SPARE PARTS CATALOG
Fourth Edition – February 2006
CONSERV REFRIGERATOR
MODELS
375 / 1200 SERIES ( OLD & NEW)

Page 2
# TABLE OF CONTENTS #
• CIRCUIT DIAGRAM..……………………….……………………..…. 3
• EXPLODED VIEW ……..…………………………………………..…. 4
• SPARE PARTS LIST …..………………………….………………….. 5 – 8

Page 3

Page 4

Page 5
SPARE PARTS LIST
Pos# PART# DESCRIPTION
0001 0-70386480153 Thermometer, freezer-SS(new)/SS(old)/AL
0001 0-70386480103 Thermometer, freezer-B(new)/B(old)
0001 0-70386480101 Thermometer, freezer-W(new)/W(old)
0004 0-7038344 Thermostat, freezer-ALL
0005 0-703806801 Refrigerator thermostat-ALL
0012 0-2038001 Screw- ALL
0044 0-52385100301 Front edging for evaporator-ALL
0061 0-6538053 Filter drier, 20 g-ALL
0067 0-5235002 Castor, complete -ALL
0073 0-2538196 Counter nut for hinge -ALL
0085 0-20381480215 Screw- ALL
0091 0-52381650153 Rubber fillet-Freezer -
SS(new)/AL(new)/SS(old)/B(new)/B(old)
0091 0-52381650128 Rubber fillet-Freezer - W(new)/W(old)
0124 0-2038058 Screw for handles - SS(new)/W(new)/AL(new)/B(new)
0124 0-20380160115 Screw for handles - W(old)
0124 0-2038066 Screw for handles - SS(old)
0124 0-20380660103 Screw for handles - B(old)
0126 8-036038205 Compressor complete R134a -(TL4F 115V) -ALL
0129 8-6000000 Compressor complete R1 34a -(TL2,5F 115V)-ALL
0138 0-52391850110 Crisper bin - SS(new)/W(new)/AL(new)/B(new)
0138 0-52383510110 Crisper bin - W(old)/SS(old)/B(old)
0139 0-52383520101 Front of crisper bin - ALL
0153 0-A129712 Mains lead - ALL
0154 0-7038254 Cover for multiple plug - ALL
0163 0-52381660253 Covering - SS(new)/AL/SS(old)
0163 0-52381660201 Covering - W(new)W(old)
0163 0-52381660203 Covering - B(new)/B(old)
0180 0-70387100101 Switch - W(new)/W(old)
0307 0-A41101101 Evaporator - ALL
0434 0-52381810153 Rubber fillet-SS(new)/AL(new)/SS(old)/B(new)/B(old)
0434 0-52381810128 Rubber fillet-W(new)/W(old)
0486 0-5238857 Iceserver - ALL
0507 0-703812803 Bulb for light - ALL
0539 0-70387100153 Switch - SS(new)/AL/SS(old)
0539 0-70387100103 Switch - B(new)/B(old)
0636 0-52386820153 Thermostat knob - SS(new)/AL/SS(old)
0636 0-52386820101 Thermostat knob - W(new)/W(old)
0636 0-52386820103 Thermostat knob - B(new)/B(old)
0643 0-52386710403 Control panel - SS(new)/AL/W(new)/B(new)

Page 6
Pos# PART# DESCRIPTION
0643 0-52386710203 Control panel - W(old)/SS(old)/B(old)
0644 0-52389980592 Cover plate for top panel - SS(new)/AL
0644 0-52389980501 Cover plate for top panel - W(new)/W(old)
0644 0-52389980553 Cover plate for top panel - SS(old)
0644 0-52389980503 Cover plate for top panel - B(new)/B(old)
0647 0-52386810192 Covering - SS(new)/AL
0647 0-52386810101 Covering - W(new)W(old)
0647 0-52386810153 Covering - SS(old)
0647 0-52386810103 Covering - B(new)/B(old)
0648 0-52386780101 Hand lever - W(old)
0648 0-A1180020424 Hand Lever - SS(old)
0648 0-A1180020303 Hand Lever - B(old)
0651 0-2038067 Screw- ALL
0652 0-52386740192 Cover plate - SS(new)/AL
0652 0-52386740101 End piece - outer part - W(new)/W(old)
0652 0-52386740153 End piece - outer part - SS(old)
0652 0-52386740103 End piece - outer part - B(new)/B(old)
0653 0-A 142003 Prism - ALL
0654 0-52386860153 Mounting plug - SS(new)/AL/SS(old)
0654 0-52386860101 Mounting plug - W(new)/W(old)
0654 0-52386860103 Mounting plug - B(new)/B(old)
0655 0-52386853901 Logo Piece
0656 0-A1040100192 Hinge - SS(new)/AL/SS(old)/B(new)/B(old)
0656 0-A1040100101 Hinge - W(new)/W(old)
0657 0-A1040100292 Centre bridge hinge - ALL
0658 0-4838046 Pivot -ALL
0661 0-5238745 Shelf edging -ALL
0662 0-5238744 Strip for rear edge - ALL
0668 0-2038097 Screw - ALL
0669 0-2038070 Screw - ALL
0670 0-52386890153 Covering - SS(new)/AL/SS(old)
0670 0-52386890101 Covering - W(new)W(old)
0670 0-52386890103 Covering - B(new)/B(old)
0671 0-52386900153 Door closer - SS(new)/AL/SS(old)
0671 0-52386900101 Door closer - W(new)/W(old)
0671 0-52386900103 Door closer - B(new)/B(old)
0672 0-52386910153 Holder for door closer - SS(new)/AL/SS(old)
0672 0-52386910101 Holder for door closer - W(new)/W(old)
0672 0-52386910103 Holder for door closer - B(new)/B(old)
0677 0-5238683 Stop - ALL
0679 0-5239260 Reflector for lamp - SS(new)/AL/B(new)
0679 0-52392600101 Reflector for lamp - W(new)
0679 0-5238684 Reflector for lamp - W(old)/SS(old)/B(old)
0680 0-703826401 Socket, complete - ALL

Page 7
Pos# PART# DESCRIPTION
0714 0-703860101 Thermal relay 115V - ALL
0798 0-52387290153 Covering - SS(new)/AL/SS(old)
0798 0-52387290101 Covering - W(new)/W(old)
0798 0-52387290103 Covering - B(new)/B(old)
0802 0-52387370110 Egg tray - ALL
0803 0-52391440110 Bottle holder - ALL
0804 0-52389200101 Stop for bottle holder - ALL
0805 0-52389280110 Door box left -ALL
0806 0-52389290101 Lid for left door box -ALL
0807 0-52389300110 Door box right - ALL
0808 0-52389310101 Lid for right door box - ALL
0809 0-52389320110 Insert for egg tray
0817 0-6938309 Bottle shelf - SS(new)/AL/W(new)/B(new)
0817 0-6938164 Bottle shelf - W(old)/SS(old)/B(old)
0819 0-52387600110 Meatbox - half - ALL
0826 0-52389170101 Extension for defrost water outlet - ALL
0827 0-52389180101 Drain for defrost water outlet - ALL
0828 0-5239220 Side edging for evaporator - SS(new)/W(new)/AL/B(new)
0828 0-52389580201 Side edging for evaporator - W(old)/SS(old)/B(old)
0831 0-6738029 Evaporator -SS(new)/W(new)/AL/B(new)
0831 0-6738039 Evaporator - W(old)/SS(old)/B(old)
0837 0-52389370110 Bottle holder - ALL
0869 0-5238956 Ajustable foot - ALL
0924 0-52389570101 Pipe covering -ALL
0979 0-A1110020292 Plate for centre brigde - SS(new)/AL/
0979 0-A1110020201 Plate for centre brigde -W(new)/W(old)
0979 0-A1110020252 Plate for centre brigde - SS(old)
0979 0-A1110020203 Plate for centre brigde - B(new)/B(old)
0980 0-52389710101 Cover strip for centre bridge -
SS(new)/W(new)/AL/W(old)/SS(old)
0980 0-52389710103 Cover strip for centre bridge - B(new)/B(old)
1000 0-A1040100592 Hinge - SS(new)/B(new)/AL/B(old)/SS(old)
1000 0-A1040100501 Hinge - W(new)/W(old)
1004 0-52390260192 Hole plugs for bottom panel - SS(new)/AL
1004 0-52390260101 Hole plugs for bottom panel - W(new)/W(old)
1004 0-52390260153 Hole plugs for bottom panel - SS(old)
1004 0-52390260103 Hole plugs for bottom panel - B(new)/B(old)
1012 0-7538090 Glass shelf 457x290mm - ALL
1034 0-52391040101 Freezer drawer - bottom - 190mm - white - ALL
1036 0-52391060101 Freezer drawer - large - 224,5mm - white - ALL
1042 0-52391420101 Side guide for plastic drawer, right - ALL
1043 0-52391430101 Side guide for plastic drawer, left - ALL
1047 0-52391170110 Front/flap - curved - 190mm -super insulated - iceblue – ALL

Page 8
Pos# PART# DESCRIPTION
1048 0-52391180110 Front/flap - curved - 224,5mm -super insulated - iceblue -
ALL.
1054 0-52391140101 Front edging with stop - super insulated - white - ALL
1055 0-52386620153 Covering - SS(new)/AL/SS(old)
1055 0-52386620101 Covering - W(new)/W(old)
1055 0-52386620103 Covering - B(new)/B(old)
1119 0-703881202 Print for control panel - SS(new)/W(new)/AL/B(new)
1119 0-703881201 Print for control panel - W(old)/SS(old)/SS(new)
1121 0-5239079 Holder thermostat + -meterphial, freezer - ALL
1170 0-52386690392 Bottom Panel, Skirting Board - SS(new)/AL
1170 0-52386690301 Bottom Panel, Skirting Board - W(new)
1170 0-52386690201 Bottom Panel, Skirting Board - W(old)
1170 0-52386690253 Bottom Panel, Skirting Board - SS(old)
1170 0-52386690303 Bottom Panel, Skirting Board - B(new)
1170 0-52386690203 Bottom Panel, Skirting Board - B(old)
1180 0-5239178 Rear edging with slide - ALL
1181 0-5239179 Slide for rear edging
1207 0-5239205 Ice cube tray - SS(new)/AL/W(new)/B(new)
1207 0-52382420101 Ice cube tray - W(old)/SS(old)/B(old)
1236 0-52392560192 Hand lever, Boomerang - SS(new)/W(new)/AL
1236 0-52392560103 Hand lever, Boomerang - B(old)
1239 0-A5100020396 Door, freezer, complete - SS(new)
1239 0-A5100020301 Door, freezer, complete - W(new)
1239 0-A5100020393 Door, freezer, complete - AL(new)
1239 0-A5020020301 Door, freezer, complete - W(old)
1239 0-A5020020353 Door, freezer, complete - SS(old)
1239 0-A5100020303 Door, freezer, complete - B(new)
1239 0-A2020020303 Door, freezer, complete - B(old)
1251 0-A5102060196 Door, refrigerator, complete - SS(new)
1251 0-A5102060101 Door, refrigerator, complete - W(new)
1251 0-A5102060193 Door, refrigerator, complete - AL(new)
1251 0-A5042060101 Door, refrigerator, complete - W(old)
1251 0-A5042060153 Door, refrigerator, complete - SS(old)
1251 0-A5102060103 Door, refrigerator, complete - B(new)
1251 0-A5042060103 Door, refrigerator, complete - B(old)
***********************************************
