HA−6400
CôrtHome Automation
Setup Using the TP−Link Router
Technical Supplement
SUMMARY
The following supplemental instructions will show you how to setup the Smart Starter Kit using the TP−Link router so that the system
will be pre−configured even before actual installment in the home. This setup can all be done in the convenience of your office! Once the
installer is at the customer’s home, they would just place the panel and add−on components in the relevant locations; and connect the
homeowner’s primary router into the TP−Link router using an Ethernet cable.
BENEFITS
Reduces installation time in the home so that you can focus on more time walking the homeowner through their new system that you
just installed
Build homeowner confidence with the installer since issues that may be experienced during initial system setup can be addressed in the
office versus in the home
Minimize potential service calls or a truck roll in the event the homeowner changes or modifies settings with their primary router
password
Maintains privacy of the homeowner’s Wi−Finetwork password since you will be using the login network of the TP−Link router
NEEDED FOR THIS SETUP
Côr Home Automation Smart Start Kit (HA−6400−KIT−S)
TP−Link router (SYSTXXXGWR01)
Connected Wi−Fi network router with Ethernet cable
Laptop or Desktop Computer with web browser access
PREPARE THE SENSORS AND Z−WAVE LIGHT DIMMER FOR INSTALLATION
(3) TX−E201 (previously TX−1012−01−1) Door/Window Sensor
Remove sensor from packaging
Use a marker or place a label on each Sensor that identifies their location i.e. Front Door
Remove the main body from the cover and gently insert the lithium battery in the battery compartment being careful not to
press the black tamper button in the middle
Leave the cover off at this time for setup in Step 7
(1) 60−807−95R Motion Sensor
Remove from packaging
(1) 60−744−95R Water Sensor (some newer Starter Kits may have the TX−E611)
Remove from packaging
(1) IS−ZW−LM−1 Z−Wave Light Dimmer
Plug Light Dimmer into a nearby power outlet
Other sensors or devices that will be included in the package
2
Step 1 — Connect Power to the Côr panel
Connect power to the back of the panel using the transformer adapter
Tip: Order an extra transformer adapter (part number ZW−PS9V) that can be used for the setup and leave the one in the package intact.
Step 2 — Connect the TP−Link router to the Côr panel
Connect power to the TP−Link router that will be included with the Smart Starter Kit
Remove the sticker covering the four Yellow ports on the TP−Link router and connect an Ethernet cable to one of the ports
Connect the Ethernet cable from the TP−Link router to the Ethernet port on the back of the Côr panel
Step 3 — Establish a network connection to the panel for firmware update
Connect the Ethernet cable from your primary router to the main Blue port on the TP−Link router (the ’ring globe’ light on the front
right side of the TP−Link router should be illuminated)
Confirm the Côr panel is using Ethernet (and not Wi−Fi)
If panel says, “Press 7 to switch to Ethernet” then Press 7, otherwise proceed to verify the IP address
If the Côr panel announces “IP is not ready”, check your network connection.
NOTE: If the “ring globe’ light on the front right side of the TP−Link router is not illuminated but an IP address is provided by the Côr
panel, confirm the primary router connection is not on a firewall network.
Step 4 — Provision the Côr panel on the UltraSync Dealer Portal
Launch your web browser and login to https://webportal.ultra−sync.com
Click on the + “plus” icon next to the Search field at the top to add a New Site and enter the requested information to provision the
panel to the customer
Account Number = Any 4 Digit number
SSID = Serial Number on the sticker back of the Côr Panel
Make sure to select “US IP” under the Service Grade drop down menu at the end
Click Create when finished
Step 5 — Update the Côr panel with the latest Firmware
On the UltraSync Dealer Portal, click on the 3 line “hamburger” icon for the Dashboard menu at the top left corner of the screen
When the menu expands on the left side of the screen, click on Operational Status to display all the panels on your portal
Locate the panel provisioned in Step 4 and click on the Retrieve Live Status “Globe” icon to the right
3
Click on the Update icon when available on the bottom left side of the screen (if the Update button does not appear, go back to the
previous screen and enter the Retrieve Live Status “Globe” again)
In the popup menu, select the latest firmware version at the top
Check the box for Auto Activate and click Update
Stay on this screen to perform the next step
Step 6 — Login to the Côr Panel
Click on the Remote Control tab on the left side of the screen
Sign in as an installer
Username: installer (lower case)
Password: 9713
Click on Settings from the menu items
NOTE: The Côr panel will automatically power cycle once the firmware download is completed and you may need to login again while
performing the setup process below.
Step 7 — Learn the TX−E201 Door Window Sensors to the Côr panel
Go to Settings and select Sensors from the dropdown menu under Settings Selector
Select Sensor to Configure for the next available slot i.e. “1 Sensor”
Click on the Learn button
Pick up one of the TX−E201 Door Window Sensor main body with the inserted battery and press the exposed black tamper button
A message will appear that a New Device Found
Enter a description under Sensor Name
Select the appropriate Sensor Type i.e. “3 Entry Exit Delay 1”
Select “1 Bypass” for Sensor Option
“Tamper” should be defaulted as checked
4
Select Voice Name(s) at the bottom
Click Save at the top when finished
Click OK if a popup message appears to confirm your changes
Place cover over the main body (“TOP” arrow is opposite of battery side) and snap in place
Repeat step for the next (2) TX−E201 Door Window Sensor
Select Sensor to Configure for the next available slot i.e. “2 Sensor”
Click on the Learn button and repeat steps as above
Step 8 — Learn the 60−807−95R Motion Sensor to the Côr Panel
Select Sensor to Configure for the next available slot i.e. “4 Sensor”
Click on the Learn button
Remove the back cover from the Motion Sensor
A message will appear that a New Device Found
Enter a description under Sensor Name
Select the appropriate Sensor Type i.e. “5 Follower”
Select “1 Bypass” for Sensor Option
“Tamper” should be defaulted as checked
Select Voice Name(s) at the bottom
Click Save at the top when finished
Click OK if a popup message appears to confirm your changes
Step 9 — Learn the 60−744−95R Water Sensor to the Côr Panel
Select Sensor to Configure for the next available slot i.e. “5 Sensor”
Click on the Learn button
Remove the top cover from the Water Sensor main body and press the program button on top of the sensor main body
A message will appear that a New Device Found
Enter a description under Sensor Name
Select the appropriate Sensor Type i.e. “2 24 Hour Audible”
Select “12 Water Leakage” for Sensor Option
“Tamper” should be defaulted as checked and check “Disable Internal Reed”
Select Voice Name(s) at the bottom
Click Save at the top when finished
Click OK if a popup message appears to confirm your changes
Confirm Water Sensor is properly sync’d with the Côr Panel
Short the contacts on the small Water Sensor unit with a metallic pin
The Côr panel will alarm or chirp
Acknowledge the alarm by entering 1 2 3 4 > Enter to silence the panel
Repeat two more times
Step 9a — Learn the TX−E611 Water/Freeze Sensor to the Côr Panel as a Water Sensor (if included in
Starter Kit)
Select Sensor to Configure for the next available slot i.e. “5 Sensor”
5
Click on the Learn button
TAP a magnet (i.e. from a Door/Window Sensor) to the vertical line mark on the side of the TX−E611 Sensor
A message will appear that a New Device Found
Enter a description under Sensor Name
Select the appropriate Sensor Type i.e. “2 24 Hour Audible”
Select “12 Water Leakage” for Sensor Option
“Tamper” should be defaulted as checked and do not check “Disable Internal Reed”
Select Voice Name(s) at the bottom
Click Save at the top when finished
Click OK if a popup message appears to confirm your changes
Learn the TX−E611 Water/Freeze Sensor to the Côr Panel as a Freeze Sensor
Select Sensor to Configure for the next available slot i.e. “6 Sensor”
Click on the Learn button
HOLD a magnet (i.e. from a Door/Window Sensor) for at least 2 Seconds to the vertical line mark on the side of the TX−E611 Sensor
A message will appear that a New Device Found
Enter a description under Sensor Name
Select the appropriate Sensor Type i.e. “2 24 Hour Audible”
Select “13 Low Temp” for Sensor Option
“Tamper” should be defaulted as checked and do not check “Disable Internal Reed”
Select Voice Name(s) at the bottom
Click Save at the top when finished
Click OK if a popup message appears to confirm your changes
Step 10 — Learn the IS−ZW−LM−1 Z−Wave Light Dimmer to the Côr Panel
Go to Settings and select Zwave Add/Remove from the dropdown menu under Settings Selector
Click Add button
Press the center button repeatedly on the Z−Wave device
The device will display under the Zwave Device Selector field when the panel learns the device
(Optional) Select the Device Room Location created earlier
Enter a description under Device Name
Click Save at the top when finished
Click OK if a popup message appears to confirm your changes
Step 11 — Add Wi−Fi Credentials; Create Web Access Passcode and Download Access Code
Go to Settings and select Network from the dropdown menu under Settings Selector
Under Wi−Fi Configuration, enter the login credentials found on the sticker underneath the TP Link Router
Wi−Fi SSID = myHVACxxxxxx (case sensitive)
Wi−Fi Security Type = WPA2 Passphrase
Wi−Fi Password = Security Key (8 digit number)
Change the Web Access Passcode to an eight (8) digit number that you and homeowner agree to use e.g. 4 digits of a number repeated
twice ’12341234’
TIP: Write down this Web Access Passcode and panel serial number in the Homeowners Quick Start Guide (01−811−20439−01) brochure in
the Starter Kit.
6
Change the Download Access Code to an eight (8) digit number. Make sure you keep a record of this number for future remote access in
the event you need to use the DLX900 software.
Click Save when finished
Step 12 — Change your Installer PIN
Go to Settings and select Change PIN from the dropdown menu under Settings Selector
Under PIN, change the default 9713 to another 4 digit PIN
Click Save when finished
IMPORTANT: Make sure to write this number down for future reference.
This completes the pre−install process. At this point, you can re−package the contents and label
the items as needed for easy reference.
Un−plug the transformer from the power outlet to the Côr panel
Remove the back cover plate on the Côr panel and install the back−up battery
7
INSTALLATION AT THE HOME
Suggested extra tools and items to have available during installation include:
Outlet power strip
Small step ladder
Cordless power drill
Ethernet cables
Wi−Fi repeater
319.5 MHz repeater (part number 80−922−1)
Magnetic strip (or remove and use magnet from Door/Window sensor)
Power Over Ethernet (POE) switch – Use for Outdoor Cameras
Step 1
Locate the Homeowner’s primary router and plug an Ethernet cable to the blue port on the back of the TP−Link router after it is powered up.
Step 2
Plug the transformer from the Côr panel to a power outlet after placement of the panel either using the wall mount or desk stand.
Step 3
Confirm the Côr panel is connected to the network.
If the Côr panel announces “IP is not ready”, login to the Côr panel using Wi−Fi Discovery. Otherwise, go to Step 4.
On a mobile device or tablet, go to Network Settings and enable Wi−Fi
Find and connect to “ZEROWIRE_xxxx”
Launch a web browser (Safari, Internet Explorer, etc.) and type in 192.168.1.3 in the address field at the top
Sign in as the installer
8
Go to Settings > WiFi Setup and press Scan For Wireless Networks
Click on the “myHVACxxxxxxxx” network and enter the WiFi Password using the 8 digit # Security Key on the sticker underneath the
TP−Link router
Press OK when finished
System will now disconnect the mobile device from the panel and attempt to connect to selected network.
Step 4
Download and install the Côr Smart Home app on the Homeowner’s smartphone or tablet device.
NOTE: Note: You should let the Homeowner enter their passwords as needed including the Wi−Fi login to their internet.
Step 5
Add a Site to the Côr Smart Home app.
Site Name
Serial Number
Passcode = 8 digit #
User Name = installer
PIN = installer 4 digit #
Step 6
Install all the Door/Window Sensors, Motion Sensor, Water Sensor, and Z−Wave Light Dimmer plug.
Step 7
Perform a Walk Test of each sensor.
Login the Côr Smart Home app as an installer and click on the hamburger menu to select Settings > Walk Test
Press Start Walk Test and follow the instructions on the app
Step 8
Deleting installer login credentials and adding homeowner login credentials on the Côr Smart Home app
Return to the main My Site screen by pressing BACK to get to the previous menu screen and pressing the Sites option at the top
Click on the “i” icon on the right side of the Côr app screen
Replace installer with ’User 1’ (case sensitive) as the User Name (Be sure to add the space after User)
Enter the PIN as 1234
Step 9
Ask the Homeowner to change their User Name and PIN by referencing the Homeowners Quick Start Guide (01−811−20439−01) brochure in
the Starter Kit.
10
Copyright 2017 Côr Home Automation P.O. Box 4808. Syracuse, NY 13221 Edition Date: 10/17
M
anufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
Catalog No: HA-6400-17SUP
Replaces: HA-6400-13SUP
Other manuals for HA-6400
2
Popular Home Automation manuals by other brands
Johnson Controls Unitary Products
Johnson Controls Unitary Products S1-TTSCC01 Zoning User's Information Manual
Essence
Essence WeR@Home WeR+ installation guide
Onvis
Onvis S4UK user manual
EVERSPRING
EVERSPRING AN181-2 Operator's manual
Eaton
Eaton xComfort CJAU-01/X Instruction leaflet
Gira
Gira X1 operating instructions
