epcom TITANIUM KIT-TT4PVTURBOX User manual

Quick Setup Guide
Features
Installation and Operation
KIT-TT4PVTURBOXKIT-TT8PVTURBOXKIT-TT16PVTURBOX
Before permanently securing the unit for final installation of cabling
behind walls or ceilings, test for proper operation of the unit and the
cables in your system.
Camera End: Connect transmitter to the camera’s video and
DC power connector. Insert UTP cat5e/6 into RJ 45 jack
of transmitter.
Power
Video
RJ45
DVR End: There’re RJ45 jack labeled “UTP In” and Female BNC
connectors labeled “BNC out” on the receiver hubs.
UTP IN BNC OUT
Insert one end of coaxial patch cord into Female BNC connectors of receiver’
hub and the other end into Female BNC connectors of DVR.
60cm Coaxial cable
Terminate the incoming UTP cat5e/6 cable from transmitter into
your RJ45 jack of 4/8/16 Video & Power Receiver hubs.
DVR
Step 1: Begin with all input/output devices turned off with power cables removed.
Step 2: Connect video source and UTP cat5e/6 cabling to transmitter
Step 3: Connect video display and/or DVR to “BNC output” of Receiver Hub
Step 4: Terminate the incoming UTP cat5e/6 cable into your RJ45
jack “UTP In” (See RJ 45 jack Pin Assignment)
Step 5: Power on all input/output devices
Application Example
Transmitter +Receiver Hub(36VDC)
Power
Video
Power
Video
12VDC Camera
12VDC Camera
Transmitter: convert 36VDC to regulated 12VDC at camera
Power Supply HD Video Receiver Hub
Receiver
Receiver Hub DVR
Transmitter
Switch on the Video & Power Receiver Hub using the on/offf switch.
Kit´s PREMIUM of Power Transmission (36@12Vdc)
and Video (HD-TVi)
Real-time transmission over UTP cat5e/6
Compatible with all HD-TVI/CVI/AHD/CVBS analog cameras
Provides camera power while receiving video signal
Please refer to “Video Transmission Distance Chart” Part to find out
distance of 720P/960P/1080P/3MP/4MP/5MP/4K cameras
Female BNC connector and RJ45 Jack
Full Channel Support OSD (On-Screen Display) with high quality image
Centralized power supply, reducing the use of engineering cables
Exceptional interference rejection
Built-in solid state TVS for surge protection & ground loop isolation
Wave Filter Design, Anti-Static Design
Lightning protection design Grade:
Black galvanized housing
Rack, wall mountable and desk installation with 4 rubber feet

Warning !
Wiring Scheme
T568A: White
Green Green White
Orange Blue White
Blue Orange White Brown Brown
White
Orange Orange White
Green Blue White
Blue
White
Brown Brown
Green
T568B:
1 2 3 4 5 6 7 8
Notes: 1.Wire should be category 5e rated Unshielded Twisted-Pair (UTP)
cable.
Video & Power Distance Char t
Video+ Video- Power- Power-
Notes: 1. You can use either T568A or T568B cables,
Make sure that both transmitter and receiver ends use the same wiring.
2. The maximum cable length is 1000ft(305m). For voltage drops over
long distances, refer to the table further in this manual.
Receiver end
Transmitter end
Power Supply HD Video Receiver Hub
Yellow LED ON: Overcurrent
Green LED ON: Power ON
1 2 3 4 5 6 7 8
1
2
3
6
4
7
5
8
Video +
Video -
Power +
Power -
Pair 3 Pair 1 Pair 4
Pair 2
1 2 3 4 5 6 7 8
T568A
Pair 2 Pair 1 Pair 4
Pair 3
1 2 3 4 5 6 7 8
T568B
300x261.2x67mm 300x261.2x67mm
Important Product Warnings:
1. Always test for proper operation of the unit before permanently securing to final
location.
2. Connect all cables before providing power to the unit.
Safety Instructions
Please be sure to follow these instructions for safe operation of your unit.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5.Keep this apparatus away from children and unauthorized users.
6.Do not use this apparatus near water.
7.Clean only with dry cloth.
8.Indoor use only. To reduce the risk of electrical shock, keep this apparatus
away from rain, moisture, splashing and dripping liquids. Never put objects filled
with liquid on top of or close to the apparatus.
9.Do not block any ventilation openings.
10.Install in accordance with the manufacturer’s instructions.
11.Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus(including amplifiers) that produce heat.
12.Always disconnect mains power when this apparatus not in use or when servicing
or maintenance activities are performed. Handle the power cord by the plug only.
13.Only use attachments/accessories specified by the manufacturer.
14.Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
Warranty
1.All manufactured products are built to high manufacturing standards and provide
one year warranty.
2.To reduce the risk of electrical shock, DO NOT disassemble or open the cover. No
user serviceable parts inside.Refer servicing to qualified service personnel.
3.All modifications of the apparatus are forbidden for safety reasons. Damage
caused by user modifications to the apparatus is not covered by the warranty.
4.Damaged by disregard of certain guidelines in this manual is not covered by
the warranty.
3. The distance between the camera and the remote video device
must not exceed 1000ft(305m) for color.
4. Actual distance will depend on the camera’s inrush and operating
current, minimum operating voltage, and the wire’s environmental
temperature.
36VDC Power Supply HD Video Receiver Hub
KIT-TT4PVTURBO KIT-TT8PVTURBO KIT-TT16PVTURBO
CVI 720P:400m(1312ft)
CVI 1080P: (721ft) 220m
TVI 720P: 190m (623ft)
TVI 1080P: 190m (623ft)
AHD 720P: 300m (984ft)
AHD 960P: 240m (787ft)
AHD 1080P: 220m (721ft)
DC to 42MHz
15KHz to 42MHz 60 dB typ
36VDC, up to 1000ft /305m via UTP cat5e/6
Mechanical/Technical Specifications
HD-TVI/CVI/AHD/CVBS
UTP:RJ45 100ohms
Coax: Male BNC 75ohms
Video Distance Chart:
Camera Type HD-TVI HD-CVI HD-AHD
720P camera 250m(820ft) 440m(1443ft) 320m(1049ft)
960P camera / / 320m(1049ft)
1080P camera 250m(820ft) 250m(820ft) 250m(820ft)
3MP camera 250m(820ft) / 250m(820ft)
4MP camera 180m(590ft) 230m(754ft) 200m(656ft)
5MP camera 180m(590ft) / 200m(656ft)
4K camera 200m(656ft) /
CVBS anolog 400m(1312ft)
430x261.2x67mm
4.7 Kg 6.85 Kg 12.5 Kg
200m(656ft)
