Morris R71362CAP User manual

R71362CAP
R76322CAP
W76359CAP
W76322CAP


EN
1
Index
BEFORE USING THE APPLIANCE................................. 5
General warnings...................................................................... 5
Old and out-of-order fridges...................................................... 9
Safety warnings ........................................................................ 9
Installing and operating your fridge.......................................... 10
Before Using your Fridge......................................................... 12
Information about New Generation Cooling Technology ......... 12
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS .......................................................... 13
THE VARIOUS FUNCTION AND POSSIBILITIES ......... 17
Display and control panel ........................................................ 17
Operating your fridge............................................................... 18
Super freeze mode .............................................................. 18
Super cool mode.................................................................. 18
Economy mode.................................................................... 18
Holiday mode....................................................................... 19
Drink cool mode................................................................... 19
Screen saver mode.............................................................. 20
Light cancelling mode .......................................................... 20
Function of Child lock .......................................................... 20
Cooler temperature settings ................................................ 21
Freezer temperature settings............................................... 21
Warnings about temperature adjustments............................... 22
Accessories ............................................................................. 23
Freezer box.......................................................................... 23
Chiller shelf .......................................................................... 23
Humidity controler................................................................ 23
Adjustable door shelf ........................................................... 24
Adjustable glass shelf .......................................................... 24
Natural Ion Tech / Ionisier .................................................... 24
Maxi-fresh preserver............................................................ 25
CLEANING AND MAINTENANCE.................................. 28

EN
2
Defrosting ................................................................................ 29
Replacing LED Lighting ........................................................... 29
ARRANGING FOOD IN THE APPLIANCE..................... 30
Refrigerator compartment........................................................ 30
Freezer compartment .............................................................. 31
TRANSPORTATION AND CHANGING OF INSTALLATION
POSITION........................................................................ 36
Repositioning the door............................................................. 36
BEFORE CALLING YOUR AFTER SALES SERVICE... 37
TIPS FOR SAVING ENERGY.......................................... 41
Dimensions.............................................................................. 42
Dimensions.............................................................................. 43
TECHNICAL DATA.......................................................... 44
INFORMATION FOR TEST INSTITUTES....................... 44
CUSTOMER CARE AND SERVICE................................ 44

EN
3
BEFORE USING THE APPLIANCE
General warnings
This appliance is not intended to be used as a built-in
appliance.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process, other than
those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance, unless
they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure
the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of
the appliance.
WARNING: In order to avoid any hazards
resulting from the instability of the appliance, it must be
xed in accordance with the following instructions:
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and installation
to prevent the cooler elements from being damaged.
R600a is an environmentally friendly and natural gas,
but it is explosive. In the event of a leak due to damage
of the cooler elements, move your fridge away from open
ames or heat sources and ventilate the room where the
appliance is located for a few minutes.

EN
4BEFORE USING THE APPLIANCE
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
- sta󰀨 kitchen areas in shops, o󰀩ces and other working
environments.
- farm houses and by clients in hotels, motels and
other residential type environments.
- bed and breakfast type environments;
- catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected to the
power cable of your refrigerator. This plug should be
used with a specially grounded socket of 16 amperes.
If there is no such socket in your house, please have
one installed by an authorised electrician.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
• Children aged from 3 to 8 years are allowed to load and

EN
5
unload refrigerating appliances. Children
are not expected to perform cleaning or user
maintenance of the appliance, very young
children (0-3 years old) are not expected to
use appliances, young children (3-8 years
old) are not expected to use appliances
safely unless continuous supervision is
given, older children (8-14 years old) and
vulnerable people can use appliances safely
after they have been given appropriate
supervision or instruction concerning use
of the appliance. Very vulnerable people
are not expected to use appliances safely
unless continuous supervision is given.
• If the supply cord is damaged, it must be
replaced by the manufacturer, an authorised
service agent or similar qualied persons, in
order to avoid a hazard.
• This appliance is not intended for use at
altitudes exceeding 2000 m.
To avoid contamination of food, please
respect the following instructions:
• Opening the door for long periods can cause
a signicant increase of the temperature in
the compartments of the appliance.
• Clean regularly surfaces that can come in
contact with food and accessible drainage
systems
• Store raw meat and sh in suitable containers
in the refrigerator, so that it is not in contact
BEFORE USING THE APPLIANCE

EN
6
with or drip onto other food.
• Two-star frozen-food compartments are
suitable for storing pre-frozen food, storing
or making ice cream and making ice cubes.
• One-, two- and three-star compartments are
not suitable for the freezing of fresh food.
• If the refrigerating appliance is left empty for
long periods, switch o󰀨, defrost, clean, dry,
and leave the door open to prevent mould
developing within the appliance.
BEFORE USING THE APPLIANCE

EN
7
BEFORE USING THE APPLIANCE
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock before
discarding it, because children may get trapped inside it and may
cause an accident.
• Old fridges and freezers may contain isolation material and
refrigerant with CFC or HFC. Therefore, take care not to harm
environment when you are discarding your old fridges.
Please ask your municipal authority about the disposal of the WEEE
reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and
using your appliance. We are not responsible for the damage
occurred due to misuse.
• Follow all instructions on your appliance and instruction manual,
and keep this manual in a safe place to resolve the problems that
may occur in the future.
• This appliance is produced to be used in homes and it can only be
used in domestic environments and for the specied purposes.
It is not suitable for commercial or common use. Such use will
cause the guarantee of the appliance to be cancelled and our
company will not be responsible for losses incurred.
• This appliance is produced to be used in houses and it is only
suitable for cooling / storing food. It is not suitable for commercial
or common use and/or for storing substances except for food.
Our company is not responsible for losses to be incurred in the
contrary case.
Safety warnings
• Do not connect your Fridge Freezer to the mains electricity
supply using an extension lead.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children
to play with the appliance or let them hang o󰀨 the door.
• Never touch the power cord/plug with wet hands as this could
cause a short circuit or electric shock.
• Do not place glass bottles or beverage cans in the ice-making
compartment as they can burst as the contents freeze.

EN
8BEFORE USING THE APPLIANCE
• Do not place explosive or ammable material in your fridge.
Place drinks with high alcohol content vertically in the fridge
compartment and make sure that their tops are tightly closed.
• When removing ice from the ice-making compartment, do not
touch it. Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream
or ice cubes immediately after you have taken them out of the
ice-making compartment.
• Do not re-freeze frozen goods after they have melted. This may
cause health issues such as food poisoning.
• Do not cover the body or top of fridge with lace. This a󰀨ects the
performance of your fridge.
• Secure any accessories in the fridge during transportation to
prevent damage to the accessories.
Installing and operating your fridge
Before using your fridge, you should pay attention to the following
points:
• The operating voltage for your fridge is 220-240 V at 50Hz.
• We do not accept responsibility for any damages that occur due
to ungrounded usage.
• Place your fridge where it will not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, gas
ovens and heater cores, and at least 5 cm away from electrical
ovens.
• Your fridge should never be used outdoors or exposed to rain.
• When your fridge is placed next to a deep freezer, there should
be at least 2 cm between them to prevent humidity forming on
the outer surface.
• Do not place anything on your fridge, and install your fridge in
a suitable place so that at least 15 cm of free space is available
above it.
• Do not place heavy items on the appliance.
• Use the adjustable front legs to make sure your appliance is
level and stable. You can adjust the legs by turning them in either
direction. This should be done before placing food in the fridge.
• Before using your fridge, wipe all parts with a solution of warm
water and a teaspoon of sodium bicarbonate, then rinse with
clean water and dry. Place all parts in the fridge after cleaning.
• Install the plastic distance guide (the part with black vanes at
the rear) by turning it 90° (as shown in the gure) to prevent the
condenser from touching the wall.
• The refrigerator should be placed against a wall with a free space
not exceeding 75 mm.

EN
9
Internal lighting
WARNING!
Risk of electric shock.
• Concerning the lamp(s) inside this product and spare part
lamps sold separately: These lamps are intended to withstand
extreme physical conditions in household appliances, such
as temperature, vibration, humidity, or are intended to signal
information about the operational status of the appliance. They
are not intended to be used in other applications and are not
suitable for household room illumination.
General notes:
Fresh Food Compartment (Fridge): Most e󰀩cient use of energy
is ensured in the conguration with the drawers in the bottom part of
the appliance, and shelves evenly distributed, position of door bins
does not a󰀨ect energy consumption.
Freezer Compartment (Freezer): Most E󰀩cient use of energy is
ensured in the conguration with the drawers and bins are on stock
position.
BEFORE USING THE APPLIANCE

EN
10 BEFORE USING THE APPLIANCE
Before Using your Fridge
• When using your fridge for the rst time, or after transportation,
keep it in an upright position for at least 3 hours before plugging
into the mains. This allows e󰀩cient operation and prevents
damage to the compressor.
• Your fridge may have a smell when it is operated for the rst time.
This is normal and the smell will fade away when your fridge
starts to cool.
Information about New Generation Cooling
Technology
Fridges with new generation cooling technology have a di󰀨erent
working system than static fridges. In normal fridges, humid air that
enters into fridge and the water vapor that comes out from the foods,
accumulates frost formation in freezer compartment. In order to melt
this frost, in other words defrost, the fridge has to be stopped. During
the stopping period, to keep the foods cold, user has to extract the
food to outside of fridge and user has to clear the ice during this
period.
In the fridges with new generation cooling technology, situation in
the freezer compartment is completely di󰀨erent. With the aid of fan,
cold and dry air is blown out through many points into the freezer
compartment. As a result of the homogenously blown cold air, even in
the spaces between shelves, foods are frozen equally and correctly.
On the other hand there will be no frost formation.
In the refrigerator compartment, there will be nearly same conguration
with freezer compartment. Air, that is emitted with the fan, located at
the top of refrigerator compartment, is cooled while passing through
the gap behind the air duct. At the same time, air is blown out through
the holes on the air duct so that cooling process is successfully
completed in the refrigerator compartment. Holes on the air duct are
designed such that the air distribution becomes homogenous in this
compartment.
As there is no air passage between freezer and refrigerator
compartment, there will be no odor mixing.
As a result of these, your fridge with new generation cooling
technology, gives you, ease of use beside the huge volume and
esthetic appearance.

EN
11
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.
1
2
3
4
5
6
7
8
9
10
11
12
13
14

EN
12
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS
A) Fridge compartment
B) Freezer compartment
1) Wine rack *
2) Fridge shelves
3) Chiller *
4) Crisper cover
5) Crisper
6) Freezer top baskets
7) Freezer bottom basket
8) Leveling feet
9) Ice tray
10) Freezer glass shelves
11) Bottle shelf
12 Water dispenser
13) Door shelf
14) Egg holder
* In some models
This presentation is only for information about the parts of the appliance.
Parts may vary according to the appliance model.

EN
13
45
6
7
8
9
1
2
3
Parts of the water dispenser
(A ) Outside the door (water dispenser’s tank group)
(B) Inside the door (Water dispenser’s tank group)
1) Top cover of the water dispenser
2) Valve lever
3) Water dispenser casing
4) Top cover of the water tank
5) Tank cover
6) Side locking covers
7) Water tank
8) Gasket ring
9) Tap detail
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS

EN
14
12
3
2
THE PARTS OF THE APPLIANCE AND THE
COMPARTMENTS

EN
15
THE VARIOUS FUNCTION AND POSSIBILITIES
Display and control panel
Use of control panel
1. It enables the setting of the freezer to be modied and super freeze mode to be
activated, if desired. The Freezer may be set to -16, -18, -20, -22, -24 °C, SF.
2. It enables the setting of the cooler to be modied and super cool
mode to be activated, if desired. The Cooler may be set to 8, 6, 5, 4,
2 °C, SC.
3. It enables the di󰀨erent modes (economy, holiday…) to be activated if desired.
4. Cooler set value screen.
5. Freezer set value screen.
6. Child-lock symbol.
7. Economy mode symbol.
8. Alarm symbol.
9. Holiday mode symbol.
10. Super freeze indicator.
11. Super cooling indicator.
c
c
DEMO
Lighting (If available)
When the product is plugged in for the rst time, the interior lights may turn on 1 minute
late due to opening tests.

EN
16 THE VARIOUS FUNCTION AND POSSIBILITIES
c
c
c
c
Operating your fridge
Super freeze mode
How would it be used?
• Press the Freezer Set Button until SF is shown on the screen.
The buzzer will sound twice and the mode will be set.
• The freezer temperature segment will show “SF”.
During this mode:
• The temperature of the Cooler and Super Cool Mode may be
adjusted. In this case, Super Freeze Mode continues.
• Economy and Holiday Mode cannot be selected.
• Super Freeze Mode can be cancelled in the same way that it
was selected.
Super cool mode
How would it be used?
• Press the Cooler Set Button until SC is shown on the screen. The
buzzer will sound twice and the mode will be set.
• The Cooler temperature segment will show “SC”.
During this mode:
• The temperature of the Freezer and Super Freeze Mode may be
adjusted. In this case, Super Cool Mode continues.
• Economy and Holiday Mode cannot be selected.
• Super Cool Mode can be cancelled in the same way it was
selected.
Economy mode
How would it be used?
• Push the “Mode Button” until a circle appears around economy
symbol.
• If no button is pressed for 1 second, the mode will be set. The
circle will blink 3 times and the buzzer will sound twice.
• The Freezer and Refrigerator temperature segments will show
“E”.
• The circle of the Economy Symbol and E will illuminate until the
mode nishes.
During this mode:
• The Freezer may be adjusted. When Economy Mode is cancelled,
the selected setting values will remain.
• The Cooler may be adjusted. When Economy Mode is cancelled,
the selected setting values will remain.
• Super Cool and Super Freeze modes can be selected. Economy
Mode is automatically cancelled and the selected mode is
activated.

EN
17
THE VARIOUS FUNCTION AND POSSIBILITIES
c
• Holiday Mode can be selected after cancelling the Economy
Mode. The selected mode is activated.
• To cancel, press the Mode Button.
Holiday mode
How would it be used?
• Push the Mode Button until a circle appears around the plane
symbol.
• If no button is pressed for 1 sec, the mode will be set. The Circle
will blink 3 times and the buzzer wil beep twice.
• The Freezer temperature segment will show “H”.
• The Circle of the plane symbol and H will be illuminated until the
mode nishes.
During this mode:
• The Freezer may be adjusted. When Holiday Mode is cancelled,
the selected setting values will remain.
• The Cooler may be adjusted. When Holiday Mode is cancelled,
the selected setting values will remain.
• Super Cool and Super Freeze Modes can be selected. Holiday
Mode is automatically cancelled and the selected mode is
activated.
• Economy Mode can be selected after cancelling the Holiday
Mode. Then, the selected mode is activated.
• To cancel, press the Mode Button.
Drink cool mode
When would it be used?
This mode is used to cool the drinks within adjustable time.
How would it be used?
• Press the freezer button for 3 seconds.
• "dc" will be seen on freezer screen and 05 blinks on the cooler
screen.
• Press the cooler button to adjust the time (05 - 10 - 15 - 20 - 25
- 30 minutes).
• When you select the time the numbers will blink 3 times on
screen and the buzzer will sound twice.
• If no button is pressed within 2 seconds the time will be set.
• The countdown starts from the adjusted time minute by minute.
• The remaining time blinks on the screen.
• To cancel this mode, press the freezer set button for 3 seconds.

EN
18 THE VARIOUS FUNCTION AND POSSIBILITIES
c
c
Screen saver mode
How to use?
• This mode will be activated when you press the mode button for
5 seconds.
• If no button is pressed within 5 seconds when the mode is active,
the lights of the control panel will go out.
• If you press any button when the lights of control panel are o󰀨,
the current settings will appear on the screen, and then you can
maket the adjustment you want. If you do not cancel the screen
saver mode or press any button within 5 seconds, the control
panel will go o󰀨 again.
• To cancel screen saver mode, press the mode button for 5
seconds again.
• When screen saver mode is active, you can also activate child
lock.
• If you do not press any button for 5 seconds after activating child
lock, the lights of the control panel will go o󰀨. Then, you can view
the previous settings and that child lock is active by pressing any
button.You can cancel child lock as described in the instructions
for that mode.
Light cancelling mode
When would it be used?
• Select this mode if you want to cancel the cooler lights.
• This mode is selected by pressing the freezer, cooler or mode
buttons or by opening and closing one of the doors 3 times. From
then on, the lights will not come on until the mode is cancelled
(or after 24 hours).
• If you want to cancel this mode, repeat the same process. This
mode will automatically cancel itself after 24 hours.
Function of Child lock
When would it be used?
Child lock is available on the appliance to prevent children from
playing with the buttons and changing the settings you have
made.
Activating Child Lock
Simultaneously press the Freezer and Cooler buttons for 5
seconds.
Deactivating Child Lock
Simultaneously press the Freezer and Cooler buttons for 5
seconds.
Note: Child lock will also be deactivated if the electricity supply is
interrupted or the fridge is unplugged.
c
c

EN
19
THE VARIOUS FUNCTION AND POSSIBILITIES
c
c
Cooler temperature settings
• The initial temperature value for the Cooler Setting Indicator is
+4 °C.
• Press the cooler button once.
• When you rst press the button, the previous value appears on
the setting indicator of the cooler.
• Whenever you press the button, lower temperatures will be set.
(+8°C, +6°C, +5°C, +4°C, +2°C, supercool).
• If you press the cooler set button until the supercool symbol
appears on the Cooler Setting Indicator and do not press any
buttons within 1 second, Super Cool will ash.
• If you continue to press the button, it will restart from +8°C.
• The temperature value selected before Holiday Mode, Super
Freeze Mode, Super Cool Mode or Economy Mode is activated,
will remain the same when the mode is over or cancelled. The
appliance continues to operate with this temperature value.
c
c
Freezer temperature settings
• The initial temperature value for the Freezer Setting Indicator is
-18°C.
• Press the freezer set button once.
• When you rst press the button, the previous value will blink on
screen.
• Whenever you press on this button, lower temperatures will be
set (-16°C, -18°C, -20°C, -22°C, -24°C superfreeze).
• If you press the freezer set button until the superfreeze symbol
appears on the Freezer Setting Indicator and do not press any
buttons within 1 second, Super Freeze will ash.
• If you continue to press the button, it will restart from -16°C.
• The temperature value selected before Holiday Mode, Super
Freeze Mode, Super Cool Mode or Economy Mode is activated,
will remain the same when the mode is over or cancelled. The
appliance continues to operate with this temperature value.
