G15 Engine
Safety, Operation, Maintenance
& Parts Manual
LT15 rev. D2.00 - E8.13
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
April 2010
Form #940
©2019
Printed in the United States of America, all rights reserved. No part of this manual may be
reproduced in any form by any photographic, electronic, mechanical or other means or used in
any information storage and retrieval system without written permission from
Wood-Mizer
8180 West 10th Street
Indianapolis, Indiana 46214
&DOLIRUQLD
3URSRVLWLRQ:DUQLQJ
:$51,1*%UHDWKLQJJDVGLHVHOHQJLQHH[KDXVWH[SRVHV\RXWRFKHPLFDOVNQRZQWR
WKH6WDWHRI&DOLIRUQLDWRFDXVHFDQFHUDQGELUWKGHIHFWVRURWKHUUHSURGXFWLYHKDUP
$OZD\VVWDUWDQGRSHUDWHWKHHQJLQHLQDZHOOYHQWLODWHGDUHD
,ILQDQHQFORVHGDUHDYHQWWKHH[KDXVWWRWKHRXWVLGH
'RQRWPRGLI\RUWDPSHUZLWKWKHH[KDXVWV\VWHP
'RQRWLGOHWKHHQJLQHH[FHSWDVQHFHVVDU\
)RUPRUHLQIRUPDWLRQJRWRZZZ3ZDUQLQJVFDJRY
:$51,1*'ULOOLQJVDZLQJVDQGLQJRUPDFKLQLQJZRRGSURGXFWVFDQH[SRVH\RXWR
ZRRGGXVWDVXEVWDQFHNQRZQWRWKH6WDWHRI&DOLIRUQLDWRFDXVHFDQFHU$YRLGLQKDOLQJ
ZRRGGXVWRUXVHDGXVWPDVNRURWKHUVDIHJXDUGVIRUSHUVRQDOSURWHFWLRQ
)RUPRUHLQIRUPDWLRQJRWRZZZ3:DUQLQJVFDJRYZRRG
Table of Contents Section-Page
Table of Contents WMdoc091819 iii
TOC
SECTION 1 ABOUT THIS MANUAL 1-1
SECTION 2 OPERATION 2-1
2.1 Starting The Engine................................................................................2-1
SECTION 3 MAINTENANCE 3-1
3.1 Safety......................................................................................................3-1
3.2 Cooling System ......................................................................................3-2
3.3 Air Filter & Pre-Cleaner.........................................................................3-2
3.4 Fuel Filter ...............................................................................................3-2
3.5 Battery ....................................................................................................3-2
3.6 RPM Adjustments ..................................................................................3-3
3.7 Miscellaneous Maintenance ...................................................................3-4
SECTION 4 REPLACEMENT PARTS 4-1
4.1 Engine Assembly....................................................................................4-1
LT15 Rev. E1.00+
4.2 Engine Assembly....................................................................................4-3
LT15 Rev. D4.00 - D7.00
4.3 Engine Assembly....................................................................................4-5
LT15 Rev. D2.00 - D3.00
4.4 Throttle/Clutch Assembly ......................................................................4-7
LT15 G13/G15 Rev. E1.00+
4.5 Throttle/Clutch Assembly ......................................................................4-9
LT15 Rev. D4.00 - D7.00
4.6 Throttle/Clutch Assembly ....................................................................4-11
LT15 Rev. D3.00
4.7 Throttle/Clutch Assembly ....................................................................4-13
LT15 Rev. A1.00 - D2.00
INDEX I
About This Manual
1
1-1 WM doc 9/18/19 About This Manual
SECTION 1 ABOUT THIS MANUAL
This manual is provided as a supplement to the equipment manufacturer’s manuals. This
manual provides information specific to the use of this equipment on the Wood-Mizer®
sawmill. Refer to the sawmill operator’s manual and manufacturer's manual before
attempting to operate this equipment.
IMPORTANT! Read the sawmill operator’s manual and engine manu-
facturer’s manual for instructions and safety precautions before oper-
ating this equipment.
The information and instructions given in this manual do not amend or extend the limited
warranties for the equipment given at the time of purchase.
Operation
Starting The Engine
Operation WM doc 9/18/19 2-1
2
SECTION 2 OPERATION
2.1 Starting The Engine
DANGER! Ensure the blade is disengaged and all persons are out of
the path of the blade before starting. Failure to do so will result in death
or serious injury.
DANGER! Operate your engine only in well ventilated areas. The
exhaust gases of your engine can cause nausea, delirium, and
potentially death unless adequate ventilation is present.
DANGER! Never operate an engine with a fuel or oil leak. This is a
fire hazard, which may cause serious injury or death.
WARNING! Do not operate engine without proper and operational
spark arrester/muffler. Sparks emitted from the engine exhaust
could ignite surrounding materials, causing serious injury or death.
CAUTION! EPA Compliant Gas Tanks Only: Always relieve all fuel
pressure inside the tank prior to filling or connecting fuel fittings.
Failure to do so may result in fuel spillage.
CAUTION! EPA Compliant Gas Tanks Only: Disconnect the fuel tank
when not in use, or engine flooding or fuel spillage may result.
1. Close the engine choke by moving the choke lever to the start position.
2. Turn the key switch to the START position and release. Release the key switch to the
RUN position after the engine starts.
3. When the engine starts, slowly open the choke all the way by moving the choke lever to
the off position.
ENGINE SHUTOFF
1. Disengage the clutch handle to stop the blade if necessary.
2. Let the engine run for 15 seconds with no load, then turn the key switch to the OFF posi-
tion.
Maintenance
Safety
3
3-1 WM doc 9/18/19 Maintenance
SECTION 3 MAINTENANCE
Refer to the manufacturer’s manual for maintenance intervals and procedures unless oth-
erwise instructed in this manual. Follow the manufacturer’s recommendations for dusty
conditions.
IMPORTANT! This manual only provides information about additional
procedures or procedures to be performed at different time intervals
than found in the manufacturer's manuals. Refer to the manufacturer's
manual for complete maintenance instructions.
WARNING! Clean sawdust from all guards, vents, control
boxes, or any area where sawdust may gather after every
shift. Failure to do so may result in fire, causing death or
serious injury.
3.1 Safety
Use caution when performing maintenance or service to the engine.
DANGER! Always be aware of and take proper protective measures
against rotating shafts, pulleys, fans, etc. Always stay a safe distance
from rotating members and make sure that loose clothing or long hair
does not engage rotating members resulting in possible injury.
DANGER! Engine components can become very hot during operation.
Avoid contact with any part of a hot engine. The exhaust components
of your engine are especially hot during and following operation. Con-
tact with hot engine components can cause serious burns. Therefore,
never touch or perform service functions on a hot engine. Allow the
engine to cool sufficiently before beginning any service function.
WARNING! Remove the blade before performing any engine service.
Failure to do so may result in serious injury.
WARNING! Always wear proper and necessary safety equipment
when performing service functions. Proper safety equipment includes
eye protection, breathing protection, hand protection and foot protec-
tion.
This symbol identifies the interval (hours of operation) at which each maintenance pro-
cedure should be performed. "AR" signifies maintenance procedures which should be
performed as required.
0
Maintenance
Cooling System
Maintenance WM doc 9/18/19 3-2
3
3.2 Cooling System
Wash the engine or brush off sawdust and debris every 50 hours of operation. Clean the
grass screen, cooling fins, and external surfaces. Remove any dust, dirt or oil. See
engine manual for further instructions.
3.3 Air Filter & Pre-Cleaner
WARNING! Always wear proper and necessary safety equipment
when performing service functions. Proper safety equipment includes
eye protection, breathing protection, hand protection and foot protec-
tion.
Service the pre-cleaner every four hours of operation. Service by gently shaking excess
sawdust and debris from the foam piece.
Clean the air filter (air cleaner element) and pre-cleaner (element wrapper) every eight
hours of operation. See the engine manual for further instructions.
Replace the air filter (cleaner) every 200 hours of operation.
Replace the pre-cleaner (element wrapper) every 2000 hours of operation.
3.4 Fuel Filter
Replace the fuel filter every 100 hours of operation or as required for engine perfor-
mance.
3.5 Battery
Check the battery electrolyte level every 50 hours of operation. See manufacturer’s man-
ual for instructions.
DANGER! Batteries expel explosive gases. Keep sparks, flames,
burning cigarettes, or other ignition sources away at all times. Always
50
4
8
200
2000
100
50
Maintenance
RPM Adjustments
3
3-3 WM doc 9/18/19 Maintenance
wear safety goggles and a face shield when working near batteries.
Failure to do so will cause serious injury.1
WARNING! Battery posts, terminals and related accessories contain
lead and lead compounds, chemicals known to the State of California
to cause cancer and reproductive harm. Wash hands after handling.
3.6 RPM Adjustments
WARNING! Remove the blade before performing any engine service.
Failure to do so may result in serious injury.
Check the RPM with a tachometer every 200 hours of operation.
See Table 3-1.
Before checking the RPM, make sure belt and brake strap tensions are correct (See Saw-
mill Maintenance). Also check oil, fuel, and coolant levels.
Make sure the throttle cable does not affect the engine RPM when the clutch handle is
disengaged. Make sure the cable is not bent or kinked.
1. Start the engine to measure the low-end RPM.
2. Refer to the engine manual to adjust the low-end RPM.
3. Engage the clutch handle to throttle the engine and measure the high-end RPM. The
high-end RPM is factory-set at 3750. Readjust the throttle cable if necessary to increase
or reduce the high-end engine speed.
1. Battery Council International, copyright 1987
Engine High End RPM Low End RPM
G15 3750 1800
TABLE 3-1
200
Maintenance
Miscellaneous Maintenance
Maintenance WM doc 9/18/19 3-4
3
3.7 Miscellaneous Maintenance
Inspect the spark plugs every 100 hours of operation. Remove any deposits and adjust
gap if necessary. See engine manual for further information.
Review the manufacturer's engine manual for maintenance intervals.
100
Replacement Parts
Engine Assembly
4
4-1 G1597doc091819 Replacement Parts
G15
SECTION 4 REPLACEMENT PARTS
4.1 Engine Assembly
LT15 Rev. E1.00+
REF DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY.
Cover, Engine P12393 1
ENGINE ASSEMBLY, 15 HP KOHLER W/CLUTCH & ELECTRIC START 034804 1 1
1Engine, 15 HP Kohler #PH44528 033377 1
2Filter, Kohler Air #47-083-01 014718 1
1
23
4
5
7
6
8
9
10
11
12
13
14
15
16
17
18
19
150146B
Replacement Parts
Engine Assembly
Replacement Parts G1597doc091819 4-2
4
G15
3Pre-Cleaner, Kohler Air #52-083-01 014719 1
4Filter, Kohler Oil #52-050-02 014717 1
Muffler Assembly, G13/G15 Kohler w/Arrestor 061128 1
5Muffler Kit, G15 Kohler #12-786-16-S 061108 1
6Gasket, Kohler Muffler N/A 1
7Arrestor, Kohler Spark 036684 1
8Cage, Muffler Kohler #12-314-32-S 061109 2 1
Plug, Kohler Spark #12-132-02 (Champion #RC12YC) P12757 1
Filter, Kohler In-Line Fuel #25-050-02 014720 1
Switch, Kohler PHI Oil #25-099-24-S 051992 1
Solenoid, Kohler Starter #25-435-02-S 038425 1
Bypass Kit, Kohler Oil PSI #82-755-25-S 038426 1
Throttle and Clutch Parts (See Section 4.4)
9Hose, Oil Drain P10082 1
10 Cap, Oil Drain Hose P04332 1
11 Plate, LT15 Engine Guard 016493 1
12 Sheave, BK55QT 016512 1
13 Key, 1/4” X 1 11/16” S04124 3 1
14 Bushing, QT x 1 016513 1
Harness Assembly, Battery To Engine 024718 1
15 BELT, BX87 DRIVE 017943 1
16 WASHER, 3/8” SAE FLAT F05011-3 4
17 WASHER, 3/8” SPLIT LOCK F05011-4 4
18 BOLT, 3/8-16 X 2 HEX HEAD GR5 F05007-124 4
19 Spacer, 17/32 x 1 1/2 x 3/4 034641 4
1 G15 engine option no longer available (3/11). Use conversion kit 065379 for service on LT15 Rev. E4.00 and later. Kit includes G18
Kohler engine, drive wheel, drive belt, tray, reduction kit and belt tensioner gauge. NOTE: Conversion kit will not work on LT15 prior
to Rev. E4.00.
2 016105 Square Muffler Cage no longer available (5/16). NOTE: Muffler Cage 061109 is a round cage and can be used only for new
engines equipped with the round muffler.
3 Replaces S21486 1/4” x 1” key. S04124 always used in production.
Replacement Parts
Engine Assembly
4
4-3 G1597doc091819 Replacement Parts
G15
4.2 Engine Assembly
LT15 Rev. D4.00 - D7.00
REF DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY.
Cover, Engine P12393 1
ENGINE ASSY, 15 HP KOHLER W/CLUTCH & ELECTRIC START 016504 1 1
1Engine, 15 HP Kohler #PH44528 033377 1
2Filter, Kohler Air #47-083-01 014718 1
3Pre-Cleaner, Kohler Air #52-083-01 014719 1
4Filter, Kohler Oil #52-050-02 014717 1
5Muffler Kit, G15 Kohler #12-786-16-S 061108 1
1
23
4
5
7
6
8
9
10
11
12
13
14
15
16
17
18
150147B
Replacement Parts
Engine Assembly
Replacement Parts G1597doc091819 4-4
4
G15
6Gasket, Kohler Muffler N/A 1
7Arrestor, Kohler Spark (Required w/Muffler) 036684 1
8Cage, Muffler Kohler #12-314-32-S (Required w/Muffler #061108) 061109 2 1
Plug, Kohler Spark #12-132-02 (Champion #RC12YC) P12757 1
Filter, Kohler In-Line Fuel #25-050-02 014720 1
Switch, Kohler PHI Oil #25-099-24-S 051992 1
Solenoid, Kohler Starter #25-435-02-S 038425 1
Bypass Kit, Kohler Oil PSI #82-755-25-S 038426 1
Throttle and Clutch Parts (See Section 4.4)
9Hose, Oil Drain P10082 1
10 Cap, Oil Drain Hose P04332 1
11 Plate, LT15 Engine Guard 016493 1
12 Sheave, BK55QT 016512 1
13 Key, 1/4” x 1 11/16” S04124 1
14 Bushing, QT x 1 016513 1
Harness Assembly, Battery To Engine 024718 1
15 BELT, BX82 DRIVE 016505 1
16 Plate, LT15 Motor MOunt 016473 1
17 WASHER, 3/8” SAE FLAT F05011-3 4
18 WASHER, 3/8” SPLIT LOCK F05011-4 4
19 BOLT, 3/8-16 X 1” HEX HEAD F05007-7 4
1 G15 engine option no longer available (3/11). Use conversion kit 065379 for service on LT15 Rev. E4.00 and later. Kit includes G18
Kohler engine, drive wheel, drive belt, tray, reduction kit and belt tensioner gauge. NOTE: Conversion kit will not work on LT15 prior
to Rev. E4.00.
2 016105 Square Muffler Cage no longer available (5/16). NOTE: Muffler Cage 061109 is a round cage and can be used only for new
engines equipped with the round muffler.
Replacement Parts
Engine Assembly
4
4-5 G1597doc091819 Replacement Parts
G15
4.3 Engine Assembly
LT15 Rev. D2.00 - D3.00
REF DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY.
Cover, Engine P12393 1
ENGINE ASSY, 15 HP KOHLER W/CLUTCH & ELECTRIC START 016416 1
1Engine, 15 HP Kohler #PH44528 033377 1
2Filter, Kohler Air #47-083-01 014718 1
3Pre-Cleaner, Kohler Air #52-083-01 014719 1
1
2
3
4
5
8
7
6
9
9
12
13
14
15
16
17
18
10
11
19
150077D
Replacement Parts
Engine Assembly
Replacement Parts G1597doc091819 4-6
4
G15
4Filter, Kohler Oil #52-050-02 014717 1
5Muffler Kit, G15 Kohler #12-786-16-S 061108 1
6Gasket, Kohler Muffler N/A 1
7Arrestor, Kohler Spark (Required w/Muffler) 036684 1
8Cage, Muffler Kohler #12-314-32-S (Required w/Muffler #061108) 061109 1 1
Plug, Kohler Spark #12-132-02 (Champion #RC12YC) P12757 1
Filter, Kohler In-Line Fuel #25-050-02 014720 1
Switch, Kohler PHI Oil #25-099-24-S 051992 1
Solenoid, Kohler Starter #25-435-02-S 038425 1
Bypass Kit, Kohler Oil PSI #82-755-25-S 038426 1
9Throttle and Clutch Parts (See Section 4.4)
10 Hose, Oil Drain P10082 1
11 Cap, Oil Drain Hose P04332 1
12 Plate, G13/G15 Engine Mount 014810 1
13 Washer, 3/8” SAE Flat F05011-3 4
14 Washer, 3/8” Split Lock F05011-4 6
15 Bolt, 3/8-16 x 1” Hex Head F05007-7 4
Harness Assembly, Battery To Engine 024718 1
16 BOLT, 3/8-16 X 1 1/4” SPRING WASHER LOCK HEX HEAD F05007-131 4
17 ROD, BELT TENSION ADJUSTMENT 014975 1
18 NUT, 3/8-16 HEX F05010-1 2
19 BELT, BX81 014819 1
1 016105 Square Muffler Cage no longer available (5/16). NOTE: Muffler Cage 061109 is a round cage and can be used only for new
engines equipped with the round muffler.
Replacement Parts
Throttle/Clutch Assembly
4
4-7 G1597doc091819 Replacement Parts
G15
4.4 Throttle/Clutch Assembly
LT15 G13/G15 Rev. E1.00+
REF DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY.
1 PLATE, THROTTLE CABLE BRACKET LT15G 034616 1
2 SCREW, 1/4-20 X 3/4 FT HEX HEAD F05005-1 1
3 NUT, 1/4-20 NYLON LOCK F05010-69 1
4 SPRING, EXTENSION 3/8 X 3 014818 1
5 PIVOT WELDMENT, THROTTLE LT15G 034805 1
6 BOLT, 1/4-20 X 2 HEX HEAD GR5 F05005-125 1
7 NUT, 1/4-20 SWAGED F05010-21 2
8 LINK, THROTTLE 2 13/16 015446 1
9 CABLE ASSEMBLY, LT15G15 THROTTLE 034838 1
10 KNOB, 5/8-11 BALL P04211 1
11 HANDLE, LT15 CLUTCH 016487 1
12 SCREW, 3/8-16 X 1/2 SOCKET HEAD CUP PT SET F05007-12 2
13 ACTUATOR WELDMENT, THROTTLE LT15D&G 034815 1
14 LINKAGE, THROTTLE LT15D&G 034818 1
150098F
1
2
3
4
5
6
7
78
9
10
11
13
12
12
14
15
16
17
17
18 19
20
22
24
23
25
26
26
27
28
29
30 31
32
33 34
39
38
35
35
37
36
36
Replacement Parts
Throttle/Clutch Assembly
Replacement Parts G1597doc091819 4-8
4
G15
15 BOLT, 1/4-20 X 1/2” HEX HEAD F05005-15 1
16 NUT, 1/4-20 SWAGED F05010-21 1
17 BUSHING, 5/8” ID X 7/8” OD X 1 1/8” LONG FLANGED BRONZE 016486 2
18 BLOCK WELDMENT, LINKAGE CLUTCH/BRAKE 034612 1
19 PIN, 3/16 X 1 1/4 ROLL F05012-16 1
20 LINKAGE ASSEMBLY, W/BEARING 034605 1
21 Bushing, 5/8” ID x 7/8” OD x 1 1/8” Long Flanged Bronze 016486 1
22 NUT, 1/2-13 FREE HEX, ZINC F05010-35 1
23 WASHER, 1/2 SPLIT LOCK F05011-9 1
24 NUT, 1/2-13 JAM F05010-31 1
25 PIVOT WELDMENT, CLUTCH/BRAKE 034608 1
26 BUSHING, 1 X 1 1/4 X 3/4 FLG BRONZE P737 2
BRAKE/CLUTCH ASSEMBLY, LT15 034603 1
27 Arm Weldment, Clutch/Brake LT15 034613 1
28 Bolt, 3/8-16 x 2 Hex Head Gr5 F05007-124 1
29 Nut, 3/8-16 Hex Nylon Lock F05010-10 1
30 Block, LT15 Brake 016488 2
31 Screw, 10-24 x 1” Socket Head F05004-2 1 4
32 Nut, #10-24 Keps F05010-14 4
33 Idler, 4" O.D. x 3/8 Bore 034602 1
34 Bolt, 3/8-16 x 2-3/4” Hex Head Gr5 Full Thread F05007-230 1
35 Washer, 3/8 Flat F05011-3 2
36 Nut, 3/8-16 Swaged Lock F05010-25 2
37 Spring, Idler Arm LT15/D/E/G 034810 1
1 Replaces F05004-50 originally supplied before 4/03 (duplicate part numbers).
Replacement Parts
Throttle/Clutch Assembly
4
4-9 G1597doc091819 Replacement Parts
G15
4.5 Throttle/Clutch Assembly
LT15 Rev. D4.00 - D7.00
REF DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY.
1 PLATE, BRAKE ACTUATOR 016470 1
2 BOLT, 5/16-24 X 1” HEX HEAD F05006-11 2
3 WASHER, 5/16” SPLIT LOCK F05011-13 2
4 NUT, 1/4-20 SWAGED F05010-21 2
5 WASHER, 1/4” SAE FLAT F05011-11 6
6 PIVOT WELDMENT, THROTTLE LT15 016503 1
7 SPRING, 3/8” X 3“ EXTENSION 014818 1
8 WIRE, THROTTLE LT15 014826 1
9 BOLT, 1/4-20 X 2” HEX HEAD GRADE 5 F05005-125 1
10 SCREW, 1/4-20 X 1 3/4” HEX HEAD CAP F05005-4 1
11 NUT, 1/4-20 KEPS F05010-9 2
12 KNOB, 5/8-18 PLASTIC ROUND P04211 1
4
4
355
5
5
45
5
6
7
8
2
1
15
16
16 15
10
11
13
14
16
16
22
21
20
18
17
42
43
46
44
11 11
41
40
39
150080B
36
38 37
35
24
25
28
23
30
31
32
33
34
26
29 27
20
19 12
11
9
29
Replacement Parts
Throttle/Clutch Assembly
Replacement Parts G1597doc091819 4-10
4
G15
13 HANDLE, LT15 CLUTCH 016487 1 1
14 PIN, 3/16 X 1 1/4” ROLL F05012-16 1
15 BUSHING, 5/8” ID X 7/8” OD X 1 1/4” LONG FLANGED BRONZE 016486 2
16 BUSHING, 3/4” ID X 1” OD X 1 1/8” LONG FLANGED BRONZE 016485 4
17 PIN WELDMENT, MOTOR PIVOT 016477 1
18 NUT, 3/8-16 SWAGED LOCK F05010-25 1
19 BOLT, 3/8-16 X 3/4” HEX HEAD GRADE 2 F05007-27 1
20 SCREW, 7/16-20 X 1 1/2” SOCKET HEAD CAP F05007-55 2
21 WASHER, 7/16” SAE FLAT 15/16” OD F05011-43 1
22 BLOCK, MOTOR HANDLE PIVOT 016481 1
TURNBUCKLE ASSEMBLY, CLUTCH A12304 1
23 Nut, 7/16-20 Jam F05010-38 1
24 Rod End, 7/16-20 Right Hand Male P11579 1
25 Turnbuckle, 3" Clutch S11577 1
26 Nut, 7/16-20 Left Hand Jam F05010-87 1
27 Rod End, 7/16-20 Left Hand Male P11578 1
28 NUT, 7/16-20 JAM F05010-38 1
29 WASHER, 7/16” SPLIT LOCK F05011-48 3
30 NUT, 3/8-16 HEX NYLON LOCK F05010-10 2
31 WASHER, 3/8” FLAT SAE F05011-3 6
32 PLATE, LOWER TURNBUCKLE MOUNT 016472 1
33 NUT, 7/16-20 NYLON LOCK F05010-83 1
34 BOLT, 3/8-16 X 4 1/2” HEX HEAD F05007-35 2
35 SCREW, 10-24 X 1 1/2” SOCKET HEAD CAP BLACK OXIDE F05004-51 4
36 BLOCK, LT15 BRAKE 016488 2
37 NUT, #10-24 KEPS F05010-14 4
38 PIN, IDLER PIVOT 040102 1
39 PIN, 1/4” DIA LYNCH P113 1
40 SCREW, 1/4-20 X 1” HEX HEAD CAP F05005-38 1
41 SPRING, 3/8” OD X 4 1/2” LONG X .047” WIRE EXTENSION 016508 1
42 NUT, 1/2-13 JAM F05010-31 1
43 BOLT, 1/2-13 X 2” HEX HEAD GRADE 5 F05008-8 2 1
44 PLATE WELDMENT, BRAKE 016482 1
45 SPRING, EXTENSION 1/2” X 2 1/4” X .06” 014817 1
46 PLATE, LT15 MOTOR MOUNT 016473 1
1 Clutch Handle 016487 modified 3/07 to eliminate possible pinch point with feed rope pulley with saw head at certain heights.
2 Replaces F05008-33 1/2-13 x 1 1/2” Hex Head Bolt supplied prior to 10/00. Longer bolt provides more brake adjustment.
Replacement Parts
Throttle/Clutch Assembly
4
4-11 G1597doc091819 Replacement Parts
G15
4.6 Throttle/Clutch Assembly
LT15 Rev. D3.00
REF DESCRIPTION ( Indicates Parts Available In Assemblies Only) PART # QTY.
1 HANDLE, THROTTLE/CLUTCH 014825 1
2 GRIP, 1/2” I.D. X 3” LONG HANDLE 014835 1
3 COLLAR, 1/2” I.D. X 7/8” O.D. LOCK 014820 1
4 BUSHING, SF1260-6 BRONZE P08060 2
5 BRACKET, THROTTLE/CLUTCH HANDLE MOUNT 014821 1
6 BRACKET, THROTTLE/CLUTCH HANDLE PIVOT 014837 1
7 PIN, 3/16” X 5/8” ROLL F05012-22 1
8 PLATE, THROTTLE MOUNT 014813 1
9 BOLT, 5/16-18 X 1 1/4” HEX HEAD FULL THREAD F05006-18 1
10 NUT, 5/16-18 HEX NYLON LOCK F05010-58 4
11 WASHER, 3/8” SPLIT LOCK F05011-4 2
12 BOLT, 3/8-16 X 3/4” HEX HEAD GRADE 2 F05007-27 2
13 SPRING, 1/2” X 2 1/4” X .06” EXTENSION 014817 1
14 BRACKET WELDMENT, THROTTLE PIVOT 014836 1
15 NUT, 1/4-20 HEX LOCK F05010-21 2
16 WASHER, 1/4” SAE FLAT F05011-11 2
17 SPRING, 3/8” X 3” EXTENSION 014818 1
18 WIRE, THROTTLE 014826 1
19 BOLT, 1/4-20 X 1 3/4” HEX HEAD GRADE 2 F05005-4 1
20 BOLT, 1/4-20 X 1” HEX HEAD GRADE 2 F05005-38 1
21 NUT, 1/4-20 SELF-LOCKING HEX F05010-9 2
22 BOLT, 5/16-18 X 1 1/2” HEX HEAD GRADE 5 FULL THREAD F05006-76 1
25
26
27
28
150058-2
1
2
3
4
4
5
6
7
8
9
10
10
11
12
13
14
15
16
17
18
19
11
12
20
10
21
22
29
24
28
29
30
31
23
32
33
36
37 34 35
38
Table of contents
