Enigma enigma TC002 User manual

lightweight
travel chair
w. i e e l. omww dr vmdica c
.d iv md a .c .ukwww re e ic l o
wdr v m di a de
ww. i e e c l.
US
UK
DE
r i
Dive Med cal, NY 11050
e c 5 P Driv Medi al Ltd, HX 9J
d G -1
Drive Me ical GmbH & Co. K,D 883 6 Isny
d c l© 2010 Me ical Depot, In . Al Rights Reserved
a
Drive is trademark of Medical Depot Inc
e
Port Washington, N w York NY 11050
Made in China
US
UK
DE

TC002 Travel Chair Page 2 of 9
contents
1. Contents
2. Parts Description
3. Legrest Adjustment
4. Disassembly and Storage
5. Half-Folding Back Mechanism
6. Using the Stepper Tube
7. Using the Lap Belt
8. Brake Operation
9. Operation and Propulsion
10. Care and Maintenance
11. Warranty
12. Spare Parts List
introduction
The Enigma Travel Chair is designed to be one of the lightest wheelchairs
on the market at under 10kg. The wheelchair is recommended for moderate
or occasional everyday use, and suitable for indoor and some outdoors
applications. The wheelchair is suitable for use outdoors where the surface
and terrain is forgiving (for example shopping malls, precincts, etc)
The wheelchair is designed for a single user up to 115kg (18 stones) and is
propelled by an attendant pushing the wheelchair from behind.
parts description
PUSH
HANDLES
STEPPER
HALF FOLD
BACK MECH
LAP BELT
LIFTING
STRAP
PARKING
BRAKE
REAR
WHEEL
FRONT
CASTOR
LEG REST

TC002 Travel Chair Page 3 of 9
leg rest adjustment and installation
Adjustment
For optimum comfort it is important to attain
the correct leg position. The footrests have
been designed so that they can be extended
into one of 5 fixed positions.
Unscrew the black knob shown. Adjust the
legrest as required then reattach the black
knob to secure.
Removal and Installation
To remove the leg rest, press the chrome lever
on the leg rest whilst swinging the leg rest out.
This will now allow the leg rest to be lifted up
and removed. To attach the leg rest, place the
leg rest on the two receiver posts on the
wheelchair frame. Then swing the leg rest
inwards until it locks in position.
Ensure that the leg rest is securely locked in
position before use.
folding back mechanism
Push the black paddle towards the back post
with your thumb whilst pulling the handle
down. Repeat this operation for the other
handle. To put the backrest back into position,
lift both handles together and the folding
mechanism will lock back automatically.
Do not push down on the handles to raise the
front of the wheelchair, as this could result in
damage to the wheelchair. Use the stepper
tube as described later in the handbook.

TC002 Travel Chair Page 4 of 9
disassembly and storage
The Travel Chair can folded and the leg rests removed for storage. The
chair also comes with a sturdy carry bag. Before folding the wheelchair,
either remove the leg rests or flip up the plastic footplates. Then holding the
centre of the front and rear edge of the seat sling, pull upwards and the
wheelchair will fold. Fold the back if required.
We recommend that the wheelchair is carried by the two lift up straps.
Please note though that the wheelchair may be too heavy for some users to
lift. Also be sure to adopt the latest health and safety recommendations
when lifting the wheelchair.
IMPORTANT: The wheelchair has not been tested as a seat in a motor
vehicle. Users should always transfer to the vehicle’s seat and the
wheelchair should be safely stowed away.
using the stepper tube
Use the stepper tube to raise the front castors (when mounting a kerb for
example). To use, push down on the stepper tube with a foot. Do not raise the
front castors by pushing down on the push handles as this could result in
damage to the wheelchair.
To mount a kerb. Approach the kerb head on. Then the attendant uses the
stepper tube to raise the front castors, and lowers the front castors on the
raised kerb. Finally the attendant should push the wheelchair forward, lifting it
up slightly to mount the kerb if required.
To go down a kerb. Line up the front castors with the edge of the kerb. The
attendant uses the stepper tube to raise the front castors and tip the user
slightly back. Keeping the castors raised, slowly lower the wheelchair down
the kerb.
TC002 Travel Chair Page 9 of 9
spare parts available
The following spare parts are available for your wheelchair:
Z16150-25 : TC002 19” RHS cross brace assembly
Z16170-25 : TC002 19” LHS cross brace assembly
Z16180-25 : TC002 Cross brace support bracket
Z16215-25 : TC002 19” seat canvas assembly
716 : Lap belt
Z16265-25 : TC002 19” back canvas assembly
Z16340-25 : TC002 RHS push handle
Z16345-25 : TC002 LHS push handle
Z16350-25 : RHS half fold back mechanism
Z16360-25 : LHS half fold back mechanism
Z16400-25 : 6” front castor wheel and fork
Z16600-25A: TC002 RHS leg rest assembly
Z16650-25A: TC002 LHS leg rest assembly
Z16705-25 : RHS fixed brake
Z16755-25 : LHS fixed brake
Z16800-25 : TC002 stepper tube
Z10531-25NY : Nylon upholstered arm pad
The parts are available exclusively from Drive Medical stockists. To order
the parts please visit the stockist where you bought the wheelchair or visit
www.drivemedical.co.uk to find your local stockist.
Spare part catalogues and other documentation can also be found at
www.drivemedical.co.uk/technical

TC002 Travel Chair Page 8 of 9
warranty
Your Drive branded product is warranted to be free of defects in
materials and workmanship for one year from date of purchase. This
device was built to exacting standards and carefully inspected prior to
shipment. This warranty is an expression of our confidence in the
materials and workmanship of our products and our assurance to the
customer.
In the event of a defect covered by this warranty, we will at our option
supply parts or replace the device. This warranty does not cover device
failure due to owner misuse or negligence, or normal wear and tear. The
warranty does not extend to non-durable components, such as rubber
accessories, castors and grips, which are subject to normal wear and need
periodic replacement.
If you have any queries or require full warranty conditions, please contact
your Drive stockist.
Drive Germany:
Drive Medical GmbH & Co. KG
Leutkircher Straße 44
D-88316 Isny/Allgäu (Germany)
Web www.drivemedical.de
Drive UK:
Drive Medical Limited
Ainley’s Industrial Estate, Elland.
UK WEST YORKSHIRE HX5 9JP
Web www.drivemedical.co.uk
TC002 Travel Chair Page 5 of 9
using the lap belt
The lap belt is to restrain the
wheelchair occupant during normal
use. The lap belt is not be used as a
seat belt in a motor vehicle. Under
no circumstances should the Travel
Chair be used as a seat in a motor
vehicle (e.g. cars, buses, trains, etc).
The lap belt comes as standard with
the TC001, TC002 and LAWC002.
It is available as an option on the
LAWC001.
The lap belt should be adjusted to
suit each user. The length of the
belt can be adjusted by the tri-
glides (as shown in the diagram
above). The lap belt has a luggage-
style large locking clip to fasten and
unfasten the lap belt.
To fasten the lap belt, push the clip
in to the receiver until it locks in the
position (which can be heard by an
audible click).
When fastened, the lap belt should
be tight around the user’s pelvis
without causing discomfort or
undue pressure. This will help keep
the user’s hips and pelvis towards
the back of the wheelchair. Use the
tri-glides (shown) to adjust the
length of the lap belt. The length of
the lap belt should be checked each
time the belt is used.
There is a risk of suffocation from
users ‘submarining’ (where they
slide down the chair until the lap
belt is around the neck area). To
reduce the risk of this, ensure that
the lap belt is used under
supervision and is used as
instructed.
The lap belt may not be suitable for
all users of wheelchairs. Seek
professional medical advice before
using the lap belt.
brake operation
To apply the parking brakes, push the handle on the brake unit until locked
in place. To release the brake, push the handle in the opposite direction.
Always apply the brakes when the wheelchair is stationary.

TC002 Travel Chair Page 6 of 9
operation and propulsion
!
Before Using the Wheelchair read the safety notices below:
•Use slow speeds on gradients. Do not exceed the maximum
gradient stated.
•The wheelchair is only suitable for single occupancy.
•Keep your feet on the footplates when moving. Do not stand
on the footplates.
•Do not use escalators.
•Do not reverse down a gradient
•Maintain proper balance at all times. Users should not move
their centre of gravity out of the seating area.
•Do not reach for items further than your arm will extend.
•Be aware of hazards in your environment, such as narrow
doorways, steps, household appliances, children’s toys, etc.
•We recommend you consult your healthcare professional for
advice about transferring to and from the wheelchair. The
parking brakes should always be applied when transferring.
•The wheelchair brakes and parking brakes and are not
suitable for slowing the wheelchair down.
The wheelchair can only be propelled by an attendant. The attendant
should push the wheelchair from behind using the handgrips, and following
the safety advice above.
Always apply the brakes when the wheelchair is stationary.
TC002 Travel Chair Page 7 of 9
care and maintenance
•Before each use of the wheelchair, the brakes and tyre pressures
should be checked.
•The wheelchair should be stored in a dry environment, away from
direct sunlight. When in storage the wheelchair can be folded up
•The wheelchair should be kept clean and dust free. This can be done
with a duster or damp cloth.
•The user should routinely check the following items. It is recommended
that a Drive Medical dealer services the wheelchair annually, where
these items should be repaired, replaced, adjusted and/or lubricated if
required:
•Tyre wear
•Wheel bearings
•Castors
•Brakes
•Legrest locking
mechanism
•Seat upholstery
•Back upholstery
•Arm pads
•Rear wheel quick release pin
•Half folding back mechanism
•Back posts
•Wheelchair (folds up)
specification
TC002
Overall dimensions
L x W x H (cm / in)
87 x 56 x 90cm
34¼” x 22” x 35½”
Folded dimensions
L x W x H (cm / in)
56 x 23 x 72cm
22” x 9” 28½”
Seat dimensions
L x W x H (cm / in)
48 x 39 x 46cm
19” x 15½” x 18”
Total weight 8.6kg (19lb)
Carry weight 7.4kg (17lb)
Maximum user weight 18 stone (115kg)
