EPS 56VDC IPS Series User manual

EDGE POWER SOLUTIONS 56VDC IPS SERIES USER MANUAL VERSION 403222021
USER MANUAL
IPS-16
IPS-32-1
&
IPS-32-2

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
Life-Support Policy
As a general policy, Edge Power Solutions does not recommend the use of any of its products in the following situations:
•Life-Support Applications where failure or malfunction of the Edge Power Solutions Product can be reasonably expected to
cause failure of the life-support device or significantly affect its safety or effectiveness.
•Direct patient care.
Edge Power Solutions will not knowingly sell its products for use in such applications unless it receives in writing assurances
satisfactory to Edge Power Solutions that:
•The risk of injury or damage have been minimized
•The customer assumes all such risks, and
•The liability of Edge Power Solutions is adequately protected under the circumstances.
The term life-support device includes but is not limited to neonatal oxygen analyzers, nerve stimulators (whether used for
anesthesia, pain relief or other purposes), auto-transfusion devices, blood pumps, defibrillators, arrhythmia detectors and alarms,
pacemakers, hemodialysis systems, peritoneal dialysis systems, neonatal ventilator incubators, ventilators (for adults or infants),
anesthesia, ventilators, infusion pumps, and any other devices designated as “critical” by the U.S. FDA
The information in this document has been carefully checked and is believed to be accurate. However, changes are made
periodically. These changes are incorporated in newer publication editions. Edge Power Solutions may improve and/or change
products described in this publication at any time. Due to continuing system improvements, Edge Power Solutions is not
responsible for inaccurate information which may appear in this manual. For the latest updates, consult the Edge Power Solutions
website at www.edgepowersolutions.net. In no event will Edge Power Solutions for direct, indirect, special, exemplary, incidental,
or consequential damages resulting from any defect or omission in this document, even if advised of the possibility of such damages.
In the interest of continued product development, Edge Power Solutions reserves the right to make improvements in this document
and the products it describes at any time, without notice or obligation.
Dangerous Voltage
This Symbol is intended to alert the user to the presence of un-insulated dangerous voltage within the products
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
Multiple Power Inputs/Sources
This Symbol is intended to alert the user to the presence of more than one power input to the enclosure and
that all power inputs/sources should be disconnected prior to servicing of the unit.
Protective Grounding Terminal
This Symbol indicates a terminal that must be connected to earth ground prior to making any other
connections to the equipment.
Instruction
This symbol is intended to alert the user to the presence of important instructions in the
literature accompanying the device.

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
Table of Contents
SECTION 1:
•Introduction………………………………………………………………………………………….
•Quick Installation Checklist……………………………………………………………………
•Technical Support………………………………………………………………………………….
•Model IPS-32-1………………………………………………………………..…………………
•Model IPS-32-2………………………………………………………………………………….
•Model IPS-16……………………….………………………………………………………………
SECTION 2: Installation
•Standard Accessories……………………………………………………………………………
•Additional Required Items……………………………………………………………………
•Safety Precautions……………………………………………………………………………….
•Mounting PDU……………………………………………………………………………………..
•Attaching Safety Earth Ground Connection…………………………………………..
•Connection Output to Field Devices……………………….……………………….……
•Connecting to Power Source…………………………………………………………………
•L.E.D Status Indicators & Reset Buttons...………………………………………………
SECTION 3: Optional Integrated Fiber Optic Splitter
•Safety Precautions……………………………………………………………………………….
•Source Signal Connection(s)…………………………………………………………………
•Output Connections……………………………………………………………………………..
1
1
1
2
2
2
3
3
4
5
5
6
7
8
9
9
9

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
SECTION 1: Introduction
Edge Power Solutions rack mount power distribution units have been designed to provide +56VDC at up to 98W per output (See
Note 1) to low voltage DC devices such as:
•GPON Optical Network Terminals
•Distributed Antenna Systems
•LED Lighting
•CCTV
•Wireless Access Point
•Other applicable devices with similar input needs.
NOTE 1:
1. IPS-16
a. The maximum output per port is 95W
b. The maximum combined output for 120VAC or DC RMS equivalent* input = 1400W
c. The maximum combined output for 208-240VAC or DC RMS equivalent input = 1600W
2. IPS-32-1 (DUAL 15A INPUT)
a. The maximum output per individual port is 95W
b. The maximum combined output for 120VAC or DC RMS equivalent* input = 2800W
(1400W INPUT 1 + 1400W INPUT 2)
c. The maximum combined output for 208-240VAC or DC RMS equivalent* input = 3200W
(1600W INPUT 1 + 1600W INPUT 2)
3. IPS-32-2 (SINGLE 20A INPUT)
a. The maximum output per individual port is 95W
b. The maximum combined output for 120VAC or DC RMS equivalent input = 1960W
c. The maximum combined output for 208-240VAC or DC RMS equivalent input = 2800W Outputs
*DC RMS equivalent inputs via approved locking DC input connector only.
For Product Assistance or Technical Support call: 321-499-1919 - Option 4
1.1 Quick Installation Checklist
•The following steps are recommended to quickly install the EPS-RM-1x(xx)-100W-(s) Power Supply Unit for use.
a) Attach Rack Mount Brackets to the Power Supply Unit
b) Mount the power supply unit in rack location
c) Connect Safety Earth Ground connection to approved ground buss
d) Connect devices to output connections using properly sized wire. (12AWG-24AWG)
e) Connect to properly sized AC power source(s)
PAGE 1

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
1.2 Product Description
IPS-32-1
•2RU 3.5”H x 16”D x 17”W
•23.2LBS
•(2) C19 Inputs – 5-15P
•(32) +56VDC Outputs (12AWG -24AWG) – (Up to 95W per output)
a) SEE NOTE 1 / PAGE 1
•Optional 1x32 or 2x32 Passive Fiber Optic Splitter
IPS-32-2
•2RU 3.5”H x 16”D x 17”W
•22.6.2LBS
•(1) C19 Inputs – 5-20P
•(32) +56VDC Outputs (12AWG -24AWG) – (Up to 95W per output)
a) SEE NOTE 1 / PAGE 1
•Optional 1x32 or 2x32 Passive Fiber Optic Splitter
IPS-16
•1RU 1.75”H x 16”D x 17”W
•16.6 LBS
•(1) 15A C19 Inputs – 5-15P
•(16) +56VDC Outputs (12AWG -24AWG) – (Up to 95W per output)
a) SEE NOTE 1 / PAGE 1
•Optional 1x16 or 2x16 Passive Fiber Optic Splitter
IPS-16-Wall Mount
•24” W x 24” L x 6.25”
•23lbs
•(1) 15A C19 Inputs / Option High Voltage DC Input
•(16) +56VDC Outputs (12AWG -24AWG) – (Up to 98W per output)
a) SEE NOTE 1 / PAGE 1
•Optional 2x16 Passive Fiber Optic Splitter
IPS-32-V1-WALL MOUNT / EPS-32-V2-WALL MOUNT
•24” W x 24” L x 6.25”
•23lbs / 26LBS
•(2) 15A C19 Inputs / (1) 20 C19 Input
•(32) +56VDC Outputs (12AWG -24AWG) – (Up to 93W per output)
a) SEE NOTE 1 / PAGE 1
•Optional 2x32 Passive Fiber Optic Splitter

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
PAGE 2
SECTION 2: Installation
2.1 Standard Accessories:
IPS-32-1
•(2) 6’ C20 – 5-15P Power Cord (AC MODEL)
•(1) Grounding Lug Kit
•(2) Rack Mounting Ears
IPS-32-2
•(1) 6’ C20 – 5-20P Power Cord (AC MODEL)
•(1) Grounding Lug Kit
•(2) Rack Mounting Ears
IPS-16
•(1) 6’ C20 – 5-15P Power Cord (AC MODEL)
•(1) Grounding Lug Kit
•(2) Rack Mounting Ears
LOCKING HIGH VOLTAGE DC PLUG ASSEMBLY TO BE USED IN HIGH VOLTAGE DC INPUT APPLICATIONS
2.2 Additional Required Items:
•Small Tip Flat Head Screwdriver
•Phillips Head Screwdriver
•Appropriately sized ground wire
•Power Meter
PAGE 3

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
2.3 Safety Precautions:
PAGE 4
Only for installation and use in a Restricted Access Location in accordance with the following
instructions.
This equipment should only be installed by qualified personnel
Always disconnect the power supply cord(s) before servicing to avoid electrical shock. For products with 2 input
power cords, both must be disconnected before servicing.
Do not block venting holes when installing this product. Allow for maximum airflow at all times above,
below and each side of the unit.
WARNING: Earth Ground connection is essential before powering on device.

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
2.4 Attach Rack Mounting Brackets
•Attach mounting brackets to each side of chassis with provided screws.
•Mount PDU into a properly secured wall mount, 2 post or 4 post rack.
•For wall mounting turn mounting brackets 90 degrees so that the mounting ear is flush with the bottom of the chassis.
oUnits should be mounted in a manner that allows for proper air intake and venting. Do not block
the side or top vent openings. When mounting in an enclosure or cabinet, the enclosure or cabinet
should have a means of ventilation in the form of side vents, open or perforated doors and or
mechanical ventilation methods. Allow at minimum 3” of clearance on each side of the unit and
1.75”(1RU) of clearance from the top of the unit.
2.5 Chassis Grounding
•Attach properly sized ground wire as required and secure to an approved earth ground prior to making any other
connections to this device.
PAGE 5

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
2.6 Connect Remote Device Power Cables
•Observing proper polarity, connect remote device power cables.
oAcceptable wire sizes: 12AWG – 24AWG
Choose appropriate AWG of wire based on Current, Distance & Acceptable Voltage Drop.
Consult with connecting device manufacturer for device requirements
oWire ferrule tipped wire recommended. Non-ferrule tipped wire recommended strip length: ¼”
•To connect wire
oPlace small flat tipped screwdriver into rectangle opening below wire insertion point
oPush in slightly with screwdriver and insert wire into the corresponding round opening.
oWhen wire is in place, release pressure on screwdriver to set connection.
PAGE 6

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
2.7 Connecting AC OR DC Power
AC CONNECTION HIGH VOLTAGE DC CONNECTION
SEE NOTE 1 / PAGE 1
•Connected provided cord to AC input on rear of chassis
oUnits can accept 120VAC-240VAC or DC RMS equivalent with appropriate cable
•DC POWER LEAD CONNECTIONS:
oWHITE LEAD TO NEGATIVE – INPUT
oBLACK LEAD TO POSITIVE + INPUT
Wall Mount:
EPS wall mount systems may utilize locking plug system for external power connections or internal direct power supply connections
from an RMS equivalent DC power source or properly configured Digital Electricity™ receiver.
Direct Power Supply Connection: Connection Point #1 in illustration below FIGURE 7.1
o(-) Negative Lead to Power Supply Neutral Input
o(+) Positive Lead to Power Supply Line Input
OPTIONAL Digital Electricity™ receiver connection: Connection Point #2 in illustration below FIGURE 7.1
EPS wall mount PDUs have internal shelves for Digital Electricity™ receiver mounting. Follow Volt Server™ connection procedures.
Volt Server™ connection procedures take precedence over EPS instructions.
•DC Power out from receiver to PDU power supply connections:
o(-) Negative Lead to Power Supply Neutral Input
o(+) Positive Lead to Power Supply Line Input
•Receiver input connection from source transmitter:
oConnect pre-connected receiver input to mating input adapter tail via conduit knockout at the top, side, or bottom
of the enclosure.
oGREEN LEAD TO GROUND
PAGE 7

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
FIGURE 7.1
2.8 LED Status Indicators and Reset Buttons
Each 56VDC output has a corresponding status indicator light and reset button.
•Green: Indicates output ready or normal circuit condition
•Red: Indicates output fault condition (Short, Over-Current or Admin Down)
oPush Button or Software output reset is required once fault is cleared.
Circuit will return to fault condition if fault still exist.
•Pushing reset button while circuit is in normal condition will remove power from the output for (2) seconds beyond the
button release.
PAGE 8

Edge Power Solutions
IPS-32-1 / IPS-32-2 / IPS-16 Installation Manual Revision 4.0 0322021
SECTION 3: Optional Integrated Fiber Optic Splitter
3.1 Optional Integrated Splitter Connection
3.1.1 Source Connection Input:
•Connect Input from active signal source equipment (GPON Port) using an LC/APC connector
•Patch other end to signal source equipment or connected fiber patch panel position.
3.1.2 Output Connection:
•Connect output from positions 1-32 on IPS-32 or positions 1-16 on IPS-16
•Patch other end to servicing device or device servicing fiber patch panel position.
END
PAGE 9
WARNING:
Avoid eye exposure to fiber optic openings on this device when connected to external equipment in any
position. A fiber optic splitter is installed in this device. A connection to any position transmits invisible
laser light on all ports that could be damaging to the eye.
