EOS C85 User manual

1
1
C85
LONG LIFE EOS ANALYZER
CO2CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
COp 28
CO2% 6.2
C85
INSTRUCTION MANUAL
ENGLISH
Long Life EOS Analyzer
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

2
TABLE OF CONTENTS
Display Symbols ......................................2
Analyzer Overview ....................................3
Getting Started........................................4
Safety Notes.......................................4
Warnings .........................................4
Menu / Setup .........................................4
Set Time ..........................................4
Set Date ..........................................4
Set Auxiliary Screen .................................5
Adjust Screen Contrast...............................5
Customizeable Header (on print-outs) ...................6
Set Language ......................................6
Viewing and Printing Reports..........................7
Print Setup ........................................7
Basic Fast Start (Operation) ............................8
Power On .........................................8
Select Fuel ........................................8
Connect Probe......................................8
Select Parameter to View / Log / Print ..................8
Status............................................8
Aux ..............................................8
Eff- X Air .........................................9
O2 CO Air Free ....................................9
CO2 CO...........................................9
Temp ............................................9
Fuel..............................................9
Date Time ........................................9
Where To Test ....................................10-11
What Results Are Generally Acceptable ................11
General Maintenance.................................12
Pre Test Checklist .................................12
Setting Inlet Temperature ...........................12
Analyzer Connections ..............................12
Emptying, Cleaning Water Trap ......................12
Changing Particle Filter .............................12
Replacing Batteries ................................13
Post Test ........................................13
Periodic Service ...................................13
Analyzer Re-Certification ............................13
Cleaning .........................................13
Other Important Factors Related To Combustion .........14
Combustion Measurement Terms ......................14
Specifications .......................................15
Electromagnetic Compatibility .........................15
Limited Warranty.....................................16
DISPLAY SYMBOLS
Excess Air Theoretical amount of air in excess of level needed to completely burn fuel
Delta T Differential temperature
Losses Losses calculated from oxygen and type of fuel
Inlet
Temperature Temperature measured and stored to calculate efficiency
Flue
Temperature Temperature measured by the flue probe or accessory k-type thermocouple
Ratio CO to CO2 Ratio. Used to indicate the general condition of the combustion process
Carbon
Monoxide Carbon Monoxide measure in parts per million ppm
Carbon Dioxide Carbon Dioxide measured in percentage%
Oxygen Oxygen calculated
Efficiency Calculated combustion efficiency based on net temperature, oxygen and fuel selected
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

3
ANALYZER OVERVIEW
C85
LONG LIFE EOS ANALYZER
CO2CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
COp 28
CO2% 6.2
Infrared Printer Port
BACKLIGHT / “s“ UP Press to HOLD values
on display and navigate UP. Press and hold
to turn Backlight on/off.
PUMP / “t“ DOWN Press to turn
pump on/off and navigate DOWN
SEND/ENTER “ ”
to Select and Print
Particle Filter
Inside Water Trap
Water Trap
Protective Rubber Boot
w/ built-in Magnets
Battery Charge
AC Adapter
Flue Gas
Inlet Connection
Water Trap
Drain
2 Line Backlit Display
On/Off Button
Rotary Test Selector Dial
Battery Compartments
in back under boot
AC Power/Charge
Indicator Light
Temperature
Connections
Flue Probe Temp: T1
Flue Probe Temperature Plug
(Plugs into T1)
Narrow Pin MUST be on the
Right hand side.
Flue Probe
Gas Inlet Plug
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

4
4
GETTING STARTED
MENU / SETUP
SAFETY NOTES
Before using this meter, read all safety information carefully.
“WARNING” is used to indicate conditions or actions that may pose physical hazards to the user.
“CAUTION” is used to indicate conditions or actions that may damage this instrument.
WARNING!
This analyzer extracts combustion gases that may be toxic in relatively low concentrations. These gases are exhausted from
the back of the instrument. This instrument must only be used in well-ventilated locations. It must only be used by trained and
competent persons after due consideration of all the potential hazards.
SET TIME
SET DATE
Rotate dial to Menu
Rotate dial to Menu
SET TIME shows press
“Send”
Press “s“ UP or “t“
DOWN to “SET DATE”
Press ENTER “ ”
Clock displays with the
cursor underneath the first
digit. Press “s“ UP or
“t“ DOWN to increase or
decrease and press
ENTER “ ” to set and
proceed to the next digit.
Set date displays with
MM/DD/YY Press “s“ UP
or “t“ DOWN to select a
different format press
ENTER “ ” to proceed.
Use MM/DD/YY for North
American.
Press “s“ UP or “t“
DOWN to increase or
decrease and press
ENTER “ ” to set and to
proceed to the next digit.
Date displays with the
cursor underneath the first
digit. Press “s“ UP or
“t“ DOWN to increase or
decrease and press
ENTER “ ” to set and
proceed to next digit.
Press “Send” to complete
setting the time once all
digits are set.
Press ENTER “ ” to
complete setting the date
once all digits are set.
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
SET TIME
08:30:15
_
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
SET TIME
09:30:15
_
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
SET TIME
09:30:15
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET DATE
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
SET DATE
MM/DD/YY
_
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
SET DATE
01/21/15
_
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
SET DATE
01/21/15
_
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

5
5
MENU / SETUP (CONT.)
SET AUXILIARY SCREEN (Aux)
Rotate dial to Menu Press “s“ UP or “t“
DOWN to “AUX”
Press ENTER “ ”
AUX PAGE 1 shows press
ENTER “ ” to set.
AUXPAGE1 LINE 1 shows
press ENTER “ ” to
continue to set line 1.
Press “s“ UP or “t“
DOWN select between
available parameters and
press ENTER “ ” to set.
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
AUX
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
AUX
PAGE1
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
AUXPAGE1
LINE 1
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
AUXPAGE1
01/20/15
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
AUXPAGE1
LINE 2
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
AUXPAGE1
EXIT
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
AUX
PAGE2
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
AUX
EXIT
AUXPAGE1 LINE 2 shows
press “Send” to continue
to set line 2. Press
“s“ UP or “t“ DOWN
select between available
parameters and press
ENTER “ ” to set.
AUXPAGE1 EXIT shows
press ENTER “ ” to
proceed.
AUX PAGE2 shows press
ENTER “ ” to proceed
to set page 2. Repeat the
same process as page 1 to
set page 2.
Press ENTER “ ” to exit.
Press ENTER “ ” to exit.
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
CONTRAST
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
CONTRAST
SET 100
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
CONTRAST
SET 150
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
ADJUST CONTRAST
Rotate dial to Menu Press “s“ UP or “t“
DOWN to “CONTRAST”
Press ENTER “ ”
Press “s“ UP or “t“
DOWN to adjust screen
contrast. NOTE: The higher
the value the lighter the
digits appear
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

6
6
MENU / SETUP (CONT.)
Press ENTER “ ” to exit.
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
CUSTOMIZABLE HEADER (ON PRINTOUTS)
SET LANGUAGE
Rotate dial to Menu
Rotate dial to Menu
Press “s“ UP or “t“
DOWN to “LANGUAGE”
Press ENTER “ ”
Press “s“ UP or “t“
DOWN to “HEADER”
Press ENTER “ ”
Press “s“ UP or “t“
DOWN to select HEADER 1
Press ENTER “ ” to
proceed.
Press “s“ UP or “t“
DOWN to change language
and press ENTER “ ” to
set and exit
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
HEADER
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
HEADER
HEADER1
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
_HEADER
SAMPLE
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
HEADER
HEADER2
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
_PHONE
NUMBER
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
HEADER
EXIT
The existing HEADER 1
will display with the cursor
underneath the first digit.
Press “s“ UP or “t“
DOWN to change and
press ENTER “ ” to set
and continue to the next
digit. Press ENTER “ ”
to proceed.
The existing HEADER 2
will display with the cursor
underneath the first digit.
Press “s“ UP or “t“
DOWN to change and
press ENTER “ ” to set
and continue to the next
digit. Press ENTER “ ”
to proceed.
Repeat the process for
HEADER 2 and press
ENTER “ ” to proceed.
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
LANGUAGE
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
LANGUAGE
ENGLISH
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

7
7
MENU / SETUP (CONT.)
VIEWING AND PRINTING REPORTS
Rotate dial to Menu Press “s“ UP or “t“
DOWN to “REPORT”
Press ENTER “ ”
Press “s“ UP or “t“
DOWN to “VIEW” press
ENTER “ ” to proceed.
Press and hold “s“ UP
or “t“ DOWN to select
log to view (LOG 01, LOG
02). Press “s“ UP or “t“
DOWN to scroll and view
parameters on second line.
Press “Send” to print
LOGGED results. press
ENTER “ ” again to
abort.
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
REPORT
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
REPORT
VIEW
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
LOG 01
01/21/15
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
LOG 02
01/25/15
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
REPORT
DEL ALL
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
DEL ALL
YES
PRINT SETUP
Rotate dial to Menu
Rotate dial to Menu
Press “s“ UP or “t“
DOWN to “REPORT”
Press ENTER “ ”
Press “s“ UP or “t“
DOWN to “PRINTING”
Press ENTER “ ”
Press “s“ UP or “t“
DOWN to “DEL ALL”
Press ENTER “ ” to
proceed.
Press “s“ UP or “t“
DOWN to select printer.
Press ENTER “ ” to
select. Analyzer will
automatically return to the
menu.
Printer Options
• KMIRP2 for legacy
infrared thermal printer
• IRP-3 for easy-load fast
printer
NOTE: If using the KMIRP2
printer and incomplete
reports are printing check
the print setup
Press “s“ UP or “t“
DOWN to select Yes or No
Press ENTER “ ” to
proceed. Analyzer will
automatically return to the
menu.
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
SET TIME
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
REPORT
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
MENU
PRINTING
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
PRINTING
KMIRP
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

8
Status Aux
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO2
CO
Temp
Fuel
Date
Time
BAT
CAL 300
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO2
CO
Temp
Fuel
Date
Time
12:34:56
01/02/03
BASIC FAST START (OPERATION)
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
01/21/15
TIME 90
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
01/21/15
TIME 90
1. POWER ON
3. CONNECT PROBE 4. SELECT PARAMETER TO VIEW / LOG / PRINT
2. SELECT FUEL
Power on in area of fresh air and allow to countdown. On
sealed combustion appliances (ducted inlet) connect flue
probe and power on outside and allow to countown to set
inlet temperature. (see page 12)
Connect flue probe
thermocouple connector to
T1, and connect flue probe to
water trap as shown above.
Insert Flue Probe in stack.
Adjust the cone so the end of
the probe is approximately at
the center of the stack
(4” stack adjust cone to
aprox. 2” from end of probe.)
Rotate selector to desired
test.
Rotate selector to Status.
The status menu shows
battery life and the number
of days until suggested
re-certification. (CAL)
Rotate selector to Aux.
The auxilliary menu shows
user defined parameters. The
display alternates between
page 1 and page 2.
To set up the auxilliary menu
see instructions on page 5.
Press “Send” to print results
or press and hold “Send” to
log results from any screen.
Rotate test selector to Fuel. Press “s“ UP or “t“ DOWN
to scroll and press “Send” to
select desired fuel. Bottom
line displays selected fuel.
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
SET FUEL
NAT GAS
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
SET FUEL
NAT GAS
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
COp 28
CO2% 6.2
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
COp 28
CO2% 6.2
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

9
Eff / X-Air
CO2 CO
Fuel
Temp
Date Time
O2 CO Air Free
Rotate selector to Eff X-Air.
The Eff/X-Air screen shows
calculated combustion efficiency
using a Gross Condensing
calculation and excess air.
When below condensing
temperature the efficiency
calculation includes and
estimated energy recovered
during condensation that
increases combustion efficiency.
This calculated value is not
the same as AFUE.
Excess air is a calculated value
representing the amount of
air above the level needed to
completely burn all of the fuel.
NOTE: Negative net temperature
will result in efficiency greater
than 100%
Rotate selector to CO2 CO.
The CO2 / CO screen is a
direct display of measured
gases. Carbon dioxide (CO2)
is displayed in percentage
(%), carbon monoxide (CO) is
displayed in parts per million
(ppm).
These two measurements are
commonly referenced target
values for appliance set up.
Rotate selector to Temp.
The temperature screen
will display values for flue
temperature (Tf) and inlet
temperature (Ti). If inlet
temperature was set during
initial power on, it will
display that temperature. If
using ambient temperature
you will observe the internal
handset temperature.
Note: The sample pump will
stop when CO is less than
40ppm.
Rotate selector to O2 CO Air
Free.
The O2/CO Air free screen
shows the calculated amount
of O2 (from CO2 measured
and fuel selected), and CO
Air Free.
CO Air free is a calculated
value for carbon monoxide
as if there were no dilution
from air.
COppm =
[20.9 / (20.9 - O2 measured)]
Rotate test selector to Fuel.
The fuel selector position will
display the current fuel being
used for calculations.
Press “s“ UP or “t“ DOWN
to scroll and press ENTER
“” to select desired fuel.
Bottom line displays selected
fuel selected for calculations
Rotate test selector to Date
Time.
Display shows internal clock
and the date.
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO2
CO
Temp
Fuel
Date
Time
EfG 88.1
X 31.4
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO2
CO
Temp
Fuel
Date
Time
O2% 21.9
COa -0>-
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO2
CO
Temp
Fuel
Date
Time
COp 28
CO2% 6.2
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO2
CO
Temp
Fuel
Date
Time
Tf 75.9F
Ti 69.9F
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO2
CO
Temp
Fuel
Date
Time
SET FUEL
NAT GAS
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO2
CO
Temp
Fuel
Date
Time
13:27:46
01/21/15
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

10
Air Conditioning / Heat Pump
Boiler & Water Heaters & High Efficiency Modulating Hot Water Systems
Furnaces: 80% Furnaces: 90%
Suction Line:
• Temperature
Verify proper:
• Static Duct Pressures
• Temperature Differential
• Static Pressure Drop Across Coils
Boiler
Verify proper combustion:
• O2
• CO Air Free
• Stack Temp
• Stack Draft
• SSE
Water Heater
Draft
Verify proper combustion:
• O2
• CO
• Stack Temp
• Efficiency
HE Boiler Instant
Water Heaters
Draft
Verify proper
combustion:
• O2
• CO
• Stack Temp
• Efficiency
Hi / Low fire Gas
Pressure
Send and Return
Water temp
80% Furnace
Verify proper combustion:
• O2
• CO
• Stack Temp
• Vent Pressure
• Efficiency
Verify/Set Up
• Gas Pressure
Test
• Limit Switch
• Pressure Switch
Verify proper operation:
• Static Duct Pressure
• Temperature Rise
• AC side Static Pressure
Drop across coils
90%+ Furnace
Verify proper combustion:
• O2
• CO
• Stack Temp
• Vent Pressure
• Efficiency
Verify/Set Up
• Gas Pressure
Test
• Limit Switch
• Pressure Switch
Verify proper operation:
• Static Duct Pressure
• Temperature Rise
• AC side Static Pressure
Drop across coils
to condensing unit
WHERE TO TEST
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

11
Furnaces (continued): Atmospheric, Gas & Oil
Atmospheric Furnace
Draft
Verify proper
• Temperature Rise
• AC side Static Pressure
Drop across coils
Verify proper combustion:
• O2
• CO
• Stack Temp
• Efficiency
WHERE TO TEST (CONT.)
Natural Gas & Propane
Verify proper combustion:
• O2
• CO
• Stack Temp
• Vent Pressure
• Efficiency
Test
• Limit Switch
• Pressure Switch
Set Up
• Gas Pressure
Verify proper:
• Static Duct Pressure
• Temperature Rise
• AC side Static Pressure
Drop across coils
Oil Furnace
Verify proper combustion:
• O2
• CO
• Stack Temp
• Stack Draft
• Efficiency
Test & Verify:
• Smoke
Set Up
• Over Fire Draft
Verify proper
• Static Duct Pressure
• Temperature Rise
• AC side Static Pressure
Drop across coils
WHAT RESULTS ARE GENERALLY ACCEPTABLE
Atmospheric Gas Fired Burners
• Oxygen ................................ 7 to 9% O2
• Stack Temperature ..................... 325 to 500°F
• Draft (Water Column Inches) ............ -.02 to -.04wc”
• Carbon Monoxide (parts per million) ...........<100ppm
Gas Fired Power Burners
• Oxygen ................................ 3 to 6% O2
• Stack Temperature ..................... 275 to 500°F
• Stack Draft (Water Column Inches) ....... -.02 to -.04wc”
• Overfire Draft (Water Column Inches) ........... -.02wc”
• Carbon Monoxide (parts per million) ...........<100ppm
Oil Fired Burners (#2 Oil Fuel)
• Oxygen ................................ 4 to 7% O2
• Stack Temperature ..................... 325 to 600°F
• Stack Draft (Water Column Inches) ....... -.04 to -.06wc”
• Overfire Draft (Water Column Inches) ........... -.02wc”
• Carbon Monoxide (parts per million) ...........<100ppm
• Smoke .......... 0 (or manufacturer’s recommendation)
Positive Overfire Gas & Oil
• Oxygen ................................ 3 to 9% O2
• Stack Draft (Water Column Inches) ....... -.02 to -.04wc”
• Overfire Draft (Water Column Inches) .... +0.4 to +0.6wc”
• Carbon Monoxide (parts per million) ...........<100ppm
NOTE: Follow manufacture guidelines for the specific equipment being
serviced.
Typical Excess Air Level
O2% (measured) Excess Air %
Natural gas 3% 16.7%
Light Oil 5% 31%
Coal 8% 62%
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

12
GENERAL MAINTENANCE
PRE TEST CHECKLIST
SETTING INLET TEMPERATURE
ANALYZER CONNECTIONS
EMPTYING & CLEANING THE IN-LINE WATER TRAP
CHANGING THE PARTICLE FILTER
• Re-certify your instrument annually to ensure it meets original performance specifications
• Keep your instrument dry. If it gets wet, wipe dry immediately. Liquids can degrade electronic circuits
• Whenever practical, keep the instrument away from dust and dirt that can cause premature wear
• Although your instrument is built to withstand the rigors of daily use, it can be damaged by severe impacts. Use reasonable caution
when using and storing the meter
• Turn on and zero the analyzer with out the flue probe connected to use ambient temperature
• Connect flue probe thermocouple to T1 during zero countdown to store probe tip temperature as inlet (ducted system)
The in-line water trap should be checked and emptied on a regular basis. Water vapor will condense in
the probe line, which may cause the water trap to fill suddenly if the probe is moved. Care should be
taken at all times.
Carefully remove the rubber plug from the bottom of the water-trap housing. Dispose of the condensate
in a suitable drain, care must be taken as it could be acidic. If condensate spills onto the skin or clothing,
clean off immediately using fresh water, seek medical advice if problems occur. Ensure plug is replaced
before performing combustion tests. Note: O2 reading will be high if the Water Trap Plug is not in place.
This is a very important part of the analyzer and should be changed regularly. It prevents dust and dirt
particles from entering the pump and sensors that will cause damage. The filter MUST be changed when
it appears discolored on the inner surface.
Remove water-trap assembly from the analyzer as shown above. Remove the filter and plastic holder
from the housing. Discard the filter element but keep the holder to fit to the new filter. Clean the inside
of the filter housing with a suitable soft cloth. Fit the holder onto the new filter element and then insert
into the housing. Refit the housing onto the analyzer.
• Clean particle filter
• Water trap and probe line are empty of water
• Power on and zero
• All hose and thermocouple connections are properly secured
• Flue gas probe is sampling ambient FRESH air
• Water trap is fitted correctly to the instrument
• Flue temperature plug is connected
WARNING!
Turning the pump off while the probe is in the flue will leave toxic gases inside
the analyzer. Once data has been printed or copied it is advisable to purge the
unit with fresh air as soon as possible. To do this remove the probe from the flue
and turn ON the pump. Always allow the readings to return to zero (20.9 for O2)
prior to shutting the unit off. The meter will not switch off until the CO reading
is below 20 ppm.
WARNING!
The probe will be hot from flue gases. Remove the probe from the flue and allow
it to cool naturally. Do not immerse the probe in water, as this will be drawn into
the analyzer and damage the pump and sensors. Once the probe is removed from
the flue and the readings have returned to ambient levels hold down “On/Off”
and switch off the analyzer. The instrument will count down from 30 to switch
off. If you pressed “On/Off“ by mistake, pressing “Send“ will return you to normal
operation.
NOTE: Take care when inserting
the temperature probes as the
pins are polarized. Insert with the
smaller pin (+) to the right.
NOTE: Do not insert anything
into programming port.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

13
REPLACING THE BATTERIES
POST TEST
PERIODIC SERVICE
ANNUAL RE-CERTIFICATION
CLEANING
This meter has been designed for use with both alkaline and rechargeable Nickel Metal Hydride (NiMH) batteries. No other types are
recommended. The analyzer is supplied with 4 “AA” size alkaline batteries. These should be installed into the instrument as shown in the diagram
indicated on the back of the unit.
CAUTION!
Take great care when installing the batteries to observe correct polarity.
Always check the meter for operation immediately after installing
new batteries.
Using Re-Chargeable Batteries
The battery charger must only be used when NiMH batteries are fitted. Alkaline batteries are not re-chargeable. Attempting to recharge alkaline
batteries may result in damage to the product and may create a fire risk.
Battery Charging
Ensure that you use the correct charger. This unit uses a 9V DC regulated charger. Ensure that the batteries are fitted in the correct manner, and
then charge for at least 16 hours. Subsequent charges should be overnight. NiMH batteries may be charged at any time, even for short periods
to conduct testing.
WARNING!
Under NO circumstance should you expose batteries to extreme heat or fire as they may explode and cause injury. Always
dispose of old batteries promptly in a manner consistent with local disposal regulations.
WARNING!
Repair and service of this instrument is to be performed by qualified personnel only. Improper repair or service could result in
physical degradation of the instrument. This could alter the protection from personal injury this meter provides to the operator.
Perform only those maintenance tasks that you are qualified to do.
Remove the probe from the flue and allow the analyzer to purge
with fresh air until readings return to zero. - O2 to 20.9%, CO to
Zero (Be careful as the probe tip will be HOT)
C85
LONG LIFE EOS ANALYZER
CO 2 CO TEMP
Menu
Status
Aux
Eff
X-Air
O2
CO Air
Free CO
2
CO
Temp
Fuel
Date
Time
O2% 20.9
COa -0>-
Drain water trap by unplugging
the drain plug and shake to
get excess water out.
Check particle filter for dirt
and any other sediment and
replace if necessary.
While the CO sensor has an expected life of more than five years in normal use it is recommended that the analyzer is re-certified at least annually.
This is so that long-term drift on the sensor and electronics can be eliminated. Local regulations may require more frequent re-calibration and
users should check with appropriate authorities to ensure they comply with relevant guidelines.
Periodically clean your instruments case using a damp cloth. DO NOT use abrasive, flammable liquids, cleaning solvents, or strong detergents as
they may damage the finish, impair safety, or effect the reliability of the structural components.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

14
OTHER IMPORTANT FACTORS RELATING TO COMBUSTION
The three T’s of combustion
Time: Amount of time that the fuel and oxygen are together in the combustion chamber
Temperature: How high the temperature is determines the rate of oxidation, or speed of the combustion
Turbulence: How well the fuel and air are mixed
These three factors are all interrelated, and will move your results along the combustion curves.
COMBUSTION MEASUREMENT TERMS
Other parameters measured include net temperature, draft and efficiency.
Net Temperature
Net temperature is the difference between the combustion air entering the combustion chamber and the flue gas temperature past the heat exchange. This
is used to determine how efficient the system is extracting heat from the combustion process in addition to the performance of the combustion process. On
sealed systems that have ducted inlet air for combustion air, the net temperature must compare this air stream temperature with the flue gases. If the appli-
ance simply uses room air for the combustion air, our analyzers have an internal temperature sensor in the handset, so it will use this temperature when
calculating net temperature. The most accurate results for efficiency are obtained when measuring flue gases at the point where flue temperature (not flame
temperature) is the highest.
Draft
Draft is the difference between the ambient pressure level and the pressure level in the flue.
This is created either by the natural buoyancy of the hot gases created in combustion lifting, or by an inducer fan that assists the flow of flue gases up the
stack. Most combustion equipment will specify the amount of draft that is required for proper operation. Draft helps draw combustion air into the combustion
chamber, and also helps in mixing the fuel and oxygen. Without proper draft, the combustion process can spill poisonous by-products into the space where the
appliance is located. This can be a risk to those in the area, or create a danger to residents or employees working near the combustion equipment.
Efficiency
Efficiency is a measure of how well the fuel is burned to create heat, and how well the generated heat is captured for the intended use.
The information used to create this value are based on the fuels heating value, the heat lost up the flue and the gas components in the flue gas. The original
method to determine efficiency included many manual methods and lookup charts. As an example you would measure the CO2 level and the stack tempera-
ture and then reference a slide scale that would give you the relative efficiency number. UEi’s electronic combustion analyzers perform the measurements
on a continuous basis, and can calculate the efficiency as adjustments are being made. Combine this with a printout and you are able to provide a before
and after comparison of the combustion equipment in relatively little time as part of normal servicing. Combustion efficiency is not the same as AFUE
(annual fuel usage efficiency). AFUE is not measurable with any portable flue gas analyzer.
Combustion Efficiency Calculations
This identifies three sources of loss associated with fuel burning:
•Losses due to flue gases:
Dry Flue gas loss, Moisture and hydrogen,
Sensible heat of water vapor, Unburned gas
• Losses due to refuse:
Combustible in ash, riddling and dust
• Other losses:
Radiation, convection, conduction other unmeasured losses
Net efficiency calculations assume that the energy contained in the water vapor (formed as a product of combustion and from wet fuel) is recovered and the
wet loss term is zero. Gross efficiency calculations assume that the energy contained in the water vapor is not recovered. Since the fuel air mixture is never
consistent there is the possibility of unburned/partially unburned fuel passing through the flue. This is represented by the unburned carbon loss. Losses due to
combustible matter in ashes, riddling, dust and grit, radiation, convection and conduction are not included.
CO Air Free
Certain standards ( ANSI Z21.1) for Carbon Monoxide are stated in terms of air-free. Air-free refers to the concentration of CO in combustion gases undiluted
with flue, or other gases containing little CO. This value is computed using an equation that takes into account the O2 concentration of the flue gas.
• If 5% O2 is measured (O2m) in the flue then the CO gas value will be recalculated as if 0% were measured. The equation for air-free is
as follows:: COaf = CO PPM x [(20.9) / (20.9 - O2m)]
• In our example if a reading of 325 PPM were measured then the air-free value would be calculated as follows:
COaf = 325 PPM x [(20.9) / (20.9 - 5)] COaf = 325 PPM x [(20.9) / (15.9)] COaf = 427
We may be given a limit on our gas range by the local authority, which stated that we must not emit more than 400-PPM Carbon Monoxide air-free. In the
example we would be breaking the limit and corrective action should be taken to reduce the level of CO. Air-free values prevent false readings being submit-
ted, e.g. allowing more air into the boiler will increase the oxygen level in the flue and dilute any toxic gas reading. Air-free referencing gives readings as if
they were undiluted.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

15
SPECIFICATIONS
Parameter Range Resolution Accuracy
Temperature Measurements
Flue Temperature 32 - 1112˚F (0 - 600˚C) 1.0˚ F/C ±5˚F (2.0˚C) ±0.3% reading
Inlet temperature 32 - 212˚F (0 - 100˚C) 1.0˚ F/C ±1˚ F/C ±0.3% reading
Temp (Nett)*2 32 - 1112˚F (0 - 600˚C) 1.0˚ F/C ±5˚F (2˚C) ±0.3% reading
Gas Measurements
Carbon Monoxide (CO) 0 - 1999 ppm 1 ppm ±5ppm <100ppm
±5% rdg >100ppm
Carbon Dioxide (CO2) 0 - 30% 0.1% ±0.3%
Calculations
Oxygen (O2) 0 - 21% 0.1% ±0.2%
Efficiency 0 - 99.9% 0.1% ±1.0%
Excess Air 0 - 250% 0.1% ±0.2%
GENERAL SPECIFICATIONS
• Operating Altitude: 2000m (6,561 ft.)
• Storage Altitude: 10,000m (32,808 ft.)
• Operating Temperature: 32°F to 104°F (0°C to 40°C) at 10 - 90% R.H
• Pollution Degree: 2
• Dimensions: Handset: 7.9” (200mm) x 3.5” (90mm) x 1.8” (45mm)
Probe: (L) 7.9” (300mm) x (D) 0.25” (6mm) with 7.8” (200mm)
6ft (3m) neoprene hose
• Weight: 2.2lbs (1kg)
• Certifications: EMC EN 50081-1, EN 50082-1, CE
• Battery Type: 4 x 1.5V AAA
• Power Supply Input: 110V AC Output: 9V DC Regulated
ELECTROMAGNETIC COMPATIBILITY (EMC)
This product has been tested for compliance with the following generic standards: EN 50081-1, EN 50082-1 and is certified to be compliant.
The European Council Directive 89/336/EEC requires that electronic equipment does not generate electromagnetic disturbances that exceed defined levels and
has an adequate level of immunity to enable it to be operated as intended.
Since there are many electrical products in use that pre-date this Directive and may emit electromagnetic radiation in excess of the standards defined in the
Directive there may be occasions where it would be appropriate to check the analyzer prior to use. The following procedure should be adopted.
• Go through the normal start up sequence in the location where the equipment is to be used
• Switch on all localized electrical equipment that might be capable of causing interference
• Check that all readings are as expected (a level of disturbance in the readings is acceptable)
• If not, adjust the position of the instrument to minimize interference or switch off, if possible, the offending equipment for the duration of the test
At the time of writing this manual (January 2015) UEi is not aware of any field based situation where such interference has ever occurred and this advice is
only given to satisfy the requirements of the Directive.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

SERVICE
IMPORTANT: PRODUCT REGISTRATION
Register your product online at www.ueitest.com and click the PRODUCT REGISTRATION banner. This allows us to notify you when your analyzer has upgrades
available or when recertification is due.We manufacture industry-leading products for professionals like you; please help us to ensure your product is always
fit for purpose by registering your new purchase online - it only takes a few minutes.
IMPORTANT: RE-CERTIFICATION
While the CO sensor has an expected life of more than 5 years in normal use, it is recommended that the analyzer is recertified annually. The C85 analyzer
typically requires an annual recertification each of the first four years and full recertification on the 5th year pending use. This eliminates long term drifting of
the sensor and electronics. Local regulations may require more frequent calibration and users should check with appropriate authorities to ensure compliance.
UEi Test Instruments offers 2 kinds of recertification services.
Annual: Calibration of all installed sensors
Full: Replacement of all applicable sensors
Both services offer:
Full system, 30-point inspection with replacement of any failed parts.
Firmware and/or software upgrades as needed.
Certificate of calibration provided for record keeping.
Recertification work report to document work completed.
Units returned cleaned with paid return freight.
All units are recertified by trained professionals, which eliminate the legal liability of self-installed sensors. In the USA we have two recertification loca-
tions, one in Indianapolis, IN the second in Portland, OR. For Canadian customers we have a recertification service center in Vancouver, BC, which is ISO/IEC
17025:2005 accredited and offers NIST certification services for select products. All recertification services are warranted for one year.
Save time with online recertification check-in by visiting www.ueitest.com and click the SERVICE REQUEST banner and filling out the form.
Our current recertification prices can be found on the SERVICE section of our web site. Up front pricing means NO surprises.
LIMITED WARRANTY
The C85 combustion analyzer is warrantied for five years including sensors.
If within the warranty period your instrument should become inoperative from such defects, the unit will be repaired or replaced at UEi’s option. This warranty
covers normal use and does not cover damage which occurs in shipment or failure which results from alteration, tampering, accident, misuse, abuse, neglect
or improper maintenance (calibration). Batteries and consequential damage resulting from failed batteries are not covered by warranty. Any implied warran-
ties, including but not limited to implied warranties of merchantability and fitness for a particular purpose, are limited to the express warranty. UEi shall not be
liable for loss of use of the instrument or other incidental or consequential damages, expenses, or economic loss, or for any claim or claims for such damage,
expenses or economic loss. A purchase receipt or other proof of original purchase date will be required before warranty repairs will be rendered. Instruments
out of warranty will be repaired (when repairable) for a service charge. Contact UEi for specific warranty and service information. This warranty gives you spe-
cific legal rights. You may also have other rights which vary from state to state.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]
