VESTEL REFRIGERATOR
SERVICE MANUAL
TECHNICAL DEPARTMENT WHITE GOODS TECHNICAL DOCUMENT : 50024371
VESTELMODEL: MODEL: CODE :
RT 260S RD 26T ( GREECE / CARAD ) 10010452
VESTEL WHITE GOODS
CONSUMER SERVICE

CONTENTS PAGE
1. SPECIFICATIONS 1-2
2. ASSEMBLE & DISASSEMBLE
A - Changing the doorway direction to right hand 3-5
B - Changing the thermostat 6
C - Thermostat knob 6
3. REFRIGERANT CYCLE DIAGRAM 7
4. MACHINE ROOM VIEW 8
5. CIRCUIT DIAGRAM 8
6. INTERIOR PARTS 9
7. INTERIOR PARTS LIST 10
8. DOOR ASSY. PARTS 11
9. DOOR ASSY. PARTS LIST 12
10. UNIT PARTS 13
11. UNIT PARTS LIST 14
Printed Date : 21 / 12 / 2001 Document No : 50024371

VESTEL
WHITE GOODS CONSUMER SERVICE
1
VESTEL
WHITE GOODS
VESTEL REFRIGERATOR
TECHNICAL
DEPARTMENT
Printed Date : 21 / 12 / 2001 Document No : 50024371
DECEMBER
2001
SPECIFICATIONS
MAIN SPECIFICATIONS
RD 26T
CLIMATE T
DOOR COLOUR WHITE
DOOR 2 SIDE AVAILABLE
DOOR INSULATION CYCLOPENTAN
INSULATION CYCLOPENTAN
LEVELLING FOOT 2
REFRIGERATOR GASKET WHITE
FREEZER GASKET WHITE
ELECTRICAL SPECIFICATIONS
RD 26T
VOLTAGE/FREQUENCY 220-240 V / 50Hz
POWER OUTPUT 230 W
LAMP TYPE E14
POWER CONSUMPTION 1.09 kWh/24h
CURRENT 0.8A
REFRIGERANT R 134a
REFRIGERANT CHARGE 130 gr
ENERGY CLASS B
COMPRESSOR
RD 26T
COMPRESSOR TYPE BPM1111Z(220-240V,50Hz)
RELAY
RD 26T
RELAY TYPE 1260001 (V230)
THERMIC TYPE T0062/26
TEMPERATURE CONTROL&DEFROST
RD 26T
CAPILLARY LENGTH 0.66x3400 mm
DEFROST TYPE Semi Automatic

VESTEL
WHITE GOODS DECEMBER
2001
VESTEL
WHITE GOODS CONSUMER SERVICE TECHNICAL
DEPARTMENT
VESTEL REFRIGERATOR
2
Printed Date : 21 / 12 / 2001 Document No : 50024371
SPECIFICATIONS
TEMPERATURE CONTROL MAXIMUM (COLD)
RD 26T
ON
+ 3.5 C
OFF
- 29 C
TEMPERATURE CONTROL MINIMUM (WARM)
RD 26T
ON
+ 3.5 C
OFF
- 16.7 C
DIMENSIONS
RD 26T
REFRIGERATOR VOLUME GROSS (l)
198
FREEZER VOLUME GROSS (l)
50
REFRIGERATOR VOLUME NET (l)
195
FREEZER VOLUME NET (l)
50
WEIGHT (kg)
45.4
HEIGHT (mm)
1440
DEPTH (mm)
600
WIDTH (mm)
540
PACKAGED DIMENSIONS
RD 26T
WEIGHT (kg)
48.4
HEIGHT (mm)
1495
DEPTH (mm)
632
WIDTH (mm)
575
FREEZER ACCESSORY
RD 26T
ICE SCRAPER
1
ICE TRAY
1
SHELF
1
REFRIGERATOR ACCESSORY
RD 26T
CRISPER
1
CRISPER COVER
1
SHELF
3
TUNNEL DRAIN PLUG
1
DOOR ACCESSORY
RD 26T
SHELF
6
SHELF SECTION
10
SHELF COVER
1
BOTTLE HOLDER WIRE
1
EGG HOLDER
1

VESTEL
WHITE GOODS CONSUMER SERVICE
3
VESTEL
WHITE GOODS
VESTEL REFRIGERATOR
TECHNICAL
DEPARTMENT
Printed Date : 21 / 12 / 2001 Document No : 50024371
DECEMBER
2001
ASSEMBLE & DISASSEMBLE
2- Remove two doors by pulling towards to you with the middle hinge. (FIG-2)
A- Changing The Doorway Direction to Right Hand
1- Unscrew the two screws which are fixing the middle hinge and remove two big
taps and one small tap. (FIG-1)
Unscrew the two
hinge screw.
Remove two big taps
and one small tap.
Pull the doors towards to
you with middle hinge.
Figure - 1
3- Dismantle both levelling feet and loosen two screws,which are fixing the bottom
hinge and dismantle the bottom hinge. (FIG-3)
Unscrew and remove the two
levelling foot and the bottom hinge.
Figure - 2
Figure - 3

VESTEL
WHITE GOODS DECEMBER
2001
VESTEL
WHITE GOODS CONSUMER SERVICE TECHNICAL
DEPARTMENT
VESTEL REFRIGERATOR
4
Printed Date : 21 / 12 / 2001 Document No : 50024371
ASSEMBLE & DISASSEMBLE
A- Changing The Doorway Direction to Right Hand
4- Then change the placement of bottom hinge pin as shown below.Unscrew the
hinge pin and screw in the next hole. (FIG-4)
Figure - 4
5- Place the two big taps and one small tap as shown in the figure. (FIG-5)
Figure - 5
Detail-B
Detail-A
Plug the two big taps
andonesmalltaphere.
6- Break this ear and cut circular hole.(FIG-6/Detail-A)
Unscrew and remove the tap hinge pin and screw on the top hinge on the left side.
(FIG-6/Detail-B)
Figure - 6
DETAIL-A
DETAIL-B

VESTEL
WHITE GOODS CONSUMER SERVICE
5
VESTEL
WHITE GOODS
VESTEL REFRIGERATOR
TECHNICAL
DEPARTMENT
Printed Date : 21 / 12 / 2001 Document No : 50024371
DECEMBER
2001
ASSEMBLE & DISASSEMBLE
A- Changing The Doorway Direction to Right Hand
7- Replace the bushing with the bushing cap on top of refrigerator door. Change the
placement of bushing on the bottom of the refrigerator door. (FIG-7)
Replace the bushing with the bushing cap on top of freezer door. Change the place-
ment of bushing on the bottom of the freezer door. (FIG-8)
Figure - 7
Figure - 8
8- Turn the middle hinge 180 clockwise direction. And then assemble with the two
doors.Finally screw it on the left holes with two screws. (FIG-9)
Turn the middle hinge
180° clockwise direction.
Figure - 9

VESTEL
WHITE GOODS DECEMBER
2001
VESTEL
WHITE GOODS CONSUMER SERVICE TECHNICAL
DEPARTMENT
VESTEL REFRIGERATOR
6
Printed Date : 21 / 12 / 2001 Document No : 50024371
Thermostat Knob
vThis knob is used to control the temperature of the freezer and refrigerator automatically. It can be set
to any value between the min and max positions.
v0 position indicates that the thermostat is off and so in this position no cooling is done.
vBy turning the knob from min to max you can increase the cooling degree.
vThe refrigerator is designed to get optimum perforformance when the thermostat knob is set in the
middle position (between min and max).
ASSEMBLE & DISASSEMBLE
1) Take off the lamp cover and unscrew the fixing screw.
2) Take off screw cap and unscrew the fixing screw.
3) Take off the thermostat box by pulling and take off the wire connector.
4) Pull out the thermostat bulb from the cabinet.
5) Take off the thermostat knob pulling forward. Loosen the nut fixing the thermostat.
6) Replace the thermostat and assemble the thermostat box following the steps backwards. Be
carefull to first mount the thermostat box to the cavity properly.
Changing the thermostat

VESTEL
WHITE GOODS CONSUMER SERVICE
7
VESTEL
WHITE GOODS
VESTEL REFRIGERATOR
TECHNICAL
DEPARTMENT
Printed Date : 21 / 12 / 2001 Document No : 50024371
DECEMBER
2001
REFRIGERANT CYCLE DIAGRAM

VESTEL
WHITE GOODS DECEMBER
2001
VESTEL
WHITE GOODS CONSUMER SERVICE TECHNICAL
DEPARTMENT
VESTEL REFRIGERATOR
8
Printed Date : 21 / 12 / 2001 Document No : 50024371
CIRCUIT DIAGRAM
MACHINE ROOM VIEW / CIRCUIT DIAGRAM
MACHINE ROOM VIEW

VESTEL
WHITE GOODS CONSUMER SERVICE
9
VESTEL
WHITE GOODS
VESTEL REFRIGERATOR
TECHNICAL
DEPARTMENT
Printed Date : 21 / 12 / 2001 Document No : 50024371
DECEMBER
2001
INTERIOR PARTS
9
14
5 2
3
6
1
5
4
10
12
6
34
33
35
36
37
18
17
15
2423222120 25
26 2827 29 23 30 31 32
19
11 8
716
5
13

VESTEL
WHITE GOODS DECEMBER
2001
VESTEL
WHITE GOODS CONSUMER SERVICE TECHNICAL
DEPARTMENT
VESTEL REFRIGERATOR
10
Printed Date : 21 / 12 / 2001 Document No : 50024371
INTERIOR PARTS LIST
NO CODE PARTS NAME RD 26T
120041377 ASSY URT CAB/260T 1
240006464 HEAD PANEL/260V 1
335004623 TOP HINGE/260V (WITH PIN) D.Ç.3,8 1
435004624 TOP HINGE/260V (WITHOUT PIN) D.Ç.3,8 1
535000714 SCREW M5*14 WN 1342-H EJOT 2
635001817 SCREW 4.2*9.5 WITH WASHER 2
735003428 MIDDLE HINGE DYED/260S 1
835001709 SCREW M5*14 WN 1342-H EJOT 2
940004843 CAP BIG 2
10 40004842 CAP SMALL 1
11 40002216 TUNNEL DRAIN PLUG 1
12 20073141 NAME PLATE /260T CARAD-ENG.(RD26T) 1
13 35003211 BOTTOM HINGE / 140V 1
14 45000563 LEVELLING FOOT 2
15 40002236 ICE TRAY 1
16 40002276 ICE SCRAPER 1
17 45000985 F COMPARTMENT SHELF/260 1
18 40003928 F SHELF TRIM/140(EXT) 1
19 30009610 THERMOSTAT BOX ASSY/260N 1
20 30007906 LAMP 1
21 30007907 LAMP HOLDER 1
22 45000976 HEAT REFLECTOR FOIL/140 1
23 35000744 SCREW 40*14 WN 1411 EJOT 2
24 40003899 THERMOSTAT BOX/140 1
25 30007921 THERMOSTAT (DNFS077B6575) 1
26 40003905 LAMP COVER/140 1
27 40008121 THERMOSTAT KNOB SRGF/260 1
28 35000730 SPRING 1
29 40003904 PLUG/140 THERM. BOX SCREW/140 1
30 40003901 SWITCH PUSH BUTTON 1
31 30011861 SWITCH 1
32 30009528 WIRING HARNESS/THERMOSTAT/260 1
33 45001966 R COMPARTMENT SHELF/260 3
34 40003913 R SHELF TRIM /140(EXT) 3
35 45000978 CRISPER COVER/140 1
36 40003914 CRISPER COVER TRIM/140(EXT) 1
37
20065270
CRISPER SRGF/140
1

VESTEL
WHITE GOODS CONSUMER SERVICE
11
VESTEL
WHITE GOODS
VESTEL REFRIGERATOR
TECHNICAL
DEPARTMENT
Printed Date : 21 / 12 / 2001 Document No : 50024371
DECEMBER
2001
DOOR ASSY. PARTS
9
7
10
7
8
3
3
4
4
5
2
3
1
12
11

VESTEL
WHITE GOODS DECEMBER
2001
VESTEL
WHITE GOODS CONSUMER SERVICE TECHNICAL
DEPARTMENT
VESTEL REFRIGERATOR
12
Printed Date : 21 / 12 / 2001 Document No : 50024371
DOOR ASSY. PARTS LIST
NO CODE PARTS NAME RD 26T
120059509 F DOOR ASSY SRGF/260S
1
220059543 R DOOR ASSY/260S
1
340002242 BUSHING/345P
3
440002243 BUSHING CAP
2
545002336 LOGO CARAD
1
740006626 BOTTLE SHELF/140
2
840006625 EGG SHELF/140
4
940003910 EGG HOLDER/140 (BLUE)
1
10 35001838 BOTTLE HOLDER WIRE
1
11 40006640 BUSHING/345S
1
12
40003915
SHELF COVER/140
1

VESTEL
WHITE GOODS CONSUMER SERVICE
13
VESTEL
WHITE GOODS
VESTEL REFRIGERATOR
TECHNICAL
DEPARTMENT
Printed Date : 21 / 12 / 2001 Document No : 50024371
DECEMBER
2001
UNIT PARTS
4
4
5
3
2
6
12
10
13
11
7
8
14
15
16
9
1
17

VESTEL
WHITE GOODS DECEMBER
2001
VESTEL
WHITE GOODS CONSUMER SERVICE TECHNICAL
DEPARTMENT
VESTEL REFRIGERATOR
14
Printed Date : 21 / 12 / 2001 Document No : 50024371
UNIT PARTS LIST
NO CODE PARTS NAME RD 26T
135002813 MAIN CONDENSER/260T 1
240002180 SPACER 1
340003898 PLUG,CABLE HARNESS 1
435001817 SCREW 4.2*9.5 WITH WASHER 4
530009529 POWER CORD GR.BPM1111Z/260(50Hz) 1
630010202 POWER CORD (1.5m) 1
730009530 OVER LOAD RELAY GR.BPM1111Z(50Hz)260 1
840006235 CABLE HOLDER PLS/140 1
935000743 SCREW 4.2*9.5 DIN 7981 YSB 2
10 40003931 EVAPORATING TRAY/260 1
11 35002601 DRYER(XH9,7.5GR) 1
12 20020023 COMPRESSOR FIXING BRACKET 2
13 30009700 COMPRESSOR/BPM1111Z(220-240V,50Hz)260 1
14 20066212 COMPRESSOR BASEMENT/140 (UL) 1
15 35000714 SCREW M5*14 WN 1342-H EJOT 2
16 40003916 FOOT/140 2
17 40006285 CONDENSER TRIM / 140 1
50012332 CIRCUIT DIAGRAM 1
50021503 PACKAGE CARTOON/260 1
50020998 STRAFOR BOTTOM/310 1
50008955 STRAFOR TOP LEFT/140 1
50008937 STRAFOR TOP RIGHT/140 1
50018979 USER'S MANUEL/GREEK 1
50020669 PACKAGE LABEL/260S(T)CARAD-ENG 1
50020664 WARRANTY LABEL/CARAD 1
50020670 ENERGY LABEL/260S(T)CARAD(RD26T) 1
50007618
OZON FRIENDLY LABEL
1

PRINTED DATE : 21 DECEMBER 2001
DOCUMENT NO : 50024371
PREPARED BY : Sirma KARAKAYA
APPROVED BY: Filiz KUNURALP
REVISION SHORT HISTORY:
NO: REV. NO: REV. DATE: PAGE NO: REV. REASON
01 00 21.12.2001 All First publication
DISTRIBUTION :
Greece-Carad Date: 28.12.2001
