Equinox Systems EQLED032 User manual

Order code: EQLED032
RGB Power Batten
User Manual

www.prolight.co.uk RGB Power Batten User Manual
2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CARE-
FULLY BEFORE YOUR INITIAL START-UP!
• Beforeyourinitialstart-up,pleasemakesurethatthereisnodamagecausedduringtransportation.
• Shouldtherebeanydamage,consultyourdealeranddonotusetheequipment.
• Tomaintaintheequipmentingoodworkingconditionandtoensuresafeoperation,itisnecessary
fortheusertofollowthesafetyinstructionsandwarningnoteswritteninthismanual.
• Pleasenotethatdamagescausedbyusermodicationstothisequipmentarenotsubjecttowarranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
Ifthisequipmentisoperatedinanyotherway,thanthosedescribedinthismanual,theproductmaysufferdamageand
thewarrantybecomesvoid.Incorrectoperationmayleadtodangere.g:short-circuit,burnsandelectricshocksetc.
Donotendangeryourownsafetyandthesafetyofothers!
Incorrectinstallationorusecancauseseriousdamagetopeopleand/orproperty.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!
• Neverletthepowercablecomeintocontactwithother
cables.Handlethepowercableandallmainsvoltage
connectionswithparticularcaution!
• Neverremovewarningorinformativelabelsfromtheunit.
• Donotopentheequipmentanddonotmodifytheunit.
• Donotconnectthisequipmenttoadimmerpack.
• Donotswitchtheequipmentonandoffinshortintervals,
asthiswillreducethesystem’slife.
• Onlyusetheequipmentindoors.
• Donotexposetoammablesources,liquidsorgases.
• Alwaysdisconnectthepowerfromthemainswhen
equipmentisnotinuseorbeforecleaning!Onlyhandle
thepower-cablebytheplug.Neverpullouttheplugby
pullingthepower-cable.
• Makesurethattheavailablemainssupplyvoltageis
between100~240VAC,50/60Hz.
• Makesurethatthepowercableisnevercrimpedor
damaged.Checktheequipmentandthepowercable
periodically.
• Iftheequipmentisdroppedordamaged,disconnectthe
mainspowersupplyimmediatelyandhaveaqualied
engineerinspecttheequipmentbeforeoperatingagain.

• Iftheequipmenthasbeenexposedtodrastic
temperatureuctuation(e.g.aftertransportation),
donotconnectpowerorswitchitonimmediately.
Thearisingcondensationmightdamagetheequipment.
Leavetheequipmentswitchedoffuntilithasreached
roomtemperature.
• Ifyourproductfailstofunctioncorrectly,stopuse
immediately.Packtheunitsecurely(preferablyinthe
originalpackingmaterial),andreturnittoyourProLight
dealerforservice.
• Onlyusefusesofsametypeandrating.
• Repairs,servicingandpowerconnectionmustonlybe
carriedoutbyaqualiedtechnician.THISUNITCONTAINS
NOUSERSERVICEABLEPARTS.
• Thislightingxtureisforprofessionaluseonly-itis
notdesignedfororsuitableforhouseholduse.The
productmustbeinstalledbyaqualiedtechnicianin
accordancewithlocalterritoryregulations.Thesafetyof
theinstallationistheresponsibilityoftheinstaller.The
xturepresentsrisksofsevereinjuryordeathduetore
hazards,electricshockandfalls.
• Warning!RiskGroup2LEDproductaccordingto
EN62471.Donotviewthelightoutputwithoptical
instrumentsoranydevicethatmayconcentratethebeam.
• WARRANTY:Oneyearfromdateofpurchase.

www.prolight.co.uk RGB Power Batten User Manual
3
Product overview & technical specications
The1mRGBPowerBattencontains240RGBLEDsdividedinto8segments.Onboardfeaturesincludecolour
mixingtocreatesoftwashesfromitsrichcolourpalette,andchaseprogramscontrolledinautomodeoractivated
bymusic.Severaldifferentchaseprogramsareincludedandcanbeselectedbythecontrolpanelalongwith
brightnessandspeed.
•240x10mmLEDs(R:96,G:72,B:72)
•Beamangle:30°
•DMXchannels:2/3/4/7/14or26selectable
•Soundactive,autoandmaster/slavemodes
•0-100%dimmingandvariablestrobe
•Bracketallowsformultipleriggingoroor
standingapplications
•4pushbuttonmenuwithLEDdisplay
•IECpowerinput/output
•3-PinXLRinput/output
•Convectioncooled
RGB Power Batten
Specications
Powerconsumption 30W
Powersupply 100~240V,50/60Hz
Fuse T1A250V
Dimensions 85x1075x65mm
Weight 1.8kg
Ordercode EQLED032 0m 1m 2m 3m 4m 5m
30° - Lux 2960 741 329
30°
185 119
1075mm 65mm
85mm

www.prolight.co.uk RGB Power Batten User Manual
4
Technical specications
Inthebox:1 x xture,
2 x mounting
brackets/feet
1 x power cable
& 1 x user manual
www.prolight.co.uk
DMX IN
FUSE:
T1A 250V
POWER OUTPUT: 100-240V~50/60Hz
POWER INPUT:
100-240V~50/60Hz
DMX OUT
MENU UP DOWNENTER
POWER
BATTEN
RGB
www.prolight.co.uk
DMX IN
FUSE:
T1A 250V
POWER OUTPUT: 100-240V~50/60Hz
POWER INPUT:
100-240V~50/60Hz
DMX OUT
MENU UP DOWNENTER
POWER
BATTEN
RGB
www.prolight.co.uk
DMX IN
FUSE:
T1A 250V
POWER OUTPUT: 100-240V~50/60Hz
POWER INPUT:
100-240V~50/60Hz
DMX OUT
MENU UP DOWNENTER
POWER
BATTEN
RGB
www.prolight.co.uk
DMX IN
FUSE:
T1A 250V
POWER OUTPUT: 100-240V~50/60Hz
POWER INPUT:
100-240V~50/60Hz
DMX OUT
MENU UP DOWNENTER
POWER
BATTEN
RGB
01 02
0308 10 05 06 0704 09
01-Brackettighteningknobs
02-Bracket
03-Earthpoint
04-LEDdisplay
05-Functionbuttons
06-3-PinXLRinput
07-3-PinXLRoutput
08-IECpowerinput
09-IECpoweroutput
10-FuseT1A250V

www.prolight.co.uk RGB Power Batten User Manual
5
Operating instructions
d. 0 0 1
d. 5 1 2
d. 0 0 1
d - p 1
d - p 6
C O L r
r 0 0 0
g 0 0 0
r 2 5 5
g 2 5 5
b 0 0 0 b 2 5 5
S U 0 0
S U 0 0
S U 3 1
P r - -
DMX address setting
Channel mode
Static colour mode
Auto mode
S L a v
Sound sensitivity
Built-in
programs
Slave mode
F 5 0 0
F 5 0 0
F 5 0 0
F 5 0 0
F 5 0 0
F 5 0 0
F 5 0 0
F 5 9 9
F 5 9 9
F 5 9 9
F 5 9 9
F 5 9 9
F 5 9 9
F 5 9 9
P r 0 1
1 - - r
2 - r g
3 - - g
4 - g b
5 - - b
6 - r b
7 r g b
8 O F F
A u t 0
n 0 0 1
s P 0 0
n 1 0 0
S P F L
F d 0 0
F 5 0 0
F d 9 9
F 5 9 9
SPFL
F599
Fd99
S P 0 1
F 5 0 0
P r 0 2 P r 2 0
F d 0 0
P r 2 1 P r 2 2
S P F L
F 5 9 9
F d 9 9
S P 0 1
F 5 0 0
F d 0 0
1 - - r
1 - r g
1 - - g
1 - g b
1 - - b
1 - r b
1 r g b
1 O F F
2 - - r
2 - r g
2 - - g
2 - g b
2 - - b
2 - r b
2 r g b
2 O F F
MENU

www.prolight.co.uk RGB Power Batten User Manual
6
Operating instructions
DMX mode:
OperatinginaDMXcontrolmodeenvironmentgivestheuserthegreatestexibilitywhenitcomes
tocustomisingorcreatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitofthe
xtureandeachxtureindependently.
ToaccesstheDMXaddressmode,pressthe“MENU”buttononthefrontoftheunittoshowd.001
ontheLEDdisplay.Nowusethe“UP”and“DOWN”buttonstosettherequiredDMXaddress.
Pressthe“ENTER”buttontoconrmthesetting.Thedisplaywillnowshowd-P1ontheLEDdisplay.
Nowusethe“UP”and“DOWN”buttonstochooseoneofthe2/3/4/7/14or26DMXchannelmodes.
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
d-p1-3channelmode
d-p2-4channelmode
d-p3-14channelmode
d-p4-26channelmode
d-p5-2channelmode
d-p5-7channelmode
3 channel mode:
CH1 CH2 CH3
Red
(0-255)
Green
(0-255)
Blue
(0-255)
4 channel mode:
CH1 CH2 CH3 CH4
Red
(0-255)
Green
(0-255)
Blue
(0-255)
Master
dimmer
(0-255)
Value CH1 CH2
000-007 Nofuntion Nofuntion
008-015 Red
Speed
(0-255)
016-023 Yellow
024-031 Green
032-039 Cyan
040-047 Blue
048-055 Purple
056-063 White
064-071 Program1
072-079 Program2
080-087 Program3
088-095 Program4
096-103 Program5
104-111 Program6
112-119 Program7
120-127 Program8
128-135 Program9
136-143 Program10
144-151 Program11
152-159 Program12
160-167 Program13
2 channel mode:
168-175 Program14
Speed
(0-255)
176-183 Program15
184-191 Program16
192-199 Program17
200-207 Program18
208-215 Program19
216-223 Program20
224-231 Program21
232-255 Soundactive
mode
Sound
sensitivity
(0-255)

www.prolight.co.uk RGB Power Batten User Manual
7
Operating instructions
Value CH1 CH2 CH3 CH4 CH5 CH6 CH7
000-007
Red
(0-255)
Green
(0-255)
Blue
(0-255)
Nofuntion Nofuntion Nofunction
Masterdimmer
(0-255)
008-015 Red
Speed(0-255) Flash(0-255)
016-023 Yellow
024-031 Green
032-039 Cyan
040-047 Blue
048-055 Purple
056-063 White
064-071 Program1
072-079 Program2
080-087 Program3
088-095 Program4
096-103 Program5
104-111 Program6
112-119 Program7
120-127 Program8
128-135 Program9
136-143 Program10
144-151 Program11
152-159 Program12
160-167 Program13
168-175 Program14
176-183 Program15
184-191 Program16
192-199 Program17
200-207 Program18
208-215 Program19
216-223 Program20
224-231 Program21
232-255 Soundactivemode Soundsensitivity(0-255) Nofuntion Nofuntion
7 channel mode:
14 channel mode:
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9
Segment
1&2Red
(0-255)
Segment
1&2Green
(0-255)
Segment
1&2Blue
(0-255)
Segment
3&4Red
(0-255)
Segment
3&4Green
(0-255)
Segment
3&4Blue
(0-255)
Segment
5&6Red
(0-255)
Segment
5&6Green
(0-255)
Segment
5&6Blue
(0-255)
CH10 CH11 CH12 CH13 CH14
Segment
7&8Red
(0-255)
Segment
7&8Green
(0-255)
Segment
7&8Blue
(0-255)
Flash
(0-255)
Slow-fast
Master
dimmer
(0-255)

www.prolight.co.uk RGB Power Batten User Manual
8
Auto mode:
Toaccessautomode,pressthe“MENU”buttononthefrontoftheunittoshowAutoontheLED
display.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoosetherequired
programn001~n100.Pressthe“ENTER”buttonthenusethe“UP”and“DOWN”buttonstoselect
therunningspeedSP01~SPFL.Pressthe“ENTER”buttonagainandusethe“UP”and“DOWN”
buttonstoselectthefadingtimeFd00~Fd99.Finallypressthe“ENTER”buttonandusethe“UP”
and“DOWN”buttonstoselecttheashspeedF500~F599.
Pressthe“ENTER”buttontoconrmthesetting.
Master/slave mode:
ThedefaultsettingforthisxtureisMaster.
Tosettheslaveunit,pressthe“MENU”buttononthefrontofthemasterunittoshowSLav
ontheLEDdisplay.TheunitisnowinSlavemode.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
PleaseensurethatallslaveunitsaresettothesameDMXchannelmodeasthemasterunit.
Sound active mode:
Toaccessthesoundactivemode,pressthe“MENU”buttononthefrontoftheunittoshowSU31
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstosetthe
soundsensitivity01~31.Pressthe“ENTER”buttontoconrmthesetting.
Value: 01 - 31 (01 = low sensitivity, 31 = high sensitivity)
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Operating instructions
26 channel mode:
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9
Segment1
Red
(0-255)
Segment1
Green
(0-255)
Segment1
Blue
(0-255)
Segment2
Red
(0-255)
Segment2
Green
(0-255)
Segment2
Blue
(0-255)
Segment3
Red
(0-255)
Segment3
Green
(0-255)
Segment3
Blue
(0-255)
CH19 CH20 CH21 CH22 CH23 CH24 CH25 CH26
Segment7
Red
(0-255)
Segment7
Green
(0-255)
Segment7
Blue
(0-255)
Segment8
Red
(0-255)
Segment8
Green
(0-255)
Segment8
Blue
(0-255)
Flash
(0-255)
Slow-fast
Master
dimmer
(0-255)
CH10 CH11 CH12 CH13 CH14 CH15 CH16 CH17 CH18
Segment4
Red
(0-255)
Segment4
Green
(0-255)
Segment4
Blue
(0-255)
Segment5
Red
(0-255)
Segment5
Green
(0-255)
Segment5
Blue
(0-255)
Segment6
Red
(0-255)
Segment6
Green
(0-255)
Segment6
Blue
(0-255)

www.prolight.co.uk RGB Power Batten User Manual
9
Static colour mode:
Toaccessthestaticcolourmodepress“MENU”untilColrshowsontheLEDdisplay.
Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstoselectthebrightness
betweenr.000~r.255.Pressthe“ENTER” buttonandrepeatforgreen(G)andblue(b).
Value: 000 - 255 (000 = low brightness, 255 = high brightness)
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Built-in programs:
Toaccessthebuilt-inprograms,pressthe“MENU”buttononthefrontoftheunittoshowPr--
ontheLEDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoosethe
requiredprogramPr01~Pr31.Pressthe“ENTER”buttontoconrmthesetting.
Pr01-Nowusethe“UP”and“DOWN”buttonstoselecttherequiredcolour.Pressthe“ENTER”
buttontoconrmthesettingandusethe“UP”and“DOWN”buttonstochoosetheashspeed
F500~F599.Pressthe“ENTER”buttontoconrmthesetting.
Pr02~Pr20-Nowusethe“UP”and“DOWN”buttonstoselecttherunningspeed
SP01~SPFL.Pressthe“ENTER”buttontoconrmthesetting.Nowusethe“UP”and“DOWN”
buttonstoselecttheashspeedF500~F599.Pressthe“ENTER”buttontoconrmthesetting.
Finallyusethe“UP”and“DOWN”buttonstoselectthefadingtimeFd00~Fd99.
Pressthe“ENTER”buttontoconrmthesetting.
Pr21~Pr22-Nowusethe“UP”and“DOWN”buttonstoselecttherunningspeed
SP01~SPFL.Pressthe“ENTER”buttontoconrmthesetting.Nowusethe“UP”and“DOWN”
buttonstoselecttheashspeedF500~F599.Pressthe“ENTER”buttontoconrmthesetting.
Usethe“UP”and“DOWN”buttonstoselectthefadingtimeFd00~Fd99.Pressthe“ENTER”
buttontoconrmthesetting.Tosetthebackgroundcolourusethe“UP”and“DOWN”buttonstoselect
between1--r~1OFF.Pressthe“ENTER”buttontoconrmthesetting.Fianllytosetthechasing
colourusethe“UP”and“DOWN”buttonstoselectbetween2--r~2OFF.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Operating instructions

www.prolight.co.uk RGB Power Batten User Manual
10
DMX setup
FurtherDMXcablescanbe
purchasedfromallgoodsound
andlightingsuppliersor
ProLightConceptsdealers.
Pleasequote:
CABL10 – 2m
CABL11 – 5m
CABL12 – 10m
Setting the DMX address:
TheDMXmodeenablestheuseofauniversalDMXcontroller.Eachxturerequiresa“startaddress”
from1-512.Axturerequiringoneormorechannelsforcontrolbeginstoreadthedataonthechannel
indicatedbythestartaddress.Forexample,axturethatoccupiesoruses7channelsofDMXandwas
addressedtostartonDMXchannel100,wouldreaddatafromchannels:100,101,102,103,104,105
and106.Chooseastartaddresssothatthechannelsuseddonotoverlap.E.g.thenextunitinthe
chainstartsat107.
DMX 512:
DMX(DigitalMultiplex)isauniversalprotocolusedasaformofcommunicationbetweenintelligent
xturesandcontrollers.ADMXcontrollersendsDMXdatainstructionsformthecontrollertothexture.
DMXdataissentasserialdatathattravelsfromxturetoxtureviatheDATA“IN”andDATA“OUT”
XLRterminalslocatedonallDMXxtures(mostcontrollersonlyhaveadata“out”terminal).
DMX linking:
DMXisalanguageallowingallmakesandmodelsofdifferentmanufacturestobelinkedtogether
andoperatefromasinglecontroller,aslongasallxturesandthecontrollerareDMXcompliant.
ToensureproperDMXdatatransmission,whenusingseveralDMXxturestrytousetheshortest
cablepathpossible.TheorderinwhichxturesareconnectedinaDMXlinedoesnotinuencethe
DMXaddressing.Forexample;axtureassignedtoaDMXaddressof1maybeplacedanywherein
aDMXline,atthebeginning,attheend,oranywhereinthemiddle.Whenaxtureisassigneda
DMXaddressof1,theDMXcontrollerknowstosendDATAassignedtoaddress1tothatunit,
nomatterwhereitislocatedintheDMXchain.
DATA cable (DMX cable) requirements (for DMX operation):
ThisxturecanbecontrolledviaDMX-512protocol.TheDMXaddressissetonthebackoftheunit.
YourunitandyourDMXcontrollerrequireastandard3-pinXLRconnectorfordatainput/output,
seeimagebelow.
Also remember that DMX cable must be daisy chained and cannot be split.

www.prolight.co.uk RGB Power Batten User Manual
11
Notice:
Besuretofollowthediagramsbelowwhenmakingyourowncables.Donotconnectthecables
shieldconductortothegroundlugorallowtheshieldconductortocomeincontactwiththeXLRs
outercasing.Groundingtheshieldcouldcauseashortcircuitanderraticbehaviour.
Special note:
Line termination:
Whenlongerrunsofcableareused,
youmayneedtouseaterminatoron
thelastunittoavoiderraticbehaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL9O, 5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Somemanufacturesuse5-pinXLRconnectorsfordatatransmissioninplaceof3-pin.5-pinXLRxtures
maybeimplementedina3-pinXLRDMXline.Wheninsertingstandard5-pinXLRconnectorsintoa
3-pinlineacableadaptormustbeused.Thediagrambelowdetailsthecorrectcableconversion.
Terminationreducessignaltransmission
problemsandinterference.itisalways
advisabletoconnectaDMXterminal,
(resistance120Ohm1/4W)betweenpin2
(DMX-)andpin3(DMX+)ofthelastxture.
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup

www.prolight.co.uk RGB Power Batten User Manual
12
WEEE notice & Optional accessories
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
Thismarkingshownontheproductoritsliterature,indicatesthatitshouldnotbedisposedof
withotherhouseholdwastesattheendofitsworkinglife.Topreventpossibleharmtothe
environmentorhumanhealthfromuncontrolledwastedisposal,pleaseseparatethisfromother
typesofwastesandrecycleitresponsiblytopromotethesustainablereuseofmaterialresources.
Householdusersshouldcontacteithertheretailerwheretheypurchasedthisproduct,ortheir
localgovernmentofce,fordetailsofwhereandhowtheycantakethisitemforenvironmentally
saferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthe
purchasecontract.Thisproductshouldnotbemixedwithothercommercialwastesfordisposal.
Pleasecontactyourlocalretailertopurchasetheseaccessories.
Tokeepup-to-dateonthelatestaccessoriesandproductrangeadditions
pleasevisitwww.prolight.co.uk
Optional Twin Case (Holds 2 x xtures)
Order code: CASE29
