Energizer Arc3 User manual

UG_EN_AR3_2020-12-17
Using the Arc3
Fully Charge your Arc3before first use!
Welcome!
Space Heater
Microwave
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772
LCD Display
A-
B-
C-
D-
E-
F-
G-
H-
I-
J-
K-
Battery Charge
How much baery power is le.
Time Remaining
Run time remaining at the current power draw.
High Temperature Warning
It’s too hot! Cool down the baery.
Low Temperature Warning
It’s too cold! Warm up the baery.
Cooling Fan
The fan will run when the baery gets hot, this is normal.
Low Battery
The baery is geing low, recharge it.
AC Output
Indicates AC output is on.
USB Output
Indicates USB output is on.
USB Type-C Output
Indicates USB Type-C output is on.
DC Output
Indicates DC output is on.
Watt Meter
Current input or output in Was.
21 3
4 6
5
A CB D E
G H I J K
F
Hairdryer
Not Recommended
(Over 350W Consumption)
Kele
Circular Saw
Air Conditioner
*Repeat the same steps for USB & DC outputs.
USB Power
USB On/Off
USB Type-C
2x USB 3.0
Type-A
Fast Charge
1.
2.
3.
62X
GoPro
(4.4Wh)
22X
Smartphone
(12Wh)
8X
Tablet
(32Wh)
Example Devices
DC Power Important!
Not permied
on aircra
Avoid extreme
temperatures
Avoid
dropping
Do not expose
to liquids
Dispose of baeries
according to
local regulations
AC
AC Power
AC Power
On/Off
110V
receptacle
110V
receptacle
1.
2.
3.
4X
Laptop
(62Wh)
3.5h
TV
(75W)
32h
Light 
(8W)
Example Devices
DC
DC Power
On/Off
2x 5.5mm 12V
DC Ports
12V Cigarette
Port
1.
2.
3.
4h
Car Cooler
(60W)
2.5h
Vacuum
(120W)
2 Nights
CPAP
(25W)
Example Devices
Recharge your Arc3
with a wall outlet,
vehicle cigarette
port, or the sun
using solar panels. 5h
AC Wall Plug
5-8h
Solar Panel
Input
5h
Vehicle Charger
1. Press and hold power button for 1 second to turn on the unit.
2. Press the AC button to power on the AC outlets.
3. The icon will appear on the display to show the output is on.
4. Plug in your devices and power up.
5. After use, press the AC button to power off the AC outlets.
6. To turn off all ports and power down press and hold the
power button for 1 second.
The power to Go.
Screen Brightness Emergency S.O.S Restart
Double click the power buon to
dim the screen. Single press to
brighten it back up.
Double press the LED buon to
engage the emergency strobe feature.
Single press again to turn it o.
Use a paperclip (or
similar) to reboot if
needed.
Power Buon
Press and hold for 1
second to turn the
unit on or o.
USB
Quick Start GuideQuick Start Guide

UG_EN_AR3_2020-12-17
Using the Arc3
Fully Charge your Arc3before first use!
Welcome!
Space Heater
Microwave
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772
LCD Display
A-
B-
C-
D-
E-
F-
G-
H-
I-
J-
K-
Battery Charge
How much baery power is le.
Time Remaining
Run time remaining at the current power draw.
High Temperature Warning
It’s too hot! Cool down the baery.
Low Temperature Warning
It’s too cold! Warm up the baery.
Cooling Fan
The fan will run when the baery gets hot, this is normal.
Low Battery
The baery is geing low, recharge it.
AC Output
Indicates AC output is on.
USB Output
Indicates USB output is on.
USB Type-C Output
Indicates USB Type-C output is on.
DC Output
Indicates DC output is on.
Watt Meter
Current input or output in Was.
21 3
4 6
5
A CB D E
G H I J K
F
Hairdryer
Not Recommended
(Over 350W Consumption)
Kele
Circular Saw
Air Conditioner
*Repeat the same steps for USB & DC outputs.
USB Power
USB On/Off
USB Type-C
2x USB 3.0
Type-A
Fast Charge
1.
2.
3.
62X
GoPro
(4.4Wh)
22X
Smartphone
(12Wh)
8X
Tablet
(32Wh)
Example Devices
DC Power Important!
Not permied
on aircra
Avoid extreme
temperatures
Avoid
dropping
Do not expose
to liquids
Dispose of baeries
according to
local regulations
AC
AC Power
AC Power
On/Off
110V
receptacle
110V
receptacle
1.
2.
3.
4X
Laptop
(62Wh)
3.5h
TV
(75W)
32h
Light 
(8W)
Example Devices
DC
DC Power
On/Off
2x 5.5mm 12V
DC Ports
12V Cigarette
Port
1.
2.
3.
4h
Car Cooler
(60W)
2.5h
Vacuum
(120W)
2 Nights
CPAP
(25W)
Example Devices
Recharge your Arc3
with a wall outlet,
vehicle cigarette
port, or the sun
using solar panels. 5h
AC Wall Plug
5-8h
Solar Panel
Input
5h
Vehicle Charger
1. Press and hold power button for 1 second to turn on the unit.
2. Press the AC button to power on the AC outlets.
3. The icon will appear on the display to show the output is on.
4. Plug in your devices and power up.
5. After use, press the AC button to power off the AC outlets.
6. To turn off all ports and power down press and hold the
power button for 1 second.
The power to Go.
Screen Brightness Emergency S.O.S Restart
Double click the power buon to
dim the screen. Single press to
brighten it back up.
Double press the LED buon to
engage the emergency strobe feature.
Single press again to turn it o.
Use a paperclip (or
similar) to reboot if
needed.
Power Buon
Press and hold for 1
second to turn the
unit on or o.
USB
Quick Start GuideQuick Start Guide

UG_EN_AR3_2020-12-17
Using the Arc3
Fully Charge your Arc3before first use!
Welcome!
Space Heater
Microwave
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772
LCD Display
A-
B-
C-
D-
E-
F-
G-
H-
I-
J-
K-
Battery Charge
How much baery power is le.
Time Remaining
Run time remaining at the current power draw.
High Temperature Warning
It’s too hot! Cool down the baery.
Low Temperature Warning
It’s too cold! Warm up the baery.
Cooling Fan
The fan will run when the baery gets hot, this is normal.
Low Battery
The baery is geing low, recharge it.
AC Output
Indicates AC output is on.
USB Output
Indicates USB output is on.
USB Type-C Output
Indicates USB Type-C output is on.
DC Output
Indicates DC output is on.
Watt Meter
Current input or output in Was.
21 3
4 6
5
A CB D E
G H I J K
F
Hairdryer
Not Recommended
(Over 350W Consumption)
Kele
Circular Saw
Air Conditioner
*Repeat the same steps for USB & DC outputs.
USB Power
USB On/Off
USB Type-C
2x USB 3.0
Type-A
Fast Charge
1.
2.
3.
62X
GoPro
(4.4Wh)
22X
Smartphone
(12Wh)
8X
Tablet
(32Wh)
Example Devices
DC Power Important!
Not permied
on aircra
Avoid extreme
temperatures
Avoid
dropping
Do not expose
to liquids
Dispose of baeries
according to
local regulations
AC
AC Power
AC Power
On/Off
110V
receptacle
110V
receptacle
1.
2.
3.
4X
Laptop
(62Wh)
3.5h
TV
(75W)
32h
Light 
(8W)
Example Devices
DC
DC Power
On/Off
2x 5.5mm 12V
DC Ports
12V Cigarette
Port
1.
2.
3.
4h
Car Cooler
(60W)
2.5h
Vacuum
(120W)
2 Nights
CPAP
(25W)
Example Devices
Recharge your Arc3
with a wall outlet,
vehicle cigarette
port, or the sun
using solar panels. 5h
AC Wall Plug
5-8h
Solar Panel
Input
5h
Vehicle Charger
1. Press and hold power button for 1 second to turn on the unit.
2. Press the AC button to power on the AC outlets.
3. The icon will appear on the display to show the output is on.
4. Plug in your devices and power up.
5. After use, press the AC button to power off the AC outlets.
6. To turn off all ports and power down press and hold the
power button for 1 second.
The power to Go.
Screen Brightness Emergency S.O.S Restart
Double click the power buon to
dim the screen. Single press to
brighten it back up.
Double press the LED buon to
engage the emergency strobe feature.
Single press again to turn it o.
Use a paperclip (or
similar) to reboot if
needed.
Power Buon
Press and hold for 1
second to turn the
unit on or o.
USB
Quick Start GuideQuick Start Guide
UG_EN_AR3_2020-12-17
Using the Arc3
Fully Charge your Arc3before first use!
Welcome!
Space Heater
Microwave
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772
LCD Display
A-
B-
C-
D-
E-
F-
G-
H-
I-
J-
K-
Battery Charge
How much baery power is le.
Time Remaining
Run time remaining at the current power draw.
High Temperature Warning
It’s too hot! Cool down the baery.
Low Temperature Warning
It’s too cold! Warm up the baery.
Cooling Fan
The fan will run when the baery gets hot, this is normal.
Low Battery
The baery is geing low, recharge it.
AC Output
Indicates AC output is on.
USB Output
Indicates USB output is on.
USB Type-C Output
Indicates USB Type-C output is on.
DC Output
Indicates DC output is on.
Watt Meter
Current input or output in Was.
21 3
4 6
5
A CB D E
G H I J K
F
Hairdryer
Not Recommended
(Over 350W Consumption)
Kele
Circular Saw
Air Conditioner
*Repeat the same steps for USB & DC outputs.
USB Power
USB On/Off
USB Type-C
2x USB 3.0
Type-A
Fast Charge
1.
2.
3.
62X
GoPro
(4.4Wh)
22X
Smartphone
(12Wh)
8X
Tablet
(32Wh)
Example Devices
DC Power Important!
Not permied
on aircra
Avoid extreme
temperatures
Avoid
dropping
Do not expose
to liquids
Dispose of baeries
according to
local regulations
AC
AC Power
AC Power
On/Off
110V
receptacle
110V
receptacle
1.
2.
3.
4X
Laptop
(62Wh)
3.5h
TV
(75W)
32h
Light 
(8W)
Example Devices
DC
DC Power
On/Off
2x 5.5mm 12V
DC Ports
12V Cigarette
Port
1.
2.
3.
4h
Car Cooler
(60W)
2.5h
Vacuum
(120W)
2 Nights
CPAP
(25W)
Example Devices
Recharge your Arc3
with a wall outlet,
vehicle cigarette
port, or the sun
using solar panels. 5h
AC Wall Plug
5-8h
Solar Panel
Input
5h
Vehicle Charger
1. Press and hold power button for 1 second to turn on the unit.
2. Press the AC button to power on the AC outlets.
3. The icon will appear on the display to show the output is on.
4. Plug in your devices and power up.
5. After use, press the AC button to power off the AC outlets.
6. To turn off all ports and power down press and hold the
power button for 1 second.
The power to Go.
Screen Brightness Emergency S.O.S Restart
Double click the power buon to
dim the screen. Single press to
brighten it back up.
Double press the LED buon to
engage the emergency strobe feature.
Single press again to turn it o.
Use a paperclip (or
similar) to reboot if
needed.
Power Buon
Press and hold for 1
second to turn the
unit on or o.
USB
Quick Start GuideQuick Start Guide

UG_EN_AR3_2020-12-17
Using the Arc3
Fully Charge your Arc3before first use!
Welcome!
Space Heater
Microwave
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772
LCD Display
A-
B-
C-
D-
E-
F-
G-
H-
I-
J-
K-
Battery Charge
How much baery power is le.
Time Remaining
Run time remaining at the current power draw.
High Temperature Warning
It’s too hot! Cool down the baery.
Low Temperature Warning
It’s too cold! Warm up the baery.
Cooling Fan
The fan will run when the baery gets hot, this is normal.
Low Battery
The baery is geing low, recharge it.
AC Output
Indicates AC output is on.
USB Output
Indicates USB output is on.
USB Type-C Output
Indicates USB Type-C output is on.
DC Output
Indicates DC output is on.
Watt Meter
Current input or output in Was.
21 3
4 6
5
A CB D E
G H I J K
F
Hairdryer
Not Recommended
(Over 350W Consumption)
Kele
Circular Saw
Air Conditioner
*Repeat the same steps for USB & DC outputs.
USB Power
USB On/Off
USB Type-C
2x USB 3.0
Type-A
Fast Charge
1.
2.
3.
62X
GoPro
(4.4Wh)
22X
Smartphone
(12Wh)
8X
Tablet
(32Wh)
Example Devices
DC Power Important!
Not permied
on aircra
Avoid extreme
temperatures
Avoid
dropping
Do not expose
to liquids
Dispose of baeries
according to
local regulations
AC
AC Power
AC Power
On/Off
110V
receptacle
110V
receptacle
1.
2.
3.
4X
Laptop
(62Wh)
3.5h
TV
(75W)
32h
Light 
(8W)
Example Devices
DC
DC Power
On/Off
2x 5.5mm 12V
DC Ports
12V Cigarette
Port
1.
2.
3.
4h
Car Cooler
(60W)
2.5h
Vacuum
(120W)
2 Nights
CPAP
(25W)
Example Devices
Recharge your Arc3
with a wall outlet,
vehicle cigarette
port, or the sun
using solar panels. 5h
AC Wall Plug
5-8h
Solar Panel
Input
5h
Vehicle Charger
1. Press and hold power button for 1 second to turn on the unit.
2. Press the AC button to power on the AC outlets.
3. The icon will appear on the display to show the output is on.
4. Plug in your devices and power up.
5. After use, press the AC button to power off the AC outlets.
6. To turn off all ports and power down press and hold the
power button for 1 second.
The power to Go.
Screen Brightness Emergency S.O.S Restart
Double click the power buon to
dim the screen. Single press to
brighten it back up.
Double press the LED buon to
engage the emergency strobe feature.
Single press again to turn it o.
Use a paperclip (or
similar) to reboot if
needed.
Power Buon
Press and hold for 1
second to turn the
unit on or o.
USB
Quick Start GuideQuick Start Guide

Safety
Register Online
www.energizerarc.com/register-your-warranty
FAQs Baery Education 101Troubleshooting Guide
Warranty
DO NOT disassemble, repair, or modify the unit or
the baery.
DO NOT place the unit close to fire, heat sources, or
leave in direct sunlight.
DO NOT connect the output socket to mains power
under any circumstances.
DO NOT expose to moisture or liquids, especially
saltwater.
Dispose of the unit properly according to local
regulations.
DO NOT dispose in regular household trash.
DO NOT operate the unit above the specified input
voltage, be especially careful with solar panels.
DO NOT use this unit if your hands are wet.
DO NOT use if the unit appears damaged.
This product IS NOT permied on aircra.
Inspect the unit prior to every use.
Keep this product away from children and pets.
Carefully read the instructions for the electric
devices you intend to connect.
Keep away from direct sunlight, water, dust, and
dirt.
DO NOT leave the unit outside in harsh
environments.
High temperatures can damage the baery and
decrease the lifecycle and capacity.
DO NOT leave outdoors overnight uncovered. The
moisture from the dew may lead to a short circuit.
Danger!
Can I fly with the Arc3?
No. FAA regulations allow a maximum of
100Wh baeries on a plane. Arc3is 300Wh.
Do I need to calibrate my battery remaining
meter?
Only if you notice a major dierence between
the predicted time le and how long your Arc
is actually running. Calibrate your Arc’s baery
runtime meter by charging to 100%,
discharging to 0% (until the unit turns o),
then charging back up to 100%.
Can the Arc3be stored and operated
indoors?
Yes, lithium-iron phosphate cells do not
exhaust any fumes and are completely safe.
Can I recharge while powering devices
at the same time?
Yes, the Arc3is equipped with pass-through
charging which means you can recharge the
Arc3while using it to power devices at the
same time.
Can I use both AC and DC ports at the same
time?
Yes, Arc3supports simultaneous operation. All
ports can be used at once, provided the total
draw is less than 350W.
What will happen if I plug in a device that
draws over 350W?
The unit will stop operation and display an
overload error message. Press the AC buon
to turn o and turn on again to reset the
system.
How long will it keep a charge?
1 Year. It’s best for your baery’s health to
charge every 3 months and store at 40-50%.
Do not store at 0% charge, lithium-iron
baeries lose 3-5% charge per month. Within
a few weeks your unit may be below the
charge level needed to accept a recharge and
permanent damage has been done.
Can I use this with my CPAP machine?
Absolutely. CPAP operation using DC ports
(with CPAP converter) will allow longer
runtime than AC ports. Runtime will dier
greatly based on heat, humidity, and pressure
seings.
Can the Arc3jump-start a car?
No, a jump start port is not available on this
unit.
Can I charge the Arc3with a generator?
Yes, it will charge in 5hrs. An inverter
generator is recommended.
Can I combine two solar panels to achieve a
faster charging rate?
Yes, as long as the combined output voltage
of the panels is between 12V -24V.
Will Arc3automatically shut down with no
power draw?
Yes, it will shut down aer 10hrs. This duration
was designed to ensure fridges operate
properly.
Will the USB-C PD (Power Delivery) Port
power my Laptop?
Yes, it can provide up to 60W of charging
power.
How much power is drawn if a port is left on
accidentally?
About 1.5W per hour with a max of 15W total.
Can I buy parts to fix my Arc3after the
warranty has expired?
Yes, please visit our website for more
information.
Do not return your product where purchased. If you feel your power station is
not meeting your expectations, simply contact our customer support center
[e-mail] for technical advice, a warranty claim or general
information. Keep a copy of the original receipt, UPC code and serial number
with this user guide.
Limited warranty period for recreational and
residential use: Two Years Limited
1st Year: Parts and Labor
2nd Year: Parts
This product is warranted to be free of defects in
material and workmanship for two years from date
of purchase and does not restart at any time under
any circumstances. This warranty guarantees that
any defective parts will be repaired or replaced at
no cost, including diagnosis and replacement parts.
Limitation of remedies and disclaimers: Energizer
Generators disclaims any responsibility for loss of
time or any other incidental or consequential
damage. Any implied warranties are limited to the
duration of this wrien warranty.
THE FOREGOING LIMITED WARRANTY IS EXCLUSIVE
OF AND IN LIEU OF ALL OTHER WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND OF ANY OTHER WARRANTY
WHETHER EXPRESS OR IMPLIED.
Exclusions not covered by this limited warranty:
damage to products caused by accident,
negligence, misuse, abuse, modification, improper
installation, improper storage, water, liquid or gas
of any kind, operation in a marine application,
operation with improper loads or conditions,
modifications contrary to published specifications,
accessories not supplied by Energizer Generators,
repairs made during the warranty period without
first obtaining a case number from Energizer
Generators, or use for anything other than the
intended use as outlined by Energizer Generators.
Energizer Generators products are distributed by:
Midland Power Inc., 376 Magnetic Drive, Toronto,
ON M3J 2C4, Canada.
Warranty Claim Procedure
Specifications
Knowledge Guide
Problem Solution
My Arc3
shut down
while
powering
my device.
My device
is not
receiving
power.
My Arc3
charge level
is fluctuating.
My Arc3is
not
charging.
My Arc3’s
screen
stopped
responding.
If the High Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from heat source.
Do not use until unit has cooled and the icon disappears. Then
turn the output on and try again. Excessive heat will degrade
the baery’s life span.
If the AC icon on the digital display is blinking the unit
has overloaded. Press the AC buon to turn o and turn on
again to reset. Max power limit for AC is 350W.
If the Low Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from the cold. Do
not use until unit has warmed and the icon disappears. Then
turn the output on and try again.
Ensure the power switch for the output you want to use is on.
For example if you want to charge your phone turn USB on,
then plug in your phone.
If the baery is very low, the Arc3can’t read the charge as
accurately. As it receives a charge the accuracy will increase.
Your baery meter may need recalibration by charging to 100%,
draining to 0% (until the unit turns o), then charging back up to
100%.
Ensure that you are using the port labeled “input”, noted by
the red circle that surrounds it. Ensure that all components are
firmly connected.
Use a paperclip to restart your unit by pressing the factory
reset buon (restart) on the front control panel. The unit will
then reboot. If this does not solve your issue please call our
technical support team.
Wa Hours
Ah
mAh
Cell Type
Cycle Life
Shelf Life
Pass-Through
Charging
Baery
Management
Protection
System
300Wh
24Ah
85,000 mAh
Lithium-iron
Phosphate
>2000
Charge every 3
months
Yes
Over-current
Overload
Over-voltage
Short circuit
Temperature
Under-voltage
Continuous Power
Inverter Type
AC Output Voltage
USB Type-A Fast
Charge
USB Type-C PD
DC Cigaree Port
(12V Optimized)
DC 5.5mm (5521)
(12V Optimized)
350W
Pure Sine Wave
110V/3.1A Pure
Sine
2x 5V/2.1A,
9V/2A, 12V/1.5A
1x 20V/3A - PD
60W
1x 12.6V/10A
2x 13V/4A
*Up to 200W panels. Do NOT exceed 24V
or damage may occur
General
Device Runtime | AC vs. DC Power
In general, it is normal for power losses to occur when
energy is transferred from the baery to the ports that
power your devices.
The AC port requires an inverter, which transforms power
from DC to AC. This process creates heat and consumes
about 15% of the power it transforms. DC ports are more
ecient and only consume 5% of the power that is
transformed.
Your device will always last longer when plugged into DC
ports if that option is available. For example, a CPAP
machine will last almost an extra night when using a DC
CPAP converter compared to the standard AC plug.
Heat is the Enemy
If the Arc3, or any power station, is le in the heat it will
impact its health, capacity and longevity. Keep out of hot
cars and direct sunlight on warm days. Heat is the #1
reason baeries degrade prematurely.
Determine The Power Consumption of Your Device
Device with no baery: locate Was (W) on the product.
If Was are not available: multiply the Voltage (V) x Amps
(A) to arrive at Was. Eg. 120V x 0.6A = 72W
Device with a baery: locate Wa Hours (Wh).
Or multiply the Voltage (V) x Amp Hours (Ah) to arrive at
Wa Hours (Wh). Eg. 12V x 1.0Ah = 12Wh (Note: 1.0Ah =
1000mAh)
Calculate Working Time or Recharges for your Device
AC Outlets Working Capacity
300Wh x 0.85 (15% inverter conversion loss) = 255Wh
working capacity. For example, assume your fan consumes
72W. To calculate working time: 255Wh ÷ 72w = 3.5 hrs
DC and USB Outlets Working Capacity
300Wh x 0.95 (5% DC conversion loss) = 285Wh working
capacity. For example, assume your smartphone has a
12.3Wh capacity baery. To calculate the number of
recharges before capacity is depleted, use the formula:
285Wh ÷ 12.3Wh = 22 recharges.
Regulated 12V vs Non-Regulated 12V
Non-regulated 12V ports are linked to the charge
percentage of the baery. For example, when a power
station is at 100% charge the DC voltage will operate at
approximately 12V, which is acceptable for 12V devices. But
as the baery charge drops to 50% the DC voltage will drop
to approximately 10.8V. 12V devices such as
mini-fridges/coolers, CPAP machines, vacuums, radios etc.,
will simply stop running when the voltage drops below ~11V.
The Arc3 does not have regulated ports but it’s 12V ports
are optimized to output up to 14 Volts on a full charge and
a minimum of 12 Volts when the baery is almost depleted.
This ensures devices, such as electric coolers, keep running
no maer how much charge is remaining.
For more information please visit www.energizerarc.com
Battery
Output
Input
Wall (AC) Charger
Wall Charge Time
12V Car Charge Time
Solar Connector
Solar Voltage
Recommended
Solar Panels
Solar MPPT Controller
Solar Charge Time
19V/3.5A 60W
5 hrs (AC)
5 hrs (DC)
MC4
12-24V*
60-200W
Yes
5-8 hrs**
9.1 lbs / 4.2kg
7.4” x 6.5“ x 7.9”
-10°C to 40°C
0°C to 40°C
2 Years
ETL, CE, ROHS, FCC
Weight
Dimensions
Operating Temp.
Recharging Temp.
Warranty
Certifications
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772 UG_EN_AR3_2020-12-17
**Solar charge time will vary based on many factors and conditions
such as the weather, time of day, location, solar panel eciency etc.
3

Safety
Register Online
www.energizerarc.com/register-your-warranty
FAQs Baery Education 101Troubleshooting Guide
Warranty
DO NOT disassemble, repair, or modify the unit or
the baery.
DO NOT place the unit close to fire, heat sources, or
leave in direct sunlight.
DO NOT connect the output socket to mains power
under any circumstances.
DO NOT expose to moisture or liquids, especially
saltwater.
Dispose of the unit properly according to local
regulations.
DO NOT dispose in regular household trash.
DO NOT operate the unit above the specified input
voltage, be especially careful with solar panels.
DO NOT use this unit if your hands are wet.
DO NOT use if the unit appears damaged.
This product IS NOT permied on aircra.
Inspect the unit prior to every use.
Keep this product away from children and pets.
Carefully read the instructions for the electric
devices you intend to connect.
Keep away from direct sunlight, water, dust, and
dirt.
DO NOT leave the unit outside in harsh
environments.
High temperatures can damage the baery and
decrease the lifecycle and capacity.
DO NOT leave outdoors overnight uncovered. The
moisture from the dew may lead to a short circuit.
Danger!
Can I fly with the Arc3?
No. FAA regulations allow a maximum of
100Wh baeries on a plane. Arc3is 300Wh.
Do I need to calibrate my battery remaining
meter?
Only if you notice a major dierence between
the predicted time le and how long your Arc
is actually running. Calibrate your Arc’s baery
runtime meter by charging to 100%,
discharging to 0% (until the unit turns o),
then charging back up to 100%.
Can the Arc3be stored and operated
indoors?
Yes, lithium-iron phosphate cells do not
exhaust any fumes and are completely safe.
Can I recharge while powering devices
at the same time?
Yes, the Arc3is equipped with pass-through
charging which means you can recharge the
Arc3while using it to power devices at the
same time.
Can I use both AC and DC ports at the same
time?
Yes, Arc3supports simultaneous operation. All
ports can be used at once, provided the total
draw is less than 350W.
What will happen if I plug in a device that
draws over 350W?
The unit will stop operation and display an
overload error message. Press the AC buon
to turn o and turn on again to reset the
system.
How long will it keep a charge?
1 Year. It’s best for your baery’s health to
charge every 3 months and store at 40-50%.
Do not store at 0% charge, lithium-iron
baeries lose 3-5% charge per month. Within
a few weeks your unit may be below the
charge level needed to accept a recharge and
permanent damage has been done.
Can I use this with my CPAP machine?
Absolutely. CPAP operation using DC ports
(with CPAP converter) will allow longer
runtime than AC ports. Runtime will dier
greatly based on heat, humidity, and pressure
seings.
Can the Arc3jump-start a car?
No, a jump start port is not available on this
unit.
Can I charge the Arc3with a generator?
Yes, it will charge in 5hrs. An inverter
generator is recommended.
Can I combine two solar panels to achieve a
faster charging rate?
Yes, as long as the combined output voltage
of the panels is between 12V -24V.
Will Arc3automatically shut down with no
power draw?
Yes, it will shut down aer 10hrs. This duration
was designed to ensure fridges operate
properly.
Will the USB-C PD (Power Delivery) Port
power my Laptop?
Yes, it can provide up to 60W of charging
power.
How much power is drawn if a port is left on
accidentally?
About 1.5W per hour with a max of 15W total.
Can I buy parts to fix my Arc3after the
warranty has expired?
Yes, please visit our website for more
information.
Do not return your product where purchased. If you feel your power station is
not meeting your expectations, simply contact our customer support center
[e-mail] for technical advice, a warranty claim or general
information. Keep a copy of the original receipt, UPC code and serial number
with this user guide.
Limited warranty period for recreational and
residential use: Two Years Limited
1st Year: Parts and Labor
2nd Year: Parts
This product is warranted to be free of defects in
material and workmanship for two years from date
of purchase and does not restart at any time under
any circumstances. This warranty guarantees that
any defective parts will be repaired or replaced at
no cost, including diagnosis and replacement parts.
Limitation of remedies and disclaimers: Energizer
Generators disclaims any responsibility for loss of
time or any other incidental or consequential
damage. Any implied warranties are limited to the
duration of this wrien warranty.
THE FOREGOING LIMITED WARRANTY IS EXCLUSIVE
OF AND IN LIEU OF ALL OTHER WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND OF ANY OTHER WARRANTY
WHETHER EXPRESS OR IMPLIED.
Exclusions not covered by this limited warranty:
damage to products caused by accident,
negligence, misuse, abuse, modification, improper
installation, improper storage, water, liquid or gas
of any kind, operation in a marine application,
operation with improper loads or conditions,
modifications contrary to published specifications,
accessories not supplied by Energizer Generators,
repairs made during the warranty period without
first obtaining a case number from Energizer
Generators, or use for anything other than the
intended use as outlined by Energizer Generators.
Energizer Generators products are distributed by:
Midland Power Inc., 376 Magnetic Drive, Toronto,
ON M3J 2C4, Canada.
Warranty Claim Procedure
Specifications
Knowledge Guide
Problem Solution
My Arc3
shut down
while
powering
my device.
My device
is not
receiving
power.
My Arc3
charge level
is fluctuating.
My Arc3is
not
charging.
My Arc3’s
screen
stopped
responding.
If the High Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from heat source.
Do not use until unit has cooled and the icon disappears. Then
turn the output on and try again. Excessive heat will degrade
the baery’s life span.
If the AC icon on the digital display is blinking the unit
has overloaded. Press the AC buon to turn o and turn on
again to reset. Max power limit for AC is 350W.
If the Low Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from the cold. Do
not use until unit has warmed and the icon disappears. Then
turn the output on and try again.
Ensure the power switch for the output you want to use is on.
For example if you want to charge your phone turn USB on,
then plug in your phone.
If the baery is very low, the Arc3can’t read the charge as
accurately. As it receives a charge the accuracy will increase.
Your baery meter may need recalibration by charging to 100%,
draining to 0% (until the unit turns o), then charging back up to
100%.
Ensure that you are using the port labeled “input”, noted by
the red circle that surrounds it. Ensure that all components are
firmly connected.
Use a paperclip to restart your unit by pressing the factory
reset buon (restart) on the front control panel. The unit will
then reboot. If this does not solve your issue please call our
technical support team.
Wa Hours
Ah
mAh
Cell Type
Cycle Life
Shelf Life
Pass-Through
Charging
Baery
Management
Protection
System
300Wh
24Ah
85,000 mAh
Lithium-iron
Phosphate
>2000
Charge every 3
months
Yes
Over-current
Overload
Over-voltage
Short circuit
Temperature
Under-voltage
Continuous Power
Inverter Type
AC Output Voltage
USB Type-A Fast
Charge
USB Type-C PD
DC Cigaree Port
(12V Optimized)
DC 5.5mm (5521)
(12V Optimized)
350W
Pure Sine Wave
110V/3.1A Pure
Sine
2x 5V/2.1A,
9V/2A, 12V/1.5A
1x 20V/3A - PD
60W
1x 12.6V/10A
2x 13V/4A
*Up to 200W panels. Do NOT exceed 24V
or damage may occur
General
Device Runtime | AC vs. DC Power
In general, it is normal for power losses to occur when
energy is transferred from the baery to the ports that
power your devices.
The AC port requires an inverter, which transforms power
from DC to AC. This process creates heat and consumes
about 15% of the power it transforms. DC ports are more
ecient and only consume 5% of the power that is
transformed.
Your device will always last longer when plugged into DC
ports if that option is available. For example, a CPAP
machine will last almost an extra night when using a DC
CPAP converter compared to the standard AC plug.
Heat is the Enemy
If the Arc3, or any power station, is le in the heat it will
impact its health, capacity and longevity. Keep out of hot
cars and direct sunlight on warm days. Heat is the #1
reason baeries degrade prematurely.
Determine The Power Consumption of Your Device
Device with no baery: locate Was (W) on the product.
If Was are not available: multiply the Voltage (V) x Amps
(A) to arrive at Was. Eg. 120V x 0.6A = 72W
Device with a baery: locate Wa Hours (Wh).
Or multiply the Voltage (V) x Amp Hours (Ah) to arrive at
Wa Hours (Wh). Eg. 12V x 1.0Ah = 12Wh (Note: 1.0Ah =
1000mAh)
Calculate Working Time or Recharges for your Device
AC Outlets Working Capacity
300Wh x 0.85 (15% inverter conversion loss) = 255Wh
working capacity. For example, assume your fan consumes
72W. To calculate working time: 255Wh ÷ 72w = 3.5 hrs
DC and USB Outlets Working Capacity
300Wh x 0.95 (5% DC conversion loss) = 285Wh working
capacity. For example, assume your smartphone has a
12.3Wh capacity baery. To calculate the number of
recharges before capacity is depleted, use the formula:
285Wh ÷ 12.3Wh = 22 recharges.
Regulated 12V vs Non-Regulated 12V
Non-regulated 12V ports are linked to the charge
percentage of the baery. For example, when a power
station is at 100% charge the DC voltage will operate at
approximately 12V, which is acceptable for 12V devices. But
as the baery charge drops to 50% the DC voltage will drop
to approximately 10.8V. 12V devices such as
mini-fridges/coolers, CPAP machines, vacuums, radios etc.,
will simply stop running when the voltage drops below ~11V.
The Arc3 does not have regulated ports but it’s 12V ports
are optimized to output up to 14 Volts on a full charge and
a minimum of 12 Volts when the baery is almost depleted.
This ensures devices, such as electric coolers, keep running
no maer how much charge is remaining.
For more information please visit www.energizerarc.com
Battery
Output
Input
Wall (AC) Charger
Wall Charge Time
12V Car Charge Time
Solar Connector
Solar Voltage
Recommended
Solar Panels
Solar MPPT Controller
Solar Charge Time
19V/3.5A 60W
5 hrs (AC)
5 hrs (DC)
MC4
12-24V*
60-200W
Yes
5-8 hrs**
9.1 lbs / 4.2kg
7.4” x 6.5“ x 7.9”
-10°C to 40°C
0°C to 40°C
2 Years
ETL, CE, ROHS, FCC
Weight
Dimensions
Operating Temp.
Recharging Temp.
Warranty
Certifications
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772 UG_EN_AR3_2020-12-17
**Solar charge time will vary based on many factors and conditions
such as the weather, time of day, location, solar panel eciency etc.
3

Safety
Register Online
www.energizerarc.com/register-your-warranty
FAQs Baery Education 101Troubleshooting Guide
Warranty
DO NOT disassemble, repair, or modify the unit or
the baery.
DO NOT place the unit close to fire, heat sources, or
leave in direct sunlight.
DO NOT connect the output socket to mains power
under any circumstances.
DO NOT expose to moisture or liquids, especially
saltwater.
Dispose of the unit properly according to local
regulations.
DO NOT dispose in regular household trash.
DO NOT operate the unit above the specified input
voltage, be especially careful with solar panels.
DO NOT use this unit if your hands are wet.
DO NOT use if the unit appears damaged.
This product IS NOT permied on aircra.
Inspect the unit prior to every use.
Keep this product away from children and pets.
Carefully read the instructions for the electric
devices you intend to connect.
Keep away from direct sunlight, water, dust, and
dirt.
DO NOT leave the unit outside in harsh
environments.
High temperatures can damage the baery and
decrease the lifecycle and capacity.
DO NOT leave outdoors overnight uncovered. The
moisture from the dew may lead to a short circuit.
Danger!
Can I fly with the Arc3?
No. FAA regulations allow a maximum of
100Wh baeries on a plane. Arc3is 300Wh.
Do I need to calibrate my battery remaining
meter?
Only if you notice a major dierence between
the predicted time le and how long your Arc
is actually running. Calibrate your Arc’s baery
runtime meter by charging to 100%,
discharging to 0% (until the unit turns o),
then charging back up to 100%.
Can the Arc3be stored and operated
indoors?
Yes, lithium-iron phosphate cells do not
exhaust any fumes and are completely safe.
Can I recharge while powering devices
at the same time?
Yes, the Arc3is equipped with pass-through
charging which means you can recharge the
Arc3while using it to power devices at the
same time.
Can I use both AC and DC ports at the same
time?
Yes, Arc3supports simultaneous operation. All
ports can be used at once, provided the total
draw is less than 350W.
What will happen if I plug in a device that
draws over 350W?
The unit will stop operation and display an
overload error message. Press the AC buon
to turn o and turn on again to reset the
system.
How long will it keep a charge?
1 Year. It’s best for your baery’s health to
charge every 3 months and store at 40-50%.
Do not store at 0% charge, lithium-iron
baeries lose 3-5% charge per month. Within
a few weeks your unit may be below the
charge level needed to accept a recharge and
permanent damage has been done.
Can I use this with my CPAP machine?
Absolutely. CPAP operation using DC ports
(with CPAP converter) will allow longer
runtime than AC ports. Runtime will dier
greatly based on heat, humidity, and pressure
seings.
Can the Arc3jump-start a car?
No, a jump start port is not available on this
unit.
Can I charge the Arc3with a generator?
Yes, it will charge in 5hrs. An inverter
generator is recommended.
Can I combine two solar panels to achieve a
faster charging rate?
Yes, as long as the combined output voltage
of the panels is between 12V -24V.
Will Arc3automatically shut down with no
power draw?
Yes, it will shut down aer 10hrs. This duration
was designed to ensure fridges operate
properly.
Will the USB-C PD (Power Delivery) Port
power my Laptop?
Yes, it can provide up to 60W of charging
power.
How much power is drawn if a port is left on
accidentally?
About 1.5W per hour with a max of 15W total.
Can I buy parts to fix my Arc3after the
warranty has expired?
Yes, please visit our website for more
information.
Do not return your product where purchased. If you feel your power station is
not meeting your expectations, simply contact our customer support center
[e-mail] for technical advice, a warranty claim or general
information. Keep a copy of the original receipt, UPC code and serial number
with this user guide.
Limited warranty period for recreational and
residential use: Two Years Limited
1st Year: Parts and Labor
2nd Year: Parts
This product is warranted to be free of defects in
material and workmanship for two years from date
of purchase and does not restart at any time under
any circumstances. This warranty guarantees that
any defective parts will be repaired or replaced at
no cost, including diagnosis and replacement parts.
Limitation of remedies and disclaimers: Energizer
Generators disclaims any responsibility for loss of
time or any other incidental or consequential
damage. Any implied warranties are limited to the
duration of this wrien warranty.
THE FOREGOING LIMITED WARRANTY IS EXCLUSIVE
OF AND IN LIEU OF ALL OTHER WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND OF ANY OTHER WARRANTY
WHETHER EXPRESS OR IMPLIED.
Exclusions not covered by this limited warranty:
damage to products caused by accident,
negligence, misuse, abuse, modification, improper
installation, improper storage, water, liquid or gas
of any kind, operation in a marine application,
operation with improper loads or conditions,
modifications contrary to published specifications,
accessories not supplied by Energizer Generators,
repairs made during the warranty period without
first obtaining a case number from Energizer
Generators, or use for anything other than the
intended use as outlined by Energizer Generators.
Energizer Generators products are distributed by:
Midland Power Inc., 376 Magnetic Drive, Toronto,
ON M3J 2C4, Canada.
Warranty Claim Procedure
Specifications
Knowledge Guide
Problem Solution
My Arc3
shut down
while
powering
my device.
My device
is not
receiving
power.
My Arc3
charge level
is fluctuating.
My Arc3is
not
charging.
My Arc3’s
screen
stopped
responding.
If the High Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from heat source.
Do not use until unit has cooled and the icon disappears. Then
turn the output on and try again. Excessive heat will degrade
the baery’s life span.
If the AC icon on the digital display is blinking the unit
has overloaded. Press the AC buon to turn o and turn on
again to reset. Max power limit for AC is 350W.
If the Low Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from the cold. Do
not use until unit has warmed and the icon disappears. Then
turn the output on and try again.
Ensure the power switch for the output you want to use is on.
For example if you want to charge your phone turn USB on,
then plug in your phone.
If the baery is very low, the Arc3can’t read the charge as
accurately. As it receives a charge the accuracy will increase.
Your baery meter may need recalibration by charging to 100%,
draining to 0% (until the unit turns o), then charging back up to
100%.
Ensure that you are using the port labeled “input”, noted by
the red circle that surrounds it. Ensure that all components are
firmly connected.
Use a paperclip to restart your unit by pressing the factory
reset buon (restart) on the front control panel. The unit will
then reboot. If this does not solve your issue please call our
technical support team.
Wa Hours
Ah
mAh
Cell Type
Cycle Life
Shelf Life
Pass-Through
Charging
Baery
Management
Protection
System
300Wh
24Ah
85,000 mAh
Lithium-iron
Phosphate
>2000
Charge every 3
months
Yes
Over-current
Overload
Over-voltage
Short circuit
Temperature
Under-voltage
Continuous Power
Inverter Type
AC Output Voltage
USB Type-A Fast
Charge
USB Type-C PD
DC Cigaree Port
(12V Optimized)
DC 5.5mm (5521)
(12V Optimized)
350W
Pure Sine Wave
110V/3.1A Pure
Sine
2x 5V/2.1A,
9V/2A, 12V/1.5A
1x 20V/3A - PD
60W
1x 12.6V/10A
2x 13V/4A
*Up to 200W panels. Do NOT exceed 24V
or damage may occur
General
Device Runtime | AC vs. DC Power
In general, it is normal for power losses to occur when
energy is transferred from the baery to the ports that
power your devices.
The AC port requires an inverter, which transforms power
from DC to AC. This process creates heat and consumes
about 15% of the power it transforms. DC ports are more
ecient and only consume 5% of the power that is
transformed.
Your device will always last longer when plugged into DC
ports if that option is available. For example, a CPAP
machine will last almost an extra night when using a DC
CPAP converter compared to the standard AC plug.
Heat is the Enemy
If the Arc3, or any power station, is le in the heat it will
impact its health, capacity and longevity. Keep out of hot
cars and direct sunlight on warm days. Heat is the #1
reason baeries degrade prematurely.
Determine The Power Consumption of Your Device
Device with no baery: locate Was (W) on the product.
If Was are not available: multiply the Voltage (V) x Amps
(A) to arrive at Was. Eg. 120V x 0.6A = 72W
Device with a baery: locate Wa Hours (Wh).
Or multiply the Voltage (V) x Amp Hours (Ah) to arrive at
Wa Hours (Wh). Eg. 12V x 1.0Ah = 12Wh (Note: 1.0Ah =
1000mAh)
Calculate Working Time or Recharges for your Device
AC Outlets Working Capacity
300Wh x 0.85 (15% inverter conversion loss) = 255Wh
working capacity. For example, assume your fan consumes
72W. To calculate working time: 255Wh ÷ 72w = 3.5 hrs
DC and USB Outlets Working Capacity
300Wh x 0.95 (5% DC conversion loss) = 285Wh working
capacity. For example, assume your smartphone has a
12.3Wh capacity baery. To calculate the number of
recharges before capacity is depleted, use the formula:
285Wh ÷ 12.3Wh = 22 recharges.
Regulated 12V vs Non-Regulated 12V
Non-regulated 12V ports are linked to the charge
percentage of the baery. For example, when a power
station is at 100% charge the DC voltage will operate at
approximately 12V, which is acceptable for 12V devices. But
as the baery charge drops to 50% the DC voltage will drop
to approximately 10.8V. 12V devices such as
mini-fridges/coolers, CPAP machines, vacuums, radios etc.,
will simply stop running when the voltage drops below ~11V.
The Arc3 does not have regulated ports but it’s 12V ports
are optimized to output up to 14 Volts on a full charge and
a minimum of 12 Volts when the baery is almost depleted.
This ensures devices, such as electric coolers, keep running
no maer how much charge is remaining.
For more information please visit www.energizerarc.com
Battery
Output
Input
Wall (AC) Charger
Wall Charge Time
12V Car Charge Time
Solar Connector
Solar Voltage
Recommended
Solar Panels
Solar MPPT Controller
Solar Charge Time
19V/3.5A 60W
5 hrs (AC)
5 hrs (DC)
MC4
12-24V*
60-200W
Yes
5-8 hrs**
9.1 lbs / 4.2kg
7.4” x 6.5“ x 7.9”
-10°C to 40°C
0°C to 40°C
2 Years
ETL, CE, ROHS, FCC
Weight
Dimensions
Operating Temp.
Recharging Temp.
Warranty
Certifications
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772 UG_EN_AR3_2020-12-17
**Solar charge time will vary based on many factors and conditions
such as the weather, time of day, location, solar panel eciency etc.
3

Safety
Register Online
www.energizerarc.com/register-your-warranty
FAQs Baery Education 101Troubleshooting Guide
Warranty
DO NOT disassemble, repair, or modify the unit or
the baery.
DO NOT place the unit close to fire, heat sources, or
leave in direct sunlight.
DO NOT connect the output socket to mains power
under any circumstances.
DO NOT expose to moisture or liquids, especially
saltwater.
Dispose of the unit properly according to local
regulations.
DO NOT dispose in regular household trash.
DO NOT operate the unit above the specified input
voltage, be especially careful with solar panels.
DO NOT use this unit if your hands are wet.
DO NOT use if the unit appears damaged.
This product IS NOT permied on aircra.
Inspect the unit prior to every use.
Keep this product away from children and pets.
Carefully read the instructions for the electric
devices you intend to connect.
Keep away from direct sunlight, water, dust, and
dirt.
DO NOT leave the unit outside in harsh
environments.
High temperatures can damage the baery and
decrease the lifecycle and capacity.
DO NOT leave outdoors overnight uncovered. The
moisture from the dew may lead to a short circuit.
Danger!
Can I fly with the Arc3?
No. FAA regulations allow a maximum of
100Wh baeries on a plane. Arc3is 300Wh.
Do I need to calibrate my battery remaining
meter?
Only if you notice a major dierence between
the predicted time le and how long your Arc
is actually running. Calibrate your Arc’s baery
runtime meter by charging to 100%,
discharging to 0% (until the unit turns o),
then charging back up to 100%.
Can the Arc3be stored and operated
indoors?
Yes, lithium-iron phosphate cells do not
exhaust any fumes and are completely safe.
Can I recharge while powering devices
at the same time?
Yes, the Arc3is equipped with pass-through
charging which means you can recharge the
Arc3while using it to power devices at the
same time.
Can I use both AC and DC ports at the same
time?
Yes, Arc3supports simultaneous operation. All
ports can be used at once, provided the total
draw is less than 350W.
What will happen if I plug in a device that
draws over 350W?
The unit will stop operation and display an
overload error message. Press the AC buon
to turn o and turn on again to reset the
system.
How long will it keep a charge?
1 Year. It’s best for your baery’s health to
charge every 3 months and store at 40-50%.
Do not store at 0% charge, lithium-iron
baeries lose 3-5% charge per month. Within
a few weeks your unit may be below the
charge level needed to accept a recharge and
permanent damage has been done.
Can I use this with my CPAP machine?
Absolutely. CPAP operation using DC ports
(with CPAP converter) will allow longer
runtime than AC ports. Runtime will dier
greatly based on heat, humidity, and pressure
seings.
Can the Arc3jump-start a car?
No, a jump start port is not available on this
unit.
Can I charge the Arc3with a generator?
Yes, it will charge in 5hrs. An inverter
generator is recommended.
Can I combine two solar panels to achieve a
faster charging rate?
Yes, as long as the combined output voltage
of the panels is between 12V -24V.
Will Arc3automatically shut down with no
power draw?
Yes, it will shut down aer 10hrs. This duration
was designed to ensure fridges operate
properly.
Will the USB-C PD (Power Delivery) Port
power my Laptop?
Yes, it can provide up to 60W of charging
power.
How much power is drawn if a port is left on
accidentally?
About 1.5W per hour with a max of 15W total.
Can I buy parts to fix my Arc3after the
warranty has expired?
Yes, please visit our website for more
information.
Do not return your product where purchased. If you feel your power station is
not meeting your expectations, simply contact our customer support center
[e-mail] for technical advice, a warranty claim or general
information. Keep a copy of the original receipt, UPC code and serial number
with this user guide.
Limited warranty period for recreational and
residential use: Two Years Limited
1st Year: Parts and Labor
2nd Year: Parts
This product is warranted to be free of defects in
material and workmanship for two years from date
of purchase and does not restart at any time under
any circumstances. This warranty guarantees that
any defective parts will be repaired or replaced at
no cost, including diagnosis and replacement parts.
Limitation of remedies and disclaimers: Energizer
Generators disclaims any responsibility for loss of
time or any other incidental or consequential
damage. Any implied warranties are limited to the
duration of this wrien warranty.
THE FOREGOING LIMITED WARRANTY IS EXCLUSIVE
OF AND IN LIEU OF ALL OTHER WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND OF ANY OTHER WARRANTY
WHETHER EXPRESS OR IMPLIED.
Exclusions not covered by this limited warranty:
damage to products caused by accident,
negligence, misuse, abuse, modification, improper
installation, improper storage, water, liquid or gas
of any kind, operation in a marine application,
operation with improper loads or conditions,
modifications contrary to published specifications,
accessories not supplied by Energizer Generators,
repairs made during the warranty period without
first obtaining a case number from Energizer
Generators, or use for anything other than the
intended use as outlined by Energizer Generators.
Energizer Generators products are distributed by:
Midland Power Inc., 376 Magnetic Drive, Toronto,
ON M3J 2C4, Canada.
Warranty Claim Procedure
Specifications
Knowledge Guide
Problem Solution
My Arc3
shut down
while
powering
my device.
My device
is not
receiving
power.
My Arc3
charge level
is fluctuating.
My Arc3is
not
charging.
My Arc3’s
screen
stopped
responding.
If the High Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from heat source.
Do not use until unit has cooled and the icon disappears. Then
turn the output on and try again. Excessive heat will degrade
the baery’s life span.
If the AC icon on the digital display is blinking the unit
has overloaded. Press the AC buon to turn o and turn on
again to reset. Max power limit for AC is 350W.
If the Low Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from the cold. Do
not use until unit has warmed and the icon disappears. Then
turn the output on and try again.
Ensure the power switch for the output you want to use is on.
For example if you want to charge your phone turn USB on,
then plug in your phone.
If the baery is very low, the Arc3can’t read the charge as
accurately. As it receives a charge the accuracy will increase.
Your baery meter may need recalibration by charging to 100%,
draining to 0% (until the unit turns o), then charging back up to
100%.
Ensure that you are using the port labeled “input”, noted by
the red circle that surrounds it. Ensure that all components are
firmly connected.
Use a paperclip to restart your unit by pressing the factory
reset buon (restart) on the front control panel. The unit will
then reboot. If this does not solve your issue please call our
technical support team.
Wa Hours
Ah
mAh
Cell Type
Cycle Life
Shelf Life
Pass-Through
Charging
Baery
Management
Protection
System
300Wh
24Ah
85,000 mAh
Lithium-iron
Phosphate
>2000
Charge every 3
months
Yes
Over-current
Overload
Over-voltage
Short circuit
Temperature
Under-voltage
Continuous Power
Inverter Type
AC Output Voltage
USB Type-A Fast
Charge
USB Type-C PD
DC Cigaree Port
(12V Optimized)
DC 5.5mm (5521)
(12V Optimized)
350W
Pure Sine Wave
110V/3.1A Pure
Sine
2x 5V/2.1A,
9V/2A, 12V/1.5A
1x 20V/3A - PD
60W
1x 12.6V/10A
2x 13V/4A
*Up to 200W panels. Do NOT exceed 24V
or damage may occur
General
Device Runtime | AC vs. DC Power
In general, it is normal for power losses to occur when
energy is transferred from the baery to the ports that
power your devices.
The AC port requires an inverter, which transforms power
from DC to AC. This process creates heat and consumes
about 15% of the power it transforms. DC ports are more
ecient and only consume 5% of the power that is
transformed.
Your device will always last longer when plugged into DC
ports if that option is available. For example, a CPAP
machine will last almost an extra night when using a DC
CPAP converter compared to the standard AC plug.
Heat is the Enemy
If the Arc3, or any power station, is le in the heat it will
impact its health, capacity and longevity. Keep out of hot
cars and direct sunlight on warm days. Heat is the #1
reason baeries degrade prematurely.
Determine The Power Consumption of Your Device
Device with no baery: locate Was (W) on the product.
If Was are not available: multiply the Voltage (V) x Amps
(A) to arrive at Was. Eg. 120V x 0.6A = 72W
Device with a baery: locate Wa Hours (Wh).
Or multiply the Voltage (V) x Amp Hours (Ah) to arrive at
Wa Hours (Wh). Eg. 12V x 1.0Ah = 12Wh (Note: 1.0Ah =
1000mAh)
Calculate Working Time or Recharges for your Device
AC Outlets Working Capacity
300Wh x 0.85 (15% inverter conversion loss) = 255Wh
working capacity. For example, assume your fan consumes
72W. To calculate working time: 255Wh ÷ 72w = 3.5 hrs
DC and USB Outlets Working Capacity
300Wh x 0.95 (5% DC conversion loss) = 285Wh working
capacity. For example, assume your smartphone has a
12.3Wh capacity baery. To calculate the number of
recharges before capacity is depleted, use the formula:
285Wh ÷ 12.3Wh = 22 recharges.
Regulated 12V vs Non-Regulated 12V
Non-regulated 12V ports are linked to the charge
percentage of the baery. For example, when a power
station is at 100% charge the DC voltage will operate at
approximately 12V, which is acceptable for 12V devices. But
as the baery charge drops to 50% the DC voltage will drop
to approximately 10.8V. 12V devices such as
mini-fridges/coolers, CPAP machines, vacuums, radios etc.,
will simply stop running when the voltage drops below ~11V.
The Arc3 does not have regulated ports but it’s 12V ports
are optimized to output up to 14 Volts on a full charge and
a minimum of 12 Volts when the baery is almost depleted.
This ensures devices, such as electric coolers, keep running
no maer how much charge is remaining.
For more information please visit www.energizerarc.com
Battery
Output
Input
Wall (AC) Charger
Wall Charge Time
12V Car Charge Time
Solar Connector
Solar Voltage
Recommended
Solar Panels
Solar MPPT Controller
Solar Charge Time
19V/3.5A 60W
5 hrs (AC)
5 hrs (DC)
MC4
12-24V*
60-200W
Yes
5-8 hrs**
9.1 lbs / 4.2kg
7.4” x 6.5“ x 7.9”
-10°C to 40°C
0°C to 40°C
2 Years
ETL, CE, ROHS, FCC
Weight
Dimensions
Operating Temp.
Recharging Temp.
Warranty
Certifications
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772 UG_EN_AR3_2020-12-17
**Solar charge time will vary based on many factors and conditions
such as the weather, time of day, location, solar panel eciency etc.
3

Safety
Register Online
www.energizerarc.com/register-your-warranty
FAQs Baery Education 101Troubleshooting Guide
Warranty
DO NOT disassemble, repair, or modify the unit or
the baery.
DO NOT place the unit close to fire, heat sources, or
leave in direct sunlight.
DO NOT connect the output socket to mains power
under any circumstances.
DO NOT expose to moisture or liquids, especially
saltwater.
Dispose of the unit properly according to local
regulations.
DO NOT dispose in regular household trash.
DO NOT operate the unit above the specified input
voltage, be especially careful with solar panels.
DO NOT use this unit if your hands are wet.
DO NOT use if the unit appears damaged.
This product IS NOT permied on aircra.
Inspect the unit prior to every use.
Keep this product away from children and pets.
Carefully read the instructions for the electric
devices you intend to connect.
Keep away from direct sunlight, water, dust, and
dirt.
DO NOT leave the unit outside in harsh
environments.
High temperatures can damage the baery and
decrease the lifecycle and capacity.
DO NOT leave outdoors overnight uncovered. The
moisture from the dew may lead to a short circuit.
Danger!
Can I fly with the Arc3?
No. FAA regulations allow a maximum of
100Wh baeries on a plane. Arc3is 300Wh.
Do I need to calibrate my battery remaining
meter?
Only if you notice a major dierence between
the predicted time le and how long your Arc
is actually running. Calibrate your Arc’s baery
runtime meter by charging to 100%,
discharging to 0% (until the unit turns o),
then charging back up to 100%.
Can the Arc3be stored and operated
indoors?
Yes, lithium-iron phosphate cells do not
exhaust any fumes and are completely safe.
Can I recharge while powering devices
at the same time?
Yes, the Arc3is equipped with pass-through
charging which means you can recharge the
Arc3while using it to power devices at the
same time.
Can I use both AC and DC ports at the same
time?
Yes, Arc3supports simultaneous operation. All
ports can be used at once, provided the total
draw is less than 350W.
What will happen if I plug in a device that
draws over 350W?
The unit will stop operation and display an
overload error message. Press the AC buon
to turn o and turn on again to reset the
system.
How long will it keep a charge?
1 Year. It’s best for your baery’s health to
charge every 3 months and store at 40-50%.
Do not store at 0% charge, lithium-iron
baeries lose 3-5% charge per month. Within
a few weeks your unit may be below the
charge level needed to accept a recharge and
permanent damage has been done.
Can I use this with my CPAP machine?
Absolutely. CPAP operation using DC ports
(with CPAP converter) will allow longer
runtime than AC ports. Runtime will dier
greatly based on heat, humidity, and pressure
seings.
Can the Arc3jump-start a car?
No, a jump start port is not available on this
unit.
Can I charge the Arc3with a generator?
Yes, it will charge in 5hrs. An inverter
generator is recommended.
Can I combine two solar panels to achieve a
faster charging rate?
Yes, as long as the combined output voltage
of the panels is between 12V -24V.
Will Arc3automatically shut down with no
power draw?
Yes, it will shut down aer 10hrs. This duration
was designed to ensure fridges operate
properly.
Will the USB-C PD (Power Delivery) Port
power my Laptop?
Yes, it can provide up to 60W of charging
power.
How much power is drawn if a port is left on
accidentally?
About 1.5W per hour with a max of 15W total.
Can I buy parts to fix my Arc3after the
warranty has expired?
Yes, please visit our website for more
information.
Do not return your product where purchased. If you feel your power station is
not meeting your expectations, simply contact our customer support center
[e-mail] for technical advice, a warranty claim or general
information. Keep a copy of the original receipt, UPC code and serial number
with this user guide.
Limited warranty period for recreational and
residential use: Two Years Limited
1st Year: Parts and Labor
2nd Year: Parts
This product is warranted to be free of defects in
material and workmanship for two years from date
of purchase and does not restart at any time under
any circumstances. This warranty guarantees that
any defective parts will be repaired or replaced at
no cost, including diagnosis and replacement parts.
Limitation of remedies and disclaimers: Energizer
Generators disclaims any responsibility for loss of
time or any other incidental or consequential
damage. Any implied warranties are limited to the
duration of this wrien warranty.
THE FOREGOING LIMITED WARRANTY IS EXCLUSIVE
OF AND IN LIEU OF ALL OTHER WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR
PURPOSE AND OF ANY OTHER WARRANTY
WHETHER EXPRESS OR IMPLIED.
Exclusions not covered by this limited warranty:
damage to products caused by accident,
negligence, misuse, abuse, modification, improper
installation, improper storage, water, liquid or gas
of any kind, operation in a marine application,
operation with improper loads or conditions,
modifications contrary to published specifications,
accessories not supplied by Energizer Generators,
repairs made during the warranty period without
first obtaining a case number from Energizer
Generators, or use for anything other than the
intended use as outlined by Energizer Generators.
Energizer Generators products are distributed by:
Midland Power Inc., 376 Magnetic Drive, Toronto,
ON M3J 2C4, Canada.
Warranty Claim Procedure
Specifications
Knowledge Guide
Problem Solution
My Arc3
shut down
while
powering
my device.
My device
is not
receiving
power.
My Arc3
charge level
is fluctuating.
My Arc3is
not
charging.
My Arc3’s
screen
stopped
responding.
If the High Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from heat source.
Do not use until unit has cooled and the icon disappears. Then
turn the output on and try again. Excessive heat will degrade
the baery’s life span.
If the AC icon on the digital display is blinking the unit
has overloaded. Press the AC buon to turn o and turn on
again to reset. Max power limit for AC is 350W.
If the Low Temperature icon on the digital display is
blinking: Turn all ports o and remove unit from the cold. Do
not use until unit has warmed and the icon disappears. Then
turn the output on and try again.
Ensure the power switch for the output you want to use is on.
For example if you want to charge your phone turn USB on,
then plug in your phone.
If the baery is very low, the Arc3can’t read the charge as
accurately. As it receives a charge the accuracy will increase.
Your baery meter may need recalibration by charging to 100%,
draining to 0% (until the unit turns o), then charging back up to
100%.
Ensure that you are using the port labeled “input”, noted by
the red circle that surrounds it. Ensure that all components are
firmly connected.
Use a paperclip to restart your unit by pressing the factory
reset buon (restart) on the front control panel. The unit will
then reboot. If this does not solve your issue please call our
technical support team.
Wa Hours
Ah
mAh
Cell Type
Cycle Life
Shelf Life
Pass-Through
Charging
Baery
Management
Protection
System
300Wh
24Ah
85,000 mAh
Lithium-iron
Phosphate
>2000
Charge every 3
months
Yes
Over-current
Overload
Over-voltage
Short circuit
Temperature
Under-voltage
Continuous Power
Inverter Type
AC Output Voltage
USB Type-A Fast
Charge
USB Type-C PD
DC Cigaree Port
(12V Optimized)
DC 5.5mm (5521)
(12V Optimized)
350W
Pure Sine Wave
110V/3.1A Pure
Sine
2x 5V/2.1A,
9V/2A, 12V/1.5A
1x 20V/3A - PD
60W
1x 12.6V/10A
2x 13V/4A
*Up to 200W panels. Do NOT exceed 24V
or damage may occur
General
Device Runtime | AC vs. DC Power
In general, it is normal for power losses to occur when
energy is transferred from the baery to the ports that
power your devices.
The AC port requires an inverter, which transforms power
from DC to AC. This process creates heat and consumes
about 15% of the power it transforms. DC ports are more
ecient and only consume 5% of the power that is
transformed.
Your device will always last longer when plugged into DC
ports if that option is available. For example, a CPAP
machine will last almost an extra night when using a DC
CPAP converter compared to the standard AC plug.
Heat is the Enemy
If the Arc3, or any power station, is le in the heat it will
impact its health, capacity and longevity. Keep out of hot
cars and direct sunlight on warm days. Heat is the #1
reason baeries degrade prematurely.
Determine The Power Consumption of Your Device
Device with no baery: locate Was (W) on the product.
If Was are not available: multiply the Voltage (V) x Amps
(A) to arrive at Was. Eg. 120V x 0.6A = 72W
Device with a baery: locate Wa Hours (Wh).
Or multiply the Voltage (V) x Amp Hours (Ah) to arrive at
Wa Hours (Wh). Eg. 12V x 1.0Ah = 12Wh (Note: 1.0Ah =
1000mAh)
Calculate Working Time or Recharges for your Device
AC Outlets Working Capacity
300Wh x 0.85 (15% inverter conversion loss) = 255Wh
working capacity. For example, assume your fan consumes
72W. To calculate working time: 255Wh ÷ 72w = 3.5 hrs
DC and USB Outlets Working Capacity
300Wh x 0.95 (5% DC conversion loss) = 285Wh working
capacity. For example, assume your smartphone has a
12.3Wh capacity baery. To calculate the number of
recharges before capacity is depleted, use the formula:
285Wh ÷ 12.3Wh = 22 recharges.
Regulated 12V vs Non-Regulated 12V
Non-regulated 12V ports are linked to the charge
percentage of the baery. For example, when a power
station is at 100% charge the DC voltage will operate at
approximately 12V, which is acceptable for 12V devices. But
as the baery charge drops to 50% the DC voltage will drop
to approximately 10.8V. 12V devices such as
mini-fridges/coolers, CPAP machines, vacuums, radios etc.,
will simply stop running when the voltage drops below ~11V.
The Arc3 does not have regulated ports but it’s 12V ports
are optimized to output up to 14 Volts on a full charge and
a minimum of 12 Volts when the baery is almost depleted.
This ensures devices, such as electric coolers, keep running
no maer how much charge is remaining.
For more information please visit www.energizerarc.com
Battery
Output
Input
Wall (AC) Charger
Wall Charge Time
12V Car Charge Time
Solar Connector
Solar Voltage
Recommended
Solar Panels
Solar MPPT Controller
Solar Charge Time
19V/3.5A 60W
5 hrs (AC)
5 hrs (DC)
MC4
12-24V*
60-200W
Yes
5-8 hrs**
9.1 lbs / 4.2kg
7.4” x 6.5“ x 7.9”
-10°C to 40°C
0°C to 40°C
2 Years
ETL, CE, ROHS, FCC
Weight
Dimensions
Operating Temp.
Recharging Temp.
Warranty
Certifications
Email us at [e-mail] more information please visit www.energizerarc.com Call us Toll Free 1.877.528.3772 UG_EN_AR3_2020-12-17
**Solar charge time will vary based on many factors and conditions
such as the weather, time of day, location, solar panel eciency etc.
3
