Decon wheel OlympicHopper User manual

2021-07-12
Assembly instructions for OlympicHopper
MED3122
1. Remove wheels on both sides.
2. Check the correct placement for the stop pin, and that the anti-tip devices are removed
and replace handle with MED4010.
5
10
9
5
10
9

2021-07-12
3. Assembly the plate (right side) according to picture.
4. Parts pair mounting set:
Item No. Part Number Qty Description
1 405239 1 Nordlock Washer M16
2 HW069 1 Sleeve M16x1
3 XSM6X70 1 Screw Round M6 x 70
4 100 400 020 1 Spacer
5 XSM6ML 3 Nut Self-Locking M6
6 XSM6BR 2 Washer Plain M6
7 100 400 017 1 Spacer
8 MED1684 1 Bracket
9 MED4010 1 Handle
10 XSM6X12 1 Screw M6 x 12
5. Adjust the parking brakes.
6. Assemble the under placed battery bag.

2021-07-12
Assembly of joystick on right side
Item No. Part Number Qty Description
1 X0F-48160-D00 1 Bracket with SwingAway
2 XSM6X16 2 Screw Round M6 x 16
3 XSM6BR 2 Plain Washer M6
4 XSM6ML 2 Lock Nut M6
5 MED1500 1 Bracket Right side
Note! For left side use MED1300 instead of MED1500

2021-07-12
Item No. Part Number Qty Description
1 XSM6X16 2 Screw - Round - M6 x 16
2 XSM6BR 2 Plain Washer M6
3 XSM6ML 2 Locknut M6
4 MED1500 1 Bracket
5 X0F-48160-D00 1 Parallel Bracket
Note! For left side use MED1300 instead of MED1500

2021-07-12
MED1682
Alternate attendant control (Only on Right side)
7. For the attendant control unit, you need these parts.
Item number. Part Number Qty Description
1 XSM6TG 1 Serrated washer
2 XOD2612K-00 1 Clamp with hole
3 XOD2612E-00 1 Clamp with hole
4 XSM6BR 1 Plain washer 6,4
5 XSM6X50 1 Screw M6x50
1
2
3
4
5

2021-07-12
Åtdragningsmoment / Tightening torque
Metriska grovgängor, stål.
Metric coarse threads, steel.
Gänga / Thread
Åtdragningsmoment / Tightening
torque
M3
1,2 Nm
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
25 Nm
M10
50 Nm
M12
85 Nm
Navhylsor.
Sleeves.
Gänga / Thread
Åtdragningsmoment / Tightening
torque
M16x1
30 Nm
M18x1
40 Nm
