Equinox Systems EQLED101 User manual

Order code: EQLED101
Dragony Quad
User Manual V1.4

www.prolight.co.uk Dragony Quad User Manual
2
Safety advice
WARNING
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL
CAREFULLY BEFORE YOUR INITIAL START-UP!
• Beforeyourinitialstart-up,pleasemakesurethatthereisnodamagecausedduringtransportation.
• Shouldtherebeanydamage,consultyourdealeranddonotusetheequipment.
• Tomaintaintheequipmentingoodworkingconditionandtoensuresafeoperation,itisnecessary
fortheusertofollowthesafetyinstructionsandwarningnoteswritteninthismanual.
• Pleasenotethatdamagescausedbyusermodicationstothisequipmentarenotsubjecttowarranty.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance
of this manual or any unauthorised modication to the equipment.
OPERATING DETERMINATIONS
Ifthisequipmentisoperatedinanyotherway,thanthosedescribedinthismanual,theproductmaysufferdamageand
thewarrantybecomesvoid.Incorrectoperationmayleadtodangere.g:short-circuit,burnsandelectricshocksetc.
Donotendangeryourownsafetyandthesafetyofothers!
Incorrectinstallationorusecancauseseriousdamagetopeopleand/orproperty.
• Neverletthepowercablecomeintocontactwithother
cables.Handlethepowercableandallmainsvoltage
connectionswithparticularcaution!
• Neverremovewarningorinformativelabelsfromtheunit.
• Donotopentheequipmentanddonotmodifytheunit.
• Donotconnectthisequipmenttoadimmerpack.
• Donotswitchtheequipmentonandoffinshortintervals,
asthiswillreducethesystem’slife.
• Onlyusetheequipmentindoors.
• Donotexposetoammablesources,liquidsorgases.
• Alwaysdisconnectthepowerfromthemainswhen
equipmentisnotinuseorbeforecleaning!Onlyhandle
thepower-cablebytheplug.Neverpullouttheplugby
pullingthepower-cable.
• Makesurethattheavailablevoltageisbetween
100~240V,50/60Hz.
• Makesurethatthepowercableisnevercrimpedor
damaged.Checktheequipmentandthepowercable
periodically.
• Iftheequipmentisdroppedordamaged,disconnectthe
mainspowersupplyimmediatelyandhaveaqualied
engineerinspecttheequipmentbeforeoperatingagain.
• Iftheequipmenthasbeenexposedtodrastic
temperatureuctuation(e.g.aftertransportation),
donotconnectpowerorswitchitonimmediately.
Thearisingcondensationmightdamagetheequipment.
Leavetheequipmentswitchedoffuntilithasreached
roomtemperature.
• Ifyourproductfailstofunctioncorrectly,stopuse
immediately.Packtheunitsecurely(preferablyinthe
originalpackingmaterial),andreturnittoyourProLight
dealerforservice.
• Onlyusefusesofsametypeandrating.
• Repairs,servicingandpowerconnectionmustonlybe
carriedoutbyaqualiedtechnician.THISUNITCONTAINS
NOUSERSERVICEABLEPARTS.
• Thislightingxtureisforprofessionaluseonly-itis
notdesignedfororsuitableforhouseholduse.The
productmustbeinstalledbyaqualiedtechnicianin
accordancewithlocalterritoryregulations.Thesafetyof
theinstallationistheresponsibilityoftheinstaller.The
xturepresentsrisksofsevereinjuryordeathduetore
hazards,electricshockandfalls.
• Warning!RiskGroup2LEDproductaccordingto
EN62471.Donotviewthelightoutputwithoptical
instrumentsoranydevicethatmayconcentratethebeam.
• WARRANTY:Oneyearfromdateofpurchase.
CAUTION!
KEEP THIS EQUIPMENT
AWAY FROM RAIN,
MOISTURE AND LIQUIDS
CAUTION!
TAKE CARE USING
THIS EQUIPMENT!
HIGH VOLTAGE-RISK
OF ELECTRIC SHOCK!!

www.prolight.co.uk Dragony Quad User Manual
3
Product overview & technical specications
TheDragonyQuadisadynamicmulti-beameffectfeaturingtwosweepingLEDbars,eachloadedwithfour
individuallycontrollable12Wquad-colourLEDs.Theeightvibrantcolourednarrowbeamsprojectacrosstheroom
makingthextureidealforamultitudeofenvironmentsfromstagesandclubstomobileDJs.Thisagilexture
createsamazinglightingshowswhenusedinmultiplesbutalsomakesanoutstandingcentrepiece.
•8x12Wquad-colourLEDs
•Beamangle:4.5°
•Pixelmappingcapabilities
•DMXchannels:11or37selectable
•Auto,soundactiveandmaster/slavemodes
plusbuilt-inprograms
•0-100%dimmingandvariablestrobe
•Pan:630°,Tilt:360°continuousrotation
•Quickreleaseomegaclampincluded
•4pushbuttonmenuwithLCDdisplay
•IECpowerinput/output
•3-PinXLRinput/output
Dragony Quad
Specications
Powerconsumption 120W
Powersupply 100~240V,50/60Hz
Fuse F5A250V
Dimensions 390x403x150mm
Weight 6.3kg
Ordercode EQLED101
403mm 155mm
390mm

www.prolight.co.uk Dragony Quad User Manual
4
Technical specications
01-Functionbuttons
02-Omegaclampreceiver
03-LCDdisplay
04-SoundLED
05-SlaveLED
06-DMXinputLED
07-MasterLED
08-Handles
09-IECpowerinput
10-FuseF5A250V
11-IECpoweroutput
12-Powerswitch
13-Microphone
14-3-PinXLRDMXinput
15-3-PinXLRDMXoutput
DRAGONFLY QUAD
DMX SLAVE
SOUND
MASTER
MENU ENTERDOWN UP
01 0302 0407 0506
08 08
POWER IN POWER OUT
ON OFF
MIC
DMX INDMX OUT
www.prolight.co.uk
111009 02 14 151312
08 08
Inthebox:1 x xture,
1 x omega clamp,
1 x power cable
& 1 x user manual

www.prolight.co.uk Dragony Quad User Manual
5
Operating instructions
DMX mode:
OperatinginaDMXcontrolmodeenvironmentgivestheuserthegreatestexibilitywhenitcomes
tocustomisingorcreatingashow.Inthismodeyouwillbeabletocontroleachindividualtraitofthe
xtureandeachxtureindependently.
ToaccesstheDMXaddressmode,pressthe“MENU”buttononthefrontoftheunittoshow“DMX
Address” ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonsto
settherequiredDMXaddress.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
ToaccesstheDMXchannelmode,pressthe“MENU”buttononthefrontoftheunittoshow“Channel
Mode” ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonsto
chooseoneofthe11or37DMXchannelmodes.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
11 channel mode:
Channel Value Function
CH1 000-255 PanMovement(0°-630°)
CH2
000-127 Tilt1Movement(0°-360°)
128-191 Fast-slowcontinuous
reverserotation
192-255 Slow-fastcontinuousrotation
CH3
000-127 Tilt2Movement(0°-360°)
128-191 Fast-slowcontinuous
reverserotation
192-255 Slow-fastcontinuousrotation
CH4 000-255 Masterdimmer(0-100%)
CH5 000-009 Nofunction
010-255 Strobe(slow-fast)
CH6 000-255 Red(0-100%dimming)
CH7 000-255 Green(0-100%dimming)
CH8 000-255 Blue(0-100%dimming)
CH9 000-255 White(0-100%dimming)
CH10
000-007 Nofunction
008-017 Program1
018-027 Program2
028-037 Program3
038-047 Program4
048-057 Program5
CH10
058-067 Program6
068-077 Program7
078-087 Program8
088-097 Program9
098-107 Program10
108-117 Program11
118-127 Program12
128-136 Program13
137-146 Program14
147-156 Program15
157-166 Program16
167-176 Program17
177-186 Program18
187-196 Program19
197-206 Program20
207-216 Program21
217-226 Program22
227-236 Program23
237-246 Program24
247-255 Program25
CH11 0-255 Programspeed(fast-slow)

www.prolight.co.uk Dragony Quad User Manual
6
Operating instructions
Show mode:
Toaccesstheshowmodes,pressthe“MENU”buttononthefrontoftheunittoshow“Show Mode”
ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoosethe
showyourequirefromeither“Auto Run” or“Sound”.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Master/slave mode:
Tosetthemasterunit,pressthe“MENU”buttononthefrontofthemasterunittoshow“Slave Mode”
ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
“Master”.Pressthe“ENTER”buttontoconrmthesetting.Thenselectyourdesiredprogram(sound
active,DMXoroneofthebuilt-inprograms).
Tosettheotherunitsinslavemode,pressthe“MENU”buttononthefrontoftheunittoshow“Slave
Mode” ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonsto
chooseeither“Slave1” or“Slave2”.Pressthe“ENTER”buttontoconrmthesetting.Theunitwillnow
runinsequencewiththemasterunit.Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
PleaseensurethatallslaveunitsaresettothesameDMXchannelmodeasthemasterunit.
36 channel mode:
Channel Value Function
CH1 000-255 PanMovement(0°-630°)
CH2
000-127 Tilt1Movement(0°-360°)
128-191 Fast-slowcontinuous
reverserotation
192-255 Slow-fastcontinuousrotation
CH3
000-127 Tilt2Movement(0°-360°)
128-191 Fast-slowcontinuous
reverserotation
192-255 Slow-fastcontinuousrotation
CH4 000-255 Masterdimmer(0-100%)
CH5 000-009 Nofunction
010-255 Strobe(slow-fast)
CH6 000-255 LED1Red(0-100%dimming)
CH7 000-255 LED1Green(0-100%dimming)
CH8 000-255 LED1Blue(0-100%dimming)
CH9 000-255 LED1White(0-100%dimming)
CH10 000-255 LED2Red(0-100%dimming)
CH11 000-255 LED2Green(0-100%dimming)
CH12 000-255 LED2Blue(0-100%dimming)
CH13 000-255 LED2White(0-100%dimming)
CH14 000-255 LED3Red(0-100%dimming)
CH15 000-255 LED3Green(0-100%dimming)
CH16 000-255 LED3Blue(0-100%dimming)
CH17 000-255 LED3White(0-100%dimming)
CH18 000-255 LED4Red(0-100%dimming)
CH19 000-255 LED4Green(0-100%dimming)
CH20 000-255 LED4Blue(0-100%dimming)
CH21 000-255 LED4White(0-100%dimming)
CH22 000-255 LED5Red(0-100%dimming)
CH23 000-255 LED5Green(0-100%dimming)
CH24 000-255 LED5Blue(0-100%dimming)
CH25 000-255 LED5White(0-100%dimming)
CH26 000-255 LED6Red(0-100%dimming)
CH27 000-255 LED6Green(0-100%dimming)
CH28 000-255 LED6Blue(0-100%dimming)
CH29 000-255 LED6White(0-100%dimming)
CH30 000-255 LED7Red(0-100%dimming)
CH31 000-255 LED7Green(0-100%dimming)
CH32 000-255 LED7Blue(0-100%dimming)
CH33 000-255 LED7White(0-100%dimming)
CH34 000-255 LED8Red(0-100%dimming)
CH35 000-255 LED8Green(0-100%dimming)
CH36 000-255 LED8Blue(0-100%dimming)
CH37 000-255 LED8White(0-100%dimming)

www.prolight.co.uk Dragony Quad User Manual
7
Blackout mode:
BlackoutmodeensureswhenthexturelosesDMXsignalitwillblackout.Tosettheblackoutmode,
pressthe“MENU”buttononthefrontofthemasterunittoshow“Blackout” ontheLCDdisplay.
Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose“YES” or“NO”.
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Sound active mode:
Toaccessthesoundactivemode,pressthe“MENU”buttononthefrontoftheunittoshow“Sound
State”ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstoset
thesoundmode“ON”or“OFF”.Pressthe“ENTER”buttontoconrmthesetting.
Toadjustthesoundsensitivity,pressthe“MENU”buttonontherearoftheunittoshow“Sound Sense”
ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstosetthe
soundsensitivitybetween0-100.Pressthe“ENTER”buttontoconrmthesetting.
Value: 0 - 100 (0 = low sensitivity, 100 = high sensitivity)
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Pan/Tilt restricted movements:
Toaccessthesoundactivemode,pressthe“MENU”buttononthefrontoftheunittoshow“Pati Mode”
ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
betweenthefollowing:
“PanTilt Angle 1” -Tiltmovementangle210°,idealforxturessituatedontheground.
“PanTilt Angle 2” -Tiltmovementangle90°,idealforxturesmountedontheceilingorsimilar.
“PanTilt Angle 3” -Tiltmovementangle90°(60°abovehorizon,30°belowhorizon),
  Panmovement160°,Beamsprojectedinaudiencesdirection.
“PanTilt Angle 4” -Tiltmovementangle90°(75°front,15back),
  Panmovement160°idealforxturesmountedontheceilingorsimilar.
Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Pan Inverse:
Toenable/disablepaninverse,pressthe“MENU”buttononthefrontoftheunittoshow“Pan Inverse”
ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonstochoose
“YES” or“NO”.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Auto test:
Toruntheautotestfunction,pressthe“MENU”buttononthefrontoftheunittoshow“Auto Test” on
theLCDdisplay.Nowpressthe“ENTER”buttonandthexturewillrunitsautotest.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Operating instructions

www.prolight.co.uk Dragony Quad User Manual
8
Fixture time:
Todisplaythetotalhoursthexturehasbeenusedfor,pressthe“MENU”buttononthefrontoftheunit
toshow“Fixture Time” ontheLCDdisplay.Nowpressthe“ENTER”buttontoshowthextureshours.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Firmware version:
Todisplaythermwareversionthextureisrunning,pressthe“MENU”buttononthefrontoftheunitto
show“Firmware Version” ontheLCDdisplay.Nowpressthe“ENTER”buttontoshowthewhatversion
thextureisrunning.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Factory reset:
Toresetthexturetofactorysettings,pressthe“MENU”buttononthefrontoftheunittoshow
“Defaults” ontheLCDdisplay.Nowpressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonsto
choose“YES” or“NO”.Pressthe“ENTER”buttontoconrmthesetting(thiswillresetallsettingsto
factorydefaults).
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Fixture position reset:
Toresetthexturespositions,pressthe“MENU”buttononthefrontoftheunittoshow“System reset”
ontheLCDdisplay.Nowpressthe“ENTER”buttontoperformthereset.
Toexitoutofanyoftheaboveoptions,pressthe“MENU”button.
Pan/tilt offset:
Toadjustthepan/tiltinthehomeposition,pressthe“MENU”buttononthefrontoftheunitonce,
nowpressandholdthe“ENTER”buttonuntil“Pan Offset” isshownontheLCDdisplay.Usethe“UP”
and“DOWN”buttonstoselect“Pan Offset”,“Tilt 1 Offset” (Top Bar) or“Tilt 2 Offset” (Bottom Bar).
Pressthe“ENTER”buttonandusethe“UP”and“DOWN”buttonsagaintoadjustthehomeposition
between“-127” and“+127”.Pressthe“ENTER”buttontoconrmthesetting.
Toexitoutofthepan/tiltoffset,pressandholdthe“MENU”button.
Operating instructions

www.prolight.co.uk Dragony Quad User Manual
9
DMX setup
FurtherDMXcablescanbe
purchasedfromallgoodsound
andlightingsuppliersor
ProLightConceptsdealers.
Pleasequote:
CABL10 – 2m
CABL11 – 5m
CABL12 – 10m
Setting the DMX address:
TheDMXmodeenablestheuseofauniversalDMXcontroller.Eachxturerequiresa“startaddress”
from1-512.Axturerequiringoneormorechannelsforcontrolbeginstoreadthedataonthechannel
indicatedbythestartaddress.Forexample,axturethatoccupiesoruses7channelsofDMXandwas
addressedtostartonDMXchannel100,wouldreaddatafromchannels:100,101,102,103,104,105
and106.Chooseastartaddresssothatthechannelsuseddonotoverlap.E.g.thenextunitinthe
chainstartsat107.
DMX 512:
DMX(DigitalMultiplex)isauniversalprotocolusedasaformofcommunicationbetweenintelligent
xturesandcontrollers.ADMXcontrollersendsDMXdatainstructionsformthecontrollertothexture.
DMXdataissentasserialdatathattravelsfromxturetoxtureviatheDATA“IN”andDATA“OUT”
XLRterminalslocatedonallDMXxtures(mostcontrollersonlyhaveadata“out”terminal).
DMX linking:
DMXisalanguageallowingallmakesandmodelsofdifferentmanufacturestobelinkedtogether
andoperatefromasinglecontroller,aslongasallxturesandthecontrollerareDMXcompliant.
ToensureproperDMXdatatransmission,whenusingseveralDMXxturestrytousetheshortest
cablepathpossible.TheorderinwhichxturesareconnectedinaDMXlinedoesnotinuencethe
DMXaddressing.Forexample;axtureassignedtoaDMXaddressof1maybeplacedanywherein
aDMXline,atthebeginning,attheend,oranywhereinthemiddle.Whenaxtureisassigneda
DMXaddressof1,theDMXcontrollerknowstosendDATAassignedtoaddress1tothatunit,
nomatterwhereitislocatedintheDMXchain.
DATA cable (DMX cable) requirements (for DMX operation):
ThisxturecanbecontrolledviaDMX-512protocol.TheDMXaddressissetonthebackoftheunit.
YourunitandyourDMXcontrollerrequireastandard3-pinXLRconnectorfordatainput/output,
seeimagebelow.
Also remember that DMX cable must be daisy chained and cannot be split.

www.prolight.co.uk Dragony Quad User Manual
10
Terminationreducessignaltransmission
problemsandinterference.itisalways
advisabletoconnectaDMXterminal,
(resistance120Ohm1/4W)betweenpin2
(DMX-)andpin3(DMX+)ofthelastxture.
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
3-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
5-pin XLR (socket)
Pin 1: GND (screen)
Pin 2: Signal (-)
Pin 3: Signal (+)
Pin 4: N/C
Pin 5: N/C
DMX setup
Notice:
Besuretofollowthediagramsbelowwhenmakingyourowncables.Donotconnectthecables
shieldconductortothegroundlugorallowtheshieldconductortocomeincontactwiththeXLRs
outercasing.Groundingtheshieldcouldcauseashortcircuitanderraticbehaviour.
Special note:
Line termination:
Whenlongerrunsofcableareused,
youmayneedtouseaterminatoron
thelastunittoavoiderraticbehaviour.
Using a cable terminator will decrease
the possibilities of erratic behaviour.
(3-pin - Order ref: CABL9O, 5-pin - Order ref: CABL89)
5-pin XLR DMX connectors:
Somemanufacturesuse5-pinXLRconnectorsfordatatransmissioninplaceof3-pin.5-pinXLRxtures
maybeimplementedina3-pinXLRDMXline.Wheninsertingstandard5-pinXLRconnectorsintoa
3-pinlineacableadaptormustbeused.Thediagrambelowdetailsthecorrectcableconversion.

www.prolight.co.uk Dragony Quad User Manual
11
WEEE notice
Correct Disposal of this Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries
with separate collection systems)
Thismarkingshownontheproductoritsliterature,indicatesthatitshouldnotbedisposedof
withotherhouseholdwastesattheendofitsworkinglife.Topreventpossibleharmtothe
environmentorhumanhealthfromuncontrolledwastedisposal,pleaseseparatethisfromother
typesofwastesandrecycleitresponsiblytopromotethesustainablereuseofmaterialresources.
Householdusersshouldcontacteithertheretailerwheretheypurchasedthisproduct,ortheir
localgovernmentofce,fordetailsofwhereandhowtheycantakethisitemforenvironmentally
saferecycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthe
purchasecontract.Thisproductshouldnotbemixedwithothercommercialwastesfordisposal.

www.prolight.co.uk Dragony Quad User Manual
12
