Philio PAN45 User manual

Smart Energy Plug PAN45
This plug-in ON/OFF switch PAN45 is a devices displaying the Z-Wave PlusTM logo can
also e used security ena led wireless switch, ased on Z-Wave Plus technology. Z-
Wave PlusTM ena led with it regardless of the manufacturer, and can also e used in
other manufacturer’s Z-WaveTM ena led networks. Remote On/Off control of the con-
nected load is possi le with another manufacturer’s wireless Controller. Each switch is
designed to act as a repeater. Repeaters will re-transmit the RF signal to ensure that the
signal is received y its intended destination y routing the signal around o stacles and
radio dead spots. Because PAN45 supports Security Command Class, it can learn with
Secured controller. Its functionality and supported command classes are identical when
included as a secure and non-secure device. It also have Zig ee as a repeater.
This plug-in ON/OFF switch is a le to detect instance wattage (3000W/230Vac/13A)
and overload current (14.5A with resistive load) of connected lights or appliances. When
detecting overload state, the Switch will e disa led and it’s On/Off utton will e lock-
out of which LED will flash quickly. However, unplug and reconnect the switch will re-
set its overload condition to normal status.
Specification
Operating Voltage 100V-240V~ 50Hz-60Hz
Maximum Load (Ampere) 13A (Resistive load)
Range Minimum 40 m in door 100m outdoor line of sight
Operating Temperature 0°C ~ 40°C, 85%RH max
Location In door use
Frequency Range Z-Wave: 868.40MHz & 869.85MHz (EU)
Zig ee: 2405-2480MHz
RF Maximum Power +10dBm (Peak), -10dBm (Average) for Z-wave
+10dBm for Zig ee
** Specifications are su ject to change and improvement without notice.
Troubleshooting
Symptom Cause of Failure Recommendation
The Switch not working
and LED off
1.The Switch is not plugged into
the electrical outlet properly
2.The Switch reak down
1. Check power connections
2. Don’t open up the Switch
and send it for repair.
The Switch LED illumi-
nating, ut cannot control
the Switch of the load at-
tached
1.Check if the load plugged into
the Switch has its own ON/OFF
switch
2. The switch is protected
1. Set the ON/OFF switch of
the load attached to ON
2. Unprotected the switch or
follow the instruction of pro-
tection.
The Switch LED illumi-
nating, ut the Detector
cannot control the Switch
1. Not carry out association
2. Same frequency interference
1. Carry out association
2. Wait for a while to retry
LED keep flashing, ut
cannot control Overload occurs
Remove the load attached or
check max. load cannot ex-
ceed 13A (Resistive load)

For nstruction to http://www.philio-tech.com
DANGER
Danger of electrocution!
All works on the device may e performed only y a qualified and licensed elec-
trician. O serve national regulations.
Any works introducing changes into the configuration must be always per-
formed with disconnected voltage.
Choosing a Suita le Location
1. Do not locate the Module facing direct sunlight, humid or dusty place.
2. The suita le am ient temperature for the Module is 0°C~40°C.
3. Do not locate the Module where exists com usti le su stances or any
source of heat, e.g. fires, radiators, oiler etc.
4. After putting it into use, the ody of Module will ecome a little it hot of
which phenomenon is normal.
Product overview
Warning:
1.Plug out to disconnect from power supply; Do not plug in line.
2. Do not exceed the max rating.

Adding to Z-WaveTM and Zigbee Network
In the front casing, there is an on/off utton with two led indicator. The red led
shows Z-Wave state and the green one shows Zig ee state. The ta le elow lists
an operation summary of asic Z-Wave and Zig ee functions. Please refer to the
instructions for your Z-WaveTM or Zig ee Certificated Primary Controller to ac-
cess the Setup function, and to include/exclude/reset devices.
Warning:
1.Plug out to disconnect from power supply; Do not plug in line.
2.Do not exceed the max rating.
Z-Wave
Function Description Annotation
No node ID The Z-Wave Controller does not allo-
cate a node ID to the Switch.
LED 2-second on, 2-second
off
add 1.Put your Z-Wave controller into
inclusion mode y following the in-
structions provided y the controller
manufacturer.
2.Pressing On/Off utton three
times within 2 seconds will enter
inclusion mode.
Smart start 1.To initiate the SmartSart pro-
cess, please type in the first five
digits of DSK string or scan the
QR code. The QR Code can e
found on PAN45 or in the ox.
Ex:
DSK:18112-24021-58001-62259-
57092- 27453-08187-47408
2.PAN45 is supported with Smart-
Start, it can e added to Z-Wave™
network y scanning the Z-
Wave™ QR code on the product.
3.Without further actions, PAN45
will e automatically included in a
certified Z-Wave™ Controller
with SmartStart inclusion a ility
in 10 minutes after it turned on.
Remove 1.Put your Z-Wave controller into ex-
clusion mode y following the in-
structions provided y the controller
manufacturer.
2.Pressing On/Off utton three times
within 2 seconds will enter exclusion
mode.
3.Node ID has een excluded. LED 2s On, 2s Off
Reset 1.Pressing On/Off utton three
times within 2 seconds will enter
inclusion mode.
Use this procedure only in
the event that the primary
controller is lost or other-
wise inopera le.
2.Within 1 second, press On/Off ut-
ton again for 5 seconds.

3.IDs are excluded. LED 2s On, 2s Off (Enter
auto inclusion)
Association 1.The PAN45 is an always listening
Z-Wave device, so associations may
e added or removed y a controller
at any time. Or If your controller re-
quires to have the PAN45 send a
node information frame or NIF for
associations, then pressing the On/
Off utton three times within 2 sec-
onds will cause the PAN45 to send its
NIF.
2.There is only one group for the
switch
Including a node ID allocated y Z-Wave Controller means inclusion. Excluding a
node ID allocated y Z-Wave Controller means exclusion.
Failed or success in including/excluding the node ID can e viewed from the Z-
Wave Controller.
Zigbee
Function Description Annotation
No node ID The Zig ee Controller does not allo-
cate a node ID to the Switch.
LED flashes 0.1s every 3s
last for three minutes
add 1.Put your Zig ee controller into
inclusion mode y following the in-
structions provided y the controller
manufacturer.
2.Pressing On/Off utton five
times within 3 seconds will enter
inclusion mode.
Remove 1.Put your Zig ee controller into ex-
clusion mode y following the in-
structions provided y the controller
manufacturer.
2.Pressing On/Off utton five times
within 3 seconds will enter exclusion
mode.
3.Node ID has een excluded. LED flashes 0.1s every 3s
last for three minutes
Reset 1.Pressing On/Off utton six times
within 3 seconds and hold at least
5s at the sixth time to reset device.
Use this procedure only in
the event that the primary
controller is lost or other-
wise inopera le.
2.Within 1 second, press On/Off ut-
ton again for 5 seconds.
3.IDs are excluded. LED 2s On, 2s Off (Enter
auto inclusion)
Including a node ID allocated y Zig ee Controller means inclusion. Excluding a
node ID allocated y Zig ee Controller means exclusion.
Failed or success in including/excluding the node ID can e viewed from the Zig -
ee Controller.
LED ndication
To distinguish what mode the switch is in, view from the LED for identification.
Z-Wave
State Type LED ndication
Normal Under normal operation, toggle On/Off utton etween On and Off. When
pressing On, LED lights up, whereas Off, LED is off.
No node ID Under normal operation, when the Switch has not een allocated a node ID,
the LED flashes on and off alternately at 2-second intervals. By pressing
On/Off utton, it will stop flashing temporarily.

Learning When PAN45 is in learning mode, LED flashes on and off alternately and
repeatedly at 0.5 second intervals.
Zigbee
State Type LED ndication
Tx/Rx Flash 1ms.
No node ID Under normal operation, when the Switch has not een allocated a node ID,
the LED flashes 0.5s every 3s last for 3 minutes.
Learning When Zig ee is in learning mode, LED flashes on and off alternately and
repeatedly at 0.5 second intervals.
Learning
complete
LED 1s on, 1s off 3 times.
Learning fail LED 0.3s on, 0.3s off 5 times
Choosing a Suitable Location
1. Do not locate the Switch facing direct sunlight, humid or dusty place.
2. The suita le am ient temperature for the Switch is 0°C~40°C.
3. Do not locate the Switch where exists com usti le su stances or any source
of heat, e.g. fires, radiators, oiler etc.
4. After putting it into use, the ody of Switch will ecome a little it hot of
which phenomenon is normal.
nstallation
1. Plug this On/Off Switch into a wall outlet near the load to e controlled.
2. Plug the load into the Switch. Make sure the load to e controlled cannot
exceed 13A.
3. Press the utton or switch on the load to the ON position.
4. To manually turn ON the Switch, press and release the On/Off utton. The
LED will turn ON, and the load plugged into the Switch will also turn ON.
5. To manually turn OFF the Switch, simply press and release the On/Off ut-
ton. The LED will turn OFF and the load plugged into the Switch will also
turn OFF.
Programming
1. Basic Command Class / Binary Switch Command Class
The Switch will respond to BASIC and BINARY commands that are part of
the Z-Wave system.
1-1 BASIC_GET / BINARY_SWITCH_GET
Upon receipt of the following commands from a Z-Wave Controller, the
Switch will report its On/Off state to the node asked.
Basic Get Command: [Command Class Basic, Basic Get]
Basic Report Command:
Report OFF: [Command Class Basic, Basic Report, Value = 0(0x00)]
Report ON:[Command Class Basic, Basic Report, Value = 255(0xFF)]
Binary Switch Get Command:[Command Class Switch Binary, Switch
Binary Get]
Binary Switch Report Command:
Report OFF:[Command Class Switch Binary, Switch Binary Report,
Value =0(0x00)]
Report ON:[Command Class Switch Binary, Switch Binary Report,
Value = 255(0xFF)]
1-2 BASIC_SET / SWITCH_BINARY_SET
Upon receipt of the following commands from a Z-Wave Controller, the load
attached to the Switch will turn on or off.
[Command Class Basic, Basic Set, Value = 1~99,255(0xFF)]: the load

attached to the Switch turns on.
[Command Class Basic, Basic Set, Value = 0(0x00)]: the load attached
to the Switch turns off.
[Command Class Switch Binary, Switch Binary Set, Value = 1~99,
(255)0xFF]: the load attached to the Switch turns on.
[Command Class Switch Binary, Switch Binary Set, Value = 0(0x00)]:
the load attached to the Switch turns off.
1. Z-Wave’s Groups (Association Command Class Version 2)
The Switch can e set to send reports to associated Z-Wave devices. It supports
one association group with one node support for Grouping 1. For group 1, the
Switch will report its latest status to Z-Wave Controller. Grouping 1 includes,
SWITCH_BINARY_REPORT, METER_REPORT, ALARM_REPORT.
2-1 Auto report to Grouping 1 (Maximum Node 5)
2-1-1 On/Off Event Report
When “on” or “off” state has een changed, it will send Binary Switch Report
to the node of Grouping 1.
Binary Switch Report
ON: [Command Class Switch Binary, Switch Binary Report, Value
=255(0xFF)]
OFF: [Command Class Switch Binary, Switch Binary Report, Value
=0(0x00)]
2-1-2 Instant Power Consumption vary over 5% report
When the power consumption of load varies over 5%, it will send Meter report
to the nodes of Grouping 1.
Meter Report Command:
[Command Class Meter ，Meter Report ，Rate Type = 0x01 ，Meter
Type = 0x01，Precision = 1，Scale = 0x02，Size = 4，Meter Value(W) ]
2-1-3 Overload alarm report
When PAN45 detects the current is more than 14.5A, it will send Alarm Report
to Group 1 node.
The content of Alarm Report
Alarm report command:
[Command_Class_Alarm, Alarm_Report, Alarm Type = 0x08, Alarm
Level = 0xFF]
2-2 Response to Meter Get Command
The Switch will report its (1) instant Power Consumption (Watt) or (2) accumu-
lated power consumption (KWH) or (3) AC load Voltage (V) or (4) AC load
current (I) (5) load power factor (PF) to Z-Wave Controller after receive the
Meter Get Command from Z-Wave Controller.
2-2-1 Instant Power Consumption (Watt) of Switch
When receiving Meter Get Command, it will report Meter Report Command to
the node.
Meter Get Command: [Command Class Meter, Meter Get, Scale
=0x02(W)]
Meter Report Command:
[Command Class Meter，Meter Report，Rate Type = 0x01，Meter
Type =
0x01，Precision = 1，Scale = 0x02，Size = 4，Meter Value(W) ]
Example:
Meter Value 1 = 0x00 (W)
Meter Value 2 = 0x00 (W)
Meter Value 3 = 0x03 (W)
Meter Value 4 = 0xEA (W)
Meter(W) = Meter Value 3 *256 + Meter Value 4 = 100.2W
2-2-2 Accumulated Power Consumption (KWh)
When receiving Meter Get Command, it will report Meter Report Command to

the node.
Meter Get Command:
[Command Class Meter, Meter Get, Scale = 0x00 KWh)]
Meter Report Command:
[Command Class Meter，Meter Report，Rate Type = 0x01 ，Meter
Type = 0x01，
Precision = 2，Scale = 0x00，Size = 4，Meter Value (KWh)]
Example:
Scale = 0x00 (KWh)
Precision = 2
Size = 4 Bytes (KWh)
Meter Value 1 = 0x00(KWh)
Meter Value 2 = 0x01(KWh)
Meter Value 3 = 0x38(KWh)
Meter Value 4 = 0xA3(KWh)
Accumulated power consumption (KWh) = (Meter Value 2*65536) + (Meter
Value 3*256) + (Meter Value 4) = 800.35 (Kwh)
2-2-3 Clearing accumulated power consumption
Whenever re-start counting the accumulated power consumption is needed, you
can use Meter Reset Command to clear it.
Meter Reset Command: [Command Class Meter, Meter Reset]
2-2-4 AC load Voltage (V)
When receiving Meter Get Command, it will report Meter Report Command to
the node.
Meter Get Command: [Command Class Meter, Meter Get, Scale
=0x04(V)]
Meter Report Command:
[Command Class Meter，Meter Report，Rate Type = 0x01，Meter
Type = 0x01 ，Precision = 1 ，Scale = 0x04 ，Size = 2 ，Meter
Value(V)]
Example:
Scale = 0x04 (V)
Precision = 1
Size = 2 (2 Bytes of V)
Meter Value 1 = 0x09(V)
Meter Value 2 = 0x01(V)
AC load Voltage = (Meter Value 1*256) +(Meter Value 2)= 230.5 (V)
2-2-5 AC load current ( I )
When receiving Meter Get Command, it will report Meter Report Command to
the node.
Meter Get Command:
[Command Class Meter, Meter Get, Scale =0x05( )]
Meter Report Command:
[Command Class Meter，Meter Report，Rate Type = 0x01，Meter Type
= 0x01，Precision = 2，Scale = 0x05，Size = 2，Meter Value( )]
Example:
Scale = 0x05 (I)
Precision = 2
Size = 2 (2 Bytes of I)
Meter Value 1 = 0x01(I)
Meter Value 2 = 0x21(I)
AC load current = (Meter Value 1*256) +(Meter Value 2)= 2.89 (A)
2-2-6 load power factor (PF)
When receiving Meter Get Command, it will report Meter Report Command to
the node.
Meter Get Command: [Command Class Meter, Meter Get, Scale

=0x06(PF)]
Meter Report Command:
[Command Class Meter ，Meter Report ，Rate Type = 0x01 ，Meter
Type = 0x01 ，Precision = 2，Scale = 0x06 ，Size = 1 Bytes ，Meter
Value(PF)]
Example:
Scale = 0x06 (PF)
Precision = 2
Size = 1 (1 Byte of PF)
Meter Value 1 = 0x63(PF) (It means that the load power factor is 0.99)
3. Z-Wave’s Configuration
Configuration
Parameter Function Size (Byte) Value Unit Default Description
1Watt Meter
Report Period 2
0x0000
-
0x7FFF
5s 720
0: Disa le Watt
Report
1~32767: 5s~ 45h
2 KWH Meter
Report Period
2 0x0000
-
0x7FFF
10min 6 0: Disa le KWh
Report
1~32767:
10min~ 227days
3
Threshold of
current for Load
caution
2 10-1300 0.01A 1300 1300*0.01A
= 13A
4
Threshold of
KWh for Load
caution
2 1-10000 1KWh 10000 10000*1KWh
= 10000 KWh
5Restore switch
state mode 1 0-2 1
0: Switch off
1: Last switch state
2: Switch on
6Mode of Switch
Off function 1 0-1 1 0: Disa le 1: Ena le
7LED indication
mode 1 1-3 1
1: Show switch state
2: Show night mode
3: One flash mode
8Watt differential
mode 1 0-1 1
0 : Disa le
1 : 5%
2: 10%
3: 15%
4: 10%
9Switch status
report mode 1 0-1 1 0: Disa le 1:Ena le
3-1 Watt Meter Report Period:
If the setting is configured for 1hour (set value =720), PAN45 will report its
instant power consumption to Group1 node every 1 hour. The maximum inter-
val to report its instant power consumption is 45 hours
(5s*32767/3600=45hr). When the setting is 0, PAN45 will disa le Watt auto
report function. The default value is 720.
3-2 KWH Meter Report Period:
If the setting is configured for 1hour (set value =6), PAN45 will report its Ac-
cumulated Power Consumption (KWh) to Group1 node every 1 hour. The
maximum interval to report its Accumulated Power Consumption (KWh) is
227.55 days (10min*32767/1440=227.55 days). When the setting is 0, PAN45
will disa le KWH auto report function. The default value is 6.
3-3 Threshold of current for Load Caution
This is a warning when the current of load over the preset threshold value, if
the setting value is 1300, when the load current of Relay1 over this value,
PAN45 will send current meter report to warn the Group1 node, the range of
the setting value is from 10 to 1300, and the default value is 1300.

3-4 Threshold of KWh for Load Caution
This is a warning when the KWh of load over the preset threshold value, If the
setting value is 10000, when the Accumulated Power Consumption of Relay1
over this value, PAN45 will send KWH meter report to warn the Group1
node, minimum value is 1KWh and default value is 10000 kWh.
3-5 Restore switch state mode:
Whenever the AC power return from lost, PAN45 will restore the switch state
which could e SWITCH OFF、LAST SWITCH STATE、SWITCH ON. The
default setting is LAST SWITCH STATE.
3-6 Mode of switch off function:
When the mode of switch On/Off is set to 0, any command of switch off will
e disa led and the On/Off function of include utton will e disa led. The
default setting is ena le mode. When manual On/Off function is disa led, the
RF command can only switch On ut not Off. This is useful function for keep-
ing the device in switch on state.
3-7 LED indication mode: The default setting is Show Switch State.
3-7-1 Show Switch State：When switch is on, LED is on. When switch is off,
LED is off.
3-7-2 Show Night mode：When switch is on, LED is off. When switch is off,
LED is on.
3-7-3 One Flash mode ：When the state of switch changes, LED will e on
only one second, then LED keeps off.
3-8 Watt differential mode：The default setting is 1 (= 5%).
Whenever Watt value of PAN45 changes over 5% of last reading value, it will
send Meter report to the group 1 nodes. However, if Watt differential mode as
0, the unsolicited report will e disa led.
3-9 Switch status report mode: The default setting is 1(Ena le)
Whenever PAN45 manually switch on or off, it will send BINARY_SWITCH_
REPORT to the node of group1.
1. Firmware update over the air (OTA)
PAN45 is ased on 700 series SoC and supports Firmware Update Command
Class, it can receive the updated firmware image sent y controller via the Z-
wave RF media. It is a helpful and convenient way to improve some function if
needed.
2. The Switch supports Command Classes including
Command Class Version Required Security Class
Z-Wave Plus Info 2 None
Security 0 1 None
Security 2 1 None
Supervision 1 None
Transport Service 2 None
Association 2 Highest granted Security Class
Association Group
Information 3Highest granted Security Class
Basic 2 Highest granted Security Class
Binary Switch 2 Highest granted Security Class
Configuration 4 Highest granted Security Class
Device Reset Locally 1 Highest granted Security Class
Firmware Update Meta
Data 5Highest granted Security Class
Indicator 3 Highest granted Security Class
Manufacturer Specific 2 Highest granted Security Class

Meter 5 Highest granted Security Class
Multi Channel Association 3 Highest granted Security Class
Notification 8 Highest granted Security Class
Powerlevel 1 Highest granted Security Class
Version 3 Highest granted Security Class
Note: Please make sure that the intensity of the plug of the electrical device must
e 16A and have same head as the enclosed plug efore inserting to the socket.
Disposal
This marking indicates that this product should not e disposed
with other household wastes throughout the EU. To prevent possi-
le harm to the environment or human health from uncontrolled
waste disposal, recycle it responsi ly to promote the sustaina le
reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environ-
mental safe recycling.
Company of License Holder：Philio Technology Corporation
Address of License Holder ：8F., No.653-2, Zhongzheng Rd., Xinzhuang Dist.,
New Taipei City 24257, Taiwan(R.O.C)
www.philio-tech.com
