ermengineering FRA-100 User manual

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
www.ermengineering.com 󰞟󰞠󰞡󰞢󰞣info@ermengineering ✆([phone]
P a g . 1
(Original) Use and maintenance manual
Type: Press device
Model: FRA-100
IMPORTANT:
Read this user manual and follow the instructions and warnings before operating this device.
Any modification or transformation performed on this machine may cause loss of the
manufacturer’s guarantee and liability.
This manual must always remain near to the machine and visible to all the operating and
maintenance staff, for any future consultation, forming part of the equipment.

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 2
Index:
Page
-CE Declaration of conformity: ............................................................................................................................................. 3
-Description of the equipment:............................................................................................................................................ 4
-Technical characteristics:..................................................................................................................................................... 4
-Workshop installation:.......................................................................................................................................................... 4
-Instructions for use: ............................................................................................................................................................... 6
-Preparing the joint.................................................................................................................................................................. 7
Inflation .................................................................................................................................................................................................................... 9
Programming:........................................................................................................................................................................................................ 9
-Electrical drawings: ..............................................................................................................................................................13
-Spare parts ...............................................................................................................................................................................15

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 3
-CE Declaration of conformity:
WE DECLARE, under our responsibility, that the machine:
- Type: Press device
- Brand: ERM Engineering
- Model: FRA-100
- Serial No.: xxxxxx
- Manufacturer date: 2021
Inspired by the directives of the Official Journal of the European Communities:
2006/42/CE Machinery Directive
2014/35/UE Low Voltage Directive
2014/30/UE Electromagnetic Compatibility Directive
Complies with the design and construction specifications of the European Standards on General
Machine Safety:
EN 349 –EN 614-1 –EN 614-2 –EN 12100 –EN 11161-1 - EN 1005-1 –EN 1005-2 –EN
1005-3 - EN 1005-4 –EN 13849-1 –EN 13849-2 –EN 894-3 - EN 61310-1 - EN 13732-1 –EN
13850 - EN 13857 –EN 14120 –EN 60204-1
General Manager: Eduardo Ramos Martínez
Arenys de Munt (Barcelona)-SPAIN
Date: 2021/08

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 4
-Description of the equipment:
➢Heating press for fusion welding of conveyor belts, comprised of two aluminium plates
with cartridge electric elements, controlled by an external temperature board.
➢Pressure by pneumatic cushions to guarantee uniform pressing.
➢Intermediate support tray to prepare and hold the joint while hot.
➢Interior cooling circuit, by water, and by air in some models, too.
-Technical characteristics:
Model FRA-100
- Control box unit options CB02 - CB01/3
- Dimensions (LxWxH) 1630x800x1570mm
- Weight 340kg
- Maximum temperature 200ºC
- Minimum length belt (mm.) 1250
- Heating area (mm.) 1050x160
- Maximum pressure 2.5 bar
- Heating time 20ºC-170ºC 6 min
- Cooling time with water 25ºC (170ºC-50ºC) 1.7min
- Voltage V. 3x230/3x400
- Power W. 4080
-Workshop installation:
These presses may be used both for in-situ assembly, as well as in fabrication workshops, for
which it is recommended to adapt the press to a metallic supporting structure, with pneumatic
or counterweighted activation, to open the top plate and adapt the water cooling circuits
correctly.

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 5
Place the control board on the rack at eye level, safely to avoid it breaking or falling.
Level the support with the regulation screws located inside the three legs.
NOTE: Once the frame is leveled, you most to introduce the trolley to level the wheels.
The distance between bottom plate and steel plate of trolley is 1 or 2 mm.
We can modify this distance across the wheel’s screws.

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 6
NOTE: In the case of several presses being connected to the same drainage line,
installation of a one-way valve at each press is recommended, thus avoiding water
entering the other presses during the purge process.
Connect control board CB-01
(For further information, consult the User Manual for CB-01)
-Instructions for use:
Open the press by releasing and extracting the two closing bolts located at both ends of the top
plate.
WARNING:
Before opening the press, check that the inflation pressure of the manometer is 0 bar.

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 7
Up the top plate using the manual valve in UP position.
-Preparing the joint
Place the first end of the belt on the lower silicone, well centred on the support tray and making
sure the joint is within the welding zone of the hotplate.
Then place two sufficiently large scraps and the same material offered up to weld, at both ends
and properly tangential to the belt, and fix them using the same holding bar.
It is also possible to use metal callipers of the same thickness as the belt and, when necessary,
use scraps of the same belt after the callipers to fill out the welding zone.
NOTE: It is always recommendable to fill out the material, at least to 70% of the pressing
surface, to avoid deformation in the plates or thickness differences in the welding.
Afterward, insert the second end of the belt, leaving the whole surface to be joined fully in
contact with the first end already fixed, and hold it with the other holding bar.

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 8
Once the joint placement operation has been completed, we cover the whole welding surface
with silicone or adequate silicone paper recommended by the belt manufacturer.
Thus, on completing the welding, we guarantee that the joint zone has the same texture and
finish as the rest of the belt.
Before closing the press, we place the metal or fibreglass plate, according to the material to be
welded, to avoid marks caused by the radical change of temperature and pressure outside the
welding zone.
We introduce the trolley inside the press and down the top plate
Once the upper plate has been put in place, we close the press using the closing controls, softly
pressing with just two fingers, and in a balanced way on both sides.

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 9
NOTE: To obtain homogeneous pressure throughout the surface, it is always
recommended not to press the closing controls too much, so the pneumatic cushion will
thus work in a more balanced way.
We can now proceed to inflate
Inflation
WARNING:
Always make sure the press is correctly closed before inflating.
There is a risk of explosion of the top plate.
We inflate the press turning the white wheel of pressure control until bar required.
We control the inflation visually using the manometer.
Programming:
At the moment of starting up the board, the actual temperatures of both plates are displayed,
and the welding time of the last programming.
To see the temperatures assigned, it shall suffice to press the relevant button for each plate.

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 10
To change these values, we must hold down the button for 3 seconds and change the value
using the central keys.
The board shall memorise these values, showing the present ones again.
NOTE:
The minimum and maximum temperatures that may be programmed are 30 to 200 ºC.
We shall perform the same operation to program the welding time, ALWAYS IN MINUTES. The
values shown are complete minutes without decimals.

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 11
That welding time shall always show the programmed value, except for starting the count, that
shall show the count-down until ending.
Once the temperatures and time values are programmed, we press START.
NOTE:
To halt the process or to make any change after beginning with START, we must press
STOP and the cycle will stop.
When the welding time ends, the relevant orange LED to start that operation shall turn on.
When the STOP led shows on the board, it means the operation has ended.

Use and maintenance manual
Press device
Model: FRA-100
__________________________________________________________________________________________________________
P a g . 12
If we have the CU-01 cooling control unit, the cooling and purging operations shall be
performed automatically.
Once the welding has ended, we deflate the press pressure reducing the pressure until 0 bar.
We can then proceed to open it and up the top plate.

Use and maintenance manual
Press device
Model: FRA-100
___________________________________________________________________________________________________________________________________________________________
P a g 13
-Electrical drawings:
3 Ph x 400 V.

Use and maintenance manual
Press device
Model: FRA-100
___________________________________________________________________________________________________________________________________________________________
P a g 14

Use and maintenance manual
Press device
Model: FRA-100
___________________________________________________________________________________________________________________________________________________________
P a g 15
-Spare parts

Use and maintenance manual
Press device
Model: FRA-100
___________________________________________________________________________________________________________________________________________________________
P a g 16

Use and maintenance manual
Press device
Model: FRA-100
___________________________________________________________________________________________________________________________________________________________
P a g 17

Use and maintenance manual
Press device
Model: FRA-100
___________________________________________________________________________________________________________________________________________________________
P a g 18

Use and maintenance manual
Press device
Model: FRA-100
___________________________________________________________________________________________________________________________________________________________
P a g 19

Use and maintenance manual
Press device
Model: FRA-100
___________________________________________________________________________________________________________________________________________________________
P a g 20
