Energy Connoisseur ESW-M8 User manual

ESW-M8
SPECIFICATIONS ESWM8
Speaker System Single active, dual passive
Woofer 8-inch (20 cm) Black anodized aluminum cone
with inverted Ribbed Elliptical Surround
Passive Radiators 2 x 8-inch (20 cm) Black anodized aluminum
cones with inverted Ribbed Elliptical Surround
Amplier Power 1200 Watts
Frequency Response 36Hz-200Hz
Max SPL 102.6dB @ 30Hz, ground plane, 1m
Variable Low Pass Filter 50Hz-200Hz, bypass
Phase Control 0° - 360°
Inputs L + R Line in/Sub in
Power Modes O / Auto / On
Units/Carton 1
Dimensions H x W x D
(Inches/cm) including feet
and grille
9 x 9 x 9 inches
22.7 x 22.7 x 22.7 cm
Finish High gloss black
Weight 16.7 lbs. / 7.6 kg
All specifications are subject to change without notice.©2008
www.energy-speakers.com
Remarkably small, powerful subwoofer
Small (9-inch) cube sub ts anywhere
1200 Watts power
For accurate reproduction of movie and music soundtracks and eects
8-inch anodized aluminum cone woofer with Ribbed Elliptical Surround
Provides tight and powerful bass response
Two 8-inch anodized aluminum cone passive radiators
Eliminate port noise; allow deep bass extension
Variable Low Pass Filter—50Hz-200Hz
Allows versatile blending using the built-in crossover or your surround
processor
Furniture grade high gloss black cabinets
Hand-nished to ensure durability
All Energy brand components were developed with these sonic
principles in mind:
• Flat On-Axis Frequency Response with Wide Bandwidth
Speakers should reproduce the entire audio range in a uniform
manner. By ensuring that no one frequency dominates any other,
Energy ensures that every note is the way it was intended to be—and
the sound is as natural as possible.
• Wide and Constant Dispersion
Sound at all frequencies radiating from the speaker should be in an
even pattern, in all directions throughout the room.
• Low Distortion and Resonance
No speaker system is totally distortion- or resonance-free, but Energy
has achieved a signicantly lower distortion level—a clearly audible
improvement.
