USER MANUAL
DUX-MTX-WP
100-METER WALL-PLATE HDBT TRANSMITTER

2USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
TABLE OF CONTENT
IMPORTANT SAFETY INSTRUCTIONS...................................................................03
INTRODUCTION.....................................................................................................04
PACKING LIST .......................................................................................................05
SPECIFICATIONS ...................................................................................................06
CABLE SPECIFICATIONS........................................................................................07
PANEL OVERVIEW.................................................................................................08
AUTO & MANUAL INPUT SWITCHING...................................................................10
EDID SWITCH ........................................................................................................11
INSTALL HARDWARE ............................................................................................12
TROUBLESHOOTING .............................................................................................14

3
USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
IMPORTANT SAFETY INSTRUCTIONS
NOTE:
We reserve the right to change the content from time to time without notice.
WARNINGS:
To reduce the risk of fire, electric shock or product damage, please observe
the following Safety Instructions while installing and operating the product:
Do not expose this apparatus
to rain, moisture, dripping or
splashing. No objects filled with
liquids, such as vases, shall be
placed on the apparatus.
To prevent risk of electric
shock or fire hazard due to
overheating, do not obstruct
the unit’s ventilation openings
with newspapers, tablecloths,
curtains, and similar items.
Do not install near any heat
sources such as radiators,
heat registers, stoves, or other
apparatus (including amplifiers)
that produce heat.
Do not place sources of naked
flames, such as lighted candles,
on the unit.
Clean this apparatus only with
dry cloth.
Protect the power cord from
being walked on or pinched
particularly at plugs.
Refer all servicing to qualified
service personnel.
Unplug this apparatus during
lightning storms or when un-
used for long periods of time.
Only use attachments/accesso-
ries specified by the manufac-
turer.
Do not install or place this
unit in a bookcase, built-in
cabinet or in another confined
space. Ensure the unit is well
ventilated.

4USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
INTRODUCTIONS
DUX-MTX-WP Wall Plate 2x1 Transmitter switches VGA and HDMI Inputs to one HDBT
Outputs and is able to transmit 1080P@60Hz with 48 bit Deep Color HD Audio up to
100m/328ft and Ultra HD 4K signal up to 70m/230ft.
DUX-MTX-WP automatically detects and switches between VGA and HDMI Input signals
when connected, with HDMI Input enjoying the priority when both Inputs are active.
Manual switching is also allowed using the front panel SELECT button.
A/V transmission, power, bi-directional IR and RS232 serial communication and Ethernet
pass-through over one signal Cat6a/7 cable, DUX-MTX-WP provides users with an
added level of convenience. An EDID Switch is also available for immediate EDID setting
adjustment while communication or compatibility becomes an issue for the users.
Fully compliant with HDMI 1.4, compatible with HDMI 2.0 and HDCP 2.2, DUX-MTX-
WP comes as an excellent solution for commercial or residential applications where
switching between VGA and HDMI over distance is required.
Features
 2x1 switching between VGA IN and HDMI IN to HDBT OUT.
 Capable of transmissions
Via Cat5e/6 cable:
- Up to 70m/230ft: 4K@30Hz YUV 4:4:4 24bit or 4K@60Hz YUV 4:2:0 24bit
- Up to 100m/328ft: 1080p@60Hz 36bit
Via Cat6a/7 cables:
- Up to 100m/328ft: 4K@30Hz YUV 4:4:4 24bit or 4K@60Hz YUV 4:2:0 24bit
- Up to 100m/328ft: 1080p@60Hz 48bit
 Auto signal detection, auto & manual switching between VGA and HDMI Inputs.
 Fully compliant with HDMI 1.4, and compatible with HDMI 2.0(4K@60Hz 4:2:0).
 HDCP 2.2 compliant.
 EDID management for VGA input.
 A/V transmission, bi-directional IR, RS232, Ethernet pass-through over HDBaseT.
 Support one-way PoE and can be powered by an HDBT Receiver with PSE (Power Supply
Equipment).
 Compact size for convenient and unobtrusive installation.
NOTE: The actual signal transmission distance depends on signal resolution and cable
quality.

5
USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
PACKING LIST
 1 x DUX-MTX-WP
 1 x Power Adapter (12 VDC,1.5A / 2-pin Phoenix connector)
 1 x Phoenix Male Connector (3.5 mm, 3-pin)
 2 x Phoenix Male Connector (3.5 mm, 2-pin)
 1 x Wall Plate Plastic Panel (2-gang US)
 1 x User Manual

6USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
SPECIFICATIONS
Technical
Input 1 x HDMI IN 1 x VGA IN 1 x AUDIO IN
Input Signal Type HDMI: TMDS
Input Resolution HDMI: Up to 4K@60Hz YUV 4:2:0
VGA: Up to 1920 x 1200@60Hz
Audio Input Analog Stereo Audio: 1 x 3.5mm mini jack
Audio Format
HDMI: Multichannel digital audio supporting up to 7.1
DTS Master HD and DolbyTrue HD
VGA: Stereo
Input Video Level 0.5-1.0 V p-p
Output 1 x HDBT OUT
Output Signal Type HDBT
Output Resolution Up to 4K@60Hz YUV 4:2:0
Video Impedance 100 Ω
Maximum Pixel Clock 297 MHz
General
Operating Temperature / RH 32°F ~ 113°F (0°C ~ 45°C)
10% ~ 90%, non-condensing
Storage Temperature / RH -4°F ~ 140°F (-20°C ~ 70°C)
10% ~ 90%, non-condensing
Power Supply 12 VDC 1.5A
Power Consumption 3.36 W
ESD Protection
Human-body model:
• ±8 kV (Air-gap discharge)
• ±4 kV (Contact discharge)
Dimension (W × H × D) 105.6 mm × 36.2 mm × 91 mm
Weight 0.20 kg
Certification CE, FCC

7
USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
CABLE SPECIFICATIONS
To ensure best performance of DUX-MTX-WP, please use stright-through Category
cables wired to T568B standard and a HDBT Receiver device which also supports
100-meter transmission.
Cable Type Range Supported Video
Cat5e/6
100m/328ft 1080p@60Hz 36bit
70m/230ft
1080p@60Hz 3D
4K@30Hz YUV4:4:4
4K@60Hz YUV4:2:0
Cat6a/7 100m/328ft
1080p@60Hz 36bit
1080p@60Hz 48bit
1080p@60Hz 3D
4K@30Hz YUV4:4:4
4K@60Hz YUV4:2:0

8USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
PANEL OVERVIEW
Item Name Description
1 VGA IN Connects to a VGA source.
2 AUDIO IN Used with VGA source for audio signal input.
3 HDMI IN Connects to an HDMI source.
4 HDMI LED
On: HDMI signal is being transmitted.
Off: No HDMI signal is being transmitted or the signal is
unstable.
5 VGA LED
On: VGA signal is being transmitted.
Off: No VGA signal is being transmitted or the signal is
unstable.
6 HDCP LED
On: HDCP video is being transmitted.
Blinking: Non-HDCP video is being transmitted.
Off: No HDMI signal.
7 LINK LED
On: HDBT OUT is linked.
Off / Blinking: HDBT OUT is not linked or there is a link
error.
8 SELECT Button Press the button to select the input source.
9 IR IR sensor. With built-in IR Receiver (30-55 kHz).
10 USB USB connector. Used for power supply.
11 EDID
Used to adjust the EDID setting. Default setting is for
1920*1080 VGA Input. (For more information, please
refer to EDID MANAGEMENT.)
1
2
3
4
5
6
7
8
9
10
11
Front Panel

9
USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
Item Name Description
1 ETHERNET Connects to an Ethernet device.
2 HDBT OUT Connects to an HDBT Receiver via a CatX cable.
3 POWER Connects to the Power Adapter provided.
4 RS232 For RS232 pass-through.
5 IR OUT Connects to an IR Emitter.
12
35
4
Rear Panel

10 USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
AUTO & MANUAL INPUT SWITCHING
After powered on, DUX-MTX-WP will automatically detect the VGA IN and HDMI IN
ports for input signals. In such auto-switching mode, HDMI IN will always enjoy priority
over VGA IN.
AUTO SWITCHING
HDMI IN VGA IN Auto Select
Yes No/Yes HDMI
No No HDMI
No Yes VGA
Otherwise, users can select the desired input source using the “SELECT” button on the
front panel when valid VGA and HDMI signals are both present.
MANUAL SWITCHING (USING “SELECT” BUTTON)
Current Input HDMI IN VGA IN Press SELECT Button will Select
HDMI No/Yes No HDMI
HDMI Yes Yes VGA
VGA Yes Yes HDMI
VGA No Yes VGA

11
USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
EDID MANAGEMENT
EDID (Extended Display Identification Data) is a data structure provided by a digital
display to describe its capabilities to a video source. DUX-MTX-WP features an EDID
management that can be used when its EDID setting’s does not meet the installation
requirements. By default, the EDID Switch is set for 1920 x 1080 VGA input.
SWITCH SETTING MODE
1 2 3
ON
For VGA Input Fix 1280 x 800 as Native Video
1 2 3
ON
For VGA Input Fix 1920 x 1200 as Native Video
1 2 3
ON
For VGA Input Fix 1920 x 1080 as Native Video (Default)
1 2 3
ON
For VGA Input Fix 1280 x 720 as Native Video
1 2 3
ON
For VGA Input Fix 1024 x 768 as Native Video
1 2 3
ON
For VGA Input Fix 800 x 600 as Native Video
1 2 3
ON
For VGA Input Reserved for future use
1 2 3
ON
For VGA Input Reserved for future use
N/A For HDMI Input Copy from detected sink
NOTE: To take effect the EDID settings, unplug and plug the VGA cable.

12 USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
INSTALL HARDWARE
WARNING:
 Before installation, disconnect the power supplies of all the devices.
 Please use quality cables and accessories specified or provided by the
manufacturer.
 During installation, connect and disconnect cables with caution.
To install DUX-MTX-WP (See Application Example: System Wiring on Page 13):
1. Connect DUX-MTX-WP’s HDMI IN or VGA IN to an HDMI or VGA input source
(e.g. Blu-ray player, game console, satellite/cable TV, media server, etc.) through a
quality HDMI or VGA cable. (AUDIO IN may also be connected when VGA IN is in
use.)
2. Connect DUX-MTX-WP’s HDBT OUT to an HDBT Receiver (e.g. DUX-RX) via a
high-quality CatX cable.
3. Connect an HDMI display device (e.g. TV or projector) to HDMI OUT of the HDBT
Receiver.
4. Connect the included Power Adapter to DUX-MTX-WP.
5. Power on all the devices and start operation.
NOTE:
1) 70m/230ft @4K or 100m/328ft @1080p are maximum transmission distances realizable when
DUX-MTX-WP and other devices are in perfect conditions and the straight cable runs with no
electrical interference, bends, kinks, patch panels or wall outlets, etc. If any of these turns to be
an issue in your installation, transmission distance will be affected.
2) When all set, check the LED indicators of DUX-MTX-WP. For LED indication, please refer to
page 08.
3) DUX-MTX-WP supports one-way PoE and can be powered directly by an HDBT Receiver with
PSE (Power Supply Equipment).

13
USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
12V G IR IN IR OUT HDMI OUT NORMALUPDATE
TX RX G
Laptop
HDBT Receiver (e.g. DUX-RX)
PC Monitor
Power
(12VDC, 1.5A)
Phone
HDBT
VGA IN AUDIO IN HDMI IN
HDMI OUT
ETHERNET
at Rear Panel
at Rear Panel
at Rear Panel
USB Power Supply
Power Adapter
(HDBT IN)
Application Example: System Wiring

14 USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
TROUBLESHOOTING
1. Why the Link LED is off or blinking?
• Check that all the devices are on.
• Check that all the cables are qualified and connected properly.
• Check that the CatX cable used complies with the recommended specifications.
For more information, see CABLE SPECIFICATIONS.
2. Why the display connected to the Receiver device shows no picture?
• Check that all the devices are on.
• Check that all the cables are qualified and connected properly.
• Check that the Link LED is steady on. For more information, see Q1 above.
• Check that the display works properly, and that the source device has normal
signals output.
• Ensure that the display device supports HDCP.
• Ensure the CatX cable and the HDMI cables used complies with the recommend-
ed specifications. For more information, see CABLE SPECIFICATIONS.
• Check that your display device is switched to the correct source input mode.
• Check that no compatibility issue exists between the Receiver and the display. If
so, replace the display with other models.
• When VGA input source is connected and used, check if the EDID Switch is in the
correct position. For more information, see EDID MANAGEMENT.
3. Why the display connected to the Receiver shows snow or mosaic?
• Check that all the cables are qualified and connected properly.
• Check that Ethernet cables are Cat5e/6 or higher gauge.
• Check that the source input device has no such problem as snow, mosaic or with
a damaged disc. If so, replace with another qualified input source.
• Check that no compatibility issue exists between the Receiver and the display. If
so, replace the display with qualified models.

15
USER MANUAL - DUX-MTX-WP 100-METER WALL-PLATE HDBT TRANSMITTER
AMX DUX SERIES
DUX-8C
Compact 8x8 HDMI 2.0
matrix switcher for video
signals up to 4K@60Hz 4:4:4
(bandwidth 18 Gbps)
DUX-8D
Dual output 8x8 HDMI 2.0
matrix switcher with 4 mir-
rored HDBT outputs for vid-
eo signals up to 4K@60Hz
4:4:4 (bandwidth 18 Gbps)
DUX-TX HDMI 1.4 over HDBT TX up
to 100m
DUX-RX HDMI 1.4 over HDBT RX up
to 100m
DUX-TX-70 HDMI 1.4 over HDBT TX up
to 70m
DUX-RX-70 HDMI 1.4 over HDBT RX up
to 70m
DUX-SCL HDMI scaler up to 4K@60Hz
4:4:4
DUX-SRX HDBT scaling receiver up to
4K@60Hz 4:4:4
DUX-MTX HDMI 1.4 & VGA over HDBT
TX up to 100m
DUX-MTX-WP HDMI 1.4 & VGA over HDBT
wall-plate TX up to 100 m

© 2017 Harman. All rights reserved. ENZO, NetLinx, AMX, AV FOR AN IT WORLD, HARMAN, and their respective
logos are registered trademarks of HARMAN. Oracle, Java and any other company or brand name referenced may
be trademarks/registered trademarks of their respective companies.
AMX does not assume responsibility for errors or omissions. AMX also reserves the right to alter specifications
without prior notice at any time.
The AMX Warranty and Return Policy and related documents can be viewed/downloaded at www.amx.com.
3000 RESEARCH DRIVE, RICHARDSON, TX 75082
AMX.com | 800.222.0193 | 469.624.8000 | +1.469.624.7400 | fax [phone].2017
