Endurance EPV Owner's manual

EPV Pellet Vent
Pellet to Chimney Adapter
Supplemental Instructions

A MAJOR CAUSE OF VENT RELATED FIRES IS FAILURE
TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES)
TO COMBUSTIBLE MATERIALS. IT IS OF THE UTMOST
IMPORTANCETHAT EPV PELLETVENT BE INSTALLED ONLY
IN ACCORDANCE WITH THESE INSTRUCTIONS.
MH8381
NOTE:
Read through all of these instructions before
beginning your installation. Failure to install
as described in this instruction will void the
manufacturer’s warranty, and may have an
eect on your homeowner’s insurance and
UL listing status. Keep these instructions for
future reference.
Dear Customer, Installer, or End User:
We welcome any comments, ideas, input or
complaints regarding matters pertaining to
our Endurance products.
If you are searching for tech support or
product information, please call us at
800-667-3387. Or email us at:
[email protected]om

ENC CHIMNEY
SYSTEM
3
INSTALLATION ONTO A CHIMNEY
1. Remove any existing connector pipe
installed between the appliance and the
Support Box connection.
2. Visually inspect with a ashlight the
condition of the interior of the chimney
for cleanliness and structural integrity. All
evidence of soot and creosote must be
removed from the existing chimney system.
If you doubt your ability to accomplish this,
contact a certied chimney sweep. Do not
use chemical cleaners, as these can possibly
damage the inside of the chimney. Do
any required maintenance on the existing
chimney system at this time.
3. Connect and seal the appropriate size
EPV Chimney Adapter to the ENC Chimney
Support Box with high temperature RTV
silicone sealant. Secure the connection with
three sheet metal screws.
4. Connect the appliance to the Chimney
Adapter using an Appliance Adapter, lengths
of pipe as required, and an Adjustable Length
pipe. Slide the Adjustable Length down over
the top pipe section, position the installation
vertically plumb, then slip the Adjustable
Length up and twist lock it to the Chimney
Adapter. Once all the components are rmly
seated and properly aligned, carefully drill
three 1/8”diameter holes through the outer
sleeve only in the center of the slots located
at the bottom of the Adjustable Length
pipe. Do not penetrate the inner liner. Use
(3) 3/8” length sheet metal screws to secure
the Adjustable Length pipe. The completed
installation will look like Figure 1.
EPV
CHIMNEY
ADAPTER
CHIMNEY
SUPPORT BOX
EPV
CHIMNEY
ADAPTER
EPV SYSTEM
Figure 1

Endurance® is a registered trademark.
All rights reserved, ©2017
Manufactured in CA
Customer Service Support 800-667-3387 www.enduranceventing.com
L502-EPVSUP_820015943_EVP to ENC Adapter_Install Instructions_03-28-18_V1
ENDURANCE® LIMITED LIFETIME WARRANTY
"Endurance" provides this limited lifetime warranty for all of its products. Subject to the limitations set forth
below, Endurance warrants that its products will be free from defects in material or manufacturing, if properly
installed, maintained and used. This Warranty is transferable from the original homeowner to the buyer of
the home. This warranty does not cover normal wear and tear, smoke damage or damage caused by chimney
res, acts of God, or any product that was: (1) purchased other than from an authorized Endurance dealer,
retailer or distributor; (2) modied or altered; (3) improperly serviced, inspected or cleaned; or (4) subject
to negligence or any use not in accordance with the installation instructions included with the product as
determined by Endurance. Installation instructions are available online at www.enduranceventing.com
under Support/Literature and through our Customer Service Department 800-667-3387 or customerservice@
enduranceventing.com. This limited lifetime warranty applies only to parts manufactured by Endurance.
Endurance provides the following warranties for its products: One Hundred Percent (100%) MSRP 15
years from the date of purchase, and Fifty Percent (50%) thereafter, except for the following limitations: all
Termination Caps are warranted at One Hundred Percent (100%) for ve years.
All warranty obligations of Endurance shall be limited to repair or replacement of the defective product
pursuant to the terms and conditions applicable to each product line. These remedies shall constitute
Endurance’s sole obligation and sole remedy under this warranty. This warranty provides no cash surrender
value.The terms and conditions of this warranty may not be modied, altered or waived by any action, inaction
or representation, whether oral or in writing, except upon the express, written authority of an executive ocer
of Endurance.
Driftwood or other wood containing salt, preservative-treated lumber, plastic and household trash or
garbage, or wood pellets containing such materials must not be burned in the appliance or replace. In case
of a chimney re, the chimney must be inspected and approved by a certied Chimney Sweep before reuse.
After each annual inspection, maintenance, and cleaning, the certied Chimney Sweep must document this
maintenance.
Endurance must be notied and given the opportunity to inspect defective product prior to replacement
under the terms of this limited lifetime warranty. All warranty claims must be submitted with proof of
purchase. Labor and installation costs are not covered under this warranty. To obtain warranty service contact
Endurance at 800-667-3387.
WHERE LAWFUL, ENDURANCE DISCLAIMS ALL OTHER WARRANTIES, INCLUDING BUT NOT LIMITED TO
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT WILL
ENDURANCE BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR SPECIAL DAMAGES OR DIRECT OR
INDIRECT LOSS OF ANY KIND, INCLUDING BUT NOT LIMITED TO PROPERTY DAMAGE AND PERSONAL INJURY.
ENDURANCE'S ENTIRE LIABILITY IS LIMITED TO THE PURCHASE PRICE OF THIS PRODUCT. SOME STATES DO
NOT ALLOW LIMITATIONS ON IMPLIED WARRANTIES, OR THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO YOU. THIS
LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY
FROM STATE TO STATE.
For the most up-to-date installation instructions, see www.enduranceventing.com.
