ET NICE WAVE User manual

Required wiring configuration for ET
E.O.L resistor monitored BM circuit.
(N/C). Fail when “High” or “Low” circuit.
For example ET Drive series operators.
Recommended wiring configuration for
push-to-make (N/O). Fail when “Low”
circuits. For example: ET500 gate
operator
Recommended wiring configuration for
push-to-br eak (N/C). Fail when “High”
circuits. For example: ET DC Blue
Advanced and Advanced Pico operators.
Recommended wiring configuration for
push-to-make (N/O). Fail when “High”
circuits.
Recommended wiring configuration for
push-to-br eak (N/C). Fail when “Low”
circuits.
(Check the operator control card instructions
for the required circuit type)
(Check the operator control card instructions
for the required circuit type)
(Check the operator control card instructions
for the required circuit type)
(Check the operator control card instructions
for the required circuit type)
Recommended wiring configuration
when using the ET Nice LED module as
a gate operator status indicator with an
ET Gate operator .
Recommended wiring configuration
when using the ET Nice LED module as
a courtesy light. (Check the operator
control card instructions for auxiliary
relay mode selection settings)
- Status LED
