AKE-5 User Guide
The Worry-Free Keyless Entry®System
Copyright © 2009 Essex Electronics, Inc. All Rights Reserved
AKE-5 – UG – Revision A– 06.09 Essex Electronics Incorporated – 1130 Mark Avenue, Carpinteria, California, 93013 – USA Voice 805.684.7601 – Fax [phone] – Email [e-mail]
- Arm Output
The Arm Output (blue wire) provides a ground when the doors are locked by entering
557 or 559. This can be used to light a flashing LED in the vehicle or provide the
ground side for a starter interrupt relay or similar device. If you locked the doors with
555, you can re-lock with 557 or 559 to enable the Arm Output without unlocking first.
559 also cause the keypad to blink every 15 seconds.
- Trunk Unlock
Some vehicles come with a power lock on the trunk. Your installer can connect any
one of three Auxiliary Outputs to the trunk to allow you to unlock the vehicle and then
the trunk. Most installers use the optional output which is triggered by pressing the 7/8
Key on the keypad within 5 seconds of entering a valid unlock code. The 3/4 Key or
the 9/0 Key could be used instead of the 7/8 Key for the trunk, or to control other
devices on your vehicle. If you are using the trunk unlock feature, you will first enter
your personal entry code followed by pressing the 7/8 Key to open the trunk.
5. Using Auxiliary Outputs
- Auxiliary Output 3/4 - Press the 3/4 Key within 5 seconds of the last key press of a
valid user code. Note: This output may be setup to toggle ON/OFF through a
programming command for special control applications.
- Auxiliary Output 7/8 - Press the 7/8 Key within 5 seconds of the last key press of a
valid user code. Normally connected to the trunk release, if available.
- Auxiliary Output 9/0 - Press the 9/0 Key within 5 seconds of the last key press of a
valid user code.
6. Special System Setups
Your system has a special 3-Digit Convenience Code Mode which can be enabled by
the system installer or by following commands listed in the Installer Guide. When the
Convenience Code Mode is enabled and the vehicle is locked by using Lock Code
555, every code in the system will now work by entering only the first 3 digits of the
code. If you have used 7 or 8 digit codes this can be a handy way to allow a friend or
service person to have temporary access by using 3 digits only, and without taking the
time to add a new Optional User Code, and without giving away your personal Master
User Code. To lock the doors so a full length Unlock Code is required, use Lock Code
557 or 559. Don't forget, you can always add 3-Digits Optional User Codes for use all
the time without activating the Convenience Code Mode if you wish.
1. How do I use the Keyless Entry System?
How do I unlock my vehicle?
Your new system is so easy to use. Simply enter your personal three to eight digit
code on the keypad and the door unlocks.
How do I lock my vehicle?
To lock the vehicle door from the keypad Simply enter Lock Code 559.
How can I remember my code?
Worried about remembering your code? Simply change the code to a number
you already know such as your phone number, birth date or anniversary.
How can I change my code?
Don't know how to change the code? Simply follow the few easy steps listed under
changing the Master User Code, or call the installer that put the system in your
vehicle for a service call.
We know you will enjoy the worry-free convenience of the Essex Keyless Entry
Keypad System - no more keys or keyfobs to lose or lock in the vehicle. For further
peace of mind, your system also provides memory for 5 Optional User Codes that
can be added, changed, or deleted to allow a family member, friend, valet, or
mechanic temporary access to the vehicle without having to give out your Master
User Code. If you have any questions or comments please contact us at 1-800-
keyless or at www.keyless.com.
2. How does my system work?
The Essex Keyless Entry Keypad system is designed to provide a convenient
method to safely and securely enter your vehicle without using keys or keyfobs. You
can also use the keypad to unlock the trunk, open the windows or sunroof, or to
actuate other accessories. If your vehicle is equipped with an alarm system, it will be
disarmed when you enter a valid entry code. If your vehicle has a keyfob system as
well, you can use it or the keypad, whichever your prefer, or whichever is more
convenient at the moment.
When you first touch the keypad the keys light up. When you enter your code the
door unlocks and the vehicle's interior safety light goes on (if connected by your
installer). Each time you press a key successfully the keypad beeps and blinks. If you
accidentally make an error during code entry, simply start over with the correct code.
*Removal of the manufacturer's date code label
will void the warranty!
If you want to unlock a power actuated trunk simply press the 7/8 Key on the keypad
within 5 seconds of entering a valid code. If you wait until the double beep, or until
the keypad lights go out, you will have to start over by entering your personal user
code plus the 7/8 Key (or 3/4 Key, or 9/0 Key, depending on how your installer has

Page 2 Page 3
Essex Electronics Incorporated – 1130 Mark Avenue, Carpinteria, California, 93013 – USA - Voice 805.684.7601 – Fax [phone] – Email [email protected]
Essex Electronics Disclaims Any And All Damages Or Injuries That May Result from The Installation Or Use Of This Product - Specifications Subject to Change Without Notice – Patent Pending
connected the three Auxiliary Outputs) to open the trunk or actuate another
accessory. If 25 invalid digits are pressed in sequence, the system locks out code
entry and activates the code tamper alarm by sounding a steady tone and flashing
the interior and keypad lights for approximately 30 seconds. Once the alarm stops,
you can enter a valid user code to unlock the vehicle.
3. Using Codes
There are two types of Codes available in the AKE-5: The Master User Code (1) and
Optional User Codes (5). The Master User Code operates all functions available in the
system plus allows you to add, change, and delete Optional User Codes.
How to enter the Master User Code
A. To Unlock the vehicle simply enter your 3 to 8 digit Master User Code
Note: The Factory Default Master User Code is 1 3 5 7 9. You or your installer should
change this immediately to a personal 3 to 8 digit code. Try using a 7 digit phone
number for your new Master User Code.
Note: The keypad on the AKE-5 has 5 keys. Each key represents two digits. The first
key can be used as either or both the numeral 1 and the numeral 2 when you are
entering a code. Example: The Factory default Master User Code can be described as
1 3 5 7 9 or as 2 4 6 8 0. To the system they are the same 5 digit code. If you want a 1
or a 2 in your Master User Code or in an Optional User Code use the first key to
represent both numbers.
How to change the Master User Code
A. Locate and press the System Programming Switch
4 Rapid Beeps will sound and you will have 2 minutes to start
programming the system.
B. Enter 1 1 1 9 on the keypad
3 Rapid Beeps will sound
C. Within 5 seconds of the 3 Rapid Beeps start entering your new 3 to 8 digit Master
User Code. Now wait 5 seconds and listen for 3 Rapid Beeps . You’re done! Try
the new Master User Code and the door will unlock. If it doesn't, please read the
following paragraph to see if you made an error or skipped a step while programming.
Note: When using or programming your system you must make each keystroke within
5 seconds of the previous keystroke or the system will timeout and reset to normal
operation. 2 Rapid Beeps signal system reset. If the system resets before you have
completed changing the Master User Code, you must start over by pressing the
System Programming Switch. 1 Long Beep signals an error has been made during the
programming sequence. Don't worry. Start over by pressing the System Programming
Switch.
Where is the Programming Switch Installed?
What is my Master User Code?
Code Padding
If you feel you are being observed when you enter your code on the keypad you can
"pad" your code by entering several random digits before you enter your actual code
and still have the door unlock. For instance, if your code is 1 3 9 1 you can enter 5 7 1
3 9 1 and the door will unlock.
What code combinations are restricted
Codes 559, 557, and 555 are pre-assigned as Lock Codes. There is no harm if
everybody knows the Lock Code. However, you can't change a Lock Code so you
can't use 559, 557, or 555 as the Master User Code or as an Optional User Code.
Furthermore, you may not program a new Master User Code or Optional User Code
that starts with the digits 5 or 6 (Key 5/6). If you want a 5 or 6 at the beginning of your
code start with 05 or 06. Example: 05 05 68 (a birth date).
Caution: Never use the first digit of your Master User Code as the Optional User
Code. If you do, you will have to press the System Programming Switch and select a
new Master User Code.
What code combinations are not recommended
- Using your ATM PIN number or computer passcodes
- Short codes using the same digit - example: 111
- Simple codes - example: 123 or 911
- The numbers on your car’s license plate
How to add Optional User Codes and what they are for
You can add up to 5 Optional User Codes in your Keyless Entry Keypad System if you
wish. What are they for? You might want to have an Optional User Code to give to a
family member or a friend if you need to lend them your vehicle temporarily. You can
change it or delete it later. You might want another Optional User Code to give to a
valet parking attendant or to a smog checker or service mechanic at the dealership.
There might be other reasons you need to give someone else access to your vehicle
when you are away and are not comfortable leaving a set of keys behind (after all,
anyone can get a key copied at the local hardware store). Remember, don't give out
your Personal Master User Code instead of an Optional User Code. That way you
won't have to worry about changing your own code. Refer to the AKE-5 User Code
Guide Form included with your system for User Code programming steps.
How to enter a Lock Code
Enter either 559, 557, or 555 Lock Codes. See the Convenience Code Mode section
at the end of this Guide to understand why you might want to use Lock Code 555
instead of Lock Code 559 or 557.
4. Using Standard Outputs
- Unlocking and Locking
Your system has several standard outputs. One output is used to unlock the power
door locks and another one is used to lock the door locks. Depending on your type of
vehicle and how your installer has hooked up the system, you may be able to unlock
only the driver's door or all of the doors.
- Interior Lights
A standard feature allows your installer to connect an output to activate the interior
lights of your vehicle when any valid user code is entered on the keypad. The lights
will stay on for about five seconds after the last keystroke is entered.
