Entrematic SPRINT PN User manual

Ditec SPRINT
Automation for swing
doors
(translation of the original instructions)
www.ditecentrematic.com
IP2185EN
Technical Manual

32
IP2185EN - 2015-09-21

33
IP2185EN - 2015-09-21
Contents
Key
i
This symbol indicates instructions or notes regarding safety, to which special atten-
tion must be paid.
This symbol indicates useful information for the correct functioning of the product.
Subject Page
1. General safety precautions 33
2. Declaration of incorporation of partly completed machinery 34
2.1 Machinery Directive 34
3. Technical specifications 35
3.1 Operating instructions 36
3.2 Dimensions 36
4. Standard installation 37
5. Main components 38
6. Mechanical installation 39
6.1 Removing the casing 39
7. Installation with SBS sliding arm 40
8. Installation with SBA articulated arm 41
9. Installation with SPRINTBRAS 3-lever articulated arm 42
10. Installing the end stop on the ground 43
11. Electrical connections 44
11.1 Electrical connections for 230V - 120V power supply 45
11.2 Electrical connections for 24V power supply 46
12. Connecting the power supply 46
13. Commands 46
13.1 Testable safety devices 47
14. Outputs and accessories 48
14.1 Function selector button 48
15. Electromagnetic emissions 49
16. Adjustments 49
16.1 Enabling procedure 49
16.2 Dip-switches 50
16.3 Trimmer 50
16.4 Signals 51
17. Door requisites for transit of disabled people 52
18. Start-up 53
19. Troubleshooting 54
20. Routine maintenance plan 55
21. Example of installation with function selector 56
Factory settings

34
IP2185EN - 2015-09-21
1. General safety precautions
This installation manual is intended for qualified personnel only.
Installation, electrical connections and adjustments must be performed in accordance with
Good Working Methods and in compliance with the present standards.
Read the instructions carefully before installing the product.
Incorrect installation could be dangerous.
The packaging materials (plastic, polystyrene, etc.) should not be discarded in the environ-
ment or left within reach of children, as they are a potential source of danger.
Before installing the product, make sure it is in perfect condition.
Do not install the product in explosive areas and atmospheres: the presence of inflammable
gas or fumes represents a serious safety hazard.
Before installing the motorisation device, make all the necessary structural modifications to
create safety clearance and to guard or isolate all the crushing, shearing, trapping and general
hazardous areas.
Make sure the existing structure is up to standard in terms of strength and stability. The mo-
torisation device manufacturer is not responsible for failure to observe Good Working Methods
when building the frames to be motorised, or for any deformations during use.
The safety devices (photocells, safety edges, emergency stops, etc.) must be installed taking
into account the applicable laws and directives, Good Working Methods, installation premises,
system operating logic and the forces developed by the motorised door.
The safety devices must protect the crushing, shearing, trapping and general hazardous areas
of the motorised door.
Display the signs required by law to identify hazardous areas.
Each installation must bear a visible indication of the data identifying the motorised door.
When requested, connect the motorised door to an effective earthing system that complies
with current safety standards.
During installation, maintenance and repair operations, cut off the power supply before opening
the cover to access the electrical parts.
The automation protection casing must be removed by qualified personnel only.
The electronic parts must be handled using earthed antistatic conductive arms. The
manufacturer of the motorisation device declines all responsibility if component parts
not compatible with safe and correct operation are fitted.
Only use original spare parts when repairing or replacing products.
The installer must supply all information on the automatic, manual and emergency operation
of the motorised door, and must provide the user with the operating instructions.
Failure to respect the information given in this manual
may cause personal injury or damage to the device.
Keep these instructions for future reference

35
IP2185EN - 2015-09-21
2. Declaration of incorporation of partly com-
pleted machinery
2.1 Machinery Directive
(Directive 2006/42/EC, Annex II-B)
The manufacturer Entrematic Group AB, with headquarters in Lodjursgatan 10, SE-261 44 Land-
skrona, Sweden, declares that the automation for Ditec SPRINT type swing doors:
- has been constructed to be installed on a manual door to construct a machine pursuant to the
Directive 2006/42/EC. The manufacturer of the motorised door shall declare conformity pursu-
ant to the Directive 2006/42/EC (Annex II-A), prior to the machine being put into service;
- conforms to the applicable essential safety requirements indicated in Annex I, Chapter 1 of the
Directive 2006/42/EC;
- conforms to the Low Voltage Directive 2006/95/EC;
- conforms to the Electromagnetic Compatibility Directive 2004/108/EC;
- the technical documentation conforms to Annex VII-B of the Directive 2006/42/EC;
- the technical documentation is managed by Marco Pietro Zini with headquarters in Via Mons.
Banfi, 3 - 21042 Caronno Pertusella (VA) - ITALY;
- a copy of technical documentation will be provided to national competent authorities, following
a suitably justified request.
Landskrona, 15-01-2013 Marco Pietro Zini
(Chairman)
Pursuant to the Machinery Directive (2006/42/EC), the installer who motorises a door or gate has
the same obligations as the manufacturer of machinery and as such must:
- prepare the technical data sheet which must contain the documents indicated in Annex V of the
Machinery Directive;
(The technical data sheet must be kept and placed at the disposal of competent national authori-
ties for at least ten years from the date of manufacture of the motorised door);
- draw up the EC Declaration of Conformity in accordance with Annex II-A of the Machinery Direc-
tive and deliver it to the customer;
- affix the EC marking on the motorised door in accordance with point 1.7.3 of Annex I of the
Machinery Directive.
M
arc
o P
iet
ro
Zin
i
(
Cha
irm
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
m
an)
an)
n)
an)
an
)
an)
an
n)
)
)
)
)
)
an)
an
n
n
an)
)
)
n)
)
an
an)
n)
n
n
n
n
an
n
n
n
n
n)
n)
)
)
an
a
a
a
a
a
n
n
n
n
n)
)
)
)
)
a
a
a
a
a
a
a
a
a
an)
)
)
)
)
a
an
a
a
a
an
a
a
a
an
an
)
)
)
)
)
a
an
a
an
a
an)
)
)
)
)
a
a
an
)
)
)
an
a
an
)
)
)
)
)
n
n
n
n
n
n
n
n
n
n
n
n
n
n
n
n
n
n
