique de la classe A respecte toutes les exigences du règlement sur le
matériel brouilleur du Canada. CAN ICES-3 (A)/ NMB-3 (A)
Notice for Japan and Translations (VCCI)
Translation:
This is a Class A product. If this equipment is used in a domestic environment, radio
interference may occur, in which case, the user may be required to take corrective
action. VCCI—A.

OneConnect OCe14000-series Adapters Installation Manual P009818-01A Rev. A
3. References
FCC and Regulatory Notices 21
Notice for Taiwan and Translations (BSMI)
Translation:
This equipment is a Class A ITE, and operation of this equipment in a residential area is
likely to cause harmful interference, in which case users will be required to correct the
interference at their own expense.
Notice for South Korea and Translations (KCC)
Translation:
Sellers and users of this equipment take note that this equipment is EMC approved for
Class A industrial use, and as such is not intended for residential use.
