How to Use This Guide

UsethisguidetoquicklysetupyourEnterasys®C5switch.

EnterasysNetworksrecommendsthatyourefertothe

EnterasysC5GigabitEthernetSwitchHardwareInstallationGuidefor

specificationsandsafetywarnings.

ThelatestC5documentationislocatedat:

www.enterasys.com/support/manuals

Hardware Components

Thefollowingfiguresshowtheseveraltypesoffrontpanelport

andrearpanelconnectionsonyourC5switch.

Figure 1 C5 Switch Front Panels

C5G124-24, C5G124-24P2

C5G124-48, C5G124-48P2

C5K125-24, C5K125-24P2

C5K125-48, C5K125-48P2

C5K175-24

Figure 2 C5 Switch Back Panels

Non-PoE C5 Switches

PoE C5 Switches

Key

1Switch status LEDs 8Console port

2RJ45 10/100/1000 Mbps ports 9Stack connection ports

3SFP slots 10 Rotary switch

4SFP+ slots 11 Password reset button

5RJ45 port status LEDs 12 AC power input connector

6SFP port status LEDs 13 Redundant power supply

7SFP+ port status LEDs (RPS) connector

Handling the Switch

Topreventelectrostaticdamage,attachanelectrostaticdischarge

(ESD)wriststraptoyourwristbeforehandlingtheswitch.

Unpacktheswitchasfollows:

1. Removethepackingmaterialprotectingtheswitch.

2. Removethetapesealonthenon‐conductivebagtoremovethe

switch.

3. Performavisualinspectionoftheswitchforanysignsof

physicaldamage.ContactEnterasysNetworksifthereareany

signsofdamage.See“GettingHelp”formoreinformationon

contactingEnterasysNetworks.

Stacking Switches

UptoeightC5switchescanbestackedtogetherandconnectedby

high‐speedstackingcables,whichallowtheentirestacktooperate

withasingleIPaddress.

TheC5supportsthefollowinghigh‐speedstackingcablesonly,

whichyoumustorderseparately:

•STK‐CAB‐SHORT

•STK‐CAB‐LONG

•STK‐CAB‐2M

•STK‐CAB‐5M

Forcompleteinformationaboutstacking,refertotheEnterasysC5

GigabitEthernetSwitchHardwareInstallationGuide.

Connecting Power to the Switch

Youcanconnecttoasingle,primarysourceofpower,ortotwo

sourcesofpowerforredundancy.Theexampleusedhere

describesconnectingtotwopowersources.

Thefollowingredundantpowersuppliesareavailabletobe

purchasedfromEnterasysNetworksforconnectiontoaC5

switch:

•STK‐RPS‐150PS,a102‐156wattDCpowersupplycapableof

providingpowertoafully‐loadednon‐PoEswitch.

•STK‐RPS‐1005PS,a1005wattDCpowersupplyrecommended

forfullPoEcapability.

Topower‐upyourC5switch:

1. Attachthepowercordfromyourredundantpowersupply

intotheC5switch’sredundantpowerreceptacle.

2. AttachtheACpowercordtotheC5switch’sACpower

receptacle.

3. PlugtheredundantpowersupplyandtheC5switchAC

powercordsintodedicated,groundedACoutlets.

4. Oncepowerisconnected,verifythattheCPU(system)LED

turnsamberuntiltheC5switchfinishesitsinitialization.

Iftheinitializationprocessissuccessful,theCPULEDturnsgreen.

IftheCPULEDdoesnotturngreen,refertotheEnterasysC5

GigabitEthernetSwitchHardwareInstallationGuidefor

troubleshootinginformation.

Caution: The switch can be damaged by electrostatic discharge.

Note: You can stack a C5 switch only with other C5 switches.

Electrical Hazard: Only qualified personnel should perform

installation procedures.

Completing Switch Setup and Downloading the Latest

Firmware

OnceyouhaveconnectedpowertotheC5switchandverified

LEDactivity,youcancompletethesetupprocessasfollows.Refer

totheEnterasysC5GigabitEthernetSwitchHardwareInstallation

Guideformoreinformation.

1. DeterminethelatestC5firmwareversionbyvisitingthe

EnterasysNetworksdownloadsiteat:

http://secure.enterasys.com/services/support/downloads/software

2. Connecttheswitchtothenetwork.

3. Connectamanagementstationtotheconsoleport.

4. Verifythatthenetworkdevicesconnectedtotheswitchports

arepoweredon,andthateachlink/activityLEDison(solid

greenorblinkinggreen).

5. Atthedeviceconnectedtotheconsoleport,performthe

following:

a. EnteradminforUsername.

b. AtthePasswordprompt,pressENTER(RETURN).

c. Atthecommandprompt,determineifthelatestfirmware

imageisloadedontheswitchbyenteringthiscommand:

show version

d. Iftheoutput(underFWVer si on )displaysanolderversion

numberthanthatdeterminedinstep1,downloadand

activatethenewversionasdirectedonthedownload

website.(Alternatively,youcanusetheCLIcommands

listedinTable 1.)

Basic Setup Commands

Table 1listsCLIcommandsthatarerequiredforsettinguptheC5

switchwiththelatestfirmware.Table 2listsadditional

configurationcommandsforyourC5switch.Forthecompletelist

ofCLIcommands,seetheEnterasysC5CLIReference.

Table 1 Required CLI Setup Commands

Step Task CLI commands

1Set a new password set password [username]

2Set the switch IP address set ip address ip-address

[mask ip-mask] [gateway

ip-gateway]

3Download, activate, and

verify new firmware on the

switch using TFTP copy

Note: You can reboot the

system immediately with the

set boot system command,

or reboot later with the reset

command.

copy

tftp://tftp_server_ip_address/

filename system:image

set boot system filename

show version

Table 2 Optional CLI Setup Commands

Task CLI commands

Save the active configuration save config

Enable or disable SSH set ssh enable | disable

Enable or disable Telnet set telnet {enable | disable}

[inbound | outbound | all]

Enable or disable HTTP

management (WebView)

set webview {enable | disable}

Enable or disable SNMP port link

traps

set port trap port-string

{enable | disable}

Set the per port broadcast limit set port broadcast port-string

threshold-value

Configure a VLAN set vlan create vlan-id

set port vlan port-string

vlan-id modify-egress

Set a Syslog server IP and severity set logging server index

ip-addr ip-addr severity

severity state enable

Specifications

Foracompletelistofspecifications,seetheEnterasysC5Gigabit

EthernetSwitchHardwareInstallationGuide.

Interfaces

Switch Dimensions

Size: 44.1Wx4.4Hx36.85Dcm

17.4Wx1.7Hx14.5Din

Power Consumption

InputVoltage:100to240VAC

Temperature and Humidity

Operatingtemperature:0°Cto50°C

Storagetemperature:‐40°Cto+70°C

Operatingrelativehumidity:5%to95%

Getting Help

Configure and enable a RADIUS

server

set radius server index

ip-addr port [secret-value]

{realm {management-access |

any | network-access}

set radius enable

Table 3 C5 Interface Descriptions

C5G124-24 • 24 10/100/1000Base-T ports

• Four combo SFP ports

C5G124-24P2 • 24 10/100/1000Base-T 802.3af and 802.3at

PoE-capable ports

• Four combo SFP ports

C5G124-48 • 48 10/100/1000Base-T ports

• Four combo SFP ports

C5G124-48P2 • 48 10/100/1000Base-T 802.3af and 802.3at

PoE-capable ports

• Four combo SFP ports

C5K125-24 • 24 10/100/1000Base-T ports

• Two combo SFP ports
