Erbauer EPHT18-Li User manual

EPHT18-Li
MNL_EPHT18-Li_V01_180608
EAN. 3663602418252
ORIGINAL INSTRUCTIONS

3
2
WARNING! Please read all safety warnings carefully and be sure
that they are fully understood before handling the tool.
x1
Product description
Safety instructions
Assembly
Use
Care & maintenance
Guarantee
Declaration of Conformity
1. Blade
2. Trimmer head
3. Angle adjustment knob
4. Locking sleeve
5. Telescopic quick-lock lever
6. Griping surface
7. Securing clip of shoulder strap
PRODUCT DESCRIPTION
8. Lock-off button
9. On/off switch trigger
10. Battery pack release button*
11. Power bar button*
12. Battery pack*
13. Blade cover
14. Shoulder strap
NOTE: Parts marked with * are not provided. Please refer to the
respective section in the instruction manual.

5
4
PRODUCT DESCRIPTION
1
2
4
5
6
7
8
10
9
3
11
14
12
13
A
4
B
13
C1
10
12
C2
12
D
9
8
E
5
F
45˚
45˚
45˚
45˚
2
3
G1
7
14
G2 H

7
6
I J
K L
1
SAFETY INSTRUCTIONS
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings, instructions,
illustrations and specications provided with this
power tool. Failure to follow all instructions listed below
may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future
reference. The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or battery
operated (cordless) power tool.”
WORK AREA SAFETY
a. Keep work area clean and well lit. Cluttered or dark areas
invite accidents.
b. Do not operate power tools in explosive atmospheres,
such as in the presence of ammable liquids, gases or dust.
Power tools create sparks which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
a. Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodied plugs and matching
outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such
as pipes, radiators, ranges and refrigerators. There is an
increased risk of electric shock if your body is earthed or grounded.

9
8
c. Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts.Damaged or
entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a cord
suitable for outdoor use reduces the risk of electric shock.
f. If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use
of an RCD reduces the risk of electric shock.
PERSONAL SAFETY
a. Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power tool
while you are tired or under the inuence of drugs, alcohol
or medication. A moment of inattention while operating power
tools may result in serious personal injury.
b. Use personal protective equipment. Always wear eye
protection. Protective equipment such as a dust mask, non-
skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the
off- position before connecting to power source and/or
battery pack, picking up or carrying the tool.Carrying power
tools with your nger on the switch or energising power tools
that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the
power tool on. A wrench or a key left attached to a rotating
part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep
your hair and clothing away from moving parts. Loose clothes,
jewellery or long hair can be caughtin moving parts.
g. If
devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection can
reduce dust-related hazards.
h. Do not let familiarity gained from frequent use of tools
allow you to become complacent and ignore tool safety
principles. A careless action can cause severe injury within a
fraction of a second.
POWER TOOL USE AND CARE
a. Do not force the power tool. Use the correct power tool for
your application. The correct power tool will do the job better
and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with the
switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or remove
the battery pack, if detachable, from the power tool before
making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
e. Maintain power tools and accessories. Check for
misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power
tool's operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly maintained
power tools.

11
10
f. Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to bind and
are easier to control.
g. Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account
the working conditions and the work to be performed. Use
of the power tool for operations different from those intended
could result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free
from oil and grease. Slippery handles and grasping surfaces
do not allow for safe handling and control of the tool in
unexpected situations.
BATTERY TOOL USE AND CARE
a. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type of battery
pack may create a risk of re when used with another battery
pack.
b. Use power tools only with specically designated battery
packs. Use of any other battery packs may create a risk of
injury and re.
c. When battery pack is not in use, keep it away from other
metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a re.
d. Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs,
ush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
e. Do not use a battery pack or tool that is damaged or modied.
Damaged or modied batteries may exhibit unpredictable
behaviour resulting in re, explosion or risk of injury.
f. Do not expose a battery pack or tool to re or excessive
temperature. Exposure to re or temperature above 130 °C
may cause explosion.
g. Follow all charging instructions and do not charge
the battery pack or tool outside the temperature range
specied in the instructions. Charging improperly or at
temperatures outside the specied range may damage the
battery and increase the risk of re.
SERVICE
a. Have your power tool serviced by a qualied repair person
using only identical replacement parts. This will ensure that
the safety of the power tool is maintained.
b. Never service damaged battery packs. Service of battery
packs should only be performed by the manufacturer or
authorized service providers.
POLE HEDGE TRIMMER SAFETY WARNINGS
a. Keep all parts of the body away from the cutter blade. Do
not remove cut material or hold material to be cut when
blades are moving. Make sure the switch is off when
clearing jammed material. A moment of inattention while
operating the hedge trimmer may result in serious personal
injury.
b. Carry the hedge trimmer by the handle with the cutter
blade stopped. When transporting or storing the hedge
trimmer always t the cutting device cover. Proper handling
of the hedge trimmer will reduce possible personal injury from
the cutter blades.
c. Hold the power tool by insulated gripping surfaces only,
because the cutter blade may contact hidden wiring. Cutter
blades contacting a “live” wire may make exposed metal parts
of the power tool “live” and could give the operator an electric
shock.

13
12
d. Check the hedge for foreign objects before operation, e.g.
wire fences. Take care that the cutting device does not come
into contact with wire or other metal objects.
e. Hold the hedge trimmer properly, e.g. with both hands if
two handles are provided. Loss of control can cause personal
injury.
ADDITIONAL SAFETY WARNINGS FOR POLE HEDGE TRIMMER
IMPORTANT:
READ CAREFULLY BEFORE USE.
KEEP FOR FUTURE REFERENCE.
WARNING! When using the product the safety rules must
be followed. For your own safety and that of bystanders
please read these instructions before operating the product.
Please keep the instructions safe for later use.
TRAINING
a. Read the instructions carefully. Be familiar with the controls and
the proper use of the product.
b. Never allow people unfamiliar with these instructions or children
to use the product. Local regulations can restrict the age of the
operator.
c. Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their property.
PREPARATION
a. THIS PRODUCT CAN CAUSE SERIOUS INJURIES. Read
the instructions carefully for the correct handling, preparation,
maintenance, starting and stopping of the product. Become
familiar with all controls and the proper use of the product.
b. Never allow children to use the hedge trimmer.
c. Beware of overhead power lines.
d. Never operate the product while people, especially children, or
pets are nearby.
e. Dress properly! Do not wear loose clothing or jewellery, which
can be caught in moving parts. Use of sturdy gloves, non-skid
footwear and safety glasses is recommended.
f. Wear eye and hear protection and stout shoes at all times while
operating the product.
g. If the cutting attachment strikes any foreign object or the
product starts making any unusual noise or vibration, shut off
the power source and allow the product to stop. Switch the
product off, disconnect it from the power supply and take the
following steps:
• inspect for damage,
• check for, and tighten, any loose parts,
• have any damaged parts replaced or repaired with parts having
equivalent specications.
OPERATION
a. Use the product only in daylight or good articial light.
b. Never operate the product with damaged guards or shields or
without guards or shields in place.
c. Keep hands and feet away from the cutting device at all times
and especially when switching on the motor.
d. Before using the product and after any impact, check for signs
of wear or damage and repair as necessary.
e. Always disconnect the product from the power supply (i.e.
remove the plug from the power supply or the battery pack)
• whenever leaving the product unattended;
• adjusting the working position of the cutting device;
• before clearing a blockage;
• before checking, cleaning or working on the product

15
14
• after striking a foreign object;
• whenever the product starts vibrating abnormally.
f. Ensure that the hedge trimmer is correctly located in a
designated working position before switching on.
g. While operating the hedge trimmer, always ensure that the
operating position is safe and secure, especially when using
steps or a ladder.
h. Do not operate the hedge trimmer with a damaged or
excessively worn cutting device.
i. Always ensure that all handles and guards are tted when
using the hedge trimmer. Never attempt to use an incomplete
hedge trimmer or one tted with an unauthorised modication.
j. Always use two hands to operate a hedge trimmer tted with
two handles.
k. Always be aware of your surroundings and stay alert for
possible hazards of which you may not be aware due to the
noise of the product.
l. Take care against injury to feet and hands from the cutting
device.
m. Always ensure that the air vents are kept clear of debris.
n. Wear slip-resistant foot protection and protective clothing when
using this product.
o. Always keep proper footing and operate the product only when
standing on a xed, secure and level surface. Change working
positions regularly to avoid tiredness and ensure a comfortable
working position at all times.
p. Never use replacement parts or accessories not provided or
recommended by the manufacturer.
q. The use of this product may be restricted due to national
regulations.
MAINTENANCE AND STORAGE
a. Disconnect the product from the power supply (i.e. remove the
plug from the power supply or the battery pack) and check for
damage after use.
b. Disconnect the product from the power supply (i.e. remove the
plug from the power supply or the battery pack) before carrying
out maintenance or cleaning work.
c. Maintain and inspect your product regularly. Check for
misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the product’s operation.
If damaged, have the product repaired before use. Many
accidents are caused by poorly maintained products.
d. Improper maintenance will lead to malfunction/failure of the
product.
e. Inspect the product before each use, after dropping the product
or exposing to other impacts to identify signicant defects.
Check for loose fasteners and damaged parts, such as cracks
in the cutting attachment.
f. Use only the manufacturer’s recommended replacement parts
and accessories.
g. inspect and maintain the product regularly. Have the product
repaired only by an authorised service centre or similar qualied
specialist.
h. When not in use, store the product out of the reach of children.
i. When transporting or storing the hedge trimmer, always t the
cutting device transport guard.
j. When the hedge trimmer is stopped for servicing, inspection or
storage, take out the batteries, make sure all moving parts have
come to a stop. Allow the hedge trimmer to cool before making
any inspections, adjustments, etc.

17
16
VIBRATION AND NOISE REDUCTION
To reduce the impact of noise and vibration emission, limit the time
of operation, use low-vibration and low-noise operating modes as
well as wear personal protective equipment.
Take the following points into account to minimize the vibration and
noise exposure risks:
a. Only use the product as intended by its design and these
instructions.
b. Ensure that the product is in good condition and well
maintained.
c. Use correct cutting attachments for the product and ensure
they in good condition.
d. Keep tight grip on the handles/grip surface.
e. Maintain this product in accordance with these instructions and
keep it well lubricated (where appropriate).
f. Plan your work schedule to spread any high vibration tool use
across a longer period of time.
EMERGENCY
Familiarise yourself with the use of this product by means of this
instruction manual. Memorise the safety directions and follow them
to the letter. This will help to prevent risks and hazards.
a. Always be alert when using this product, so that you can
recognise and handle risks early. Fast intervention can prevent
serious injury and damage to property.
b. Switch off and disconnect from the power supply if there
are malfunctions. Have the garden power tool checked by a
qualied professional and repaired, if necessary, before you
operate it again.
RESIDUAL RISKS
Even if you are operating this product in accordance with all the
safety requirements, potential risks of injury and damage remain.
The following dangers can arise in connection with the structure
and design of this product:
a. Health defects resulting from vibration emission if the product
is being used over long periods of time or not adequately
managed and properly maintained.
b. Injuries and damage to property due to broken cutting
attachments or the sudden impact of hidden objects during use.
c. Danger of injury and property damage caused by ying objects.
WARNING! This product produces an electromagnetic eld
during operation! This eld may under some circumstances
interfere with active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend persons
with medical implants to consult their doctor and the
medical implant manufacturer before operating this product!

19
18
ASSEMBLY
01 UNPACKING
• Unpack all parts and lay them on a at, stable surface.
• Remove all packing materials and shipping devices, if applicable.
• Make sure the delivery contents are complete and free of any damage. If you nd that parts
are missing or show damage do not use the product but contact your dealer. Using an
incomplete or damaged product represents a hazard to people and property.
• Ensure that you have all the accessories and tools needed for assembly and operation.
This also includes suitable personal protective equipment
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There is a
danger of choking and suffocation!
02 ASSEMBLY
INSTALL THE HEDGE TRIMMER HEAD ONTO THE TELESCOPIC TUBE (FIG. A)
Slide the hedge trimmer head(2) onto the tube.
Align the arrow mark on the handle section with the groove on the trimmer head.
Tighten the locking sleeve(4) by turning it clockwise to attach the hedge trimmer head to
the tube.
BLADE COVER (FIG. B)
Remove the blade cover(13) from the cutting device before use.
CHARGING YOUR BATTERY PACK
The battery has been shipped in a low charge condition. Charge it fully before rst use.
Refer to the charger instruction manual for the details.
TO REMOVE OR INSTALL THE BATTERY PACK (FIG. C1, C2)
Depress the battery pack release button (10) to release and slide the battery pack (12)
out from your tool. (Fig. C1)
After recharge, slide the battery pack (12) back into your tool. A simple push and slight
pressure will be sufcient.
BATTERY PACK POWER BAR
The Li-Ion battery pack (12) is equipped with a POWER BAR (11) which is used to give
an indication of the battery pack’s remaining charge. Press the POWER BAR button (11)
to check battery charge as below. The LED will stay lit for approximately 5 seconds.
11
76-100% Charge
51-75% Charge
26-50% Charge
5-25% Charge
under 5% Charge
Flash On Off

21
20
USE
01 INTENDED USE
The product is intended for cutting and trimming of high and wide hedges, bushes and
shrubs. Observe the technical data for the maximum cutting capacity. Do not cut non-
plant material or branches exceeding the stated maximum capacity.
02 OPERATION
ON/OFF SWITCH (FIG. D)
Press the locking off button (8), and then press the on/off switch (9).
Release the locking off button.
To turn it off, simply loosen the on/off switch.
SETTING THE WORKING LENGTH (FIG. E)
WARNING! Always remove the rechargeable battery before inspection
and adjustment work.
Loosen the telescopic quick-lock lever(5) of the telescopic handle. Push or pull the tube
to adjust the length of the tube. Tighten the quick lock lever when the desired length is
achieved.
NOTE: Only extend the tube far enough to just reach the hedge and
shrubs.
PIVOTING THE TRIMMER HEAD (FIG. F)
WARNING! Always remove the battery before inspection and
adjustment work.
Push the angle adjustment locking knob(3) inward.
Grasp the power head motor housing and rotate the power head to either of the 5 positions
(Fig. F).
Release the locking knob.
It should snap back into a seated position. If it does not, rotate the power head back and
forth slightly until the button snaps back into its seated position. The power head is now
locked into position and ready for use.
PUTTING ON THE SHOULDER STRAP (FIG. G1, G2)
Place the shoulder strap(14) over your left shoulder (Fig. G2).
Fasten the snap hook on the securing clip on the shaft (Fig. G1).
The length of the shoulder strap can be adjusted.
USING THE TELESCOPIC HEDGE TRIMMER (FIG. H-K)
The telescopic Trimmer is a dual- purpose tool. It is designed to trim and shape tall, hard-
to reach hedges and bushes with its extended reach and pivoting power head. You can
also adjust the Telescopic Trimmer to trim and shape smaller hedges and shrubs near
the ground without having to bend or stoop.
To use the Telescopic Trimmer for trimming tall, hard-to-reach hedges or shrubs, hold
the Telescopic Trimmer at the positions shown. Pivot the power head to several different
positions to shape or sculpt shrubs or hedges (Fig. H).
To use the Telescopic Trimmer for trimming smaller hedges or shrubs, hold the Telescopic
Trimmer at the positions as shown (Fig. I).
To use the Telescopic Trimmer for trimming the bottoms and sides of hedges and shrubs,
hold the Telescopic Trimmer at the positions as shown (Fig. J).
To use the Telescopic Trimmer for trimming low lying foliage or ground cover, hold the
Telescopic Trimmer at the position as shown (Fig. K).
Use the Telescopic Trimmer properly. Always wear eye protection, rubber gloves, and
substantial foot wear while using the Telescopic Trimmer. Always maintain proper footing
and balance and never overreach when using Telescopic Trimmer.
Before starting the Telescopic Trimmer, hold the tool with both hands on the grip areas.
Make sure that the cutter blade is not touching anything.
Do not try to cut too much at one time. This can cause the Telescopic Trimmer to slow
down or get jammed, reducing the cutting efciency.
Do not force the Telescopic Trimmer through dense growth. A slight back and forth
sawing action may ease the cutting of larger, more dense growth. If the Telescopic
Trimmer begins to slow down or becomes jammed, immediately turn Telescopic Trimmer
off and remove the battery pack off. Wait for the cutting blade to cool before removing
any blockage.
Do not try to cut branches larger than 18mm in diameter.
For best results, trim the sides of hedges with an upward sweeping motion. Trim the
hedges so that the top is slightly narrower than the bottom.

23
22
OVERLOAD, TEMPERATURE AND CHARGING PROBLEM
PROBLEM TOOL / BATTERY
STATUS
POSSIBLE
CAUSE
SOLUTION
Overload
protection
Product suddenly
stops
Extremely high
torque, binding and
stalling situations,
overloading of the
tool
Relieve the load immediately,
reset the tool by switching off
and back on again.
Temperature
extremely
high
The rst and the
third LED light of the
POWER BAR will be
ashing altemately
Battery
temperature
exceeds 77°C
during operation
Cool down the battery to
below 77°C for operation and
below 57°C for charging.
Low charge Power for the tool
will drop quickly;
The rst LED on
the POWER BAR
begins to ash
The battery pack is
under 5% charge
Remove the battery pack
from the tool and charge it
Other
problems
Short charges Not fully charged Make sure that battery is
fully charged every time
by allowing the charger to
complete its full charging
cycle
Poor storage
condition
Always remove battery from
the tool and charger when
not in use and store in a dry
secure place.Avoid charging
of storing your battery in
temperatures below 5°C and
above 40°C. Cool down a
hot battery pack from a tool
that has just been operated
for approximately 30 minutes
before storage
CARE & MAINTENANCE
WARNING! Always switch the product off, remove the battery pack and
let the product cool down before performing inspection, maintenance and
cleaning work!
Only perform care and maintenance work according to these instructions!
All further works must be performed by a qualied specialist!
BLADE CLEANING AND LUBRICATING
WARNING! Wear safety gloves when working on the cutting device and
close to it! Use appropriate tools to remove debris e.g. a brush or wooden
stick! Never use your bare hands!
Keep the blade (1) clean and free of debris. Remove trimmings.
Apply a small amount of suitable lubricant on the cutting device to retain a good cutting
performance.
Keep the blade (1) sharp. Only replace blade with a new one from authorised repairer.
Adjustment of the distance between blades is not necessary, as this is predetermined by
the manufacturer.
If the cutting device overheats during operation, it is necessary to lubricate the internal
surfaces of the blades (Fig. L).
CLEAN
• Clean the product with a dry cloth. Use a brush for areas that are hard to reach.
• Check for worn or damaged parts. Replace worn parts as necessary or contact an
authorised service centre for repair before using the product again.
NOTE: Do not use chemical, alkaline, abrasive or other aggressive
detergents or disinfectants to clean this product as they might be harmful to
its surfaces.

25
24
MAINTENANCE
Your power tool requires no additional lubrication or maintenance.
There are no user serviceable parts in your power tool.
Before and after each use, check the product and accessories (or attachments) for wear
and damage. If required, exchange them for new ones as described in this instruction
manual. Observe the technical requirements.
TRANSPORTATION
WARNING! Always carry the product by its main handle.
Never use the cord for carrying the product.
• Switch the product off and remove the battery pack.
• Protect the product from any heavy impact or strong vibrations which may occur during
transportation in vehicles.
• Secure the product to prevent it from slipping or falling over.
STORAGE
• Switch the product off and remove the battery pack.
• Clean the product as described above.
• Store the product and its accessories in a dark, dry, frost-free, well-ventilated place.
• Always store the product in a place that is inaccessible to children. The ideal storage
temperature is between 10 °C and 30 °C.
• We recommend using the original package for storage or covering the product with a
suitable cloth or enclosure to protect it against dust.
RECYCLING AND DISPOSAL
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or retailer
for recycling advice.
DISPOSAL OF AN EXHAUSTED BATTERY PACK
To preserve natural resources, please recycle or dispose of the battery pack
properly. This battery pack contains Li-Ion batteries. Consult your local waste
authority for information regarding available recycling and/or disposal options.
Discharge your battery pack by operating your tool, then remove the battery
pack from the tool housing and cover the battery pack connections with heavy-
duty adhesive tape to prevent short circuit and energy discharge. Do not
attempt to open or remove any of the components.
GUARANTEE
At Erbauer we take special care to select high quality materials and use manufacturing
techniques that allow us to create ranges of products incorporating design and durability.
That’s why we offer a 2 year trade guarantee against manufacturing defects on our
Erbauer power tool products.
This power tool is guaranteed for 2 years from the date of purchase, if bought in store,
delivered or bought online. You may only make a claim under this guarantee upon
presentation of your sales receipt or purchase invoice. Please keep your proof of
purchase in a safe place.
This guarantee covers product failures and malfunctions provided the Erbauer power
tool was used for the purpose for which it is intended and subject to installation, cleaning,
care and maintenance in accordance with standard practice and with the information
contained above and in the user manual. This guarantee does not cover defects and
damage caused by or resulting from:
• Normal wear and tear, including accessory wear
• Overload, misuse or neglect
• Repairs attempted by anyone other than an authorised agent
• Cosmetic damage
• Damage caused by foreign objects, substances or accidents
• Accidental damage or modication
• Failure to follow manufacturer’s guidelines
• Loss of use of the goods
This guarantee is limited to parts recognised as defective. It does not, in any case, cover
ancillary costs (movement, labour) and direct and indirect damage.
If the Erbauer power tool is defective during the guarantee period, then we reserve
the right, at our discretion, to replace the item with a product of equivalent quality and
functionality or to provide a refund.
This guarantee only applies to the country of purchase or delivery and is not transferrable
to any other countries. This guarantee is non-transferrable to any other person or
product. Relevant local law will apply to this guarantee.
Guarantee related queries should be addressed to a store afliated with the distributor
you purchased the Erbauer power tool from.
This guarantee is in addition to and does not affect your statutory rights relating to faulty
goods as a consumer.

27
26
01 TECHNICAL SPECIFICATIONS
Rated voltage: 18 V d.c
Rated no load speed: 2800 /min
Max. cutting length: 410mm
Blade length: 450mm
Max. cutting capacity: 20mm
Angle at which the motor can be set: ±45° & ±90°
Max. length of the tool: 2.9m
Weight (without battery): 4.2kg
Ambient temperature range for tool and battery use: 0℃to 40℃
For use with battery pack and charger as below:
Battery pack model: EBAT18-Li-2 / EBAT18-Li-4 / EBAT18-Li-5
(sold separately)
Charger model: EC18-Li / EFC18-Li / EMC18-Li
(sold separately)
Measured sound pressure level LpA: 69.62 dB(A)
Uncertainty K: 0.51 dB(A)
Measured sound power level LWA: 89.62 dB(A)
Uncertainty K: 0.51 dB(A)
Guaranteed sound power LWA: 92 dB(A)
Vibration level ah: 2.093 m/s²
Uncertainty K: 1.5 m/s²
The sound values have been determined according to noise test code given in EN
60745-2-15, using the basic standards EN ISO 11094 and EN ISO 3744.
The sound intensity level for the operator may exceed 80 dB(A) and ear protection
measures are necessary.
The declared vibration value has been measured in accordance with a standard test
method (according to EN 60745-1) and may be used for comparing one product with
another. The declared vibration value may also be used in a preliminary assessment of
exposure.
WARNING! Depending on the actual use of the product the vibration
values can differ from the declared total. Adopt proper measures to
protect yourself against vibration exposures. Take the whole work process
including times the product is running under no load or switched off into
consideration. Proper measures include among others regular maintenance
and care of the product and accessories, keeping hands warm, periodical
breaks and proper planning of work processes.
RATING LABEL EXPLANATION
EPHT18-Li = MODEL NUMBER E = ERBAUER
PHT = POLE HEDGE TRIMMER
18 = 18 V d.c.
Li = LITHIUM
02 SYMBOLS
On the product, the rating label and within these instructions you will nd among others
the following symbols and abbreviations. Familiarise yourself with them to reduce
hazards like personal injuries and damage to property.
V~ Volt, (alternating voltage) V Volt, (direct current voltage)
WWalt mA Milliampere
mAh Milliampere-hour AAmpere
/min per minute mm Millimetre
kg Kilogram dB(A) Decibel (A-rated)
m/s2Metres per seccond aquared
Lock / to tighten or secure Unlock / to loosen

29
28
Note/Remark Wear tight-tted protective clothes
Caution / Warning. Read the instruction manual.
Wear protective gloves. Wear protective footwear.
Wear hearing protection. Wear eye protection.
Wear respiratory protection. Do not expose to rain or wet
conditions.
Switch the product off and remove
the battery pack to disconnect
from the power supply before
assembly, cleaning, adjustments,
maintenance, storage and
transportation.
Objects thrown by the product could
hit the user or other bystanders.
Always ensure that other people
and pets remain at a safe distance
from the product when it is in
operation. In general, children must
not come near the area where the
product is.
10 m
Maintain a minimum clearance of
10 m from current-carrying lines.
Life-threatening danger from
electric shock!
Keep ngers away from moving
cutting device!
The product complies with the
applicable European directives and
an evaluation method of conformity
for these directives was done.
Guaranteed sound power level
WEEE symbol. Waste electrical
products should not be disposed
of with household waste. Please
recycle where facilities exist.
Check with your Local Authority or
local store for recycling advice.
yyWxx
Manufacturing date code; year of
manufacturing (20yy) and week of
manufacturing (Wxx)
DECLARATION OF CONFORMITY
DECLARATION OF CONFORMITY
We
Kingsher International Products Limited
3 Sheldon Square
London W2 6PX
United Kingdom
Declare that the product:
Erbauer 18V Li-Ion pole hedge trimmer EPHT18-Li
Serial number 000001-999999
Complies with the essential health and safety requirements of the following directives:
2006/42/EC The Machinery Directive
References to the following harmonized standard were made:
EN 60745-1:2009 + A11:2010
EN 60745-2-15:2009 + A1:2010
EN ISO 10517:2009 + A1:2013
2014/30/EU Electromagnetic Compatibility directive
References to the following harmonized standard were made:
EN55014-1: 2017
EN55014-2: 2015
(EU) 2015/863 amending 2011/65/EU Restrictions of the Use of Certain Hazardous Substances in
Electrical and Electronic Equipment
The Outdoor Noise Directive 2000/14/EC & 2005/88/EC
Measured Sound Power Level: 89.62 dB(A)
Guaranteed Sound Power Level: 92 dB(A)
Authorised signatory and technical le holder:
Kingsher International Products Limited
3 Sheldon Square
London W2 6PX
United Kingdom
on: 29/10/2018
Lisa Davis
Group Quality Director

Manufacturer • Fabricant • Producent • Hersteller • Producator • Fabricante:
Kingsher International Products Limited
3 Sheldon Square London W2 6PX
United Kingdom
www.kingsher.com/products
DISTRIBUTOR:
B&Q plc,
Chandlers Ford, Hants, SO53 3LE
United Kingdom
www.diy.com
Screwx Direct Limited,
Trade House, Mead Avenue,
Yeovil, BA22 8RT, United Kingdom
www.screwx.com
