Energy Connoisseur ESW-C8 User manual

ESW-C8
SPECIFICATIONS ESWC8
Speaker System Bass reex with down-ring port
Woofer 8-inch (20 cm) Injection molded cone with
Ribbed Elliptical Surround
Amplier Power 240 Watts dynamic, 60 Watts continuous
Frequency Response 36Hz-180Hz
Max SPL 97dB @ 30Hz, ground plane, 1m
Variable Low Pass Filter 40Hz-150Hz
Phase Control 0°, 180°
Inputs L + R Line in/Sub in, speaker level in
Power Modes O / Auto / On
Units/Carton 1
Dimensions H x W x D
(Inches/cm) including feet
and grille
12.7 x 10.5 x 12.3 inches
32.2 x 40 x 31.2 cm
Product Weight 16 lbs (7.3 kg)
Finish Black ash cabinet with high gloss black bae trim
All specifications are subject to change without notice.©2008
www.energy-speakers.com
240 Watts peak power
For accurate reproduction of movie and music soundtracks
8-inch injected molded cone with Ribbed Elliptical Surround
Provides tight and powerful bass response
Variable Low Pass Filter—40Hz-150Hz
Allows versatile blending using the built-in crossover or your surround
processor
Bass-reex design with down ring port
Provides excellent bass extension, deep-reaching bass
All Energy brand components were developed with these sonic
principles in mind:
• Flat On-Axis Frequency Response with Wide Bandwidth
Speakers should reproduce the entire audio range in a uniform
manner. By ensuring that no one frequency dominates any other,
Energy ensures that every note is the way it was intended to be—and
the sound is as natural as possible.
• Wide and Constant Dispersion
Sound at all frequencies radiating from the speaker should be in an
even pattern, in all directions throughout the room.
• Low Distortion and Resonance
No speaker system is totally distortion- or resonance-free, but Energy
has achieved a signicantly lower distortion level—a clearly audible
improvement.
