Encore ENXDVR-4C User manual

1
E
EN NX XD DV VR R- -4 4C C
Digital Surveillance In A Box
4-Channel Digital Video Recorder and
4 CCD Security Cameras with Night Vision
Q
Qu ui ic ck k I In ns st ta al ll la at ti io on n G Gu ui id de e
P
Pa ac ck ka ag ge e C Co on nt te en nt ts s
● Encore H.264 DVR ● USB Mouse
● Quick Installation Guide ● IR Remote Control
●Power Adapter and AC Power Cord ●Setup Disc
●Four Encore CCD 24-LED Encore Surveillance Cameras and stands
C
Ca au ut ti io on n
For your safety, please unplug the device from the power source before moving the DVR
or when replacing the hard drive or removing other parts including cameras.
Carefully read the manuals and follow all the operating procedures.
Make sure camera cables are installed properly
Don’t leave any unnecessary parts inside the DVR to avoid electrical damage
As much as possible, avoid exposing the DVR to excessive dust, high temperatures and
extremely high humidity. Keep the DVR in a place with a temperature ranging from
5ºC~40ºC (41ºF to 104ºF)
Keep the DVR in a well-ventilated place and away from any heat-generating objects.
Do not block the DVR’s vent holes and make sure there is enough space for air to flow in
and out around the area where the DVR will be placed
Do not expose this unit directly to the sun.
If you are unsure of the installation and setup procedure, please consult qualified
technicians.
If there’s any damage to this unit or the power supply, please consult the technician or
the distributor. Don’t try to fix it by yourself.

2
H
Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
Be sure that the power is unplugged before starting hardware installation!
Internal Hard Disc Drive Installation:
The ENXDVR-4C kit package is not bundled with a disc drive. If you have no hard disc drive
ready at this moment do not proceed, you have to install a SATA 2.5” type hard disc drive to
the DVR before it can be fully operational.
Install the hard drive by following steps
Step 1 Using a Philips screw driver, remove all the screws that secure the DVR
cover. Two screws in the back of the DVR box as shown in the picture and
four screws in the bottom of the DVR not shown in the pictures.
Step 2 Remove the screws that secure the hard disk plate bracket to its mount on
the DVR.
Top Cover

3
Step 3 Secure the hard disk to the plate bracket with screws. (Most hard drive
when purchased comes with screws that fit to their individual brands).
Step 4 Remember to connect the hard disk data cable and power cable to the
DVR board.
Step 5 Connect the other end of the hard disk data and power cables to the hard
disk itself. Secure the bracket on to its mount.

4
Step 6 Place cover back on the DVR and secure with screws.
DVR Panel Ports
No
Label
Function
1
DC IN 12V
DC power port for the power adaptor
2
IR_ext **
IR extender connector (optional)
3
(USB)*
This USB port is used for USB backup and firmware
updates only.
4
(LAN)
RJ45 port for the network cable
5
(Mouse)
Mouse port (for USB compatible mouse only)
6
SENSOR **
Sensor ports (marked “1~4”) and a common ground (marked
“G”) (Optional)
7
ARM (ALARM) **
Alarm port (Alarm 1+ and Alarm 1-) (Optional)
8
485+ and - (RS-485) **
RS-485 connector (typically for PTZ cameras and
keyboards) (Optional)
9
VGA-OUT
VGA output (DB-9) port for the LCD monitor
10
VIDEO-OUT
Video output port for the security monitor
11
AUDIO-IN and -OUT
Connectors of audio input for microphone and output for
speaker
12
VIDEO-IN
Cat5 Cable with RJ45 connectors for video input: Ch1 to Ch4
13
Dimensions
180 x 142 x 125 mm (Width x Height x Depth)
* For USB flash drive only for backup and Firmware upgrades
** Not included in the ENXDVR-4C kit package

5
Bundled Cameras and Installations
The kit package comes bundled with four
Encore ¼” CCD cameras. For the
cameras complete specifications, you
can find it in User’s Manual.
The bundled CCD cameras comes with a
RJ-45 port each. This is where the video
signal goes out to feed to the DVR and
this is also used by the camera to get
power input from, the DVR. In other
words the camera share one port and
one Ethernet cable for power input and
video output like other surveillance
cameras.
An Ethernet network cable such as CAT5
or better with RJ-45 conector can be
used to connect the cameras to the DVR, The pinouts should be set to the standard
straight-thru only. The connection should be a straight DVR to camera, no hub or any other
devices in between. The cable safest length is up to 300 feet, it can go more depending on
high environmental or electrical signal interference where the cable would pass thru.
Make sure to connect all cameras (and all other peripherals) before powering up the DVR to
avoid damage to the camera’s sensitive internal circuitry as well as to the DVR system.
Powering up the DVR also powers up the cameras at the same time
Power Up the DVR
The ENXDVR-4C is ready for operation after all the peripherals and the hard disc drive
have been properly installed and connected. Make sure the power plug is the last to
connect. Connect the power connector to the power-in port and then power cord to the
electrical outlet supply. The ENXDVR-4C has no power switch, therefore as soon as you
plugged-in the adapter to the electrical outlet, the DVR will start its operation. It may take a
few seconds for the DVR to fully startup. When the newly installed hard drive is detected
the system will ask whether or not you would like to format it.
Release Date: May 25 2011 17:33:16
Video: NTSC
Hard Drive: WDC WD7500AYPS-01ZKB Rec:02.0
715403MB…Empty Disk
DVR needs to format HDD,
All data will be lost…
Format / Cancel?

6
S
St ta ar rt ti in ng g u up p t th he e E EN NX XD DV VR R- -4 4C C S Sy ys st te em m
The ENXDVR-4C is ready for operations after all the peripheral devices are properly installed
and powered up. This section briefly tells you about the initial screens you will see when the
ENXDVR-4C is first powered up. More detailed explanations and steps in setting up the DVR
system as you would like it to be can be found in the User’s Manual, these are User’s setup,
color, playback, backup, etc..
H
Ho om me e S Sc cr re ee en n
The Status Bar is fixed; it only gives out status information, you can change what
would show up in this bar from setup.
The Control Bar is hidden most of the time. It will only show up when the mouse arrow
is moved to its place (lower portion of the Home Screen) and will stay visible as long
as the mouse arrow stays in the area. Click any of icons to activate it.
The 1,2,3,4 quadrant refers to the Channel 1 to Channel 4 video area.
1% 2011/06/06 15:37:47
Status Bar
Control Bar

7
State Bar Information
The State Bar displays the status and notification icons set for the surveillance system.
Icon
Function
Icon
Function
Camera is working
No signal from camera
Recording
Recording Stop
Force Record Start
Network connected
USB disk connected
Network disconnected
Hard drive overwrite enabled
Hard drive status
Channel display rotation enabled
XX%
Percentage of hard drive already used
2011/06/03
Current date
15:37:47
Current time
Control Bar Information
The Control Bar may be used to access channels and their related applications.
Icon
Function
Icon
Function
Load default channel display
location
4-channel split view
Auto channel rotation
Enter main menu
Start recording
Stop recording
Start force recording
Stop force recording
Playback menu
Calendar Menu
Event search
Pan/Tilt/Zoom control screen
Recording information
Hard drive information
Network information
1% 2011/06/06 15:37:47

8
The Main Menu Screen
Press the icon to enter the “Main Menu”. The default password is “123456”.
MAIN MENU
Icon
Name
Function
DVR Power Supply
To reboot or shutdown the DVR system
Channel Setup
Set the channel display, record, channel name and
video color adjustment.
Record Setup
Set the record schedule, video performance and
quality
Detector Setup
Set the motion, sensor and alarm mode.
Authentication Setup
Set the login account, password and the
authentication.
System Setup
Set the status icons display, languages, date/time,
rotation time, button beep tone, input device speed,
and other relevant system features.
Hardware Setup
Configures error message checks, hard drive
information, overwrite settings, network settings,
Audio and screen settings.
Utility/Tools
These are used to format USB devices, to update
firmware, to export event logs, and to restore system
settings.
Exit Main Menu
Exit the main menu.
E
En nd d o of f Q Qu ui ic ck k I In ns st ta al ll la at ti io on n G Gu ui id de e
F
Fo or r m mo or re e a an nd d d de et ta ai il le ed d s so of ft tw wa ar re e s se et tt ti in ng gs s, , c ch he ec ck k t th he e U Us se er r’ ’s s M Ma an nu ua al l. .
