Energie AquaPura Split 300i User manual

AQUAPURA MONOBLOC
300i | 300ix
Review: 1
Version: 0
Date: 02/Jun/2014
ENG
Technical Manual

AquaPura Monobloc
2
Technical Manual
Esteemed Client,
We would like to thank you for your choice when you acquired an equipment for
sanitary water heating.
The heat-pump AquaPura Monobloc will surely meet all your expectations and
provide many years of comfort with a maximum power saving.
Our organization dedicates much time, energy and economic resources in order
to develop innovations that will promote power saving in our products.
Your choice has demonstrated your good sense and concern with power
consumption, a matter that affects the environment.
We have taken on a permanent commitment to conceive innovative and efficient
products so that this rational use of energy can actively contribute to the
preservation of the environment and natural resources of the planet.
Keep this manual whose objective is to inform, alert and advise about the use
and maintenance of this equipment.
Our services are always at your disposal. Feel free to call upon us!

AquaPura Monobloc
3
Technical Manual
INDEX
1. PARTS NAMES......................................................................................................................6
2. BASIC OPERATION PRINCIPLE...............................................................................................7
3. SAFETY INFORMATION.........................................................................................................7
4. BEFORE INSTALLATION.........................................................................................................9
4.1. Unpacking .....................................................................................................................9
4.1.1. Acessories ..........................................................................................................9
4.1.2. How to Transport ...............................................................................................9
4.2. Location Requirements..................................................................................................9
4.3. Space Requirements....................................................................................................10
4.4. Enclosed Space............................................................................................................10
4.5. Unit Dimensions..........................................................................................................11
5. INSTALLATION....................................................................................................................11
5.1. Water System Piping ...................................................................................................11
5.2. Air Duct Connection ....................................................................................................12
5.3. Electric Connection .....................................................................................................14
5.3.1. Electric Wiring ..................................................................................................15
5.3.2. Power Supply ...................................................................................................15
5.3.3. PCB I/O Ports Description .................................................................................16
5.3.4. Switch Setting ..................................................................................................16
5.3.5. Electric Leakage Protector ................................................................................16
5.4. Installation Checklist ...................................................................................................16
6. ..........................................................................................................................................11
6.1. Water Affusion Before Operation ................................................................................17
6.2. Trial Running...............................................................................................................18
7. OPERATION........................................................................................................................20
7.1. Control Panel Explanation ...........................................................................................20
7.2. Display Explanation .....................................................................................................21
7.3. Combination Button....................................................................................................24
7.4. Auto Re-start...............................................................................................................24
7.5. Button Auto Lock.........................................................................................................24
7.6. Screen Auto Lock.........................................................................................................24
8. TROUBLESHOOTING...........................................................................................................24
8.1. Non Error Tips .............................................................................................................24

AquaPura Monobloc
4
Technical Manual
8.2. Something About Self-Protection of Unit.....................................................................25
8.3. When Error Happened.................................................................................................25
8.4. Error Phenomenon Shooting .......................................................................................26
8.5. Error Code Shooting Table...........................................................................................26
9. MAINTENANCE....................................................................................................................27
9.1. Maintenance...............................................................................................................27
9.2. Recommended Regular Maintenance Table.................................................................28
10. SPECIFICATIONS ................................................................................................................29

AquaPura Monobloc
5
Technical Manual
WARNING
This unit is required reliable earthing before usage,
otherwise mightcause death or injury
If you can't make sure that your house power supply is earthed
well, please don't install the unit.
Please have a qualified person perform the reliable earthing
connection and the installation of the unit.
Examples of a qualified person include: licensed plumbers,
authorized electric company personnel, and authorized service
personnel.
Your safety is the most important thing we
concerned!

AquaPura Monobloc
6
Technical Manual
1. PARTS NAMES
NOTE: All the pictures in this manual are for explanation purpose only. They may be slightly different from
the heat pump water heater you purchased (depend on model). Please refer to the real sample instead of
the picture of this manual.
A
1915
Height
B
650
Diameter
C
77
Cold water inlet
3/4” M
D
757
Recirculation
3/4”M
E
1071
Magnesium anode
1” 1/4 F
F
1300
PT Valve*
1/2” F
G
1157
Hot water outlet
3/4” M
H
610*
Heat exchager outlet*
1” M
I
920*
Heat exchanger inlet*
1” M
*Optional

AquaPura Monobloc
7
Technical Manual
2. BASIC OPERATION PRINCIPLE
As we know with our experience, the natural flow
of heat, which moves from a higher to a lower
temperature source. the heat pump can transfer
heat from a lower temperature source to a higher
temperature source with high efficiency.
The advantage of a heat pump water heater is
that it can supply more heat energy, normally 3
times than input electricity power by extracting
the heat from ambient atmosphere in a free-of
charge way to Sanitary Hot Water, compare to the
traditional water heater, such as electric water
heater or gas burner water heater, their efficiency
is normally less than 1, which means it will
dramatically cut off the bill of family daily SHW by
the application of Heat pump water heater,
following data will show more details.
Power consumption comparison under the same
condition to heat 1 ton water from 15˚C to 55˚C
The equivalent heat load
Q = CM(T1 -T2)
Q = 1 (KCal/Kg.°C ) x 1000(Kg) x (55-1 5) ( °C )
HPWH
Gas
Burner
E-Heater
Energy Source
Air/Electricity
Gas
Electricity
Transfer Factor
Kcal/kWh
860
24000
860
Average
Efficiency
3,5
0,8
0,95
Energy
Consumption
13,33kWh
2,08m3
49,13kWh
NOTE: Above calculation is based on the ideal
condition , the final cost bill will be different
caused by the actual running conditions, such as
running period, ambient temperature, etc.
3. SAFETY INFORMATION
Please read thoroughly all of the instructions
before installing or operating the unit.
Following safety symbol is very important, always
read and obey all safety symbol:
CAUTION
You may be injured if you don't
obey instructions.
WARNING
You may be killed or seriously
injured if you don't obey
instructions.
DANGER
You may be killed or seriously
injured immediately if you don't
obey instructions.
The unit must be earthed effectively.
A creepage breaker must be installed
adjacent to the power supply
Do not remove, cover or deface any
permanent instructions, labels, or the data
label from either the outside of the unit or
inside of unit panels.
Ask qualified person to perform the
installation of this unit in accordance with
local national regulations and this manual.
Improper installation may result in water
leakage, electric shock or fire.
Do not insert fingers, rods or other objects
into the air inlet or outlet.
When the fan is rotating at high speed, it will
cause injury.
Never use a flammable spray such as hair
spray, lacquer paint near the unit.
It may cause a fire.
Ask qualified person for relocating, repairing
and maintaining the unit instead of doing by
yourself.
WARNING

AquaPura Monobloc
8
Technical Manual
Improper installation may result in water
leakage, electric shock or fire.
Electric connection work should obey the
instructions of local power company, local
electric utility and this manual.
Never use the wire and fuse with wrong rated
current, otherwise unit may break down and
cause fire furthermore
Do not insert fingers, rods or other objects
into the air inlet or outlet.
When the fan is rotating at high speed, it will
cause injury.
Never use a flammable spray such as hair
spray, lacquer paint near the unit.
It may cause a fire
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a similarly qualified person.
DISPOSAL: Do not dispose this product as
unsorted municipal waste. Collection of such
waste separately for special treatment is
necessary. Do not dispose of electrical
appliances as unsorted municipal waste, use
separate collection facilities. Contact your
local government for information regarding
the collection systems available. If electrical
appliances are disposed of in landfills or
dumps, hazardous substances can leak into
the groundwater and get into the food chain,
damaging your health and well-being
The earthing pole of socket must be grounded well,
make sure that power supply socket and plug are
dry enough and connected tightly.
How to check the power supply socket and
plug are qualified?
Turn on power supply and keep the unit
running for a half hour, then turn off power
supply and plug out, check whether the
socket and plug is hot or not.
Before cleaning, be sure to stop the
operation and turn the breaker off or pull out
the power plug.
Otherwise, an electric shock and injury may
be caused.
Water temperature over
50℃can cause severe
burns instantly or death
from scalds. Children,
disabled and elderly are at
highest risk of being
scalded. Feel water before bathing or
showering. Water temperature limiting valves
are recommended.
Do not operate the unit with a wet hand. An
electric shock may be caused.
The installation height of power supply
should be over 1.8m, I there is any water
spattered, separate the power supply from
water.
A one-way valve must be installed on the
water inlet side, which is available from
accessories, see manual "accessories" part.
It’s normal if some water drops from the hole
of PT valve during operation. But, if there is a
great amount of water, call your service
agent for instructions.
After a long term use, check the unit base
and fittings. If damaged, the unit may sink
and result in injury.
Arrange the drain pipe to ensure smooth
draining. Improper drainage work may cause
wetting of the building, furniture etc.
Do not touch the inner parts of the controller.
Do not remove the front panel. Some parts
inside are dangerous to touch, otherwise a
machine malfunction may be caused.
CAUTION

AquaPura Monobloc
9
Technical Manual
Do not turn off the power supply. System will
stop or restart heating automatically. A
continuous power supply for water heating is
necessary, except service and maintenance.
If the unit has not been used for a long period
of time (2 weeks or more), hydrogen gas will
be produced in the water piping system.
Hydrogen gas is extremely flammable. To
reduce the risk of injury under these
conditions, it is recommended that open the
hot water tap for several minutes at the
kitchen sink before using any electrical
appliance connected to the hot water system.
When hydrogen is present, there will
probably be an unusual sound such as air
escaping through the pipe as the water
begins to flow. There should be no smoking
or open flame near the tap at the time it is
open.
4. BEFORE INSTALLATION
4.1. Unpacking
4.1.1. Acessories
Acessory
Name
Qty
Purpose
Owner’s
Manual
1
Installation and use
instructions
One Way
valve
1
Prevent water from
flowing backards
Drain Pipe
1
Discharge Condensated
water
4.1.2. How to Transport
In order to avoid scratch or
deformation of the unit
surface, apply guard boards to
the contacting surface. No
contact of fingers and other
things with the vanes. Don’t
incline the unit more than 75° in moving, and
keep it vertical when installing.
This unit is heavy, it needs to be carried by two or
more persons otherwise might cause injury and
damage.
4.2. Location Requirements
Enough space for installation and
maintenance shall be preserved.
The air inlet and outlet should be free from
obstacles and strong wind.
The base surface should be flat, surface
should be inclined no more than 2°and able
to bear the weight of the unit and suitable for
installing the unit without increasing noise or
vibration.
The operation noise and air flow expelled
shall not affect neighbours.
No flammable gas is leaked nearby.
It is convenient for piping and wiring.
If it is installed in indoor space, it might cause
indoor temp decreased and noise, Please
take preventive measures for this.
If the unit has to be installed on a metal part
of building, make sure the well electric
insulation which should meet the relevant
local electric standard.
The ambient air temperature must also be
considered when installing this unit, in heat
pump mode the ambient air temperature
must be above -7℃and below 43℃.If the
ambient air temperature falls outside these
upper and lower limits, the electrical
elements will activated to meet the hot
water demand and the heat pump does not
operate.
The unit should be located in an area not
subject to freezing temperatures. The unit
located in unconditioned spaces (i.e.,
garages, basements, etc.) may require the
water piping, condensate piping, and drain
CAUTION

AquaPura Monobloc
10
Technical Manual
piping to be insulated to shelter against
freezing.
Installing the unit in any of the following places
may lead to malfunction (If it is inevitable, consult
the supplier).
The site contains mineral oils such as lubricant
of cutting machines.
Seaside where the air contains much salt.
Hot spring area where corrosive gases exist,
e.g., sulfide gas.
Factories where the power voltage fluctuates
seriously.
Inside a car or cabin.
The place with direct sunlight and other heat
supplies. If there’s no way to avoid these,
please install a covering.
Place like kitchen where oil permeates.
Place where strong electromagnetic waves
exist.
Place where flammable gases or materials
exist.
Place where acid or alkali gases evaporate.
Other special environments.
The unit must be securely fixed, elsewise,
noise and shaking may be resulted.
Make sure that there’s no obstacle around the
unit.
In the place where there is strong wind like
seashore, fix the unit in the location protected
from the wind.
4.3. Space requirements
4.4. Enclosed Space
The water heater must be located in a space
>15m³, and must have unrestricted air flow. As an
example, a room that has an 2.5 tall ceiling and is
3 meter long by 2 meter wide would contain
15m³.
CAUTION
WARNING

AquaPura Monobloc
11
Technical Manual
4.5. Unit Dimensions
5. INSTALLATION
The circulating air for every unit should be more
than 350m3/h. Make sure there is enough
Installation space. Outline dimensional drawing.
5.1. Water System Piping
Water inlet or outlet pipes: The spec of the water
inlet or outlet thread is RC3/4” (external thread).
Pipes must be heat-insulated well.
1. Installation of the pipe for PT valve: The spec
of the valve connecting thread is RC3/4”
(internal thread). After installation, it must be
confirmed that the drainpipe outlet is
exposed in the air.
Piping water system, as the above figure. In
case of installing it at a place where outside
temperature below freezing point, insulation
must be provided for all hydraulic
components.
Do not block off the
Drainage pipe, it will cause
explosion and injury, if do
not comply with the above
instruction.
2. Installation of the One Way Valve: The spec of
the One Way Valve thread in accessories is
WARNING
WARNING

AquaPura Monobloc
12
Technical Manual
RC3/4”. It is used to prevent water from
flowing backwards.
3. After water system piping work, turn on the
cold water inlet valve and hot water outlet
valve and start effusing the tank. When water
flow smoothly out from water outlet pipe (tap
water outlet), the tank is full, turn off all valves
and check pipeline to make sure there is no
any leakage.
4. If the inlet water pressure is less than
0.15MPa, a pump should be installed at the
water inlet. For guarantee the safety usage of
tank at the condition of water supply hydraulic
higher than 0.65MPa, a reducing valve should
be installed at the water inlet pipe.
5. Condensate may be leaked from unit if
drainage pipe is blocked, a drainage pan is
recommended as shown as following figure:
5.2. Air Duct Connection
1. Air inlet and outlet with duct (A+B<10m)
2. Air outlet without canvas, air inlet
connect to duct (A<10m)
It is recommended to install unit by this
way in the winter where there is other
heat source in the room.

AquaPura Monobloc
13
Technical Manual
3. Air outlet connect to canvas, air inlet without
duct (A<10m)
It is recommended to install unit by this way in
summer that could charge fresh air into room
4. Duct Description
Duct
Round
Duct
Rectangle
Duct
Other
Duct
Dimension
(mm)
ϕ190
190 x 190
Refer to
above
data
Straight-line
pressure drop
(palm)
<2
<2
Straight-line
length (m)
<10
<10
Bent pressure
<2
<2
Bent’s qty
<5
<5
NOTE: The resistance of duct will decrease air-
flow-rate, which will lead to capacity of unit
decreased.
For the case of unit with canvas, of the duct total
length should be no more than 10m or the
maximum static pressure should be within 25Pa,
and the quantity of bending should be no more
than 3.
For unit air outlet with duct, when unit operating,
condensate will be generated around outside of
duct. Please pay attention to the drainage work,
we suggest to wrap the thermal insulated layer
around outside of the duct.
It is recommended to install the unit in the indoor,
it is not allow to install the unit at the rainy space
Air outlet
Air inlet

AquaPura Monobloc
14
Technical Manual
In case of rain entering to internal components of
the unit, the component might be damaged or
causing physical danger. In terms of the unit
connect with duct reaching to outdoor, reliable
water-resistant measure must be conduct on the
duct, to prevent water from dropping into internal
of the unit.
5. Filter installing at the unit inlet. In terms of
the unit with duct, filter in there must be put
on the position of duct inlet.
6. To smoothly drain condensate from unit,
please install the main unit at a horizontal
floor. Otherwise, please ensure the drain
vent is at the lowest level. Recommending
the inclination angle of unit to the ground
should be no more than 2°.
5.3. Electric Connection
The power supply should be an independent
circuit with rated voltage.
Power supply circuit should be earthed
effectively. The wiring must be performed by
professional technicians in accordance with
national wiring regulations and this circuit
diagram.
An all-pole disconnection device which has at
least 3mm separation distance in all pole and
a residual current device (RCD) with the
rating of above 10mA shall be incorporated in
the fixed wiring according to the national
rule.
WARNING
CAUTION

AquaPura Monobloc
15
Technical Manual
Set the electric leakage protector according
to the relevant electric technical standards of
the State.
The power cord and the signal cord shall be
laid out neatly and properly without mutual
interference or contacting the connection
pipe or valve.
After wire connection, check it again and
make sure the correctness before power on.
5.3.1. Electric Wiring
5.3.2. Power Supply
Please choose the power cord according to above
table, and it should comply with local electric
standard. The power cord model, recommended
power cord mode is H05RN-F.
The unit must be installed with an Creepage
Breaker near the power supply and must be
effectively earthed.
CAUTION

AquaPura Monobloc
16
Technical Manual
5.3.3. PCB I/O Ports Description
5.3.4.Switch Setting
PCB has 2 bits of switches
5.3.5. Electric leakage protector
5.4. Installation Checklist
The flooring beneath the water heater must
be able to support the weight of the water
heater when filled with water (286kg full).
Located indoors (such as a basement or
garage) and in a vertical position. Sheltered
from freezing temperatures.
Provisions made to shelter the area from
water damage. Metal drain pan installed and
piped to an adequate drain.
Sufficient room to service the water heater.
Sufficient air for the heat pump to function,
the water heater must be located in a space
>15m³, and must have unrestricted air flow.
For optimal efficiency and serviceability, the
following clearances should be maintained:
800mm on the air inlet side, 800mm on the

AquaPura Monobloc
17
Technical Manual
air outlet side, 600mm in the back, and
600mm in the front.
The unit cannot be placed into any type of
closet or small enclosure.
The site location must be free from any
corrosive elements in the atmosphere such as
sulfur, fluorine, and chlorine. These elements
are found in aerosol sprays, detergents,
bleaches, cleaning solvents, air fresheners,
paint, and varnish removers, refrigerants, and
many other commercial and household
products. In addition excessive dust and lint
may affect the operation of the unit and
require more frequent cleaning.
The ambient air temperature must be above -
7ºC and below 43ºC.If the ambient air
temperature falls outside these upper and
lower limits the electrical elements will be
activated to meet the hot water demand.
PT valve(Temperature and pressure relief
valve) properly installed with a discharge pipe
run to an adequate drain and sheltered from
freezing.
All piping properly installed and free of leaks.
Unit completely filled with water.
Mixing valve (recommended) installed per
manufacturer’s instructions.
Must be located with access to an adequate
drain or condensate pump.
Condensate drain lines installed and piped to
an adequate drain or condensate pump.
The water heater requires 230 VAC for proper
operation.
Wiring size and connections comply with all
local applicable codes and the requirements
of this manual.
Water heater and electrical supply are
properly grounded.
Proper overload fuse or circuit breaker
protection installed.
Understand how to use the User Interface
Module to set the various modes and
functions.
Understand the importance of routine
inspection/maintenance of the condensate
drain pan and lines. This is to help prevent
any possible drain line blockage resulting in
the condensate drain pan overflowing.
IMPORTANT: Water coming from the plastic
shroud is an indicator that both condensation
drain lines may be blocked. Immediate action
is required.
To maintain optimal operation check, remove
and clean the air filter.
6.
6.1. Water Affusion Before
Operation
Before using this unit, please follow the steps
below.
Water Affusion: If the unit is used for the first
time or used again after emptying the tank, please
make sure that the tank is full of water before
turning on the power.

AquaPura Monobloc
18
Technical Manual
Operation without water in water tank may
result in the damage of auxiliary e-heater.
Due to such damage, manufacturer will not
be liable for any damages caused by this
issue.
After powered on, the display lights up. Users
can operate the unit through the buttons
under the display.
Emptying: If the unit needs cleaning, moving
etc, the tank should be emptied.
6.2. Trial Running
Checking list before commissioning
1. Checking list before trial-running.
2. Correct installation of the system.
3. Correct connection of water/air piping
and wiring;.
4. Condensate draining smoothly well
insulation work for all hydraulic part.
5. Correct power supply.
6. No air in the water pipeline and all valves
opened. Effective electric leakage
protector installation.
7. Sufficient inlet water pressure (between
0.15Mpa and 0.65MPa) (≥0.15MPa).
8. System Structure Figure Unit has two
kinds of heat sources: Heat pump
(compressor) and electric heater. Unit will
automatically select heat sources to heat
water to the target temperature
9. Water Temperature Display. The
temperature shown on the display
depends on the upper sensor. So it is
normal that the display temperature has
reached to target temperature but
compressor still running, because the
lower water temperature does not get to
target temperature.
10.Modes will be automatically selected by
unit. Manually mode selection is
unavailable.
CAUTION

AquaPura Monobloc
19
Technical Manual
11. Heat Source Shift
The default heating source is heat
pump.
If ambient is range out of heat pump,
heat pump will stop running, the unit
will shift automatically to activate E-
heater and show the icon LA on the
display, then if the ambient
temperature goes into the running
range of heat pump again, it will stop
E-heater and shift automatically to
heat pump again, and the icon LA will
be extinguished.
If the target setting water
temperature is higher than Max temp
(Heat pump), the unit will activate
heat pump firstly to the Max.
Temperature, then stop heat pump,
activate E-heater to continually heat
water to the target temperature.
If manually activate the E-heater
running mode when heat pump
running, E-heater and heat pump will
work together until the water
temperature gets to target
temperature. So if want to heat
quickly, please manually activate E-
heater.
NOTE: E-heater will be activated once for the
current heating progress, if want to apply E-heater
again, please push
If system occurs some malfunctions, error code
"E7" and will be shown on the display, then
heat pump will stop running, and the unit will
activate automatically E-heater as the backup
heat source, but the code "E7" and will be
shown until power off.
NOTE: If only use E-heater, about only 150 liters
water will be heated, so must set higher target
water temperature if ambient temperature is out
of heat pump running range.
Defrosting During Water-heating
In heat pump running period, if the evaporator
frosted in lower ambient temperature, the system
will defrost automatically to keep effective
performance(about 3~10min). At defrosting time,
the fan motor will stop, but compressor will still
run.
COP
There is different COP in different ambient
temperature.
Normally lower ambient temperature result
longer heat-up time because of lower effective
performance.
When ambient temp below 2℃, heat pump and
E-heater will take different portions of heating
capacity, generally the lower of ambient
temperature, the lower portion of heat pump will
be taken as well as the higher portion of E-heater
will account for.
About TCO and ATCO
The power of E-heater will be automatically shut-
off or turn on by TCO and ATCO.
If the temperature is higher than 78℃, the ATCO
will automatically shut off the power of E-heater,
and turn on it if the temperature falls down below
68℃.

AquaPura Monobloc
20
Technical Manual
If the water temperature is higher than 85℃, the
TCO will automatically shut off the power of E-
heater, it must be re-turn on manually.
Restart After a Long Term Stop
When the unit is restarted after a long term stop
(trail running included), it is normal that outlet
water is unclean. Keep the tap on and the water
will be clean soon.
NOTE: While the ambient temperature below
than -7℃, heat pump efficiency will decrease
dramatically, the unit will automatically shift to E-
heater mode
Basic function
Weekly disinfect function:
Under disinfection mode unit immediately start to
heat water up to 65℃to kill the potential
legionella bacteria inside water of tank, icon
will light on the display screen during disinfection;
Unit will quit disinfection mode if water
temperature is higher than 65℃and extinguish
icon.
Vacation mode:
After pressing "Vacation" button, Unit will
automatically heat water to 15℃for the purpose
of energy saving during vacation days.
How is the unit running:
If unit is OFF->press ->unit will be waken-
>press to set target water temperature
(38-60℃)->press ->unit
will automatically select mode and start to heat
water to target temperature.
Query Function
For the convenience of maintenance and debug,
query function is available by Press 2 buttons
together: “ ” + “ ”
,then system running parameters will be shown
one by one with following sequence by each
pushing of " " or " " button.
7. OPERATION
7.1. Control Panel Explanation
