Enofrigo H2000 Programming manual

Code CT89900003_(i.Am-USA)_USA - 05/2019 - R01
International styl
e
with Italian flavour
H1600
Dual Vent
H2000 H2000 FIT H2000 MIX
INSTRUCTIONS FOR INSTALLATION,
OPERATION AND MAINTENANCE
i.Am
Read this manual carefully before installing and using the product. Keep this manual with the product for future reference.
Refrigerated wine bottle display
cabinets
EN (USA)
Code

2
INTRODUCTION
Dear Customer,
Thank you for purchasing a product from
Enofrigo
.
The
i.Am
model you have purchased is a high performance product characterised by advanced design and technology and excellent
reliability and quality.
We recommend that you entrust its maintenance and servicing to a qualified professional of your choice and insist on the use of
original spare parts, if required.
This manual contains important information and instructions that must be followed in order to install and operate the product cor-
rectly and efficiently.
RANGE
This manual refers to the following products:
MODEL CODE NO. BOTTLES INPUT RATING (A)
i.Am H2000 VT L1V3SN* 260 4.5
i.Am H2000 VT L1V3DN* 182 4.5
i.Am H2000 VT L1V3LN* 132 4.5
i.Am H2000 VT L1V3MN* 214 4.5
i.Am H2000 VT TROPICAL L1W3SN* 260 4.9
i.Am H2000 VT TROPICAL L1W3DN* 182 4.9
i.Am H2000 VT TROPICAL L1W3LN* 132 4.9
i.Am H2000 DUAL VENT L2V3SN* 260 4.8
i.Am H2000 DUAL VENT L2V3DN* 168 4.8
i.Am H2000 DUAL VENT L2V3LN* 120 4.8
i.Am H2000 DUAL VENT L2V3MN* 214 4.8
i.Am H2000 VT B1V3SN* 144 4.5
i.Am H2000 VT TROPICAL B1W3SN* 144 4.9
i.Am H2000 DUAL VENT B2V3SN* 144 4.8
i.Am H2000 VT M1V3SN* 195 3.5
i.Am H2000 VT M1V3DN* 140 3.5
i.Am H2000 VT M1V3LN* 96 3.5
SYMBOLS USED IN THIS MANUAL AND THEIR MEANINGS
l
IMPORTANT!
Indicates particularly important information.
m
CAUTION!
Indicates particularly important or delicate operations.
a
WARNING!
Indicates actions that, if not performed correctly, may lead to accidents of a generic nature or cause
malfunctioning or damage to the product, and therefore require particular care and adequate prepa-
ration.
f
WARNING! RISK OF ELECTROCUTION!
Indicates actions that, if not performed correctly, may lead to electrical accidents and therefore require
particular care and adequate preparation.
d
STOP!
Indicates actions that MUST NOT be done.

3
CONTENTS
WARRANTY
This
Enofrigo
product benefits from a
conventional warranty
, valid from the date of purchase. The terms of this warranty are specified
in the GENERAL CONDITIONS OF SALE published on the website www.enofrigo.com.
m
CAUTION!
–The warranty is invalidated if the instructions provided in this manual are not followed.
–The warranty is also invalidated if the customer modifies the product or has others modify it without
the approval of the manufacturer or an authorised dealer or attempts to make repairs to the product
himself.
–The product must only be used for the purpose for which it has been expressly designed and made
by
Enofrigo
.
Enofrigo
cannot accept any responsibility, contractual or otherwise, for injury to per-
sons or animals or damage to property deriving from incorrect installation, operation, settings or
maintenance.
1 General 4
1.1 General warnings and safety precautions 4
1.2 STOP! 5
1.3 Description of the appliance 6
1.4 Identification 6
1.5 Structure 7
1.6 Safety devices 8
1.7 Technical specifications 8
1.8 Control panel 9
2 Installation 10
2.1 Receiving the product 10
2.2 Dimensions and weight 10
2.3 Place of installation 11
2.4 Installation 13
2.4.1 Moving 13
2.4.2 Positioning and levelling 14
3 Operation 15
3.1 Preliminary steps 15
3.1.1 Checks 15
3.1.2 Connecting to the electricity supply 15
3.2 Putting into service 16
3.2.1 Changing the temperature setpoint 16
3.2.2 Defrosting 16
3.2.3 Keypad lock 17
3.3 Alarm codes and resetting 17
3.4 Interior equipment 17
3.4.1 Removing and fitting shelves and drawers 17
3.4.2 Temperature distribution 17
3.5 Switching off 18
3.5.1 Switching off temporarily 18
3.5.2 Switching off for extended periods 18
4 Maintenance 19
4.1 Good practice 19
4.2 External cleaning 19
4.3 Cleaning the interior and important parts 19
4.3.1 Cleaning the interior of the cabinet 20
4.3.2 Clean the condenser 20
4.4 Regular checks 21
4.5 Extraordinary maintenance 21
4.6 Problems - Possible causes - Solutions 22
4.7 Technical assistance and spare parts 23
4.8 Disposal 23
5 Appendices 24
5.1 Functional electrical diagram 24
5.2 Declaration of conformity 26

4
1 GENERAL
1.1 General warnings and safety precautions
l
IMPORTANT!
–This manual is the intellectual property of
Enofrigo
. Copying its contents or transmitting them to
others is strictly forbidden. All rights reserved. This manual is an integral part of the appliance. It must
accompany the appliance at all times, even if the appliance is sold or transferred to another owner,
so that it can be consulted by the user or person responsible for servicing or repair.
–Read this manual thoroughly before using the appliance in order to ensure safe operation.
–The appliance is delivered in a single pack. Check immediately that the appliance received conforms
to the order, and report any discrepancy to the local dealer from whom it was purchased.
–Report any damage to the appliance's packing to the carrier and supplier.
–This appliance is designed and made to cool drinks.
Enofrigo
cannot accept any responsibility, con-
tractual or otherwise, for injury to persons or animals or damage to property deriving from incorrect
installation, operation, settings or maintenance.
–This appliance is designed exclusively to display non-hazardous products in bottles or packages. It is
not suitable for displaying potentially hazardous food products.
–The appliance is not designed for installation and use in places where it is exposed to the weather.
–If you have any doubts concerning operating conditions and/or the functioning of the appliance or
any of its component parts, contact your local dealer for clarifications.
–If you notice any problems or malfunctions when you put the appliance into service, report them
immediately to the dealer who sold it.
–Check the condition of the power cable, plug and socket at regular intervals. If the power cable is
damaged, it can only be replaced by the manufacturer, the local dealer who sold the appliance, or
personnel authorised to perform servicing and repairs.
–If you are not going to use the appliance for an extended period of time, perform the following op-
erations:
-Set the cabinet's ON/STAND BY switch to "STAND BY”
-Remove the plug from the power socket. If the plug cannot be accessed easily, switch off power to the
socket to which the appliance is connected by means of its double pole switch
-Empty the cabinet and clean all internal parts with a cloth damped in water or a neutral detergent.
–When the appliance is functioning, take care not to touch any steel surfaces inside the cabinet with
wet or damp hands as your skin could stick to the cold surface.
–Only load drinks that are already cooled or at least not hot into the cabinet.
–Only use original spares or parts approved by the manufacturer. Use of other parts may damage the
appliance.
–Empty and clean out the condensate drip tray at regular intervals to ensure correct functioning.

5
1.2 STOP!
d
STOP!
–Do not modify or attempt to repair the appliance yourself. All repairs must be referred to a qualified
technician.
–Store flammable or explosive materials (e.g. aerosol cans containing flammable propellants) in or
near the appliance.
–Do not use electrical equipment of any kind inside the cabinet.
–Do not expose the appliance to the weather.
–Do not touch the appliance with damp or wet hands or while standing in bare feet. If you experience
an electrical shock on contact with a metal surface of the appliance, turn it off at the switch, discon-
nect the plug from the power socket and contact an authorised dealer immediately.
–Do not allow children, differently able persons or persons with insufficient experience or knowledge
to operate the appliance unless supervised by somebody who is suitably qualified and responsible
for their safety.
–Do not dispose of packing material into the environment or leave it within reach of children as it can
become a hazard. Dispose of packing materials in accordance with applicable legislation.

6
1.3 Description of the appliance
i.Am
refrigerated cabinets are extremely versatile units that represent the latest development in wine display. They come in a wide
range of external finishes and as units for integration in existing furnishings.
i.Am
refrigerated cabinets are easy to install in all environ-
ments and allow interior designers to express their creativity to the full.
The unique and revolutionary
i.Am
display cabinets feature a robust design and fully usable interior space. A TOUCH SCREEN control
panel and four functioning modes (NORMAL, BOOST, SILENT, ECO) make operating the cabinet simple and intuitive.
Low energy consumption (Class A) is guaranteed by effective thermal insulation, LED lighting and a low-noise refrigeration system
with an automatic controller for optimised functioning. The cabinet is also extremely efficient thanks to thick insulation and low emis-
sion double glazed doors.
Bottle arrangement inside the cabinet is extremely flexible: users can choose the display layout they prefer to achieve maximum ca-
pacity or maximum visibility. The fixed shelves and removable drawers are made from black painted steel with polycarbonate bottle
supports, and can be arranged at various heights.
The refrigeration system is of the ventilated type. This lets you select a uniform temperature setpoint for the entire cabinet.
A wide range of models is available to satisfy different space requirements, and to display different quantities of wine in different ways.
Two ranges are available: H1600 and H2000. H2000 models are also available in a DUAL VENT version incorporating two separate and
independent compartments that can operate at different temperatures as needed.
1.4 Identification
i.Am
refrigerated display cabinets are identified by a nameplate. The nameplate is located inside the cabinet, as shown in Fig. 1, and
declares the appliance's technical and performance and other mandatory details.
*********
***********
******
*****
******
2
1
3
4
5
6
****** Kg
***-*** V
******
*** Kg
*** W
** Hz
****** **
1
CE mark
2
Identity of manufacturer
3
Type of appliance
4
Serial number
5
Model
6
Technical specifications
Fig. 1
m
IMPORTANT!
If the nameplate or any other identifying information is defaced, removed or missing, correct installa-
tion and maintenance of the appliance may be compromised.

7
1.5 Structure
10
11
8
7
6
12
4 5
9
1
2
3
13
14
16
15
Dual Vent
17
18
i.Am
1600
i.Am
2000
1
Door
2
Roll bond evaporator protection panel
3
Glass
4
Key
5
Lock
6
Fan protection grille
7
Shelves
8
Removable drawers
9
Roll bond evaporator
10
Structure
11
LED light
12
Control panel
13
Adjustable feet
14
Condensate collection tank
15
Power cable and plug
16
Motor protection grille
17
Top compartment (*)
18
Bottom compartment (*)
(*) Only for DUAL VENT models
Fig. 2

8
1.6 Safety devices
i.Am
refrigerated display cabinets are equipped with the following safety devices:
–Motor protection grille
–Fan protection grille
1.7 Technical specifications
DESCRIPTION
i.Am
H1600 H2000
Capacity US gal (l) 125,5 (460) 158,5 (600)
T.A. 86°F (30°C) - U.R. 55%
Climate class = 4 °F (°C) 36 (+2) / 68 (+20)
Fixed shelves n° 3 4
Removable drawers n° 10 13
Maximum permissible weight on each shelf lbs (kg) 176 (80)
Consumption at Qn max W 220 220
Electrical data V / Ph / Hz 115 / 1 / 60
Refrigerant Hfc R134a
Noise emission level dB(A) 38
The performance declared above is obtained at an ambient temperature below 86°F (30°C) and with relative humidity of less than
55%.

9
1.8 Control panel
11 2 2
1
FUNCTION KEYS
ILIGHT ON / LIGHT OFF: switches cabinet lighting on/off.
zON/STAND BY: hold down for over 3s to switch from ON
to STAND BY or vice-versa
GUP: enters SETPOINT programming mode or incre-
ments value.
HDOWN: enters SETPOINT programming mode or decre-
ments value.
Press and hold the UP and DOWN buttons simulta-
neously for a few seconds to activate/deactivate the
keypad lock. This function locks all keys apart the ON/
STAND BY key.
(The performance declared above is obtained at an
ambient temperature below 30°C and with relative hu-
midity of less than 55%.
(Only present on DUAL VENT models)
)BOTTOM COMPARTMENT: to view and set the SET
POINT and temperature settings of the bottom com-
partment.
(Only present on DUAL VENT models)
KNORMAL: press to activate NORMAL mode.
JSILENT: press to activate SILENT mode.
NECO: press to activate ECO mode.
OBOOST: press to activate BOOST mode.
2
DISPLAY
aLock
ON: keypad lock on. OFF: keypad lock off.
0Compressor
ON: on. OFF: off. Flashing: standby.
bDefrosting
ON: on. Flashing: standby.
ILight
ON: cabinet lighting on. OFF: cabinet lighting off.
qThermometer
Shows the temperature inside the cabinet.
jSilent
ON: SILENT mode active.
kNormal
ON: NORMAL mode active.
oBoost
ON: BOOST mode active.
nEco
ON: ECO mode active.
tSetting the SETPOINT
ON: lights up during SETPOINT programming.
vSet temperature thermometer
ON: when the temperature inside the cabinet reaches
the SETPOINT value. OFF: if the temperature inside the
cabinet exceeds the SETPOINT value by 39°F (4°C).
wFan
ON: on. OFF: off. Flashing: standby.
Fig. 3

10
2 INSTALLATION
2.1 Receiving the product
i.Am
cabinets are delivered in a single pack, wrapped in shrink-wrap film inside a cardboard box.
1
The following material is also supplied, inside the cabinet:
–Installation, operation and maintenance manual
–Keys for the door lock
This manual is an integral part of the appliance. Read it thoroughly be-
fore installing the appliance or putting it into service. Keep it with the
appliance for future consultation and transfer it to any new owner or
user along with the appliance.
Fig. 4
d
STOP!
Do not dispose of packing material into the environment or leave it within reach of children as it can
become a hazard. Dispose of packing materials in accordance with applicable legislation.
2.2 Dimensions and weight
LD
H
i.Am
1600
i.Am
2000
LD
H
Fig. 5
Description H1600 H2000 FIT
L (in-mm) 32 1/4 - 820 32 1/4 - 820 32 1/4 - 820
D (in-mm) 30 - 760 30 - 760 22 - 554
H (in-mm) 63 3/4 - 1620 72 1/4 - 1962 72 1/4 - 1962
Weight (lbs-kg) 275.5 - 125 297.5 - 135 286 - 1966
The above figures are purely indicative.

11
2.3 Place of installation
The place of installation must conform to all applicable technical and health standards. Position the appliance in a dry, well ventilated
place. In particular:
–Do not position the appliance near sources of heat (radiators, ovens, cookers, etc.) or in draughts.
–Do not expose the appliance to direct sunlight.
When installing a
i.Am
appliance as a replacement for an older product, perform the following checks:
–Check that the electrical power supply has been installed by a qualified electrician in conformity to applicable standards
–Check that the place of installation conforms to all applicable technical and health standards.
m
IMPORTANT!
To ensure optimal functioning of the appliance, the place of installation must conform to the following
conditions:
–ambient temperature = 86°F (30°C)
–RH (relative humidity) = 55%
–climate class = 4.
m
IMPORTANT!
In installations at altitudes over 2950 feet (900 metres), a compensation valve must be installed in each
double glazing compartment. This must be specified AT THE TIME OF ORDER.
d
STOP!
–Do not use the appliance in places where there is a risk of fire/explosion due to the presence/devel-
opment of dusts, gases or flammable mixtures.
–Do not store flammable materials inside or near the appliance.
–Do not expose the appliance to the weather.
m
IMPORTANT!
Bear in mind the space necessary to access the various safety/control devices and power plug, also the
space needed for maintenance and proper ventilation (see Fig. 7).

12
NO!
FORBIDDEN positions
Narrow niche
Back against
wall
NO!
I II
Fig. 6
PERMITTED positions
B
A
A A
A
✓
I
II
C
C
Fig. 7
Description H1600 H2000
A (in-mm) 8 - 200 8 - 200
B (in-mm) 8 - 200 8 - 200
C (in-mm) 8 - 200 8 - 200

13
2.4 Installation
2.4.1 Moving
Proceed as follows to remove the packaging from the appliance
–Move the appliance near the place of installation
–Steer the forks (1) of the pallet transporter under the appliance and lift it just clear of the floor
–Remove the screws (2) from all the corner panels (3) and remove the corner panels from the pallet
–Lower the appliance to the floor and carefully manoeuvre it clear of the forks of the pallet transporter
1
2
3
1
Fig. 8
–Unscrew the screws (6) and remove the two cross plates (7) from the pallet
–Very carefully tilt the appliance to the left and remove the right side of the pallet (8)
–Lower the appliance to the floor again, taking care not to damage the feet or the bottom
–Tilt the appliance to the right and remove the left side of the pallet (9).
7 6
5
4
Fig. 9
a
WARNING!
While moving the appliance, take great care to prevent it falling over.

14
2.4.2 Positioning and levelling
–Move the appliance into its final installation position, proceeding in small steps at a time
–Very carefully tilt the appliance and adjust the feet (8)
–Make sure that the door of the cabinet opens properly.
8
Fig. 10
a
WARNING!
Take care not to damage the feet or the bottom of the appliance throughout the positioning and lev-
elling procedure.

15
3 OPERATION
3.1 Preliminary steps
3.1.1 Checks
Before switching the appliance on, perform the following checks:
–Check that the electrical power supply has been installed by a qualified electrician in conformity to applicable standards
–Check that the voltage of the appliance, as stated on the nameplate, corresponds to the voltage of the power socket
–Check that the power supply circuit has an efficient earth (ground) connection and a double pole switch with a residual current
circuit breaker
–Check that the power socket is of the right kind for the appliance's plug. Do not use extension cables or multi-socket adapters
–Check that the power socket is easily accessible after installation
–Check that the place of installation conforms to all applicable technical and health standards.
d
STOP!
Do not put the appliance into service immediately. Wait
AT LEAST TWO HOURS
from the time of un-
packing. If the appliance has been placed horizontally during transport, this time will be needed for the
refrigerant to settle inside the cooling system.
3.1.2 Connecting to the electricity supply
The appliance comes with the correct power plug for the country of destination.
Check that the power socket (1) is of the correct type for the appliance's plug (2), then push the plug into the socket.
2 1
Fig. 11
f
WARNING! RISK OF ELECTROCUTION!
If the socket is NOT suitable for the appliance's plug, do not force the plug into the socket. Contact your
local dealer for further information.
d
STOP!
Do not use extension cables or multi-socket adapters.

16
3.2 Putting into service
Once you have completed the operations listed in the section "
Preliminary steps", the appliance can be put into service.
To do so, proceed as follows:
–Power up the cabinet. The cabinet enters STAND BY. The z
key lights up and the indicator (1) turns red
–Press the zkey to switch the cabinet on. The remaining sev-
en keys light up. The refrigeration system functions in NOR-
MAL mode (the Ksymbol lights up). The (1) indicator on the
display turns green and the symbols for the compressor A
and thermometer qlight up. The temperature inside the cab-
inet is also displayed.
1
Fig. 12
The refrigeration system continues to function until the cabinet
reaches the set temperature. The following table shows the de-
fault (factory) parameter settings.
DESCRIPTION Default settings
Setpoint °F (°C) 39 (4)
Hysteresis °F (°C) 34 (1)
Defrost start hours After 20 hours of compressor
functioning
Defrost Time-out
minutes
20
NORMAL mode
In NORMAL mode, the setpoint assumes the value of 39°F (+4°C)
when the cabinet is switched on for the first time. Every time the
Kkey is pressed, the setpoint returns to the previously mem-
orised value. NORMAL mode is recommended for the normal
functioning of the refrigeration system.
SILENT mode
Press the Jkey to switch the refrigeration system to SILENT
mode (the jsymbol lights up). In SILENT mode, the cabinet
makes less noise though the temperature setpoint remains as
set previously. Use SILENT mode to reduce noise from the cabi-
net when customers are nearby.
ECO mode
Press the Nkey to switch the refrigeration system to ECO
mode (the nsymbol lights up). In ECO mode, the cabinet
consumes less energy though the temperature setpoint re-
mains as set previously. Use ECO mode at night or when your
business is closed.
BOOST mode
Press the Okey to switch the refrigeration system to BOOST
mode (the osymbol lights up). In BOOST mode, the cabinet
cools more quickly, though the temperature setpoint remains
as set previously. Use BOOST mode to cool the display cabinet
rapidly, e.g. after loading a large number of bottle.
3.2.1 Changing the temperature setpoint
To change the SETPOINT [default=39°F (4°C)]:
–Press the Kkey to select NORMAL mode
–Press the Gor Hkey to display the required value. The t
symbol lights up and the current temperature setpoint flash-
es. The new setpoint value is memorised after a few seconds.
The temperature inside the cabinet is now displayed again
and the tsymbol goes out.
Fig. 13
DUAL VENT models
On DUAL VENT cabinets, the temperature SET POINT can be set
independently for both compartments.
To do so, press the (key to select the top compartment or the )
key to select the bottom compartment then follow the proce-
dure described above to set the temperature SET POINT.
Fig. 14
3.2.2 Defrosting
i.Am
refrigerated cabinets incorporate a special function that
defrosts them automatically whenever necessary.

17
3.2.3 Keypad lock
To activate the keypad lock:
–Press and hold the Gand Hkeys for a few seconds
–The asymbol comes on and all the keys are locked except
for the zkey
Fig. 15
–Press and hold the Gand Hkeys again for a few seconds to
deactivate the keypad lock. The lock symbol on the display
goes out.
3.3 Alarm codes and resetting
If the appliance detects a malfunction, an alarm code flashes on
the display, alternating with the temperature.
All alarms are of the automatic reset type, i.e. they are cancelled
as soon as the cause is eliminated.
Alarm Description
CF Failure to reach the temperature setpoint after 6 hours
(Cooling Fail)
PF Probe damaged or disconnected (Probe Fail)
3.4 Interior equipment
i.Am
refrigerated display cabinets are supplied with the interior
equipment specified by the customer at the time of order.
An LED lighting system illuminates the refrigerated cabinet to
ensure an optimal view of the products on display.
In the event of a malfunction or failure of the lighting system,
contact the dealer who sold the appliance.
3.4.1 Removing and fitting shelves and drawers
If necessary, shelves or drawers can be repositioned or added
inside the cabinet.
Proceed as follows to remove the shelves:
–Unscrew the four screws (1) securing the shelf to the sides of
the cabinet
–Remove the shelf (2).
Proceed as follows to remove a drawer:
–Pull out the drawer (3)
–Unscrew the screws (4) holding the drawer runners in place
–Remove the runners (5).
2
1
2
4
5
3
Fig. 16
To reposition a shelf or drawer, simply reverse the procedures
given above.
3.4.2 Temperature distribution
Refrigeration inside each cabinet is ventilated, ensuring even
temperature distribution.
t °C
°F
VENTILATED
Fig. 17

18
3.5 Switching off
3.5.1 Switching off temporarily
To switch the appliance off for a short time (e.g. for cleaning or maintenance) proceed as follows:
–Press the zkey. The refrigeration system and the display switch off
–pull the plug (1) out of the power socket (2) and turn the supply off at the double pole switch.
1 2
Fig. 18
3.5.2 Switching off for extended periods
If you need to switch the appliance off for an extended period (e.g. for holidays) proceed as follows:
–Press the zkey. The refrigeration system and the display switch off
–pull the plug (1) out of the power socket (2) and turn the supply off at the double pole switch
–empty the cabinet completely, clean and dry it and leave the door partly open to prevent bad odours from forming inside.

19
4 MAINTENANCE
4.1 Good practice
It is good practice to clean the outside and inside surfaces of the cabinet at regular intervals. This guarantees correct functioning and
an extended working life.
4.2 External cleaning
Clean the outside of the cabinet and the inside of the door every day. Apart from keeping the cabinet looking attractive, this also helps
to ensure an extended working life.
m
CAUTION!
–Clean all external surfaces using only a cloth damped in a solution of warm water and neutral deter-
gent. Rinse and dry thoroughly with a soft cloth.
–To clean the door glass, use a glass cleaning spray or a solution of water and neutral detergent.
d
STOP!
–Do not use scouring powders, solvents or aggressive detergents that could damage the surfaces of
the cabinet
–Do not use excessively hot water to clean cold glass parts. The difference in temperature could cause
the glass to crack or even shatter.
4.3 Cleaning the interior and important parts
f
WARNING! RISK OF ELECTROCUTION!
Before starting to clean the inside of the refrigerated cabinet, switch it off as instructed in "Switching
off temporarily" on page 18.
f
WARNING! RISK OF ELECTROCUTION!
Do not use water to clean electrical parts or the control panel.
d
STOP!
–Do not use scouring powders, solvents or aggressive detergents that could damage the surfaces of
the cabinet
–Do not use excessively hot water to clean cold glass parts. The difference in temperature could cause
the glass to crack or even shatter.
The frequency at which the inside of the cabinet requires cleaning must be decided by the user. It is recommended to clean the inside
of the cabinet and all important parts as instructed below
at least once a month
.

20
4.3.1 Cleaning the interior of the cabinet
Switch off the refrigerated cabinet and remove all contents, then:
–Clean all internal surfaces using only a cloth damped in a solution of warm water and neutral detergent
–Rinse and dry thoroughly with a soft cloth
–At regular intervals, check that the drain channel and drain slot (1) are not blocked. This is essential for proper condensate drainage.
1
Fig. 19
4.3.2 Clean the condenser
The condenser must be cleaned once a month. With the cabinet switched off and the plug removed from the electrical power socket:
–Unscrew the screws (1) shown in the figure and remove the panel (2)
–Clean the condenser (3) using a vacuum cleaner and/or brush. Do NOT use tools that might cause damage to the condenser
–Replace the panel after cleaning.
23
1
I
0
Fig. 20
m
CAUTION!
Take care not to damage the fins of the condenser.
This manual suits for next models
6
Table of contents
