eSmart LC3100C User manual
Questions, problems, missing parts? Contact technical support department at
657-341-0362, 9:00 a.m. - 5 p.m., PST, Monday - Friday or visit us online at
www.esmartpro.com
Please have your model and serial number ready
M_LC31
OOC_20
17
Printed in China
smarr
Massage
Chair
LC3100C
Manual
Contents
Thankyou for purchasing eSmart massage chair.
Please read the owner's manual (operating manual) before use.
Safety Precautions...................................1-4
Main Function.............................................5
Components & Descriptions....................5-7
Before Use............................................ 8-13
Adjusting Massage Chair..........................13
Start Massage...........................................14
After Use...................................................14
Troubleshooting........................................15
Safety Check............................................
15
Storage and Care.....................................16
Specification..............................................17
• This product is intended for residential use only.
• Use this product only as described
in
this manual. Any other
use is not recommended
by
the manufacurerand may cause
fire, electricshock
or
injury
to
persons.
• Remember
to
keep the manual
in
an easily accessible place.
Safety Precautions
e Be sure
to
read this manual thoroughly in order
to
operate the product correctly.
e The manual contains important information about how
to
usethe productsafely and correctly,
avoiding possible damage
to
property
or
injury to persons using the product.
e
To
clearly indicate the degrees
of
dangerand damage, symbols"WARNING" and "CAUTION"
shown below are used throughout the Operation Manual to highlight importantsafety instructions.
AwARNING
AcAUTION
[Symbols]
~
c
This action could result
in
serious injury
or
death.
This action could result
in
minorpersonal injury
or
damage to
property.
The symbol on the left means "Do notdisassemble."
The symbol on the left means "Unplug the chair."
A Symbol is inform you the content of"WARNING"and "CAUTION"(The
Symbol on the left means "read the "WARNING" and "CAUTION"
before use")
• Remember to keep this Operating Manual in an easily accessible places.
A WARNING
If
any
of
the below abnormal conditions exist
or
occur, please stop operating the product
immediately. Electric shock
or
risk
of
fire may occur. Tum
off
the main powerswitch and
unplug the unitfrom the wall outlet. Do not
try
to repairthe malfunctioned product and
contact the manufacturer.
A
c
0
e Do not operate this product during a lightning storm
or
sound
of
abnormal
noises coming from the unit.
e Do not operate this product aftera spill
or
contact with moisture.
e Do not operate this product after
any
objectfalls inside the massager.
e Do not operate this product ifthe casing is broken, drooping
or
tipped over.
CAUTION
e Discontinue the use
of
this product
if
it becomes uncomfortable.
e Use this producton a flat level surface.
e Before operating, make use the product's controls are properly functioning
and not damaged.
..1
''-------------------------------------------------------------------------------------------------------------------------------------
0
WARNING
The following persons must notuse this product
PROHIBITED
Person who has thrombosis, serve aneurism, acute varicosity
or
skin infection,
including inflammation
of
the hypodermis.
I'
0
Persons with
any
of
the following conditions should seekmedical advice
before using.
1.Peoplewho has electronic medical devices easily susceptible to electromagnetic
interference
2.People with malignant tumors
3.People with serious heat disease
4.Woman who is
in
menstrual period orpregnant
5.Sensory disturbance caused by peripheral circulatory disorder due
to
diabetes
6.People with sensory distrubance
?.Persons being treated for personal injury
8.High fever
(1
00°F
or
higher),such as acute inflammation,high blood pressure or
chills
9.Persons with sickness orunder
bed
rest orders
10.0steoporosis, spinal fractures and acute pain
11.1nflammation due to sprains and muscle strain
It is not recommended forthose who are
in
uncomfortable or sickness
The
time
of
a program can be adjusted as 10,20,30 minutes, Do not over massage
or
continue
to
massage a specific area
of
the body longerthan 30 minutes.Please
stop
for
at
least 30 minutes before restarting the massage chair. Continually using
themassager
for
extended periods
of
time can result in overstimulation
of
the
muscle
or
nerves. A wARNING '
® Wet Hands Forbidden-Do not touch the poweroutlet, plug
or
powercord with
wet
damp hands as this will cause electric
FORBIDDEN
WET
HAND shock and damage to the unit.
® ProtectAgainst Liquids-Do not spill water
or
other liquids on the
product. Do not place the product in humid environments such
CUARDAGINST DAMP
as
bathrooms.This may result
in
electric shock
or
malfunction.
0 Caution is necessary when operating the unit by
or
nerchildren,
invalids,
or
pets.
REQUIREDACTION
~
Do not try to disassemble
or
repair the product, power cord,
or
control panel as this may result
in
malfunction
or
risk
of
fire.
DO NOT DISASSEMBLE
(S)
Do not alter
or
tamperwith the powercord. Do not bend,stretch,
twist
or
wrap the powercord. Ifthe power cord is damaged
or
broken this may result
in
electric shock, short circuit
or
fire.
PROHIBITED
'
../
Safety Precautions
I'
(S)
PROHIBITED
'
A wARNING
~
Do notletchildren
or
mentally retarded persons operate the product alone.
Keep children
or
mentally retarded persons away from the product when not using.
Use onlyAC120V power.Power cord can not bewrapped on the product
to
avoid
electricshock,shortcircuit
or
fire.
Do notput hand
or
foot into the gap between backrest and seat,
or
beneath the
seat.lt may cause injury
or
accident.
Do not operate the product on head,belly,it may cause injury
or
uncomfortable.
Do notuse the productwith body naked,it may cause damage
to
the skin.
Product can not be used when cover is disconnected
or
damaged.
A CAUTION
e In the event
of
a powerfailure-switch OFF the main power switch
and disconnect the unit from the poweroutlet.
e Do not touch the poweroutlet or powercord with
wet
hands.
./
FORBIDDEN
WET
HAND
PROHIBITED
• Disconnect the unitfrom the poweroutlet when not
in
use.
e Disconnect the unitfrom the poweroutlet before cleaning the unit.
•
To
prevent damage, electricshock,
or
short circuit, disconnectthe
unitfrom the poweroutlet
by
holding the power plug and not
by
the
powercord.
e Do notusethis product during
or
after drinking alcohol.
e Do nothang heavy objects on the powercord.
e Do notusethis product nearopen flames, fires,
or
heating devices.
e Do not smoke while using this product.
e Do notplace this product direct heating devices including heating floors.
e This product is not intended
for
use by children, invalids,
or
persons with
reduced mental capabilities.
e Children should not playwith
or
sit on this product as
it
may
result in
injury.
e
0
PROHIBITED
r
0
PROHIBITED
'
0
•
•
•
•
•
•
•
•
•
A wARNING
Do not pull hard
or
use knife,sharp object to scratch the fabric,it may cause
injury
or
accident.
Do not bend,pull power cord hard,it
may
cause fire.
Controller can notfall
or
be impacted,it may cause wrong movement
or
malfunction
Do not use the productwhen power cord and plug are damaged
or
plug
is loose,it
may
cause electricshock,shortcircuit
or
fire.
Mind fingers when open
or
close the chair backrest.
Do notexert external force on the parts,it may cause malfunction
or
injury.
Do not use the productwhen sleeping,it may cause injury and discomfort
Move the product by using rollers,do not move it not
in
rollers' direction.
Place the product gently after moving
,
A CAUTION
This product is for residential use only. Commercial applications will not be
warranted.
Do not operate this productwith
any
coverings
or
blankets as excessive heating
can occur and cause risk
of
fire.
Make sure a tight connection between the plug and power outlet. Wipe away
any
dust that may accumulate. Risk
of
electric shock, short circuit
or
fire.
Do not stand
or
step on the product. Excessive force may result in injury,
malfunction
or
risk
or
fire.
Do not use this product nearopen flames
or
flammable
gas
as it may result in
product distortion, malfunction,
or
risk
of
fire.
Do not use this product where aerosol spray products are being used
or
oxgen is
"'
being administered as it may result
in
product distrotion, malfunction,
or
risk
of
fire.
Do not use abrasive solvents
to
clean this product as it
may
cause damage to the
internal parts,the exterior finish
or
casing.
Keep children, invalids, and pets away from the functioning product.
This product is notintended
to
be used
by
persons with reduced mental
capabilities, ill
or
under bed rest.
..)
Main function
0 Zero-Gravity
One key Zero-Gravityoperation, easy to reach your natural and complete relax position
G\
8-point Masssage
~
8 masssage balls on the back, provide a complete massage to comfort and relax your body
~
HeatTherapy
'!}
Carbon fiber heating technique warms users body safely and enhance massage experience
~
Full Body
Air
Massage
\L1
Airbags wrapping your shoulders, arms, legs and feet, relieve tension muscles
.:-.
Extended Legrest
~
Extend the legrest 6.3in longereasily by spring,suitfor people in different height
A.
BodyStretch
\!1
Body stretch function effective relieve fatigue, enable your body swaying rhythmically
~
Foldable Design
V Backrestfoldable, easy
to
store, save space.
Easy to Use
All
of
the functions can be easily activated
by
pressing the key.
Components & Descriptions
• Chair
Pillow
--------
........
/
Foot massage unit
e Powercord and power socket
Attention1:Before inserting power cord,please ensure
main powerswitch
is
off.
Attention2:Do not disassemble
or
replace the power
cord when it is damaged.Aretailer
or
a qualified
professional shall be needed.
e Main power switch
Tum on the main power switch, massage chair into
standby mode
e Controller Press
the
button
to
lighton the LCD screen.
Press any massagefunction button to start
B
D
E
F
G
H
-;;
··::·
.;
..
'l
. .
d.•
- -
fl
~
BB
...
II
I
IIPW
-··
:BBIIN
All
-··
Sho
u
~or
c
I
M
J
N
K
0
L
p
A
B
c
D
E
F
G
H
1-
I
1- J
K
1- L
1-
M
N
0
1-
p
Power
Refresh
function
Stretch
Relax
Pause
-
Heating
Neck massage
Leg air
massage
Zero Gravity
Waist massage
Arm air
massage
Shoulder
massage
-
Backrest rising
Backrest
declining
Speed
Air
massage. Press the button again to stopall
massage function, the massage rollers will return
to
its original position
Press
the
button
to
begin Refresh function -
Press this button to begin Stretch massage -
Press this button
to
begin Relax massage
Press this button, the chair stops massage, press
the button again,
it
starts massage.
Press this button to start heating function. Press
this button again to stop heating function
Press
the
button
to
start massage on the neck.
Press
the
button again
to
stop the neckmassage.
Press
the
button
to
start rhythmic
air
pressure
massage
on
legs. Press the button to stop the
function.
Press this button to activate the Zero-Gravity
function. The icon (
.-#
) will be lighted. Press
the button to return to idle position. The
icon(.-#
)
will notbe lighted.
Press this button
to
start roller
massa~e
on your
waist. Press the button again to stop t e function.
Press this button
to
start rhythmic
air
pressure on
yourarms. Press the button
to
stop the function.
Press this button
to
startshouldermassage with
rhythmic
air
pressure. Press the button to stop
the function. -
Press and hold on this button, until the backrest
raise
to
your
desired angle.
Press and hold on this button until the backrest
decline to yourdesired angle.
The
speedAdjustment button
for
Kneading speed.
Each timethe button is pressed, the intensitywill
increase by 1 level.
The
maximum level is 3.
The
speed can be
adjusted in the cycle.
The
Air
IntensityAdjustment button
for
Air-pressure
Each time the button
is
pressed, the intensitywill
increase
by
1 level.
The maximum level is 3.
AwARNING e Please do not spray water
or
other liquid on the chair.
• Do not operate the chairwith
wet
hand.
ACAUTION • Do not sit on the controller, do not drop
or
step on the controller. Do not
pull over the wire.
• Do not press the button with sharp object
or
it will result in damage.
Before use
• When the temperature is too low
to
run the machine, please increase the ambient
temperature gradually,
do
not increase the temperature
in
sudden. Please move
the
chair
to
the warm place and keep on waiting
for
1
hour
before starting.Or itwill result
in
moisture
of
parts and abnormal operation.
~Or
it will result in moisture
of
parts and abnormal operation.
Howto assemble the shoulder
• Unzipping the shoulder device, put
the
iron part into the slots on
the
end
of
the shaft, let
the
hole "A" match with the slots "B"
• Connect the
air
hose "E"
to
the
air
hose "F" exposed on
the
backrest.
• Use
the
screw (M6 X 16)
to
fix on the shaft
of
the backrest.
• Zip the cover
• Repeat above steps to assembly the othershoulder.
Howto assemble backrest pad and seat cushion
• Connect the wire
of
the heater plug from the backrest to underneath
of
the
seat (Fig 1)
• Connect the backrest and the seat by zipper. (Fig 2)
• Attached backrest pad with zipper. (Fig 3)
• Attached the pillow pad using the velcro fasten (fig 4)
Heater
(Fig 3) (Fig
4)
(Fig 2)
Where to place
the
chair
Please
make sure
that
the
massage chair
has
about 19.685in in
front
of
it,
leaving about 19.685in behind
the
chair
to
allow free reclining
of
the
backrest.
r
CAUTION
e Please do not use
in
a humid place such as sauna or bathroom.
e Place
on
a levels surface before use.
e Please do not use
in
the following situations:
in
a utility room or dusty place or
in high temperatures (over40°C).
e
Do
notplace it
in
the sun
or
nearheating appliances.
e Please
keep
cigarettes, ashtrays or flammable goods
away
from
the massage chair
:.1
e
To
prevent damageto the floor and reduce noise, please
lay
carpet underthe massage
chair(do
not
use
an
electric blanket).
e Please be careful placing this machines, as
it
is heavy.
e
To
avoid excessive noise, make surethe massage chairis a minimum
of
1 meteraway
from the
TV,
radio, and otherAV machine.
19.685
in
t
~-
- \\
--
~
--
~,
---
·- .
~,
~
- ~
\\ :
19.685 in
\\>\
_
:\
-'·
)__-
e Please ensure there is a chairand accessories inside
the
packing box
~-----------------------------------------------------------~
' chair 1 Accessories '
[ I
I
:~I
I I
Manual book
Warrantycard
I I
1 Accessories bag
for
installation
I
I I 1
, chair Controller Manual book Power cord 1
' ,
-----------------------------------------------------------~
How
to
move
When moving,please turn
off
main power switch,then unplug the power plug.
Using caster
to
move
Please putthe back
of
the chair
to
the bottom and then hit the rear wheel, then move
Lift up the calvesrest then recline the chair to about 45 degrees to easily move the chair
with a slight pull
or
push
• The chair cannot be moved
if
the passage is less than 29.528in in width.
• Contact the dealerin case you cannot move the chair normally.
• Due to the heavyweight
of
the chair,make sure that itwill not damage
yourwaist
or
other parts
of
your body during moving.
CAUTION • Controller is connected to the chair,make sure it does notfall during
moving.
e Do not move the chairwith person loaded.
• Please move the chair after unplugging.
--->Otherwise it may cause damages to the power plug,causing fire
disaster
or
electric.
How to open the backrest
•
Turn the backrest
to
backuntil a "click" sound is heard.
Fold backrest
A 4 •
Release lockIeaver as figured
to
lay to backrest onto the seat cushion.
Howto switch on the power
Q) Insert power cord into outlet ® Turn on main powerswitch on the back
of
the chair
Fuseholder
*If
the rollers get stuck,turn
of
the switch and press the ON/OFF button,the rollerwill be
back to its initial position.
'AwARNING
• Do notconnect powercord to an external transformer
AcAUTION
'
• Ensure the main power switch is off before plugging the powersocket
or
controller.
e Please insert power plug and controller plug fully
• Read this manual book carefully before using,setthe chair according to
the requires,ensure normal operation
Connecting the power
Check the power cord,power plug,socket on the chair,main power
switch,controller are unbroken for the first time use
or
use after long
time storage.Then plug power cord.
Powercord
Plug Controllerwire Socket
Confirm the fabric
Make sure
if
the fabric is damaged according to the following procedures before use.
<D
Open zipper and back cushion
from one side @ Put your hand between cushion and
backrestto see
if
the fabric is damaged.
Fabric
Open from this side Back cushion
CAUTION
Before using the chair, confirm that whetherthere is damage
in
the material
of
the armchair
or
of
ot
her
parts.
In
case
of
damage, even the smallest
tear-
ing, in the chair, please stop using it immediately, trun
off
the power switch,
unplug the chair, and contact the customer service center. Never use the
armchair with dismantled cushion
or
damaged material, otherwise there will
be
se
rious safety hazard.
Adjusting massage chair
Sitting
in
the chair
Adjust the backrest to yourdesired position
by
press and holding on the "UP" "DOWN" buttons.
r e Do not sit in the chairwhen legrest is rising,or after legrest rises,it may "
A result in accident
or
reclining chair,causing personal injury.
• Raise the chair before using.Enjoy the massage from light massage course.
CAUTION Adjust the angel
of
your reclining angel according to your bodyfigure.
• Do not stand on the legrest, itwill break the legrest
or
even the whole chair.
A When adjusting angle,please make sure there is no person(Especially
children)
or
pet around.Besides,there must be at least
11.811
in space
at
WARNING the front
or
back
of
the chair,and there is no foreign matter
in
the way
\ when rotating.
~
Start massage
1. Connecting the power,turn on main powerswitch
II
...._____
_
______;,___
_____
_______,
• In the Auto Mode
You may change from one massage program to another
at
any time
without having to wait for
it
to complete. The twinkled button is the
current massage mode
• In the Manual Mode
You may change from one massage program to aonther
at
any time
without having to wait for
it
to complete.
After use
Rise the chair up and lowerthe footrest completely.
Press ON/OFF key to turn offthe chair,wait until chair gets back to its initial status.
After airbags deflate completely,rollers get backto its initial position,sole massage stops,
heating stops,then step out
of
the legrest.Do notstand in the legrest.Turn off main power
switch,unplug power plug.
,A
CAUTION
After you use the chair, turn offthe main power switch, and unplug the
power plug from the socket.
-+Otherwise, accident
or
injuries may be caused by children
or
pets.
After you use the chair, be sure to raise back completely and lower
the footrest completely.
After you use the chair, please clean itand place it in dry places.
When unplugging the powercord, please do not pull it directly;
instead, you should unplug it pinching the power plug.
Please be sure to put the powercord away in prevention
of
tripping
over.
Troubleshooting
If
there
is still a problem aftertrying
the
solutions given
in
this troubleshooting guide,
stop
using
the
chair
immediately
to
preventaccident
or
injury, and unplug
the
power
plug from thewall outlet. Contactthe vendor
or
your near
est
servicecenter
for
assistance.
Problem
Causes and troubleshooting
The massage chair
can notopoerate
eventhoughithas
~
been connected to
,.
the powersupply.
• Checkwhetherthe plug is well connected and
working well
• Checkwhetherthe main switch on the
massage chairis turned to position "I"
During operation,
the controller is
working, but the
chaircan notwork
During operation,
both the controller
and the massage
can notwork
Safety check
~
• The massage chair could be overheated after
prolonged use.
It
will automatically cool down
to
resume its normal condition.
• Please turn offthe powerand allow the chair
to
cool down for 30
or
50 minutes
• Ifthe set-time
in
the Timer
is
complete, please
~
press thetimerfunction again to resume
,.
operation
• Switch OFFthe power and switch ON again to
restartthe chair
RegularMaintenance Will Preserve the Life
of
You
r Chair
Haveyou experienced
any
of
these problems?
•
The
chair
does
not startwith the Main
POWER
switch
se
t to ON
...=:
·
=---,--,...--...,..,....,..--,-.,.......,.-,
•
The
power cord
has
been cracked
or
scratched.
If
you find anything listed
•
The
power cord
or
plug becomes abnormally hot. on the left, stop using and
. . . unplug thepowercord from
•
The
chair produces a burnt smell, abnormal sound
or
v1bra
t
1on.
the
outletto pre
vent
fail
ure
e
The
auto timer function does not
wor
k
in
some
cases.
or
an
acc
ident.
Be
sure
to
e
Other
failur
es
contact the
ve
ndor
or
our
.
servb:l
a:rterfa'
rrEi'1tenarlre
To
use
safely
The
chairfabric (ro
ll
er
fabric) is a consumable part, and its
serv
ice life is 3 years
(conditions
of
use:
two
15-minute
sessions a day, every day).
For
safe use, periodic inspection
by
the vendoris recommended before the end of its
service life.
*Durable years
vary
depending
on
conditions of use.
*After
aboutfive years
of
use, a professional inspection is recommended even
if
there
are
no
symptoms
or
problems.
For
inspection fees, contact t
he
vendor.
Storage and care
Storage
e Aftercleaning
the
dirtand dust,place the chair
in
a
dry
place
e
If
the chair is left unused
for
a while,please cover the chair to prevent from dust.
e Pets sometimes
chew
on powercord,so try
to
keep the pets
away
from the chair
even when it is stored.
ACAUTION Do not install the chairwhere it can come into contact with direct heat,
such as directsunlight
or
a radiator.
Care and Maintenance
rearing
for
the
Back
Pad and Covers]
Soak
a piece
of
softcloth
in
lukewarm
water
in
which a small
amount
of
mild detergent
has
been added. Then thoroughlywring it
out
before cleaning
off
any
spots
or
grime.
rearing
for
Other
Plastic
Parts
l
Soak
a piece
of
soft
cloth
in
lul<ewarm
water
in which a small
amount
of
mild
detergent
has
been added,
thoroughly
wring it
out
1 and clean
off
any
spots
or
grime.
Then
w1pe
with a
dry
cloth
so
that
no
detergent
res1due remains.
ACAUTION
• Do
not
use
alcohol-based
or
other
household cleaning products
or
abrasives
because
the
can scratch
or
crack
the
finish
or
cause
color
to
fade.
rearing
for
the Remote Control]
Wipe dirt
off
the remote control with a
dry
cloth.
ACAUTION
•
Never
use
a moistened
or
wet
cloth.
May
resultin a mechanicalfailure.
Product specification
Type
Power
Rated power
Rated time
Dimension
Weight
Outer material
Accessories
LC3100C
AC120V-
60Hz
100W
15
minutes
Approx 29.92*55.90
(71.26)
*44.88
(30.51)
in {W*L*H)
The
length and heightfigures
in
() represent
the
dimensions when fully reclined.
About 152.12 lb
PU leather
Main power cord,Controller,manual book,warranty card,
accessories bag
for
installation
About55.90 in
About71.26in
About
44.88in
Table of contents
Other eSmart Massager manuals
