Energy pI0 Panoramic User manual

ENERGY
Photo Frame
p10 Panoramic
DIGITAL PHOTO FRAME
Manual de usuario / User manual
Manuel de l’utilisateur / Manual do Utilizador

23
ESPAÑOL
User manual

25
ENGLISH
INTRODUCTION
≥Energy Sistem®thanks you for buying your new digital photo frame Energy™
Photo Frame p10. We wish you enjoy using it.
This digital photo frame is a perfect gift to remember the most special moments,
it offers exceptional picture quality with the 10.1” LED High Definition screen.
Furthermore, it also offers functions such as calendar, clock, card reader and USB
Host.
We recommend that you fully read this user manual in order to enjoy the product in
a safe way and with the best results.
CARE AND MAINTENANCE
≥Do not expose your Energy™ Photo Frame to collisions, violent shakes, dust, direct
sun light, moisture or extreme temperatures.
≥Do not use abrasive or corrosive cleansers.
≥Keep the device clean and dust free with a soft and dry cloth. We recommend you
to use the provided cleaning cloth.
≥Clean the unit while it is turned off and unplugged from electric power.
≥Do not disassemble the device. Any repairs must be performed by the qualified
Energy Sistem Soyntec´s personnel.

26
MAIN FEATURES
≥10,1” TFT LED backlight 16:9 screen.
≥1024x600 pixels resolution, 250cd / m2, 500:1.
≥Compatible with the JPEG/JPG/BMP pictures of the majority of the digital cameras
with maximum resolution 8000 x 8000 pixels.
≥Compatible with memory cards: MMC / MS / SD / SDHC (up to 32GB).
≥USB Host connector to load pictures from your USB flash drive (up to 32GB).
≥Selection of pictures by miniatures on screen and starting Slide Show from the
selected picture.
≥Slide Show with Magic Window mode (4 windows).
≥Several time intervals for the Slide Show (5/15/30 sec., 1/5/15 min.).
≥Different transition effects for the Slide Show (6 effects including random mode).
≥Calendar and clock functions with photo Slide Show at the same time.
≥Automatic image fit (3 modes: Auto-Fit, Optimal and Full).
≥Brightness, contrast, color and tone adjustments.
≥Allows 90º, 180º and 270º picture rotation.
≥5 levels of zoom available.

27
ENGLISH
≥File browser function.
≥Slim remote control.
≥AC/DC power adapter (Europlug). Input 100-240V; Output 5V/1.5A; 50/60Hz.
≥Includes mounting holes on the back to be fixed to the wall.
PRODUCT CONTENT
≥Energy Sistem® Digital Frame Energy™ Photo Frame p10 Panoramic.
≥Stand.
≥User manual.
≥Screen cleaning cloth.
≥Slim remote control.
≥AC/DC power adapter (Europlug).

28
GENERAL OVERVIEW
MENU
8
1
2
4
7
5
6
3
9
10
11

29
ENGLISH
1. ON/OFF: Turn on-off the digital photo frame.
2. UP: Go up one position in the current menu / move the current view up when applying
zoom to an image.
3. NEXT: Show next image / move the current view to the right when applying zoom to an
image / add value in the setting options menu.
4. PLAY / PAUSE: Show the selected image in full screen / execute the option currently
selected in the menu / start or pause the slide show / enter the current folder.
5. PREVIOUS: Show previous image / move the current view to the left when applying
zoom to an image / reduce value in the setting options menu.
6. DOWN: Go down one position in the current menu / move the current view down when
applying zoom to an image.
7. MENU / EXIT: Return to the previous screen (menu) / copy file to built-in memory (from
Thumbnail Mode only) / delete file (from Thumbnail Mode only).
8. Mounting hole on the back to be fixed to the wall.
9. SDHC/SD/MS/MMC memory card slot.
10.USB HOST: USB input to load pictures from USB memory device.
11. AC/DC power adapter.

30
REMOTE CONTROL
MENU
ROTATE
EXIT
ZOOM
12
4
5
8
11
10
3
6
9
7
SLIDE
SHOW
1. ON/OFF: Turn on/off the digital photo frame.
2. MENU: Copy file to built-in memory (from Thumbnail Mode only) / delete file (from
Thumbnail Mode only).
3. ROTATE: Rotate the current image 90º, 180º ó 270º.
4. UP: Go up one position in the current menu / move the current view up when
applying zoom to an image.
5. ZOOM: Perform a zoom to the current image (up to 5 zoom levels are available).
6. PREVIOUS: Show previous image / move the current view up when applying zoom
to an image / reduce value in the setting options.

31
ENGLISH
7. PLAY/PAUSE: Show the selected image in full screen / execute the option
currently selected in the menu / start or pause the slide show / enter the current
folder.
8. NEXT: Show next image / move the current view to the right when applying zoom to
an image / add value in the setting options.
9. SLIDESHOW: Start slide show mode.
10. DOWN: Go down one position in the current menu / move the current view down
when applying zoom to an image.
11. EXIT: Return to the previous screen (menu).
MAIN MENU
PHOTO.
FILE EXPLORER.
CALENDAR.
SETTINGS.

32
POWER SOURCE
Your Energy™ Photo Frame p10 is powered through the AC/DC 5V adapter provided
with the product. Please firstly connect the photo frame with the power adapter then
connect the power adapter with electrical outlet.
The remote control is powered by a CR2025 3V lithium battery that you can easily
replace when depleted by releasing the battery compartment in the back of the
remote control.
IMPORTANT: In case you will not use the digital frame for a few days, we recommend
unplugging the power electricity adapter from the socket.
SWITCHING ON / OFF
To power on your Energy™ Photo Frame p10 just plug in the provided power adapter to
a 100-240V AC source and press the ON/OFF button located on the back side of the
frame or press the ON/OFF button from remote control.
To turn off your photo frame, simply press the ON/OFF button on the back side of the
frame or press the ON/OFF button from remote control.
IMAGE DISPLAY (PHOTO)
You can use 3 display modes: “Thumbnail”, “Slideshow” and “Single”.
THUMBNAIL
This is the display mode by default, the digital photo frame shows the miniatures
of pictures loaded from the memory device currently connected to the frame
