Encore E-2 User manual

.
TO REMOTE START THE VEHICLE:
When you want to start your vehicle,
• Press button Twice on the transmitter.
• The parking light will activate to indicate the remote start received the signal.
• The engine will start in approximately 5 seconds.
• Once the engine is running, after couple seconds the parking lights will turn on
and the climate controls will activate and ad ust the vehicle’s interior
temperature to your preset setting.
• The vehicle will run for a programmable 5 to 30 minute cycle before shutting
down.
NOTE: The Remote Start Unit will not start the vehicle i any one o the ollowing
conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. The optional remote start enable toggle is switched to the “OFF” position. (If
installed)
4. The gear selector is in any gear other then “PARK” or “NEUTRAL”.
SAFE START (Child sa ety mode)
Factory default is set to press the button Twice on the transmitter to start the vehicle.
This feature to eliminate an accidental remote start:
1. The user presses the transmitter buttons twice within 3 seconds to start the
vehicle.
NOTE: Contact your installing dealer to de-activate this feature for one push start
OPERATE THE VEHICLE WHILE RUNNING FROM THE REMOTE START:
To operate the vehicle while the engine is running from the remote start,
• Insert the ignition key and turn it to “ON” (not the start) position.
• Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON position, the engine will
shut down.
TEMPORARY STOP FEATURE:
This feature allows the vehicle to remain running after the key has been removed from
the ignition. This feature is useful for occasions when you wish to exit and lock the
vehicle for short periods of time, but would like to leave the motor running and the
climate control on.
• Before turning off the engine, press the button twice on the transmitter and
the LED indicator will flash 3 times to confirm enter.
• Turn the ignition key to OFF position. (The engine will stay running.)
• The engine will run until the pre-programmed time elapsed or shutdown input is
received.
TO TURN OFF THE REMOTE START:
When the engine is running (by remote start), if you want to stop it,
Press button twice on the remote transmitter under the remote start mode.
Press this button once if the unit is programmed for one push start.
Press the brake pedal
The vehicle will shut down and turn off the parking light to indicate the engine
has stopped.
SHUT-DOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exist while the system is operating, the
engine will not start or will shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. The parking (hand) brake is released (For Turbo Timer Mode)
4. Engine is over-revved. {“Tachometer checking type” only}
5. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed.
6. Press button on the remote transmitter under remote start mode.
7. The vehicle re used to start running a ter {3} unsuccess ul attempts.
E
ncore Automotive Systems, LLC.
All rights reserved .
For Warranty information, Please go to www.encoreautomotivesystems.com and
download the complete user’s manual. For customer service, please call us toll free @
(855) GO-ENCORE 855.463.6267. 8:00-5:00 PST Thanks for your purchase!
ENCORE
LIMITED LIFETIME WARRANTY PROVISIONS
( U.S. ,Continental U.S. and Canada Only)
1. Encore Automotive Systems LLC. WARRAN S that this new unit has been
thoroughly inspected and tested at the factory prior to delivery. Your Encore
equipment is guaranteed for “life” to the original purchaser/user of the
equipment and the original vehicle in which it was installed by an authorized
installer under the following conditions: If the product proves defective
(according to Encore’s testing) within the first year, the defective unit may be
exchanged or repaired free of charge. “Proof of Purchase” (dated sales receipt)
must accompany all warranty returns; otherwise, your return will be rejected
and sent back. After one (1) year, the purchaser should ship the unit prepaid to
Encore with a money order in the amount of $30.00 to cover shipping and
handling charges. Note: he product needs to be registered online at time of
installation. o register this product go to,
www.encoresautomotivesystems.com .
2. Exclusion to the Limited Lifetime Warranty Provision: All two-way LCD and two-
way OLED remote transceivers are excluded from the Limited Lifetime Warranty
noted in paragraph no.1. All two-way LCD and two-way OLED remote
transceivers are guaranteed to the original purchaser for a period of one year
from date of purchase. If the product proves to be defective within the first
year, the defective unit may be exchanged or repaired free of charge. All other
provisions stated on this card apply.
3. his WARRAN Y will be considered void if the equipment has been misused,
neglected, improperly serviced or installed, altered, dropped or damaged by
water, contrary to the Encore OPERA IONS MANUAL. Or, if used with
accessories not approved by Encore, which may have contributed to the defect.
See note below regarding product installation**.
4. he purchaser’s remedies under this WARRAN Y shall be limited to the repair or
replacement of electronic components only. THE F LL WING IS N T
C VERED: Damages or deterioration to cases, batteries, covers and cabinets;
the cost of repairs, replacement and labor of which shall be borne by the
purchaser even if occurring during the WARRAN Y period.
5. Any equipment or parts which are claimed to be defective under this
WARRAN Y must be sent to the Encore Service center with “proof of purchase”
at the purchaser’s expense prior to such return, a Return Authorization Number
needs to be obtained. Encore will return the equipment, charges prepaid.
Warranty Service can be provided through the dealer where the equipment is
originally purchased.
6. Any unexpired WARRAN Y shall be applicable to equipment and parts in the
possession of the original purchaser only.
7. HIS WARRAN Y IS IN LIEU OF ANY AND ALL O HER WARRAN IES, EXPRESSED
OR IMPLIED, INCLUDING BU NO LIMI ED O ANY WARRAN Y OF
MERCHAN ABILI Y OR FI NESS FOR A PAR ICULAR PURPOSE.
8. Encore shall not be liable, under the foregoing WARRAN IES or otherwise, for:
Any personal injury or property damage of any kind to the purchaser or
property, its employees or agents or anyone else whomsoever resulting directly
or indirectly from the use or presence of the equipment or parts; Consequential
damages of any kind; any inability of the purchaser to use the equipment.
**IMP RTANT N TE: Any damages resulting from an installation performed by
anyone other than a professional installation technician authorized by Encore will
void the product’s Limited Lifetime Warranty.
Remote Start Operation:

QUICK START
USERS
GUIDE
If you do not understand any part of this quick start users
manual and would like the complete version, Please visit
our web site @ www.encoreautomotivesystems.com
The complete manual is necessary or advanced users and not all user
unctions are covered in this quick start guide.
E7s
Transmitter
Button
System Function Remark
Lock Doors
Panic Press & hold or 3 sec.
Unlock Doors
- Two Steps Door Unlock &
Disarm System
Press twice within 3
seconds.
Trunk Release (Channel 3) Press and Hold for 2
seconds
- Activate The Remote Start Push twice to start
- Stop remote start operation ** Push Twice to stop engine
+ Switching code For 2nd Car
Operation.
The units default is safety start. This requires the user to push the start
button twice to remote start the vehicle and prevent accidental starts. The
unit can be programmed to start on one push of the start button.
Programming required.
E
ncore
E
-
2
Encore E
-
7
s
Remote Transmitt
er
REMOTE TRANSMITTER OPERATION:
CHIRP INDICATORS:
PARKING LIGHT:
Chirp Function Parking light Function
1 chirp Lock 1 flash Lock
2 chirps Unlock 2 flashes Unlock
ON Running on remote start
LED i installed Optional E2s Two button remote
LED Function
Off Unlock
Slow
Flash Locked
On
(Solid) Valet Mode
OPTIONAL: E2s Ultra Miniature Remote
This optional remote can be used in applications where the factory
Keyless entry system is the main source for locking and
unlocking the vehicle. For example, vehicles with the
factory smart key/ “push button” start or one-piece remote with key, an E2s Ultra Miniature remote may be
purchased for remote start and unlock only applications. This ultra-small remote may be preferred if your factory
remote is integrated within your key.
PROGRAMMING TRANSMITTERS:
Note: This mode will only retain the last 4 remote transmitters programmed. If the transmitter
memory is exceeded, the security system will start deleting transmitters from memory in
chronological order.
1. Turn the Ignition 'switch ‘OFF/ON’ 4 TIMES and stay in ON position.
“Within 15 seconds”.
2. Push the Valet switch 4 times and hold it on the 4th push until a long chirp is heard then release
the valet switch. You are now in the Transmitter programming mode.
3. Press and hold any button of the transmitter until the siren responds with a confirming chirp,
indicating the signal has been stored into memory.
4. If you have additional transmitters (up to 4) that need to be programmed, repeat step 3 for each
transmitter.
Exit: Turn Ignition to 'OFF' position, or leave it for 15 seconds. 3 long chirps & 3 parking light flashes
will confirm exit.
Please register your product @ www.encoreautomotivesystems.com
For Customer service, Please call (855) Go-Encore
855-463-6267, 8:00-5:00 PST
BATTERY CHANGING:
Depending on the usage, the remote batteries should be changed at least
once a year.
The 1-way remote, (E-7s) is powered by a pair of 3V, CR2016 batteries.
These batteries are available at most locations batteries are sold and can
be replaced by the user.
WARN
INGS:
As with any product that performs automatic functions, there are certain safety precautions
that you must practice and be aware of.
• Keep the transmitter out of children’s reach.
• Do not leave anyone in the vehicle while running on remote control.
• Alert servicing personnel that the vehicle can be started automatically.
• Do not start the vehicle by remote while it’s in an enclosed area or garage.
• Always apply the parking brake and lock the vehicle as you exit the vehicle.
• The vehicle windows must be rolled up.
• Should the unit malfunction, disconnect the fuse until the problem is corrected.
• The use and operations of this system is the sole responsibility of the operator.
• Some areas may have local ordinances that prohibit leaving a vehicle running on public
streets.
• THIS DEVISE CANNOT BE USED ON ANY STANDARD TRANSMISSION VEHICLE.
FOR AUTOMATIC TRANSMISSIONS ONLY!
ACTIVE LOCK:
1. Press button on the transmitter.
2. The horn, if installed will chirp once and parking lights will flash once
indicating that the system is now active. The vehicle doors will lock upon
activating when interfaced with the keyless entry system.
ACTIVE UNLOCK:
1. Press button on the transmitter.
2. The horn will chirp twice and parking light will flash twice to indicating that
the keyless system is now unlocked. The vehicle doors will unlock.
DEACTIVATING WITHOUT A TRANSMITTER
The Override function may be used if the remote transmitter is lost or
inoperative.
1. Enter the vehicle and turn the ignition switch to ‘ON’ position.
2. Within 10 seconds push and release the valet switch
VALET MODE:
The valet switch allows you to temporarily by-pass all system function,
eliminating the need to hand your transmitter to parking attendants or garage
mechanics. When the system is in valet mode, and remote start functions are
bypassed, Enter Valet Mode:
1. Under Unlock condition, turn the ignition to “ON” position.
2. Press and hold valet switch for 2 seconds until the LED turns on. The LED
will remain on as long as the system is in ‘valet mode’.
Exit Valet Mode:
1. Return to normal operation, turn ignition ‘on’.
2. Press and hold valet switch for 2 seconds, The LED will turn off
Indicating that the system has exited the valet mode.
IGNITION CONTROL DOOR LOCKS.
If the vehicle’s door locks have been interfaced to the security system, the
system will automatically lock the vehicle’s doors when the ignition is turned
“ON” and /or unlock the vehicle’s doors when the ignition is turned “OFF”.
TRUNK RELEASE (Additional Installation Required)
Press and hold the button on transmitter for 3 seconds to activate the trunk
release or other electric devices.
PANIC FUNCTION:
The transmitter can be used as a remote panic switch to manually trigger the system
in case of emergency.
1. Press and hold the button for 3 second. The unit will immediately sound.
2. During panic mode, the normal function of this transmitter button will be disabled.
The transmitter and buttons can be used to lock and unlock the door (if the
option is installed).
3. To stop the alarm, press and hold the transmitter button on the transmitter again for
3 seconds.
.
4. If the button is not pressed, the system will stop after 30 seconds.
THIS PRODUCT IS DESIGNED FOR PROFESSIONAL
INSTALLATION ONLY
