ENCA-MDD
Mini DisplayPort to DVI Adapter
ENCA-MDD enables you to connect directly any DVI ready device (monitor, projector…) to a
Mini DisplayPort interface (on Laptop or Desktop…). This product provides an easy and
affordable solution between host system and DVI ready display device. This product is also
compliant with both low-bit-rate and high-bit-rate DisplayPort.
ENCA-MDD allows you to connect a DVI ready display device to all new Macs (MacBook /
MacBook Pro / MacBook Air / Mac Mini / iMac).
Note:
Interlaced modes and reduced blanking modes are not support

Features and Benefits
Easiest way to connect Mac and PC with Mini DisplayPort output to DVI ready devices,
such as monitor and projector
Compliance with DisplayPort Specification V1.1a
Support up to 1920 x 1200 (WUXGA display) and 1080p HD Video
Support 18/24/30 bitdepth per pixel color format
Support DPCD Rev 1.1
Specification
Connector Mini DisplayPort Male to DVI Female
Standard Compliant with DisplayPort Specification v1.1a
Resolution Up to 1920X1200 (WUXGA Display) and 1080p @ 60Hz (Full HD
Video)
Cable Length 135 mm (excluding the connectors at both ends)
Dimension 48.5 x 46 x 20 mm (L x W x H) (DVI side)
Weight 45 g
Housing Plastic (ABS)
Operation temperature 10 ~ 40 ºC
Storage temperature -10 ~ 80 ºC
Certification FCC, CE, RoHS

Connection Diagram
Package Content
ENCA-MDD
※ The specifications and picture are subject to change without prior notice! Please refer to the directions in product package
