ENQUATICS AquaMaster Masters Decorative Series User manual

®
½HP Masters Decorative Series
60Hz Owner’s Manual
A DIVISION OF ENQUATICS INC.

Every AquaMaster® unit is fully inspected and produced in accordance with
applicable standards for safety, and are listed by Underwriters Laboratories, Inc.
(UL) for safety in the USA and Canada. AquaMaster® will continue to build the
best units to assure you, the customer, of many years of enjoyable and reliable
service. AquaMaster’s commitment to excellence ensures superior aquatic
management systems.
All AquaMaster® products are designed and built to be installed with an
AquaMaster® UL Listed control panel and to be operated as a complete system.
Any alterations to or substitution for items in this system, unless allowed by
these installation instructions, will void the UL Listing and will void the product
warranty. It may also create a hazardous installation. Read these instructions
thoroughly before starting your installation and follow them carefully throughout.
WARNING
NOTICE: Save and pass the installation, anchoring and operating instructions
to subsequent owners. The information provided is intended to notify and warn
about making unsafe modications, making unsafe repairs, or using unauthorized
parts or repair facilities.
• Improper installation, operation, service, repair, maintenance or alteration of
this product may result in property damage or bodily injury.
• Turn OFF electrical power at disconnect switch or service panel before
servicing this unit or lighting system.
• Risk of electric shock! This pump or lighting system has not been
investigated for use in swimming pool or marine areas. DO NOT use in
swimming or marine areas.
• Only qualied personnel shall service and install AquaMaster® pumps or
lighting systems. Installation and service to be in accordance with the
National Electric Code and local codes and/or ordinances. This unit is
intended to be operated only after it is properly installed, anchored and
wired.
• Risk of electrical shock! DO NOT operate this unit dry unless testing for
proper rotational/mechanical function (see electrical connections, later in this
manual). If this unit has been inadvertently operated out of the water, the unit
must be serviced by a qualied person before being returned to service.
• Risk of electric shock! This pump and lighting system is supplied with a
grounding conductor. To reduce the risk of electric shock, be certain that it is
connected only to a proper ground. Use a copper conductor of the correct
size from the grounding terminal in the control box to a grounding connection
in the service panel.
• This pump and lighting xtures are provided with exible underwater cable
and strain relief. DO NOT remove as electrical shock and/or damage to this
unit or lighting system could occur.
• Risk of electrical shock! DO NOT remove the wire harness from the pump
housing or underwater disconnect. DO NOT connect conduit to pump.
• This unit and lighting system is intended for water use only. DO NOT operate
out of the water unless checking for proper mechanical/electrical function.
• This lighting system is intended to be used with the AquaMaster® oating
fountain or aeration systems only. DO NOT use this xture in any other
manner.
• Risk of electrical shock! Submerse lighting xtures before turning on.
• This pump and lighting xtures are for fresh water only.

TABLE OF CONTENTS
Assembly Instructions ....................................................................................... 2-6
Electrical Assembly Instructions (Standard Panel)............................................. 7-8
Electrical Assembly Instructions (Upgraded Panel).......................................... 9-10
Digital Timer Operating Instructions...................................................................11-15
Anchoring Instructions.....................................................................................16-19
Maintenance........................................................................................................ 20
Winterization........................................................................................................21
Product Warranty.................................................................................................22
UnderwaterNight GlowLightingSystemWarranty.................................................23
GeneralWarrantyInformation................................................................................23
120 Volt Lamp Replacement.................................................................................24
Troubleshooting Guide ........................................................................................25
ElectricalWiringDiagram.......................................................................................26
AquaLock(ALC)ComponentsView........................................................................27
Internal Fountain Components List.......................................................................28
Internal Parts Drawing.....................................................................................29
Power Units Parts Lists.........................................................................................30
Power Unit Drawing.......................................................................................31
SHIPPING CLAIMS
When you receive your AquaMaster® unit, examine the package for any
signs of external damage it may have sustained enroute. If there is apparent
damage either outside the box or to its contents, make a claim with the shipper
immediately. Save the original shipping carton and the packing material if a claim
is to be led.
Page 1

MASTERS DECORATIVE ASSEMBLY INSTRUCTIONS
WARNING: Read these instructions carefully. Failure to follow these
instructions could cause a malfunction of the system. Improper installation,
wiring or anchoring could result in property damage or bodily injury.
Carefully unpack your unit and inspect for damage.
Parts Included:
1 – Float
1 – Intake Screen with Fasteners
(Nut, Washer and Bolt Included)
1 – Power Unit and Power Cord
6 – ¼-20 Socket Head Cap Screws
1 – 3/16” Allen Wrench
1 – Owners/Instruction Manual
FLOAT ASSEMBLY
1. Slide the oat onto the oat tube until it bottoms against the impeller housing.
The oat must be installed as shown with the inner ring toward the motor.
Installing the oat upside-down will adversely affect its performance.
2. Using the 3/16” Allen wrench, install four (4) of the ¼-20 socket head cap
screws into the upper oat tube mounting holes. These holes are closest to the
grooved end of the oat tube. DO NOT over-tighten the screws.
3. Slide the oat up until the socket head cap screws are seated in the slots on the
top of the oat.
4. Maintain this oat position and install the two (2) remaining ¼-20 socket head
cap screws in the oat tube found on the bottom of the oat. DO NOT
over-tighten the screws.
Pictures and images used in this manual are for representational
purposes only, may not depict the actual product.
Page 2

ASSEMBLY INSTRUCTIONS (CONT.)
SCREEN ASSEMBLY
CAUTION: DO NOT OPERATE WITHOUT THE SUCTION SCREEN IN PLACE.
1. Loosen and remove the nut, lock washer and bolt holding the screen closed.
Save these parts for reuse once the screen is in place.
2. Gently ex open the intake screen far enough to t around the oat tube.
3. After it is installed around the oat and on top of the power unit, close the screen
tabs and reassemble the bolt, lock washer and nut to retain the screen
in its proper location.
NOZZLE ASSEMBLY (optional)
1. Check the nozzle thumbscrews to make sure that they are not extending
beyond the inner mounting surface. If they are, back the thumbscrews out until
the tips are ush with the inner mounting surface. This will allow for easy
installation onto the oat tube.
2. Install the o-ring (provided) into the top oat tube groove. This may have been
done at the factory.
3. Liberally apply grease (provided) to the inside of the nozzle mounting surface
and the o-ring on the oat tube.
4. Slide the open end of the nozzle over the oat tube using a twisting and sliding
motion until the nozzle is fully contacting the top of the oat tube.
5. Carefully tighten the thumbscrews into the lower groove on the oat tube. Using
your hand, check that the nozzle is secure by pulling and twisting the nozzle.
The nozzle should not move.
Page 3

AQUA LOCK (ALC) POWER CORD CONNECTOR
1. Locate the Female end of the ALC on the power cord. Remove the protective
caps from the power cord and fountain.
Note: When your unit and/or lighting system requires removal, protective
caps are provided to assist in maintaining a clean cable connector
environment. Simply hand-tighten one half to your power unit and the other
half to your cable end. When you remove the protective caps, keep them in a
safe place, such as the control panel.
2. Connect the two halves of the ALC together. CAUTION: HAND TIGHTEN
ONLY! DO NOT use tools such as a pipe wrench or pliers as you may over
tighten and damage the connectors.
3. Locate the cable support grip and clip it onto the snap clip located on the motor
housing assembly clamp. This will protect your cord connectors from damage
if the power cord is pulled.
ASSEMBLY INSTRUCTIONS (CONT.)
ALC
Page 4

NIGHT GLOW LIGHTING SYSTEMS
ASSEMBLY INSTRUCTIONS
1. Place light bracket in mating cavity on the underside of the oat as shown in
Figure 1.
2. Insert 3/8” SS bolt through washer, through the oat into light bracket as
shown.
3. Secure the light bracket from the bottom with a 3/8” locking nut and washer.
4. Tighten the nut using (2) 9/16” wrenches or pliers. DO NOT over tighten.
5. Make sure the light retaining clips are in the “open” position. The clips are
positioned without the use of tools.
6. Insert the light housing from the top down as shown in Figure 2.
Figure 2
Light Housing
Light Retaining
Clips
Page 5
Figure 1
3/8-16 SS Bolt
3/8 SS Extra
Thick Washer
Light Bracket
3/8 SS Extra
Thick Washer
3/8-16 SS
Nylock Nut

Figure 3
NIGHT GLOW LIGHTING SYSTEMS
ASSEMBLY INSTRUCTIONS (CONT.)
7. When the light housing is seated into the bracket, turn the retaining clips to
ensure the housing is as shown in Figure 3.
8. After xtures are installed on the oat, connect the AquaLock (ALC) ends
together. HAND TIGHTEN ONLY!
Page 6

ELECTRICAL CONNECTION - STANDARD PANEL
Standard Panel - reference page 32
Electrical Connection to be completed by licensed electrician in accordance with
the National Electric Code and local codes or ordinances.
WARNING: This unit is pre-wired and is provided with a GFCI for your safety
and the safety of your equipment in the event of an electrical short, ground
or equipment failure. DO NOT remove or modify the GFCI. Removal or
modications could result in the danger of electrocution to any one, human or
animal, in contact with the water.
 DO NOT bypass the supplied control panel. The control panel enclosure
is rain-resistant and includes a GFCI breaker and timer. Bypassing the
control panel could result in electrocution to anyone, human or animal, in
contact with the water.
 Underwater splices are dangerous and will void the warranty. Electrical
cable(s) must extend completely onto shore to power source without
breaks or splices.
ELECTRICAL CONNECTION TO CONTROL PANEL
TIMER PANEL ASSEMBLY
1. The unit comes with a timer panel that must be mounted vertically with the
cord holes downward to a solid structure. Correct mounting will prevent rain
entry into the timer panel.
2. Once the panel is securely mounted, open the front cover and plug the timer
panel into a 120V outlet using the power cord supplied.
3. Before installing the fountain into the pond, test run the fountain for 20
seconds by plugging it into the live outlet in the timer panel. The motor should
energize and run smoothly and quietly. Listen for any unusual noises. Do not
continue or install into the pond if the motor is noisy.
4. Install the fountain into the pond and refer to the anchoring instructions on the
following pages. Note: Improper installation can result in damaged property
and power cords.
5. Now the fountain is ready for nal set up. Plug the fountain power cord into
the outlet labeled fountain. This will allow the timer in the panel to control
if the fountain is on or off.
6. Set the timer per the instructions found in the front cover.
Page 7

ELECTRICAL CONNECTION - STANDARD PANEL (CONT.)
BEFORE INSTALLING INTO THE WATER, test the unit briey (30 seconds or
less) to make sure it runs and check for proper rotation (counter clockwise
looking down from top of power unit). Listen for any unusual noises. Unit should
run smoothly and quietly. If single phase rotation is backwards, PLEASE
CONTACT THE FACTORY IMMEDIATELY.
WARNING: Always make sure power is OFF when changing motor direction.
WARNING: DO NOT operate the unit out of the water except for testing and
checking rotation (30 seconds or less). DO NOT attempt maintenance
procedures or adjustments with unit in operation.
WARNING: DO NOT burn the lighting xtures out of the water except to test the
lamps (60 seconds or less). Light lenses MUST BE completely covered with
water to prevent lens failure.
NOTE: Excessive buildup on the lenses may cause the lenses to crack, lamps
to burn out and gaskets to fail. To maintain maximum light output and long lamp
life, cleaning of the lenses may become necessary.
Your line voltage 120 Volt lighting system was designed with your safety in mind.
They include the following:
A. GFCI Protection (in main fountain timer panel)
B. 120 Volt 11 Watt LED lighting
C. Timer Box
WARNING: Your lighting system is pre-wired and is provided with a GFCI
for your safety and the safety of your equipment in event of an electrical
short, ground or equipment failure. Do not remove or modify, to do so
could result in the danger of electrocution to anyone, human or animal, in
contact with the water if an electrical short should occur.
Your lighting system is not intended for use in swimming pools and spas.
Electrical cables must extend completely onto shore to power source without
breaks or splices. Underwater splices are dangerous and will void the warranty.
NOTE: Excessive build up on the lens may cause lens to crack, lamps to burn
out and gaskets to fail. To maintain maximum light output and long lamp life
cleaning of the lens may become necessary.
CAUTION: DO NOT burn the xtures out of the water except to test the
lamps. Light lens has to be covered completely with water to prevent lens
failure.
Page 8

ELECTRICAL CONNECTION - UPGRADED PANEL
Upgraded Panel - reference page 32
Electrical Connection to be completed by licensed electrician in accordance with
the National Electric Code and local codes or ordinances.
WARNING: This unit is pre-wired and is provided with a GFCI for your safety
and the safety of your equipment in the event of an electrical short, ground
or equipment failure. DO NOT remove or modify the GFCI. Removal or
modications could result in the danger of electrocution to any one, human or
animal, in contact with the water.
 DO NOT bypass the supplied control panel. The control panel enclosure
is rain-resistant and includes a GFCI breaker and timer. Bypassing the
control panel could result in electrocution to anyone, human or animal, in
contact with the water.
 Underwater splices are dangerous and will void the warranty. Electrical
cable(s) must extend completely onto shore to power source without
breaks or splices.
 TURN OFF electrical power at fuse box or service panel before making
any electrical connections.
 If supplied with a control panel, DO NOT bypass the control panel. The
control panel enclosure is rain-right and includes a GFCI breaker, timer,
contactor and overload assembly. Bypassing the control panel could
result in electrocution to anyone, human or animal, in contact with the
water.
ELECTRICAL CONNECTION TO CONTROL PANEL
TIMER PANEL ASSEMBLY
1. The unit comes with a timer panel that must be mounted vertically with the
cord holes downward to a solid structure. Correct mounting will prevent rain
entry into the timer panel.
2. Once the panel is securely mounted, open the front cover and plug the timer
panel into a 120V outlet using the power cord supplied.
3. Before installing the fountain into the pond, test run the fountain for 20
seconds by plugging it into the live outlet in the timer panel. The motor should
energize and run smoothly and quietly. Listen for any unusual noises. Do not
continue or install into the pond if the motor is noisy.
4. Install the fountain into the pond and refer to the anchoring instructions on the
following pages. Note: Improper installation can result in damaged property
and power cords.
5. Now the fountain is ready for nal set up. Plug the fountain power cord into
the outlet labeled fountain. This will allow the timer in the panel to control
when the fountain is on and off.
6. Set the timer per the instructions found in the front cover.
ELECTRICAL CONNECTION TO CONTROL PANEL
WARNING: Make sure power is OFF!
1. Take the electrical cable from your unit and securely fasten it to the control
panel.
2. Connect black lead from cable to terminal marked 1T1 on terminal strip.
3. Connect white lead from cable to terminal marked 1T2 on terminal strip.
4. Connect green lead to grounding terminal.

ELECTRICAL CONNECTION - UPGRADED PANEL (CONT.)
Steps A – D are for optional LED lighting system.
a. Take the three (3) conductor cable for the lighting system and securely
fasten it to the control panel.
b. Connect black lead from cable to terminal marked X1 on terminal strip.
c. Connect white lead from cable to terminal marked X2 on terminal strip.
d. Connect green lead to grounding terminal.
Steps E – J are for optional LED RGBW lighting system.
e. Take the ve (5) conductor cable for the lighting system and securely
fasten it to the control panel.
f. Connect black lead from cable to terminal marked X1 on terminal strip.
g. Connect white lead from cable to terminal marked X2 on terminal strip.
h. Connect green lead to grounding terminal.
i. Connect orange lead from cable to terminal marked X4 on terminal strip.
j. Connect red lead from cable to terminal marked X5 on terminal strip.
WARNING: Make sure power is OFF!
1. Connect Line 1 to L1 on terminal strip.
2. Connect Line 2 to L2 on terminal strip (208-240V only).
3. Connect the neutral to N on terminal strip.
4. Connect the ground to the grounding terminal.
5. On 208-240V units, the overload relay must be set to the motor nameplate
value plus two (2) amperes.
BEFORE INSTALLING INTO THE WATER, test the unit briey (30 seconds or
less) to make sure it runs and check for proper rotation (counter clockwise
looking down from top of power unit). Listen for any unusual noises. Unit should
run smoothly and quietly. If single phase rotation is backwards, PLEASE
CONTACT THE FACTORY IMMEDIATELY.
WARNING: DO NOT operate the unit out of the water except for testing and
checking rotation (30 seconds or less). DO NOT attempt maintenance
procedures or adjustments with unit in operation.
WARNING: DO NOT burn the lighting xtures out of the water except to test the
lamps (60 seconds or less). Light lenses MUST BE completely covered with
water to prevent lens failure.
NOTE: Excessive buildup on the lenses may cause the lenses to crack, lamps
to burn out and gaskets to fail. To maintain maximum light output and long lamp
life, cleaning of the lenses may become necessary.
GROUNDING
Permanently ground this unit in accordance with the National Electric Code and
local codes or ordinances. Use a copper conductor of the correct size from the
grounding terminal in the control box to a grounded connection in the service
panel or a properly driven and electrically grounded ground rod.
Page 10

Day Button
1. Apply power to turn the timer on.
2. Press the RESET button to clear all data from memory. Use a pen point to
press.
SETTING THE CLOCK
1. Press and hold the CLOCK button.
2. While holding the CLOCK button, press the DAY, HOUR or MINUTE button to
the desired day / time.
Note: You must advance past 12:00 to set PM.
3. Release the CLOCK button.
Reset
Button
Minute
Button
Hour
Button
Timer Button
Clock
Button
On Button
DIGITAL TIMER OPERATING INSTRUCTIONS
Page 11

DIGITAL TIMER OPERATING INSTRUCTIONS (CONT.)
PROGRAMMING
1. There are 15 daily program settings built into the timer.
a. MO TU WE TH FR SA SU
b. MO
c. TU
d. WE
e. TH
f. FR
g. SA
h. SU
i. MO TU WE TH FR
j. SA SU
k. MO TU WE TH FR SA
l. MO TU WE
m. TH FR SA
n. MO WE FR
o. TU TH SA
2. Press the TIMER button once. "1ON --:--" appears.
3. Press the DAY button repeatedly for desired days ON.
Ex. Mo Tu We Th Fr Sa Su.
4. Press the HOUR / MIN button repeatedly for desired ON time.
Note: You must advance past 12:00 to set PM.
5. Press the TIMER button once. "1OFF --:--" appears.
6. Press the DAY button repeatedly for desired days OFF.
Note: Must match "1ON" day settings.
7. Press the HOUR / MIN button repeatedly for desired OFF time.
Note: You must advance past 12:00 to set PM.
8. Repeat steps 1 through 7 for more events if desired, up to a maximum of 8
ON/OFF events per day.
9. When nished programming, press the CLOCK to execute programs.
10. Press the MANUAL button until the line is above AUTO.
Page 12

DIGITAL TIMER OPERATING INSTRUCTIONS (CONT.)
PROGRAMMING (CONT.)
Program Example 1
Simple 7 Day Week Program - Timer to turn on at 7:00 AM everyday and off at
11:30 PM everyday.
PROGRAM KEY DISPLAY
EVENT 1 - ON
1. Press the TIMER button. "1ON --:--" appears.
2. Press the DAY button until Mo through Su is displayed.
3. Press the HOUR button until 7:00 AM appears.
4. Use the MIN button until :00 appears.
5. Press the TIMER button. "1OFF --:--" appears.
EVENT 1 - OFF
1. Press the DAY button until Mo though Su is displayed.
2. Press the HOUR button until 11:00 PM appears.
3. Press the MIN button until :30 PM appears.
4. Press the CLOCK button to execute the program.
5. Press the MANUAL button until the line is above AUTO.
Program Example 2
3 Event Program
Event 1:
Turn timer ON at 7:30 AM and OFF at 11:30 PM Monday through Friday.
Event 2:
Turn timer ON at 8:00 AM Saturday and turn timer OFF at 2:00 AM Sunday.
Event 3:
Turn timer ON at 9:00 AM Sunday and turn timer OFF at 10:00 PM Sunday.
This is a 3 event program. There will be 5 events left if needed.
EVENT 1 - ON (Timer is ON at 7:30 AM Monday through Friday)
PROGRAM KEY DISPLAY
1. Press the TIMER button. "1ON --:--" appears.
2. Press the DAY button until Mo Tu We Th Fr appears.
3. Press the HOUR button until 7:00 AM appears.
4. Press the MIN button until :30 AM appears.
5. Press the TIMER button. "1OFF --:--" appears.
Page 13

DIGITAL TIMER OPERATING INSTRUCTIONS (CONT.)
Program Example 2 (cont.)
EVENT 1 - OFF (Timer is OFF at 11:30 PM Monday through Friday)
1. Press the DAY button until Mo Tu We Th Fr appears.
2. Press the HOUR button until 11:00 PM appears.
3. Press the MIN button until :30 PM appears.
4. Press the TIMER button until "2ON --:--" appears.
EVENT 2 - ON (Timer is ON at 8:00 AM Saturday)
1. Press the DAY button until Sa appears.
2. Press the HOUR button until 8:00 AM appears.
3. Press the TIMER button until "2OFF --:--" appears.
EVENT 2 - OFF (Timer is OFF at 2:00 AM Sunday)
1. Press the DAY button until Su appears.
2. Press the HOUR button until 2:00 AM appears.
3. Press the TIMER button until "3ON --:--" appears.
EVENT 3 - ON (Timer is ON at 9:00 AM Sunday)
1. Press the DAY button until Su appears.
2. Press the HOUR button until 9:00 AM appears.
3. Press the TIMER button until "3OFF --:--" appears.
EVENT 3 - OFF (Timer is OFF at 10:00 PM Sunday)
1. Press the DAY button until Su appears.
2. Press the HOUR button until 10:00 PM appears.
3. Press the CLOCK button to execute the program.
4. Press the MANUAL button until the line is above AUTO.
Page 14

DIGITAL TIMER OPERATING INSTRUCTIONS (CONT.)
REVIEWING PROGRAMMED EVENTS
To review the events at any time, press the TIMER button, "1ON" will be displayed.
Press the TIMER button again to review the "1OFF" setting. Press the TIMER
button repeatedly to review events 2 through 8. Press the CLOCK button to return
to the time of day.
CHANGING AN EVENT
1. Press the TIMER button repeatedly until the event that you wish to change is
displayed.
2. Press the DAY, HOUR, or MIN button to adjust the event setting.
3. Press the CLOCK button to return to the time of day.
Note: If you need to delete an on / off time, you must RESET the timer.
HOW TO REPLACE THE BATTERIES
1. The timer is equipped with a CR2032 lithium battery which keeps the time on
the timer correct if power is removed from the timer.
2. To replace the battery, use a coin to remove the battery cover on back of the
timer. Turn the cover one quarter turn clockwise and remove the cover.
3. Using a small screwdriver, pry out the battery. Install the new battery and
replace the cover.
Note: The timer settings will be retained for approximately one (1) minute once
the battery is removed.
Note: The battery can be purchased in most local drug and big box stores.
TEMPORARY OVERRIDE
1. When the timer's output status is "ON".
Press the MANUAL key to move the indicator from "AUTO" to "OFF", timer
shall turn to "OFF" status, programs overrided. Press the MANUAL again to
switch the timer status to "AUTO", timer's output shall continue maintaining
"OFF". Timer shall resume its automatic operation when the next program
(event) calls for "ON".
2. When the timer's output status is "OFF".
Press the MANUAL key, to move the indicator from "AUTO" to "ON", timer
shall turn to "ON" status, programs overrided. Press the MANUAL again to
switch the timer's status to "AUTO", the timer's output shall continue
maintaining "ON". The timer shall resume its automatic operation when the
next program (event) calls for "OFF".
Page 15

ANCHORING INSTRUCTIONS
CAUTION: If the unit is not properly anchored with adequate tension, the unit will
rotate when in operation, resulting in twisted and damaged electrical cable(s).
FIGURE 1 is most applicable for a smaller pond, or one that is easily accessible
from two sides.
Required Equipment (not provided)
• Two (2) anchor lines (1/4 inch nylon, 1/8” stainless steel cable, or
equivalent).
• Two (2) stakes (wood stake or metal rod that can be driven securely into
pond’s edge).
Anchoring Steps
1. With the unit fully assembled and still on shore, attach anchor lines
to the oat. Only use the anchor holes which are opposite from one
another. Next, carefully lower unit into the pond. DO NOT tangle anchor
lines and electrical cable(s).
2. Once the unit is oating freely hold or secure one anchor line. With
second line, walk slowly away from the rst stake to opposite side of
pond, pulling the unit with you. Continue until unit is in desired location.
3. Secure all lines, keeping tension on all. Make sure electrical cable(s) is
untangled and has some slack from unit to shore.
Stake Stake
Anchor Line
FIGURE 1
Page 16

ANCHORING INSTRUCTIONS (CONT.)
CAUTION: If the unit is not properly anchored with adequate tension, the unit will
rotate when in operation, resulting in twisted and damaged electrical cable(s).
In a larger body of water or where vandalism is a concern, FIGURE 2 is the
preferred method.
Required Equipment (not provided)
• Two (2) anchor lines (1/4 inch nylon, 1/8” stainless steel cable or
equivalent). Anchor line length should equal twice the depth of the pond
at point of installation. (Example, if pond depth is eight feet, each anchor
line should be at least sixteen feet.) If the depth of the pond varies more
than three feet use FIGURE 1.
• Two (2) anchors (eight inch concrete blocks, approximate weight of 30
pounds each is sufcient).
Anchoring Steps
1. With unit fully assembled and still on shore, attach anchor lines to the
oat. Only use the anchor holes which are opposite from one another.
Next, carefully lower unit into the pond. DO NOT tangle anchor lines
and electrical cable(s).
2. Position unit at desired location in pond, playing out electrical cable(s)
from shore. Attach anchor lines to anchors and anchor unit making
sure you cannot rotate unit more than 45 degrees. Some movement
is necessary to allow oat to move up and down with changes in water
depth. If you can rotate oat more than 45 degrees, adjust anchor
lines or relocate anchors.
Anchor Line
Anchor
FIGURE 1
Page 17
