Encore E6 Setup guide
CAR LOCATOR
Under armed mode, press the button to active car locator function. The siren will chirp 6
times. The parking light will flash 12 times, for you to easily locate your car.
PANIC FUNCTION:
The transmitter can be used as a remote panic switch to manually trigger the alarm in
case of emergency.
Press and hold the button for 3 second. The alarm will immediately sound.
To stop the alarm, press the trunk button on the remote control.
If the button is not pressed, the alarm will automatically stop after 30 seconds.
TRIGGER THE SYSTEM
When armed, your vehicle is protected as follows:
Light impact will trigger the warn-away signal.
Heavy impacts / Doors open /(if installed) Hood open / (if installed) Trunk open / Turning
on the ignition key will trigger the programmed sequence.
The starter disable relay (if installed) prevents the vehicle’s starter from cranking. The
siren, horn, parking lights, and dome light will turn on alerting of an intrusion for 30
seconds. Then it will stop and automatic reset and re-arm. If the any one of the sensors or
detectors is still active, the alarm system will sound a maximum of 3 times of 30
seconds cycles.
NOISE ABATEMENT CIRCUIT: Your system has a “Noise Abatement Circuit”. It prevents
annoying repetitive trigger sequences due to faulty door pin switches or environmental
conditions such as thunder, jackhammers, airport noise, etc.
Here’s how “Noise Abatement Circuit” works: The shock sensor triggers five times, the
“Noise Abatement Circuit” will interpret this pattern of triggers as a false alarm. After the 5th
trigger, the “Noise Abatement Circuit” ignores, or bypasses, that sensor or switch until a
different sensor or switch is triggered.
TRUNK RELEASE: Press and hold button on the transmitter for two seconds to
remotely control the trunk release.
ANTI CAR- JACKING (Programmable)
Warning: If you don't need the carjacking function in this alarm system, be sure to set
carjacking feature “OFF”. This systems default setting is “OFF” for all carjacking modes.
ACTIVE ANTI CAR JACKING:
1. Ignition ON, press and hold the and buttons at the same time for 2 seconds.
The parking lights will turn on for 1.5 seconds to indicate the system has entered the
anti car-jacking mode.
2. Once the system in anti car-jacking mode, the system will be triggered when any
door is opened and closed while the ignition is “ON”.
PASSIVE ANTI CAR- JACKING: (Programmable)
It will operate as noted below:
1.Turn the ignition switch to the “ON” position and the system will arm.
2.Once the system is armed, if you are forced from the vehicle, the system will trigger
when the door is opened and closed while the ignition is “ON”.
TRIGGERING THE ANTI CAR -JACKING MODE:
A). 50 seconds after the system has been triggered. The siren will start chirping for 15
seconds.
B). During this 15 second period of chirping, you will be alerted to push the valet switch once
to turn off the car-jacking feature. If not, it will enter a second timer for carjacking.
C). 65 seconds after the system has been triggered, the siren will start sounding and the
parking lights will start flashing.
D). 90 seconds after the system has been triggered,
1. The siren will sound and the parking lights will flash, and
2. The starter disable will activate to prevent the vehicle from starting.
3. It will remain active until the vehicle's battery power is exhausted.
OVERRIDE THE SYSTEM TO TURN OFF ANTI CAR- JACKING:
Turn the ignition switch from OFF to ON, and within 10 seconds push valet switch, the
siren will stop and the system disarmed
Remote Start Operation:
WARNINGS:
As with any product that performs automatic functions, there are certain safety precautions that
you must practice and be aware of.
1. Keep the transmitter out of children’s reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started automatically.
4. Do not start the vehicle by remote while it’s in an enclosed area or garage.
5. Always apply the parking brake and lock the vehicle as you exit the vehicle.
6. The vehicle windows must be rolled up.
7. Should the unit malfunction, disconnect the fuse until the problem is corrected.
8. The use and operations of this system is the sole responsibility of the operator.
9. Some areas may have local ordinances that prohibit leaving a vehicle running on public
streets.
10.It is not safe to remote start the vehicle if the vehicle is parked on a steep incline.
TO REMOTE START THE VEHICLE:
When you want to start your vehicle,
1. Press button once on the transmitter.
2. The parking light will activate to indicate the remote start received the signal.
3. The engine will start in approximately 5 seconds.
4. Once the engine is running, after couple seconds the parking lights will turn on and the
climate controls will activate and adjust the vehicle’s interior temperature to your preset setting.
(While the vehicle is running, the “minutes” digit on the LCD screen will flash and the will indicate
countdown timer based on the 5, 10, 20 or 30 minute run time set up by your installation center.)
5. The vehicle will run for a programmable 5 to 30 minute cycle before shutting down. (When
the unit shuts off the countdown timer will turn off and the transmitter will play a melody.)
NOTE: The Remote Start Unit will not start the vehicle if any one of the following
conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. The optional remote start enable toggle is switched to the “OFF” position. (If installed)
4. The gear selector is in any gear other then “PARK” or “NEUTRAL”.
SAFE START (Child safety mode)
Factory default is set to press the button once on the transmitter to start the vehicle. You can
program this feature to eliminate an accidental remote start:
1. The user presses the transmitter buttons twice within 3 seconds to start the vehicle.
NOTE: Contact your installing dealer to activate this feature.
OPERATE THE VEHICLE WHILE RUNNING FROM THE REMOTE START:
To operate the vehicle while the engine is running from the remote start,
Insert the ignition key and turn it to “ON” (not the start) position.
Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON position, the engine will shut down.
TEMPORARY STOP FEATURE:
This feature allows the vehicle to remain running after the key has been removed from the ignition.
This feature is useful for occasions when you wish to exit and lock the vehicle for short periods of
time, but would like to leave the motor running and the climate control on.
1. Before turning off the engine, press the button once on the transmitter and the LED
indicator will flash 3 times to confirm enter.
2. Turn the ignition key to OFF position. (The engine will stay running.)
3. The engine will run until the pre-programmed time elapsed or shutdown input is received.
TO TURN OFF THE REMOTE START:
When the engine is running (by remote start), if you want to stop it,
Press button once on the remote transmitter under the remote start mode.
Press this button twice if the unit is programmed to child safety start.
Press the brake pedal
The vehicle will shut down and turn off the parking light to indicate the engine has
stopped.
SHUT-DOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exist while the system is operating, the engine will
not start or will shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. The parking (hand) brake is released (For Turbo Timer Mode)
4. Engine is over-revved. {“Tachometer checking type” only}
5. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed.
6. Press button on the remote transmitter under remote start mode.
7. The system triggers.
8. The vehicle refused to start running after {3} unsuccessful attempts.
Encore Automotive Systems, LLC.
All rights reserved.
For Warranty information, Please go to www.encoreautomotivesystems.com and download
the complete user’s manual. For customer service, please call us toll free @ (855) GO-
ENCORE 855.463.6267. 8:00-5:00 PST Thanks for your purchase!
ENCORE LIMITED LIFETIME WARRANTY PROVISIONS
(U.S.,ContinentalU.S.andCanadaOnly)
1. EncoreAutomotiveSystemsLLC.WARRANTSthatthisnewunithasbeenthoroughlyinspectedand
testedatthefactorypriortodelivery.YourEncoreequipmentisguaranteedfor“life”totheoriginal
purchaser/useroftheequipmentandtheoriginalvehicleinwhichitwasinstalledbyanauthorized
installerunderthefollowingconditions:Iftheproductprovesdefective(accordingtoEncore’s
testing)withinthefirstyear,thedefectiveunitmaybeexchangedorrepairedfreeofcharge.“Proof
ofPurchase”(datedsalesreceipt)mustaccompanyallwarrantyreturns;otherwise,yourreturnwill
berejectedandsentback.Afterone(1)year,thepurchasershouldshiptheunitprepaidtoEncore
withamoneyorderintheamountof$30.00tocovershippingandhandlingcharges.Note:The
productneedstoberegisteredonlineattimeofinstallation.Toregisterthisproductgoto,
www.encoresautomotivesystems.com.
2. ExclusiontotheLimitedLifetimeWarrantyProvision:Alltwo‐wayLCDandtwo‐wayOLEDremote
transceiversareexcludedfromtheLimitedLifetimeWarrantynotedinparagraphno.1.Alltwo‐way
LCDandtwo‐wayOLEDremotetransceiversareguaranteedtotheoriginalpurchaserforaperiodof
oneyearfromdateofpurchase.Iftheproductprovestobedefectivewithinthefirstyear,the
defectiveunitmaybeexchangedorrepairedfreeofcharge.Allotherprovisionsstatedonthiscard
apply.
3. ThisWARRANTYwillbeconsideredvoidiftheequipmenthasbeenmisused,neglected,improperly
servicedorinstalled,altered,droppedordamagedbywater,contrarytotheEncoreOPERATIONS
MANUAL.Or,ifusedwithaccessoriesnotapprovedbyEncore,whichmayhavecontributedtothe
defect.Seenotebelowregardingproductinstallation**.
4. Thepurchaser’sremediesunderthisWARRANTYshallbelimitedtotherepairorreplacementof
electroniccomponentsonly.THEFOLLOWINGISNOTCOVERED:Damagesordeteriorationtocases,
batteries,coversandcabinets;thecostofrepairs,replacementandlaborofwhichshallbeborneby
thepurchaserevenifoccurringduringtheWARRANTYperiod.
5. AnyequipmentorpartswhichareclaimedtobedefectiveunderthisWARRANTYmustbesentto
theEncoreServicecenterwith“proofofpurchase”atthepurchaser’sexpensepriortosuchreturn,
aReturnAuthorizationNumberneedstobeobtained.Encorewillreturntheequipment,charges
prepaid.WarrantyServicecanbeprovidedthroughthedealerwheretheequipmentisoriginally
purchased.
6. AnyunexpiredWARRANTYshallbeapplicabletoequipmentandpartsinthepossessionofthe
originalpurchaseronly.
7. THISWARRANTYISINLIEUOFANYANDALLOTHERWARRANTIES,EXPRESSEDORIMPLIED,
INCLUDINGBUTNOTLIMITEDTOANYWARRANTYOFMERCHANTABILITYORFITNESSFORA
PARTICULARPURPOSE.
8. Encoreshallnotbeliable,undertheforegoingWARRANTIESorotherwise,for:Anypersonalinjuryor
propertydamageofanykindtothepurchaserorproperty,itsemployeesoragentsoranyoneelse
whomsoeverresultingdirectlyorindirectlyfromtheuseorpresenceoftheequipmentorparts;
Consequentialdamagesofanykind;anyinabilityofthepurchasertousetheequipment.
**IMPORTANTNOTE:Anydamagesresultingfromaninstallationperformedbyanyoneotherthana
professionalinstallationtechnicianauthorizedbyEncorewillvoidtheproduct’sLimitedLifetime
Warranty.
QUICK START USERS GUIDE
If you do not understand any part of this quick start users
manual and would like the complete version, Please visit
our web site @ www.encoreautomotivesystems.com
The complete manual is necessary for advanced users and not all user
functions are covered in this quick start guide.
Transmitte
r Button System Function Remark
Lock Doors & Arm
System
Panic function Press and Hold for 3 seconds.
Press Trunk button to stop
panic function
Car Locator Press when in armed mode
-Arm and Delete The 2
Stage Shock Sensor Press twice within 3 seconds.
Pass will appear on the remote
- Arm System and Silent
Alarm Function Press within 3 seconds and Hold
the button
+ Silent Arming / Disarming Ignition in "off" position.
+ Active Anti Car-Jacking
Mode Ignition in "on" position press and
hold for 2 seconds
Unlock Doors & Disarm
System
-Two Steps Door Unlock &
Disarm System (optional) Press twice within 3 seconds.
Trunk Release (Channel
3) Press and Hold for 2 seconds
-Passive Arming By-pass While the system Disarmed.
Activate or Turn Off The
Remote Start Press button once or -
Press Twice if set to start safety
mode
+Channel # 4 Timer Output
(4) Optional
+ Switching code For 2nd
Car Operation. For regular remote transmitter
A
CTIVE ARMING
–
LOCK & ARM:
1.Press button on the transmitter.
2.The siren will chirp once and parking light will flash once indicating that the system is
now armed. The vehicle’s doors will lock upon arming if interfaced with the security
system.
DEFECTIVE SENSOR REMINDER: If the siren sounds 3 chirps, then you have left a
door, trunk, or hood lid ajar.
SILENT ARMING / DISARMING: Press the transmitter and buttons at the same
time. This will arm or disarm your security system, No chirp sound will be heard, arm /
disarm confirmation will be through the vehicles parking lights only.
SENSOR BY-PASS: Press the button two times within 5 seconds will arm the
security system and by-pass the shock sensor.
HIDDEN ALARM FUNCTION: Silent Alarm
Press the button first; within 3 seconds press the button to activate the hidden
alarm function. The security system will arm and with “Hidden Alarm Mode” The siren /
horn will be silenced even if the sensor is triggered in the armed mode. Alarm
indication will only appear on the LCD Transmitter.
PASSIVE ARMING (Programmable)
Active arming / disarming is controlled by your security system via the remote
transmitter. This security system is equipped with an optional Passive Arming feature
which allows the security system to arm 30 seconds after the last door is closed.
Operation is as follows.
1. Turn the ignition to the “OFF” position and exit the vehicle.
2. After all entrances are closed, the security system LED will flash fast for 30 seconds.
If you reopen any door / hood / trunk, the security system LED will stop flashing. It
will begin flashing again once all vehicle entrances are closed.
3. After the 30-second time has elapsed, the security system will automatically “ARM”.
The siren will chirp [1] time and the parking lights will flash [1] time.
PASSIVE ARMING WITH PASSIVE DOOR LOCKING
The vehicle doors will automatically lock after the passive arming cycle has been
completed.
PASSIVE ARMING BY-PASS: While the system is disarmed, Press the button
twice, the system will respond with [1] chirp and LED will turn “ON”. The security
system will remain in this temporary state for as long as you wish. To exit passive
by-pass, press the transmitter or buttons and the system will return to normal
status.
ACTIVE DISARMING – UNLOCK & DISARM:
1. Press button on the transmitter.
2. The siren will chirp twice and the parking lights will flash twice indicating that the
security system is now disarmed. The vehicle’s doors will unlock.
TAMPER DISARMING: If the alarm is triggered, upon disarm the system’s siren will
chirp 4 times, and the parking lights will flash 3 times telling you the alarm has been
triggered during the last armed state.
PATHWAY ILLUMINATION: When receiving an unlock /disarm signal, this feature will
turn the parking lights “ON” for 30 seconds and for 10 seconds upon the lock signal.
(Programmable)
AUTOMATIC RE-ARM: If this feature is selected, the security system will automatically
re-arm itself in 60 seconds after disarming with remote transmitter. Automatic rearm will
cancel if any door is opened before the 60 seconds timer has elapsed.
DISARMING WITHOUT A TRANSMITTER:
The Override function may be used if the remote transmitter is lost or
inoperative.
1. Enter the vehicle and turn the ignition switch to the 'ON’ position.
2. (Alarm will sound.)
3. Within 10 seconds push and release the valet switch. The alarm will stop sounding
and enter the disarm mode. You can now start and operate the vehicle normally.
VALET MODE: (System is in Disarm Mode)
The valet switch allows you to temporarily bypass all alarm function, eliminating the
need to hand your transmitter to parking attendants or garage mechanics. When the
system is in valet mode, all alarm functions and remote start functions are bypassed,
however, the remote panic feature and remote door locks will remain operational. To
use the valet mode, the system must first be disarmed either by using your remote
transmitter, or by operating the Manual Override sequence.
a). Under disarm mode, turn the ignition to “ON” position.
b). Press and hold valet switch for 2 seconds until the LED turns ON solid. The
LED will remain on as long as the system is in 'valet mode'.
Exit Valet Mode:
a). Turn ignition 'ON'.
b). Push and hold valet switch for 2 seconds, The LED will turn off indicate the
system are exiting the valet mode.
Encore E‐6
Encore E-7s Remote Transmitter
BATTERY CHANGING:
Depending on the usage, the remote batteries should be changed at least once
a year .
The 1-way remote, (E-7s) is powered by a pair of 3V, CR2016 batteries. These
batteries are available at most locations batteries are sold and can be replaced
by the user.
REMOTE TRANSMITTER OPERATION:
CHIRP INDICATORS: PARKING LIGHT:
Chirp Function Parking light Function
1 chirp Arm 1 flash Arm
2 chirps Disarm 2 flashes Disarm
3 chirps Defective Reminder 3 flashes Disarm / Triggered
4 chirps Disarm / Triggered 12 flashes Car Locator
6 chirps Car Locator Constant On Under Remote Start
ALARM OPERATING CONDITION:
Siren /
Horn Parking
Light LED Doors Starter Dome Light
1. Arming 1 or 3
Chirps 1 Flash Slow
Flash Locking Disable
2. Disarming 2 or 4
Chirps 2 or 3
Flashes Unlocking
Turns on for 30
-second
3. Trigger Alarming Flashes Slow
Flash Disable Flashes
4. Passive
Starter
Disable Fast Flash Disable
5. Panic Alarming Flashes Flashes
6. Car-Jacking Alarming Flashes Disable Flashes
7. Car Locator 6 Chirps 12 Flashes Locking
PROGRAMMING TRANSMITTER:
Note: This mode will only retain the last 4 remote transmitters programmed. If the transmitter memory
is exceeded, the security system will start deleting transmitters from memory in chronological order.
1. Turn the Ignition 'switch ‘OFF/ON’ 4 TIMES and stay in ON position.
“Within 15 seconds”.
2. Push the Valet switch 4 times and hold it on the 4th push until a long chirp is heard then release
the valet switch. You are now in the Transmitter programming mode.
3. Press and hold any button of the transmitter until the siren responds with a confirming chirp,
indicating the signal has been stored into memory.
4. If you have additional transmitters (up to 4) that need to be programmed, repeat step 3 for each
transmitter.
Exit:Turn Ignition to 'OFF' position, or leave it for 15 seconds. 3 long chirps & 3 parking light flashes
will confirm exit.
Pleaseregisteryourproduct@www.encoreautomotivesystems.com
Other manuals for E6
1
This manual suits for next models
1
Other Encore Remote Starter manuals
