Esco ETS LINDGREN 8000-075 User manual

Model 8000-075
RF Power Amplifier
User Manual

ii www.ets-lindgren.com
ETS-Lindgren Inc. reserves the right to make changes to any products herein to improve
functioning or design. Although the information in this document has been carefully reviewed and
is believed to be reliable, ETS-Lindgren does not assume any liability arising out of the
application or use of any product or circuit described herein; nor does it convey any license under
its patent rights nor the rights of others. All trademarks are the property of their respective
owners.
© Copyright 2023 by ETS-Lindgren Inc. All Rights Reserved. No part of this document may
be copied by any means without written permission from ETS-Lindgren Inc.
Trademarks used in this document: The ETS-Lindgren logo is a registered trademark and
Calibration Services Plus! is a trademark of ETS-Lindgren Inc.
Revision Record
MANUAL,8000-075 | Part #1785139, Rev. A
Revision Description Date
A Initial Release September, 2023

www.ets-lindgren.com iii
Table of Contents
Notes, Cautions, and Warnings .........................................................................v
Safety Symbols ...................................................................................................v
1.0 Introduction ...................................................................................................7
Standard Configuration....................................................................................................... 7
2.0 Maintenance ..................................................................................................9
Service Procedures .......................................................................................................... 10
Contacting ETS-Lindgren........................................................................................... 10
Sending a Component for Service ............................................................................. 10
Calibration Services ................................................................................................... 10
3.0 Specifications..............................................................................................11
Electrical Specifications.................................................................................................... 11
Physical Specifications ..................................................................................................... 12
Environmental................................................................................................................... 12
4.0 Before You Begin........................................................................................14
Unpacking......................................................................................................................... 14
Safety Information ............................................................................................................ 14
Warnings........................................................................................................................... 15
5.0 Installation...................................................................................................16
Star / Delta Configuration ................................................................................................. 16
Mains Input ....................................................................................................................... 16
Amplifier Protection .......................................................................................................... 16
6.0 Operation.....................................................................................................18
Equipment Use ................................................................................................................. 18
Mains Switch..................................................................................................................... 18
Standby/Operate Switch (Center Unit) ............................................................................. 18
Fault Indicator (Red LED)................................................................................................. 19
Interlock Indicator (Orange LED)...................................................................................... 19
Local Lockout Indicator..................................................................................................... 19
RF Input (Rear Panel Mounted) ....................................................................................... 19
RF Output (Rear Panel Mounted) .................................................................................... 20
Air Inlet.............................................................................................................................. 20
Safety Interlock................................................................................................................. 20
Fan Outlet......................................................................................................................... 20

iv www.ets-lindgren.com
Appendix A: EC Declaration of Conformity....................................................22

www.ets-lindgren.com v
Notes, Cautions, and Warnings
Note: Denotes helpful information intended to provide tips for better use of the
product.
CAUTION: Denotes a hazard. Failure to follow instructions could result
in minor personal injury and/or property damage. Included text gives
proper procedures.
WARNING: Denotes a hazard. Failure to follow instructions could result
in SEVERE personal injury and/or property damage. Included text gives
proper procedures.
Safety Symbols
Warning: Avoid exceeding the stated maximum input level as this can
cause a risk of damaging the equipment.
Warning: There is a significant risk of an electrical or burn hazard, to
avoid this always ensure the output is terminated prior to switching on
the equipment.
Protective Earth Ground (Safety Ground): Indicates protective earth
terminal. You should provide uninterruptible safety earth ground from
the main power source to the product input wiring terminals, power
cord, or supplied power cord set.
Waste Electrical and Electronic Equipment (WEEE) Directive: (European
Union) At end of useful life, this product should be deposited at an
appropriate waste disposal facility for recycling and disposal. Do not
dispose of with household waste.

vi www.ets-lindgren.com
This page intentionally left blank.

www.ets-lindgren.com Introduction 7
1.0 Introduction
The ETS-Lindgren Model 8000-075 RF Power Amplifier is capable of supplying a
minimum of 450 watts into a 50 ohm load over the frequency range 1000 MHz to
3200 MHz. The amplifier is designed with sufficient gain so that it may be used with
normal output levels of signal sources.
A safety interlock on the rear panel is also provided, which will mute the
amplifier when grounded.
The unit is powered by a switched mode power supply for high efficiency,
high power factor, and a wide voltage range operation. The unit is air cooled
with integral fans and is protected against faulty cooling by excess
temperature sensing.
A front panel fault indicator is provided to indicate over-temperature.
The amplifier is designed for rugged operation into a variety of loads and is primarily
intended for use as an RF power source for EMC susceptibility testing, but is also
applicable to other systems requiring a wide-band linear amplifier.
This amplifier is designated as Professional Equipment and should not be operated
by untrained staff. As this product has the capability to generate high levels of RF
energy it is not intended for use in a residential environment.
Standard Configuration
The 8000-075 amplifier system comes already assembled and connected
into a 19-inch 20U rack.
The N type input and 7/16 output connectors are located on the rear panel.

8 Introduction www.ets-lindgren.com
This page intentionally left blank.

www.ets-lindgren.com Maintenance 9
2.0 Maintenance
If you have any questions concerning maintenance or if the amplifier system is
misoperating, contact ETS-Lindgren Customer Service. See Service Procedures for
contact information.
CAUTION: Before performing any maintenance, follow the information
provided in Before You Begin on page 12.
WARNING: There are no user serviceable parts within the 8000-075
amplifier system.
WARRANTY
To prevent electrical shock DO NOT remove the covers.
Warranty will be void if the covers are opened.
ALWAYS UNPLUG THE UNIT BEFORE CLEANING. Clean the exterior of
the cabinet using a damp cloth.
Note: The cables which form part of the amplifier are matched lengths and are
critical to its performance. If replacement is necessary use only genuine spares.

10 Maintenance www.ets-lindgren.com
Service Procedures
CONTACTING ETS-LINDGREN
Note: Please see ets-lindgren.com for a list of ETS-Lindgren offices, including
phone and email contact information.
SENDING A COMPONENT FOR SERVICE
1. Contact ETS-Lindgren Customer Service to obtain a Service Request Order (SRO).
2. Briefly describe the problem in writing. Give details regarding the observed
symptom(s) or error codes, and whether the problem is constant or intermittent in
nature. Please include the date(s), the service representative you spoke with, and the
nature of the conversation. Include the serial number of the item being returned.
3. Package the system or component carefully. If possible, use the original packing
materials or carrying case to return a system or system component to ETS-Lindgren.
CALIBRATION SERVICES
Annual Calibration—For reliable and repeatable long-term performance, annual
recalibration of your measuring device by an ETS-Lindgren experienced technician is
recommended. The ETS-Lindgren calibration team will calibrate most any type or
brand of measuring device. Additional information is available at
ets-lindgren.com.
Calibration Services Plus!™—Calibration Services Plus! is a customized, optional
program to help you expertly maintain your test and measurement assets. It is
designed to address the challenges of managing the calibration and repair of test and
measurement components, including scheduling and planning to ensure peak
performance. Additional information is available at
ets-lindgren.com.
