ENYA MUSIC NEXG SE User manual

USER MANUAL
SMART AUDIO GUITAR

CONTENTS
2 MANUAL
To obtain the PDF manual
Enter the following URL in
your browser:
hps://www.enya-music.com/
pages/downloads-user-manual
2

CONTENTS
3
3
39
EFFECT PARAMETERS
MIXER
MANUAL 3

CONTENTS
4
IMPORTANT NOTES
4 MANUAL

MANUAL 5
Headstock
Zero Fret
Speaker
Saddle
Indicator Light
I/O Panel
Nut
Strings
Bridge
Bridge Hole Cover
Detachable
Upper Body
Frame
OVERVIEW

Fretboard
Strap Button
& Frame Bolt
Control Panel
Tuning Peg
Side Marker
Strap Button &
Frame Bolt
6 MANUAL

Model NEXG SE Smart Audio Guitar
Size 38-inch Detachable Body
38.2
inches
11.90 inches 3.36 inches
SPECIFICATIONS
MANUAL 7

Scale Length 23.7 Inches
Fret Round-End Nickel Silver
Body Carbon Fiber Composite
Fretboard Carbon Fiber Composite
Bridge Carbon Fiber Composite
Tuning Peg Enya 1:21 Steel Tuning Peg
Nut Carbon Fiber & Zero Fret Design
Saddle Nubone
Strings Enya Custom Bronze Guitar Strings
8 MANUAL

MANUAL 9
Finish Satin
Battery Power 11.1V/2600mAh
Max Charging Power 24W
Wireless Audio V5.1
Screen 2.0 inch color screen display
Speaker Enya AR technology speaker,
rated power 30W
SNR >85dB
System
Weight
Enya SE Smart Audio
6.4 lbs

ASSEMBLY INSTRUCTIONS
1. Attach the detachable upper body frame to NEXG SE by
inserting it into the grooves near the headstock and bridge.
2. Secure the body frame with the provided screws, using the
longer screw for the headstock and the shorter screw for the
bridge.
3. Use a clockwise motion to lock the screws, and anti-clock-
wise to unlock.
10 MANUAL

MANUAL 11
I/O PANEL
USB Port
USB Port
Line Out Jack
Mic In Jack
Phone Jack
A USB Type-C port for charging and data transfer, including
OTG* audio function. Use the provided adaptor and cable for
MAC via USB cable. Check device and cable compatibility for
OTG audio function.

Line Out
Mic In
Phone Jack
Use a 3.5mm TRS output jack to connect your earphones.
After connection, the NEXG SE's built-in speaker system will
be automatically muted. To avoid hearing damage, make sure
to set an appropriate volume level before use.
Connect to external speakers, amps, mixers, or audio inter-
faces using a 6.35mm TS cable. The built-in speaker system
long-distance signal transmission.
6.5mm input for external microphones and instruments. Im-
pedance is optimized for microphones, which may cause tonal
loss for instruments.
12 MANUAL

MANUAL 13
CONTROL PANEL
Function Key A
Function Key B
Display
Main Knob
Function Key A
Press for Tuner Mode. Hold to remove vocals when using
NEXG SE as a Bluetooth speaker.

Function Key B
Main Knob
Display Screen
Press to mute the strings on NEXG SE. Hold to activate Blue-
tooth and connect smartphones for audio playback.
Use this knob to adjust values by turning it clockwise or coun-
terclockwise.
• Turn to change the master volume.
• Press the knob to switch between preset banks.
•
A color screen for easy access and control.
NOTE: If the NEXG SE system crashes, hold down the main
knob to perform a forced shutdown control.
14 MANUAL

MANUAL 15
Note: It is recommended to use the
provided power adapter or a PD char-
ger to charge your NEXG SE. Using
other chargers may cause a charging
issue or product damage.
CHARGING

To charge your NEXG SE, please follow these instructions:
1. Connect the provided power adapter to the NEXG SE's
charging port. Or place the NEXG SE on the charging stand,
and connect the adapter to stand’s charging port.
2. Plug the power adapter into a wall outlet.
charging process.
4. The power indicator light on the NEXG SE will illuminate,
indicating that it is charging.
5. Allow the device to charge until the power indicator light
turns solid or the charging process is complete.
6. You can now power on your NEXG SE and enjoy uninter-
rupted performance.
16 MANUAL

MANUAL 17
MAIN MENU
After skipping the pop-up notification or activating the device,
the NEXG SE will land on the Main Menu.
①Status Bar
Displays the current device status
②Sound Presets
Indicates the preset group for the
current sound.
③Numerical Values
In the regular mode, it displays t
he current output volume within a
range of 0-16. It can also show th
e current pitch and travel in the
tuning table mode.
Status Bar
FunctionIcon
Wireless audio pairing or paired.
Headphone connected.

FunctionIcon
OTG device connected.
Mic In jack connected.
Battery Level
Music mode on
(Mutes guitar pickup signal.)
Vocal removal mode on
(Removes vocal signal from audio played
through wireless audio.)
(If a non-complementary adapter is used to
charge NEXG SE, the system may mistake
it for an OTG device and display the corre-
sponding icon on the status bar.)
18 MANUAL

MANUAL 19
TUNER
To tune your smart audio guitar, play a string and turn the tuning
peg until the display turns green. Repeat for each string until
your guitar is fully tuned. Tune in a quiet environment and refer
to the manual or contact support if needed.
Note Order
A→A#→B→C→C#→D→D#→E→E#→F→G→G#→A→A
#→B→C→C#...
How to Tune Your NEXG SE

Tighten the tuning peg of the string until the meter on the
display reaches the center and turns green. Repeat for each
string until your guitar is fully tuned. Refer to the manual or
contact support for help if needed.
Tune Up (Too Low)
Note of Each String (Standard Tuning)
6th string: Low E;
5th string: A;
4th string: D;
3rd string: G;
2nd string: B;
1st string: High E.
20 MANUAL
