Et system Umpetha User manual

UMPETHA U 082009/072010.012
USER GUIDE
1
Domestic sliding gate operator by ET SYSTEMS.

UMPETHA U 082009/072010.012
2
Glossary of terms used in this manual.
BT
PD or PED Pedestrian operation trigger
BM
TX Remote transmitter / remote control
RX Radio receiver for remote transmitters
LED
Condo Condominium or Complex mode
Loop
Button trigger or full operation trigger for vehicle
access.
Safety infra-red beam set for the detection of
objects in the path of the gate.
(Light emitting diode) visual light indicator
A metal detector loop (antenna) for the
detection of motor vehicles installed in the
driveway surface.
Table of contents
Page Description
3Manual override
3
4 Standard mode
4 Simple auto-close mode
4 Condominium mode
4 PIRAC auto-close mode
4 Courtesy light functionality
5 Pedestrian operation
5Master remote functions and additional features
6
6 Auto-close override/party mode
7 Holiday lock-out Trouble shooting
7 Status LED indication guide
8 Buzzer indications
8 Warranty
Safety obligations and general warnings
How to mov e the gate by hand. Manual override
Operating mode options.
Safety sensing system.
Registering a transmitter using the master remote

UMPETHA U 082009/072010.012
GENERAL SAFETY OBLIGATIONS TO THE INSTALLER AND END USER.
Caution! It is important for personal safety to follow all the instructions carefully. Incorrect installation or misuse may cause serious
personal harm.
Keep the instructions in a safe place for future reference.
This product was designed and manufactured strictly for the use indicated in this documentation. Any other use not expressly
indicated in this documentation, may damage the product and/or be a source of danger.
We accept no responsibility due to improper use of this product.
Care must be taken not to install this product in an unsafe environment. I.e. near inflammable gases and or fumes.
We will not accept responsibility if the principles of good workmanship are disregarded by the installer. The construction of the gate
must be sound and automatable. It is the responsibility of the installer to ensure that all mountings to the gate are sufficient to
withstand the necessary forces in cases of overload.
Before carrying out any work on the product, ensure that the electrical supply is switched off.
It is highly recommended that a set of safety infra red beams be used in conjunction with this product.
We accept no responsibility regarding safety and correct operation of the automation if other manufacturer’s equipment is added
to this product.
Do not make any modifications or alterations to this product.
It is the responsibility of the installer/ service provider to completely instruct and demonstrate the proper use of this product,
especially the emergency override, to the end user. It is also the responsibility of the installer/ service provider to issue all end user
documentation, which accompanies this product, to the end user.
It is the responsibility of the installer to instruct the end user on the proper maintenance of the operating system and it components.
i.e. The clearing of gravel from the track, testing the manual override regularly, testing the gate travel manually for variance in
load.........etc.
Ensure that other persons, especially children are clear of the gate and opener before and during operation.
Keep remote transmitters away from children to prevent accidental activation of the system.
The end user should refrain from attempting to make any repairs or adjustments to the system and should contact professional
qualified assistance timorously.
Anything other than expressly provided for in these instructions is not permitted.
The electrical supply to this product must comply with the local electrical code of practice and any electrical work must be carried
out by a qualified electrician.
Over and above the recommendation to use safety infra red beams with this product it is mandatory to ensure a set has been
installed and is in proper working condition when using the automatic closing feature.
Manually overriding the gearbox to be enable movement of the gate by hand.
The manual release in the open position also deactivates the electronic control. To operate the unit normally the
release door must be fully closed.
Remember to gently push or pull the gate until the gearbox re-engages before running the motor. The gears will
lightly click into place.
3
Locked and engaged Unlocked and engaged
Insert key and turn clockwise. Unlocked and disengaged
Turn override cam anti-clockwise

UMPETHA U 082009/072010.012
OPERATING MODE OPTIONS.
For further information about how your UMPETHA has been configured please refer to your service provider/installer.
4
Mode Simple
Auto-close
As per Standard mode above however the followingdiffers: -
The unit times out the pre-programmed auto-close time fromany open position after which it begin closing the gate.
While closing the gate any BT or BM input will stop and reverse the motor direction backtowards the full open position.
In any open position while auto-close is timing out a BM input will reset the auto-close timer.
Auto-close override/Party mode is available in this mode. (See additional features below)
Holiday lockout is available in this mode. (See additional features below)
Master remote programming is available in this mode. )
Mode Complex
Auto-close (selected when using a loop detector)
In this mode any BT input trigger is treated as an openingtrigger. On reaching the full open position the unit times out
the pre-programmed auto-close time after which it will begin closing the gate.
Ifthe BM or BT input is activated while the auto-close timer isrunning the time will simply reset.
On closing any BT input or BM input will re-open the gate to the full open position.
USE THIS MODE WHEN CONECTING ALOOP DETECTOR.
Thismode excludes Holiday lock-out, Auto-close override/Party mode and Master remoteprogramming.
Mode P.I.R.A.C.
Auto-close
In this mode the unit will operate as perSimple auto-close above. The added feature here is quickclosing once the
BM input has been activated and cleared.
I.e The gate is opening; a car enters the beams and passes right through. The BM input is now clear again and the
gate immediately closes.
If the gate reaches the full open position the pre-programmed auto-close timer times out after which the gate will
begin closing.
This mode includes Holiday lock-out, Party mode/auto-close override and master remote programmingexcept when
used in conjunction with Complex auto-close mode.
Courtesy light out
Active in all operating modes.
The courtesy light output will activate on any opening trigger (BT or Pedestrian). The
light output will remain active until the gate has re-closed. It will switch off3 minutes
after the gate has closed.
Mode Standard (Four step logic)
When the motor is activated using any BT input the gate will open or close and can be stopped in mid cycle using
any BT input again.
The gate can then be reversed by activating the BT input again.
In this mode the gate will remain open where it has been stopped either by button or open limit until the BT input is
activated again. (No auto close)
Party mode is available in this mode. (See additional features below)
Holiday lock out is available in this mode. (See additional features below)
Master remote programming is av ailable in this mode.

UMPETHA U 082009/072010.012
INHERENT SAFETY SENSING SYSTEM
Collision/obstruction/hindrance while opening. (All modes)
If a collision, obstruction or hindrance is encountered before the full open position is reached while opening, the gate will
stop, back off and wait for the next trigger input before closing slowly. The status LED will flash rapidly while stationery after
backing off of collision. Closing trigger clears LED indication.
Collision/obstruction/hindrance while closing. (All modes)
If a collision, obstruction or hindrance is encountered while closing, the gate will stop and reverse to the fully open position.
The next trigger input start the gate closing slowly. The status LED will flash rapidly while stationery after backing off of
collision. Closing trigger clears LED indication.
Multiple collision/obstruction lock-outs. (All modes)
On encountering 4 consecutive obstructions while closing the gate, the UMPETHA will not reverse back to the full open
position. The response will be a 5 sec beep tone, followed by a gentle momentary reverse away from the obstruction. The
unit will now begin a mandatory 30sec lockout whereby the only response to any trigger input will result in a tone so long as
the trigger button is held. After 30sec a trigger input will result in a repeat of the 5 sec beep and the gate opening 1 meter
or to the full open position whichever is reached first. The unit will once again lock out. This time the user must manual release
the unit and test the travel by hand before attempting any further automation of the gate.
The Status LED will flash rapidly throughout this procedure indicating an obstruction has occurred.
Releasing the gearbox and re-engaging it will clear the LED status and the Collision lock out routine.
Collision with closed stopper due to faulty or missing closed limit. (All modes)
If no limit input is made when expected (as calculated by the programmed run time) the UMPETHA will not reverse back to
the open position as it normally would when obstructed. It will however stop at the point of impact with the closed catch
and emit a 5sec long beep tone. At the next valid opening trigger the UMPETHA will re-emit the 5sec long beep tone and
only open the gate by ±1 meter. This will allow for the user to be able to enter the property and manually override the gate.
The magnet actuator and limit can now be checked. If not corrected and further attempts are made to operate the
UMPETHA with a faulty closed limit condition the same routine will be repeated on every operation.
If the user continues to attempt to operate the gate without manually releasing the gearbox while the gate is at the ±1meter
position, the result will only be a repeat of the 5sec beep tone.
5
Action Response
Pedestrian opening
Available in all modes.
1. Gate in closed position
2. Press and release any PED
(pedestrian) input.
A) 3 x 1sec beeps after which gate opens
to pedestrian opening position.
B) At pedestrian opening position
pedestrian auto-close timer times out.
C) 3 x 1sec beeps after which gate re-
closes.
Any further PED (pedestrian) input triggers while the gate is running are ignored except in the pedestrian
opening position, where the auto-close timer will simply reset.
Any BM (beam) input while the pedestrian routine is running will cause the gate to continue to the pedestrian
opening position or rev erse back to the pedestrian opening position. If already in the pedestrian opening
position, the auto-close timer will simply reset.
Any BT (full opening input while the pedestrian routine is running will open the gate to the full open position
and the unit will rev ert to the operating mode selection that has been setup.

UMPETHA U 082009/072010.012
REGISTERING ADDITIONAL REMOTE USERS ON YOUR UMPETHA.
For additional master remote transmitters or Pedestrian control transmitters contact your service provider/installer.
6
Action Response
Continues to beep.
To continue adding remotes repeat from point 2.
Learning a TX button for BT (Full opening) operation using the RX Master remote: - (25 user
memory)
The RX Master remote can only be learnt into memory using the RX pins!
The RX Master remote is the first remote learnt into the BT memory and it must be able to operate
the PED function of the built-in RX as well.
Feature not av ailable in Condo/loop mode
Feature limited to learning in BT operation transmitters only.
1. Open gate fully using the
RX master remote Gate runs to full open position and stops
2. Press and hold RX Master
remote pedestrian button. Start of 5sec. Beep. Waiting for new remote trigger.
3. Release RX Master remote
pedestrian button
4. Press and hold required
button on new TX before
learn mode timer expires and
beep stops.
Long beep changes to.....
2 beeps = Successful there is still memory
av ailable
Multiple rapid beeps = memory full
No beep = Button already in RX
memory or non ET Blue TX used.
If no new TX button is pressed within 5sec. Of the continuous beep beginning, then the RX will
exit learn mode. All other functions return to normal.

UMPETHA U 082009/072010.012
7
Action Response
Until 5sec beep begins.
To unlock repeat
Holiday lock-out
Av ailable in all but Complex Auto-close mode.
1. Close gate
2. Press and hold the PED (pedestrian)
button on a master remote
3. Release PED (pedestrian) button on
master remote Beeping will continue until confirmation or 5sec expires.
4. Press and release BT (full opening)
button on the master remote before 5sec
beep stop.
1 x multiple rapid beeps will confirm holiday lock-
out is active.
After multiple confirmation beeps gate will
immediately start opening when unlocked.
Holiday lock-out is available only when using a master remote. (No hardwired dev ices will activ ate)
A master remote is a remote that has BT (full opening) control as well as PED (Pedestrian) opening control.
If no BT (full opening) confirmation trigger is received by the time the intermittent beeps stop (5sec.), the gate will not
change status.
Auto-close override
Action Response
1 x long beep and gate starts closing.
Party mode
Available in all but Complex Auto-close mode.
1. With the gate at any open position
2. Press and hold any TX (transmitter)
BT (full opening) button After 5sec unit will emit Multiple rapid beeps to confirm.
3. Release input after beeps Gate will not begin closing after auto-close time
has expired.
4. To deactivate repeat 2 and 3
above
If any PED (Pedestrian) or BT (full opening) input is momentarily activated while the unit is in either Holiday lock-out or
Auto-close override/Party mode the unit will only emit the multiple rapid beeps and not run the gate.

UMPETHA U 082009/072010.012
Buzzer indications
Beeps Gate status Program
Jumper Action Response Motor Condition Solution Table ref:
5 x Rapid
beeps Full closed Off Momentary BT or Ped input None Holiday lock- out active Toggle off pg 26
Continuou
s rapid
beeps
Gate
anywhere On None None Holiday lock- out active Toggle off pg 26
5 x Rapid
beeps
Gate
anywhere
but closed Off Momentary BT
or Ped input None
Auto-close
override/part
y mode
active
Toggle off pg 27
1 x 5sec
beep
(long
beep)
opens 1m
and remains
there. Off Momentary BT
or Ped input None limit failure check magnet on gate and limit switch pg 20
2 x Rapid
beeps Gate anywhere Off or On Momentary BT or Ped input Attempts to run Battery flat or faulty
Allow recharge and
check for Aux
devices overload. If
problem persists after
±8 hours charging,
replace battery
3 x 1sec.
Beeps Gate closed Off Momentary Ped Gate opens partially
Pedestrian
function
activated pg 27
2 x 2sec.
Beeps Gate stopped Off Momentary BT Gate runs Household mains failure Restore power supply
1 x 5sec
beep
(long
beep)
Gate
stopped Off Any input triggered None Multiple
collision lock-
out
Check gate closing
resistance pg 20
20 x 1sec.
Beeps. Gate stopped Off or On
First BT input
after a reset or
Set button in
runtime set up
None
No motor
movement
detected or
beam input
is active
Check beam circuit
or setting. Check
gate resistance.
Check motor and
battery
wiring/looms.
pg 19,
20 &14
8
STATUS LED INDICATIONS.
An extension LED needs to be installed for the end user to make use of this feature.
Off Gate closed
Slow flash Gate is running or waiting for auto-close time to time out
On Gate is open
Rapid Flash Gate is obstructed or has exceeded max run time.

UMPETHA U 082009/072010.012
WARRANTY: All goods manufactured by G&C Electronics cc T/A ET Systems carry a 12 month factory warranty from date of invoice. All goods
are warranted to be free of faulty components and manufacturing defects. Faulty goods will be repaired or replaced at the sole discretion of
ET Systems free of charge. This warranty is subject to the goods being returned to the premises of ET Systems. The carriage of goods is for the
customers account. This warranty is only valid if the correct installation and application of goods, as laid out in the applicable documentation
accompanying said goods, is adhered to. All warranty claims must be accompanied by the original invoice. All claims made by the end user
must be directed to their respective service provider/installer.
The following conditions will disqualify this product from the warranty as laid out above.
These conditions are non-negotiable.
•Any unauthorized non-manufacturer modifications to the product, components thereof.
•Variations to the installation technique as laid out here-in
•Incorrect application and use of the product.
The following are excluded or limited from the warranty as laid out above.
These conditions are non-negotiable.
•The battery carries a limited 6 month warranty
•The motor brushes
•Acceptable wear and tear.
9
