CopyrightInformation

©Copyright2011EscoMicroPte.Ltd.Allrightsreserved.
Theinformationcontainedinthismanualandtheaccompanyingproductiscopyrightedandallrightsare
reservedbyEsco.
Escoreservestherighttomakeperiodicminordesignchangeswithoutobligationtonotifyany
personorentityofsuchchange.
Sentinel™andAscentMax®areregisteredtrademarksofEsco.

“Materialinthismanualisprovidedforinformationalpurposesonly.Thecontentsandtheproductdescribedin
thismanual(includinganyappendix,addendum,attachmentorinclusion),aresubjecttochangewithout
notice.Escomakesnorepresentationsorwarrantiesastotheaccuracyoftheinformationcontainedinthis
manual.InnoeventshallEscobeheldliableforanydamages,directorconsequential,arisingoutoforrelated
totheuseofthismanual.”




i
DuctlessFumeHoods
TableofContents
 INTRODUCTORYPAGES
i TableofContents
iii WarrantyTermsandConditions
v Introduction
v  1.ProductsCovered
v  2.SafetyWarning
v  3.LimitationofLiability
vi  4.EuropeanUnionDirectivesonWEEEandRoHS
vii DeclarationofConformity
  
USERSECTION
1  Chapter1–ProductInformation
1  1.1AboutAscentMaxDuctlessFumeHood
1  1.2Labels
2  1.3QuickView
2   1.3.1ADC‐_B_/ADC‐_D_SeriesQuickView
3   1.3.2ADC‐_C_/ADC‐_E_SeriesQuickView
4  1.4AirflowPattern
4  1.5Filtracheck
   
5  Chapter2–ControlSystem
5  2.1SentinelControlSystem
6  2.2MenuOptions
7   2.2.1Settings
8   2.2.2Calibration
9   2.2.3Admin
11   2.2.4SettingMode
11  2.3AlarmandWarnings
   
13  Chapter3‐BasicHoodOperation
13  3.1SashWindowOperation
13   3.1.1SashWindowState
13   3.1.2OperatingMotorizedSashWindow
14   3.1.3UsingSashWindow
14  3.2StartingandShuttingDowntheDuctlessFumeHood
14   3.2.1TurningontheHood
14   3.2.2TurningofftheHood
14  3.3OperatingtheDuctlessFumeHood
14   3.3.1WorkingintheHood
15   3.3.2WorkingErgonomics
   
SERVICESECTION
17  Chapter4‐Installation
17  4.1GeneralRequirements
17   4.1.1LocationRequirements
18   4.1.2EnvironmentalRequirements
18   4.1.3SupportRequirements
19   4.1.4ExhaustRequirements
19   4.1.5ElectricalRequirements
19   4.1.6ServiceLineRequirements




ii
19  4.2Installation
19   4.2.1ConnectingtheElectricalSupply
19   4.2.2SafetyLabelsontheFumeHood
19   4.2.3PreliminaryCleaning
20  4.3PerformanceValidation/Certification
20  4.3.1Disclaimer
20  4.3.2ReferencesforQualifiedCertifiers
   
21  Chapter5–ServiceandMaintenance
21  5.1ScheduledMaintenance
22  5.2ReplacingtheFilters
22   5.2.1MainCarbonFilter(s)ChangingProcedureforADC‐2__,ADC‐3__andADC‐4__
22   5.2.2MainCarbonFilter(s)ChangingProcedureforADC‐5__andADC‐6__
23   5.2.3SecondaryBackupFilterChangingProcedure
23  5.3ReplacingtheAirflowSensor
24  5.4ReplacingtheBlower
24  5.5ReplacingtheFluorescentLamp
24  5.6Maintenance/ServiceLog
   
25  Chapter6–Recertification&Calibration
25  6.1CertificationFlowchart
26  6.2AirflowAdjustment
26  6.3CertificationandCalibration
   
27  Chapter7‐Troubleshooting
   
41  Chapter8–EngineeringDetails
41  8.1AscentMaxADC‐_B_Series
41   8.1.1EngineeringDrawingforADC‐2B_
42   8.1.2EngineeringDrawingforADC‐3B_,ADC‐4B_,ADC‐5B_andADC‐6B_
43   8.1.3GeneralSpecification
44  8.2AscentMaxADC‐_C_Series
44   8.2.1EngineeringDrawing
45   8.2.2GeneralSpecification
46  8.2AscentMaxADC‐_D_Series
46   8.2.1EngineeringDrawing
47   8.2.2GeneralSpecification
48  8.2AscentMaxADC‐_E_Series
48   8.2.1EngineeringDrawing
49   8.2.2GeneralSpecification
   
   APPENDIX
   
   
   
   
   
   
   
   
   




iii
DuctlessFumeHoods
WarrantyTermsandConditions
Escowarrantsthattheproductdescribedinthismanualwillperformaccordingtospecificationsforaperiodof60months
fromthedateofpurchase.

Esco’slimitedwarrantycoversdefectsinmaterialsandworkmanship.Duringthewarrantyperiod,Esco'sliabilityshallbe,
atouroption,torepairorreplaceanydefectivepartsoftheproduct,providedifproventothesatisfactionofEscothat
thesepartsweredefectiveatthetimeofbeingsold,andthatalldefectivepartsshallbereturned,properlyidentifiedwith
aReturnAuthorization.

ThislimitedwarrantycoverspartsONLYandnottransportation/insurancecharges.

Thislimitedwarrantydoesnotcover:

•Freightorinstallation(insidedeliveryhandling)damage.Ifyourproductwasdamagedintransit,youmustfilea
claimdirectlywiththefreightcarrier
•Productswithmissingordefacedserialnumbers
•ProductsforwhichEscohasnotreceivedpayment
•Problemsthatresultfrom:
oExternalcausessuchasaccident,abuse,misuse,problemswithelectricalpower,improperoperating
environmentalconditions
oServicingnotauthorizedbyEsco
oUsagethatisnotinaccordancewithproductinstructions
oFailuretofollowtheproductinstructions
oFailuretoperformpreventivemaintenance
oProblemscausedbyusingaccessories,parts,orcomponentsnotsuppliedbyEsco
oDamagebyfire,floods,oractsofGod
oCustomermodificationstotheproduct

Factoryinstalled,customerspecifiedequipmentoraccessoriesarewarrantedonlytotheextentguaranteedbytheoriginal
manufacturer.ThecustomeragreesthatinrelationtotheseproductspurchasedthroughEsco,ourlimitedwarrantyshall
notapplyandtheoriginalmanufacturer'swarrantyshallbethesolewarrantyinrespectoftheseproducts.Thecustomer
shallutilizethatwarrantyforthesupportofsuchproductsandinanyeventnotlooktoEscoforsuchwarrantysupport.

Escoencouragesusertoregisterproductonlineatwww.escoglobal.com/warrantyorcompletethewarrantyregistration
formincludedwitheachproduct.

ALLEXPRESSANDIMPLIEDWARRANTIESFORTHEPRODUCT,INCLUDINGBUTNOTLIMITEDTOANYIMPLIEDWARRANTIES
ANDCONDITIONSOFMERCHANTABILITYANDFITNESSFORAPARTICULARPURPOSEARELIMITEDINTIMETOTHETERM
OFTHISLIMITEDWARRANTY.NOWARRANTIES,WHETHEREXPRESSORIMPLIED,WILLAPPLYAFTERTHELIMITED
WARRANTYPERIODHASEXPIRED.ESCODOESNOTACCEPTLIABILITYBEYONDTHEREMEDIESPROVIDEDFORINTHIS
LIMITEDWARRANTYORFORSPECIAL,INDIRECT,CONSEQUENTIALORINCIDENTALDAMAGES,INCLUDING,WITHOUT
LIMITATION,ANYLIABILITYFORTHIRD‐PARTYCLAIMSAGAINSTYOUFORDAMAGES,FORPRODUCTSNOTBEING
AVAILABLEFORUSE,ORFORLOSTWORK.ESCO'SLIABILITYWILLBENOMORETHANTHEAMOUNTYOUPAIDFORTHE
PRODUCTTHATISTHESUBJECTOFACLAIM.THISISTHEMAXIMUMAMOUNTFORWHICHESCOISRESPONSIBLE.

TheseTermsandConditionsshallbegovernedbyandconstruedinaccordancewiththelawsofSingaporeandshallbe
subjecttotheexclusivejurisdictionofthecourtsofSingapore.

TechnicalSupport,WarrantyServiceContacts
Toll‐FreeUSAandCanada877‐479‐3726
Singapore:+6565420833
GlobalEmailHelpdesk:[email protected]

Visithttp://www.escoglobal.com/totalktoaLiveSupportRepresentative
DistributorsareencouragedtovisittheDistributorIntranetforself‐helpmaterials.

Policyupdatedon30thJan2007(Thislimitedwarrantypolicydoesnotapplytoproductspurchasedbefore30thJan2007).




iv




v
DuctlessFumeHoods
Introduction
1.ProductsCovered
EscoDuctlessFumeHood–AscentMax(ADCSeries)
ElectricalRating0.6meters
2feet
0.9meters
3feet
1.2meters
4feet
1.5meters
5feet
1.8meters
6feet
220‐240VAC,50Hz,1ΦADC‐2B1
ADC‐3B1
ADC‐3C1
ADC‐3D1
ADC‐3E1
ADC‐4B1
ADC‐4C1
ADC‐4D1
ADC‐4E1
ADC‐5B1
ADC‐5C1
ADC‐5D1
ADC‐5E1
ADC‐6B1
ADC‐6C1
ADC‐6D1
110‐120VAC,50Hz,1ΦADC‐2B2
ADC‐3B2
ADC‐3C2
ADC‐3D2
ADC‐3E2
ADC‐4B2
ADC‐4C2
ADC‐4D2
ADC‐4E2
ADC‐5B2
ADC‐5C2
ADC‐5D2
ADC‐5E2
ADC‐6B2
ADC‐6C2
ADC‐6D2
220‐240VAC,60Hz,1ΦADC‐2B3
ADC‐3B3
ADC‐3C3
ADC‐3D3
ADC‐3E3
ADC‐4B3
ADC‐4C3
ADC‐4D3
ADC‐4E3
ADC‐5B3
ADC‐5C3
ADC‐5D3
ADC‐5E3
ADC‐6B3
ADC‐6C3
ADC‐6D3
2.SafetyWarning
•Anyoneworkingwith,onoraroundthisequipmentshouldreadthismanual.Failuretoread,
understandandfollowtheinstructionsgiveninthisdocumentationmayresultindamagetotheunit,
injurytooperatingpersonnel,and/orpoorequipmentperformance.
•Anyinternaladjustment,modificationormaintenancetothisequipmentmustbeundertakenby
qualifiedservicepersonnel.
•Theuseofanyhazardousmaterialsinthisequipmentmustbemonitoredbyanindustrialhygienist,
safetyofficerorsomeothersuitablyqualifiedindividual.
•Beforeyouprocess,youshouldthoroughlyunderstandtheinstallationproceduresandtakenoteof
theenvironmental/electricalrequirements.

•Inthismanual,importantsafetyrelatedpointswillbemarkedwiththesymbol.

•Iftheequipmentisusedinamannernotspecifiedbythismanual,theprotectionprovidedbythis
equipmentmaybeimpaired.
3.LimitationofLiability
Thedisposaland/oremissionofsubstancesusedinconnectionwiththisequipmentmaybegovernedby
variouslocalregulations.Familiarizationandcompliancewithanysuchregulationsarethesoleresponsibility
oftheusers.Esco’sliabilityislimitedwithrespecttousercompliancewithsuchregulations.




vi
4.EuropeanUnionDirectiveonWEEEandRoHS
TheEuropeanUnionhasissuedtwodirectives:
•Directive2002/96/EConWasteElectricalandElectronicEquipment(WEEE)
ThisproductisrequiredtocomplywiththeEuropeanUnion’sWasteElectrical&
ElectronicEquipment(WEEE)Directive2002/96/EC.Itismarkedwiththefollowing
symbol:
EscosellsproductsthroughdistributorsthroughoutEurope.ContactyourlocalEsco
distributorforrecycling/disposal.
•Directive2002/95/EConRestrictionontheuseofHazardousSubstances(RoHS)
WithrespecttothedirectiveonRoHS,pleasenotethatthishoodfallsundercategory8(medicaldevices)and
category9(monitoringandcontrolinstruments)andisthereforeexemptedfromrequirementtocomplywith
theprovisionsofthisdirective.








vii
DuctlessFumeHoods
DeclarationofConformation
InaccordancetoENISO/IEC17050‐1:2004



We, EscoMicroPte.Ltd.
of21ChangiSouthStreet1
Singapore,486777
Tel:+6565420833
Fax:+6565426920


declareonoursoleresponsibilitythattheproduct:
Category:DuctlessFumeHoods
Brand :AscentMax
Model :ADC‐2B1,ADC‐3B1,ADC‐4B1,ADC‐5B1,ADC‐6B1
ADC‐3C1,ADC‐4C1,ADC‐5C1,ADC‐6C1
ADC‐3D1,ADC‐4D1,ADC‐5D1,ADC‐6D1
ADC‐3E1,ADC‐4E1,ADC‐5E1

inaccordancewiththefollowingdirectives:
2006/95/EEC:TheLowVoltageDirectiveanditsamendingdirectives
89/336/EEC:TheElectromagneticCompatibilityDirectiveanditsamending
directives

hasbeendesignedtocomplywiththerequirementofthefollowingHarmonizedStandard:
LowVoltage:EN61010‐1:2001
EMC :EN61326‐1:2006ClassB

MoreinformationmaybeobtainedfromEsco’sauthorizeddistributorslocatedwithintheEuropeanUnion.A
listofthesepartiesandtheircontactinformationisavailableonrequestfromEsco.








_______________________________
LinXiangQian
VicePresidentofEngineeringDivision








ThisDeclarationofConformityisonlyapplicablefor230VAC50Hzunits



viii



1
DuctlessFumeHoods
Chapter1‐ProductInformation

1.1AboutAscentMaxDuctlessFumeHood
EscoAscentDuctlessFumeHoodsprovideprotectiontobothlaboratorypersonnelandtheenvironmentfrom
toxicfumesandarequicklybecomingaviablealternativetoconventionalfumehoods.

Unlikeconventionalfumehoods,thesehoodsfilteroutchemicalfumesandrecycleairdirectlybacktothe
laboratory,providingenergysavings,personnelandenvironmentalprotection,convenienceasyoudonot
havetodealwithcomplicatedductingsystems,andmobility,asductlesshoodsareindependentsystems
whichdonotrequireconnectiontoextractionsystems.

EscoductlessfumehoodsareindependentlytestedbyINVENT‐UKfortheabilitytofiltercontaminatedairwith
efficiencyandretentioncapacityasrequiredbytheBritishStandardBS7989andFrenchStandardAFNORNFX
15‐211.FumecontainmentandairflowuniformitymeettherequirementsofASHRAE110‐1995,BS7258,EN
14175‐3andAFNORNFX15‐203.TheEscocombinationofeffectivecontainmentandsafecarbonfiltration
opensnew,costeffectiveapplicationsforfumehoodtechnologyinlaboratoriesofthe21stcentury.
1.2Labels



Model‐Themodeloftheunit.
Serial‐Theserialnumberoftheunit.
Power‐Thepowerconsumptionandelectrical
requirementoftheunit.
Manufacturedyear‐Theyearofmanufacture.
AirflowInformation
ElectricalRequirement



2
1.3QuickView
1.3.1ADC_B_/ADC_D_SeriesQuickView




















1. ExhaustCollar(optional)
2. Blower
3. CarbonFilter(s)
4. TemperedGlassSideWall
5. ServiceFixtureProvision(optional)
6. ElectricOutletProvision(optional)
7. StainlessSteelWorktop
8. SupportStand(optional)
9. Electrical/ElectronicPanel
10. EscoSentinelMicroprocessorControl
11. TemperedGlassSlidingSashWindow
12. TemperedGlassBackWall(DSeriesonly)


1
3
4
5
6
7
8
9
10
11
12
2



3
DuctlessFumeHoods
1.3.2ADC_C_/ADC_E_SeriesQuickView



















1. ExhaustCollar(optional)
2. Blower
3. CarbonFilter(s)
4. TemperedGlassSideWall
5. ServiceFixtureProvision(optional)
6. ElectricOutletProvision(optional)
7. StainlessSteelWorktop
8. SupportStand(optional)
9. BackupCarbon(CSeries)Filteror
HEPA(ESeries)Filter
10. Electrical/ElectronicPanel
11. EscoSentinelMicroprocessorControl
12. TemperedGlassSlidingSashWindow


1
3
4
5
6
7
8
9
10
11
12
2



4
1.4AirflowPattern


1. Aninflowaircurtainfromtheambientenvironmentintothecabinetwithanaveragevelocityof0.5
m/sor100fpmisinducedbythecabinetblowersystem.
2. AdditionalinflowairtakenthroughtheAutoPurge™slotsatthebackoftheworkzonepreventsfume
accumulationforbetteroperatorprotection.
3. Theinflowflushestheentireworkzoneofthecabinet;withinthemainchamberofthecabinet,
negativepressure(relativetotheambientenvironment)ismaintainedinordertoensurethatno
chemicalfumesorvaporsescapetheworkzone.
4. Airistakenthroughanactivatedcarbonfiltermountedintheinterior;thisremovesallfumesfrom
theexhaustairstream;exhaustairisre‐circulateddirectlybacktotheroomfromthetopofthe
cabinet.
1.5Filtracheck
FiltraCheckisatrademarkserviceprovidedbyEsco’sfumefiltrationdivision.Customerswhointendto
purchaseaductlessfumehoodbutareunsurewhetherthecabinetissuitablefortheirapplication,can
forwardalistofchemicalsthattheywillbehandlingandtheirpatternofusagetoEsco'sFiltraCheckservice
team.

APDFQuestionnaireformisavailableathttp://ductless.escoglobal.com/.Thisquestionnairecanbe
downloadedandeitherforwardedbyemailorbyfaxtoEsco.Aftercarefulanalysisoftheprovidedchemicals
listandpatternofusage,aproperadvicedocumentwillbegeneratedandprovidedtothecustomerin3days
period.

Thisdocumentwillrecommendtheappropriatelaboratoryequipment;ductedfumehoodorductlessfume
hoodorneitherbasedontheinvestigationdonebytheFiltraCheckteam.Dependingonthetypeofchemicals
used,thedocumentmayalsocontainalistofprocedures,warnings,etc.thatwillhelpinensuringasafer
laboratoryworkingenvironment.Inthecaseofarecommendationofaductlesscabinet,appropriategrade
andtypeofactivatedcarbonalsobecomesafactorthathastobetakenintoconsideration.




5
DuctlessFumeHoods
Chapter2‐ControlSystem
2.1SentinelControlSystem








1. FanButton
oTurnsonandturnoffthefan.

2. LampButton
oTurnsonandturnoffthelamp.

3. SocketButton
oTurnsonandturnofftheelectricalsocket(retrofitkit).
oThemaximumratingofalltheoutletsinthecabinetis5A.ifoverloaded,thefusewillblow.

4. UVButton
oAlthoughpresent,thisfeatureisnotapplicable.

5. Up(▲)andDown(▼)ArrowButton
oMoveupwardsanddownwardsthemenuoptions.
oIncreaseanddecreasecorrespondingvalueinsideoneofthemenuoptions.
oMovethesashwindowupwardanddownward(formotorizedsashhood).

6. SetorMuteButton
oChoosethemenuorsub‐menucurrentlydisplayedontheLCDscreen.
oProceedtothenextsteporsequenceinsideoneofthemenuoptions.
oSashalarmcanbemutedbypressingSetbutton.

7. MenuButton



oToenterandexitfromthemenuoptions.
oTogobacktothepreviouslevelofthemenuoptions.
oToaccessmaintenancemodefrom“AIRFAIL!”errorcondition.
Alarmisdisabledwhenyouentermenuoptions
Menu
Button
Set/Mute
Button
Up
Button
Down
Button
LCD
Display
Fan
Button
Lamp
Button
Socket
Button
UV
Button



6
2.2MenuOptions



Pleaserefertothefollowingdiagramforcompletereferencetoallmenuoptionsavailable.

PressMENUbuttonandentertheADMINPINtoenterthemenu.

Inthemenuoptions:
•PressUPorDOWNbuttontomovethroughthemenuoptions.
•PressSETbuttontochooseandproceedtothenextstep.
•PressMENUbuttontocancelandreturntothepreviousstep.

Exitmenuoptionsaftermakinganychangesinordertopreventunauthorizedaccesstothemenu.


Whenyouareenteringmenuoptions,thealarmwillsoundtoindicatethatthemicroprocessoris
notmonitoringtheoperationofthehoodandassuchwillnotgiveairflowalarms.Nofurther
warningswillbegiven.Therefore,itishighlyrecommendedthattheusersettheADMINPIN,which
willrestrictunauthorizedaccesstothemenu.ThedefaultADMINPINfromthefactoryis0009.



7
DuctlessFumeHoods
2.2.1Settings
TheusermayusethesettingsmenufunctiontocustomizetheoperationoftheBSCtomeetspecific
applicationrequirements.
2.2.1.1SetTime
Userscansetthetimebyincreasing/decreasingthehourandminutevalues.Thecorrecttimewillbe
maintainedevenaftertheunitisturnedoff.

1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“SETTINGS”.PressSETbuttontoconfirm
5. PressUPandDOWNbuttonsuntildisplayshow“SETTIME”.PressSETbuttontoconfirm
6. PressUPandDOWNbuttonstochoosethehour(HH).PressSETbuttontoconfirm
7. PressUPandDOWNbuttonstochoosetheminute(MM).PressSETbuttontoconfirm
8. Displaywillshow“TIMESET”forafewseconds
9. PressMENUbuttontoexitthemenuoptions
2.2.1.2WarmUp
Therewillbeaperiodofwarm‐up,beforethefanisfullyfunctioning.Thisistoensurethatthesensors,the
blower,andthecontrolsystemarestabilized,aswellaspurgingtheworkzoneofcontaminants.Thedefault
settingis3minutesandtheusercansetitbetween3to15minutes.

1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“SETTINGS”.PressSETbuttontoconfirm
5. PressUPandDOWNbuttonsuntildisplayshow“WARMUP”.PressSETbuttontoconfirm
6. PressUPandDOWNbuttonstochoosetheminute(XX).PressSETbuttontoconfirm
7. Displaywillshow“WARMUPSET”forafewseconds
8. PressMENUbuttontoexitthemenuoptions
2.2.1.3PostPurge
Aftertheuserswitchesoffthehood’sfan,therewillbeapost‐purgeperiod.Thisfeatureistoensurethatall
residualcontaminantsarepurgedfromtheworkzone.Thedefaultsettingis0minuteandusercansetit
between0to15minutes.Settingitto0minutewilldisablethisfeature.However,itisrecommendedtopurge
thefumehoodbyleavingthefanonforaround3minutesaftertheworkiscomplete.

1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“SETTINGS”.PressSETbuttontoconfirm
5. PressUPandDOWNbuttonsuntildisplayshow“POSTPURGE”.PressSETbuttontoconfirm
6. PressUPandDOWNbuttonstochoosetheminute(XX).PressSETbuttontoconfirm
7. Displaywillshow“POSTPURGESET”forafewseconds
8. PressMENUbuttontoexitthemenuoptions




8
2.2.1.4VelocityUnit
Usingthisoption,theusercanselecttheunitinwhichairvelocityismeasuredanddisplayed.
MENU SETTINGS VELOCITYUNIT
FPM
M/S 
1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“SETTINGS”.PressSETbuttontoconfirm
5. PressUPandDOWNbuttonsuntildisplayshow“VELOCITYUNIT”.PressSETbuttonto
confirm
6. PressUPandDOWNbuttonstochoose.PressSETbuttontoconfirm
7. PressMENUbuttontoexitthemenuoptions
2.2.1.5TemperatureUnit
Usingthisoption,theusercanselecttheunitinwhichairvelocityismeasuredanddisplayed.
MENU SETTINGS TEMPUNIT
CELCIUS
FAHRENHEIT 
1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“SETTINGS”.PressSETbuttontoconfirm
5. PressUPandDOWNbuttonsuntildisplayshow“TEMPUNIT”.PressSETbuttontoconfirm
6. PressUPandDOWNbuttonstochoose.PressSETbuttontoconfirm
7. PressMENUbuttontoexitthemenuoptions
2.2.2Calibration
Thepurposeofcalibrationistoensuretheaccuracyoftheairflowdisplayandalarm(ifpresent).Thisinvolves
measuringairflowwithreferenceinstrumentationandestablishingreferencebetweenairflowsensor(s)onthe
hoodtothestandardreference.Calibrationshouldonlybecarriedoutbytrainedpersonnel.Thissectionis
presentsabriefoverviewofthecalibrationmenufunction.Formoreinformation,refertotestreport.


2.2.2.1SetConstant
EverysensormanufacturedbyEscohasaspecificSensorConstantwhichisusedfortemperature
compensationperformedbythetemperaturesensor.
2.2.2.2ZeroSensor
Thisoptionletthecontrollerrecordthespecificsensoroutputvoltageandcorresponditto0m/sor0fpm.
2.2.2.3CalibSensor
Thisoptionallowspropercalibrationandoperationoftheairflowsensoralarm.Therewillbethreepointsto
becalibrated,namelyinflowfailpoint,inflownominalpoint,anddownflownominalpoint.



9
DuctlessFumeHoods
2.2.3Admin
TheadminmenuallowsyoutochangebothfanandAdmin.PIN,alsotodisableit(notrecommended).The
resetblowerhourmeterisusuallyusedafteryouchangetheblower(orfilter)anditcaneasilygiveyouthe
indicationonwhentodomaintenance.Whiletheresetdefaultfunctionwillreturntheoptionsinthesettings
menutotheirfactorysettings.
2.2.3.1NewAdmin.PIN
ADMINPINrestrictsaccesstoMENUfunctions,includingservicefunctions,likecalibration.Usermustenter
fourdigitsPINbeforeaccessingMENU.ADMINPINhashigherpriorityandcanbeusedtocontrolthefan
(overrideFanPIN).

ADMINPINcanalsobeusedtoswitchtomaintenancemodefromERR.MSWITCHandAIRFAIL!errors
condition.

ThedefaultPINis0009.SettingPINto0000willdisablethisfeature.

1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“ADMIN”.PressSETbuttontoconfirm
5. PressUPandDOWNbuttonsuntildisplayshow“NEWADMINPIN”.PressSETbuttonto
confirm
6. PressUPandDOWNbuttonstochoosethenumericaldigit.PressSETbuttontoconfirm.Do
thisforall4digits
7. Displaywillshow“CONFIRMPIN?”.PressSETbuttontoconfirm
8. PressMENUbuttontoexitthemenuoptions
2.2.3.2NewFanPIN
FanPINrestrictsaccesstofancontrol.Usermustenterfour‐digitPINbeforeswitchingfanonoroff.Assuch,it
canrestrictaccesstooperatingthehoodbyunauthorizedpersonnel.FanPINisalsoneededtodisablethe
alarmwhenthesashisfullyraisedandcleaningneedstobeperformed.

ItisrecommendedthattheFanPINbeissuedonlytopersonnelauthorizedtousethehood.

ThedefaultPINis0001.SettingthePINto0000willdisablethisfeature.

1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“ADMIN”.PressSETbuttontoconfirm
5. PressUPandDOWNbuttonsuntildisplayshow“NEWADMINPIN”.PressSETbuttonto
confirm
6. PressUPandDOWNbuttonstochoosethenumericaldigit.PressSETbuttontoconfirm.Do
thisforall4digits
7. Displaywillshow“CONFIRMPIN?”.PressSETbuttontoconfirm
8. PressMENUbuttontoexitthemenuoptions





10
2.2.3.3A/FMonitor
Whenevertheairvelocityfallsbelowthefailpoint,theairfailalarmwillbetriggered.Thisoptionisusedto
enable/disablealarm.
A/FMONITOR
ENABLE
DISABLE
MENU ADMIN

1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“ADMIN”.PressSETbuttontoconfirm
5. PressUPandDOWNbuttonsuntildisplayshow“A/FMONITOR”.PressSETbuttonto
confirm
6. PressUPandDOWNbuttonstochoose.PressSETbuttontoconfirm
7. PressMENUbuttontoexitthemenuoptions
2.2.3.4FilterType
Tosetthetypeofmaincarbonfilter(s)usedinthehood.Theoptionsincludestandard,acidfilter,aldehyde
compound,ammonia/amines,halogencompound,mercurycompoundandsulphurcompound.
TEMPUNITMENU ADMIN
STANDARD
ACIDFILTER
ALDEHYDECPD.
AMMONIA/AMINES
HALOGENCPD.
MERCURYCPD.
SULPHURCPD. 
1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“ADMIN”.PressSETbuttontoconfirm
5. PressUPandDOWNbuttonsuntildisplayshow“FILTERTYPE”.PressSETbuttontoconfirm
6. PressUPandDOWNbuttonstochoose.PressSETbuttontoconfirm
7. PressMENUbuttontoexitthemenuoptions
2.2.3.5ResetBlowerHourMeter
Thisoptionisusedtoresettheblowerhourmeter.Theblowerhourmeterindicateshowlongtheblowerhas
beeninoperation.Maximumcounterissetat9999hours.Thecountervaluecanbecheckedwhilein
maintenancemode.Thevaluecanalsoprovidesomehelpinsettingupmaintenanceschedule,includingfilter
change.

1. PressMENUbuttontoenterthemenuoptions
2. Ifrequested,enterADMINPINdigitbydigitbyusingtheUP,DOWNandSETbuttons
3. Thealarmwillsoundforafewsecondtoindicatethatthehoodisunsafeforwork
4. PressUPandDOWNbuttonsuntildisplayshow“ADMIN”.PressSETbuttontoconfirm
