General information
1 General information
Copyright
All contents of this document are property of ETA
Heiztechnik GmbH and are protected by copyright.
Any reproduction, transfer to third parties or use for
other purposes is prohibited without written permission
from the owner.
Subject to technical changes
We reserve the right to make technical modifications
without notice. Printing and typesetting errors or
changes of any kind made in the interim are not cause
for claims. Individual configurations depicted or
described here are only available optionally. In the
event of contradictions between individual documents
regarding delivery scope, the information in our current
price list applies.
Software Description
The software version described in this documentation
corresponds to the version valid at the time of publica-
tion. The software version installed on your product
may differ from that described in this documentation.
A software update to a more recent version can
always be performed. With the appropriate au-
thorisation, the required files can be found at
"www.eta.co.at".
Explanation of symbols
Instructions and information
Layout of safety instructions
SIGNAL WORD!
Type and source of danger
Possible effects
• Measures for avoiding the danger
Types of safety instruction
CAUTION!
On non-compliance withthis safety instruction, there is
a risk of material damage.
WARNING!
On non-compliance withthis safety instruction, there is
a risk of physical injury.
DANGER!
On non-compliance with this safety instruction, there is
a risk of major physical injury.

Description of the configuration wizard
5
2 Description of the configuration wizard
Configuration with the wizard
Configuration with the wizard takes place in several
steps. These are described below:
1) Add the function blocks required for the installed
heating system components. Choose your settings
and options individually in each function block.
2) When you have added all the necessary function
blocks, set the individual connections between
"producers" and "consumers".
"Producers" are components that provide heat or
fuel. "Consumers" consume this heat or fuel.
3) Next, the terminal assignments of each function
block is displayed on the corresponding circuit
board. In this step, the heating system
components are electrically connected. You may
also adjust the terminal assignments during this
step.
4) Finally, the configuration is installed, and the
software rebooted.
After this, you can make customer-specific
adjustments to the heating system, such as: buffer
charging times, room temperatures for the heating
circuit, hot water temperatures, etc.
When you have completed these customer adap-
tations, save this configuration. It is saved in the
ETAtouch control system. You can additionally save it
on a USB stick.
The description below explains the general way
in which the configuration wizard works. Your
heating system's individual configuration depends on
the installed components, and can vary.
Starting the configuration assistant
In the system settings, increase the authorization
to [Service], and open the system configuration menu
with the [Systems configuration] button.
Fig. 2-1: System configuration menu
Start the configuration assistant with the [Starting
the assistant] button.
Function block overview
The [Possible function blocks] column shows the
function blocks available for selection, and the
[Selected function blocks] column shows the function
blocks that have already been added.
Fig. 2-2: Function block overview
1 Function blocks available for selection
2 Type and node number of circuit board
3 Add a function block
4 Function blocks already added
5 Next step of configuration
6 End configuration
7 Delete an added function block
8 Show the options of an added function block
Press the button to see the options and settings for
an added function block. With the button function
blocks that have already been added can be deleted.
Adding another function block is quick and uncompli-
cated. In this example, the [Heating circuit] function
block is used to explain the process. Select the
function block from the [Possible function blocks]
column, and then press the button.

6 www.eta.co.at
Description of the configuration wizard
A window opens showing the function block's settings.
Adjustments may be necessary, depending on the
installed heating system components.
Fig. 2-3: Function block settings
1 Possible selections
2 Display information
3 Show function block options
Press a row to select it. Press the button to see the
information. Press the [Options] button to view the
function block options.
Fig. 2-4: Function block options
1 Function block options
2 Show function block settings
3 Save options and settings
Select the required options, depending on your
installed heating system components, and save
with the [Accept] button.
The function block has been added and appears in the
overview screen in the [Selected function blocks]
column. Add further function blocks in the same way.
Continue the configuration by pressing the [Next]
button.
Connections overview screen
In this window, you can determine the individual
connections between producers and consumers.
Fig. 2-5: Connections overview screen
1 Overview of created connections
2 Possible producers
3 Possible consumers
4 Delete selected connection
5 Create a new connection
You can create a connection by pressing [New connec-
tion]. The choice of possible connections shown
depends on the previously selected function blocks,
options and settings:
• [Heating water]: For all connections between
producers and consumers that are connected via
the heating water.
• [SolarMedium]: For all solar heating system con-
nections.
• [Pellets]: For all pellet fuel system connections.
• [Woodchips]: For all wood
chip fuel system connections.
• [Ash]: For all de-ashing system connections.
• [SH-Twin]: For the connection between log boilers
and TWIN pellet burners.
• [Indv. room]: For all individual room control con-
nections.
Select the type of connection you require, then tap the
necessary producers and consumers to select them.
This connection then appears in the [Connections]
window.

Description of the configuration wizard
7
When you have set up all the necessary connections,
press [Next] to continue configuration.
Terminal allocation overview screen
The terminal allocations for the individual heating
system components are shown in this window.
Fig. 2-6: Terminal allocation overview screen
1 Overview of added function blocks
2 Terminal allocations of individual components of
the selected function block
All configured function blocks for the individual circuit
boards are listed in the [Selected function blocks]
window. When you select a function block, its assigned
terminal allocation is shown in the window below. In
this step, the individual components are connected to
the respective terminals on the circuit board.
Once all components have been connected, press the
[Next] button to continue configuration.
You can already change the terminal allocations
in this step. The next section explains how to
change the terminal allocation for the temperature
sensor of the hot water tank.
Changing terminal allocation
1. In the function block of the hot water tank, tap the
temperature sensor [Hot water tank] twice. A
window opens.
Fig. 2-7: Example: Changing terminal allocation
1 Current terminal allocation
2 Available terminals, the factory setting is
highlighted
3 Delete current terminal allocation
4 Allocate new terminal allocation
5 Close window
2. In the upper window, select the terminal and press
[Disconnect] to delete the current terminal
allocation.
3. After this, select a free terminal in the lower
window and allocate the new allocation by
pressing [Connect]. Finish by closing the window
with the [Close] button.
Installing a configuration
Finish by pressing [Apply] to install the configuration.
The configuration will then be adopted and the
software restarted.

8 www.eta.co.at
Changing the access level Checking outputs, changing terminal assignments
3 Checking outputs, changing terminal assignments
3.1 Changing the access level
Setting the [Service] access level
For setting some parameters, the [Service] access
level is required. To do this, open the system
preferences and tapthe[Authorisation] symbol.
A settings window appears. Enter the password "135"
and press [Accept the authorisation] to confirm.
3.2 Setting manual mode
Switching on an output manually
The terminal assignment of the individual components
of the selected function block are displayed in the
inputs and outputs menu, e.g. pumps, temperature
sensors, and mixers. In this menu, these can be
activated manually (manual mode), for example, to
check their function.
In the example below, the heating circuit pump of the
heating circuit is started manually.
The heating circuit pump is started manually
1. Increase the authorisation to [Service]. See
Chapter 3.1 "Changing the access level".
2. Select the heating circuit and change the inputs
and outputs in the menu by tapping on the
symbol, followed by the symbol. The overview
screen opens.
Fig. 3-1: Overview
3. In the heating circuit pump, tap on the symbol.
A settings window appears. With the [On] button,
the pump is turned on manually, and turned off by
pressing the [Off] button.
Fig. 3-2: Settings window
4. If the pump is switched on manually, the [On]
button will light up yellow to confirm. In addition,
the name of the function block is displayed in red.
Fig. 3-3: Manual mode is activated
In manual mode, the [Automatic] button appears. It
is used to switch off manual mode, and automatic
mode is again started by the ETAtouch control
system. You can close this setting window with the
arrow on the left side, even if manual mode is still
active.
After a period of 30 minutes the ETAtouch
control system automatically reverts all
manually switched on outputs back to automatic
mode.
In the same manner, the running direction of a mixer is
checked. See the example below.

Checking outputs, changing terminal assignments Modify terminal assignment
9
Running direction of the heating circuit mixing
valve
1. With the [Service] authorization, open the inputs
and outputs menu in the heating circuit function
block. On the heating circuit mixing valve, tap the
symbol. The current status and position is
displayed.
2. The mixer can be opened and closed with the
[Forward] and [Back] buttons. Pressing the [Stop]
button keeps it in its current position.
3.3 Modify terminal assignment
Modify terminal assignment
The terminal assignment of the individual components
of the selected function block are displayed in the
inputs and outputs menu, e.g. pumps, temperature
sensors, and mixers. In this menu, the terminal
assignment can be changed.
In the example below, the terminal assignment of the
heating circuit pump is changed.
Modify terminal assignment of the heating circuit
pump
1. Increase the authorisation to [Service]. See
Chapter 3.1 "Changing the access level".
2. Select the heating circuit and change the inputs
and outputs in the menu by tapping on the
symbol, followed by the symbol. The overview
screen opens.
Fig. 3-4: Overview
3. In the heating circuit pump, tap on the symbol.
The current terminal assignment is shown in the
upper area at [Current terminal assignment].
Fig. 3-5: Terminal allocation overview screen
The current allocation is erased with the button.
Next, select a free terminal from the [Available
terminals] list, and assign it using the button.
The changed allocation is displayed in the upper
area at [Current terminal assignment].

10 www.eta.co.at
Modify terminal assignment Checking outputs, changing terminal assignments
The factory terminal allocation is shown in the
[Available terminals] list with a yellow font
colour.
Fig. 3-6: Factory setting (yellow font)

Backing up and restoring a configuration
11
4 Backing up and restoring a configuration
Backup configuration
After you have made adjustments to satisfy customer
requirements, you should save the configuration. This
backup saves the configuration, parameter settings,
input and output terminal allocations, etc. – in other
words, all relevant data and settings in the ETAtouch
control system. This makes it possible to quickly
restore the original settings.
Backup configuration
1. In the system settings, increase the authoriza-
tion to [Service], and open the system configura-
tion menu with the [Systems configuration] button.
Fig. 4-1: System configuration menu
2. The backup is started by pressing the [Configura-
tion save] button. Once this is finished, a
message appears on the screen prompting an
additional backup to a USB stick. If you wish to do
this, insert the USB stick into the port on the boiler
and perform the backup.
Restoring the configuration
You can restore the heating system configuration at
any time. The configuration is restored either from a
configuration saved in the ETAtouch control system or
via a USB stick. The counter readings are not
overwritten by this.
Control systems in a wall mounted box are
supplied with a USB stick for backing up the con-
figuration. Leave this in the wall mounted box after you
have restored the configuration.
Restoring the configuration
1. In the system settings, increase the authoriza-
tion to [Service], and open the system configura-
tion menu with the [Systems configuration] button.
To restore a configuration, press the [Configuration
restore] button. Another menu appears:
Fig. 4-2: Restore menu
2. In the upper part of the screen, select the location
of the configuration you wish to restore. Then
select the required backup in the lower part of the
screen with the button.
If the configuration has been loaded from a USB
stick, you should additionally back it up in the
ETAtouch control system. To do this, perform the
backup again.

12 www.eta.co.at
Example with solar heating system Examples
5Examples
5.1 Example with solar heating
system
Hydraulic schematic

Examples Example with solar heating system
13
Circuit
board Function blocks Description
PE-C 0 Twin TWIN pellet burner
In the boiler settings, adjust the installation
side.
PE-C 0 Standard store Pellet discharge conveyor
Standard screw Standard conveyor with screw
Circuit
board Function blocks Description
SH-C 0 Boiler SH log boiler
TWIN pellet burner Intheboilersettings,adjusttheinstallationside
of the secondary engines.
SH-C 0 Sys System
Outside temperature sensor
Circuit
board Function blocks Description
GM-C 0 Buffer Buffer storage tank
Solar charging For solar charging
Temp. sensor at buffer middle
Start relief for log boiler
GM-C 0 HWT Hot water tank
Charging pump for HWT
Solar charging For solar charging
GM-C 0 Heating circuit External heating circuit as radiator heating
Heating circuit pump
Heating circuit mixing valve
Digital room sensor
GM-C 0 Heating circuit External heating circuit as underfloor heating
Heating circuit pump
Heating circuit mixing valve
Digital room sensor
GM-C 0 Solar panel Solar heating system
2 tanks + diverter valve For switching between buffer and hot water tank

14 www.eta.co.at
Example with solar heating system Examples
Connections
= Type [Heating water]
= Type [SolarMedium]
= Type [Pellets]
= Type [SH-Twin]
Producers Consumers
SH-C 0: Boiler: Flow GM-C 0: Buffer: .
GM-C 0: Buffer: HC/HWT GM-C 0: HC: .
GM-C 0: HC2: .
GM-C 0: HW: .
GM-C 0: Solar: Tank 1 bottom GM-C 0: Buffer: Solar bottom
GM-C 0: Solar: Tank 2 bottom / Tank 1 top GM-C 0: HW: Solar bottom
PE-C 0: Store: Pellets PE-C 0: Twin: Fuel
PE-C 0: Twin: Flow SH-C 0: Boiler: Twin

Examples Example with solar heating system
15

16 www.eta.co.at
Example with solar heating system and stratified charging module Examples
5.2 Example with solar heating
system and stratified charging
module
Hydraulic schematic
In this example, 2 GM-C circuit boards are
installed. The first of these is factory-installed in
the log boiler. The two heating circuits are to be
connected on this GM-C circuit board.
The second GM-C circuit board is located in the wall
mounted box supplied with the stratified charging
module for the buffer storage tank. The buffers, the
fresh water module and the solar heating system are
to be connected to this board.

Examples Example with solar heating system and stratified charging module
17
Circuit
board Function blocks Description
PE-C 0 Twin TWIN pellet burner
In the boiler settings, adjust the installation
side.
PE-C 0 Standard store Pellet discharge conveyor
Standard screw Standard conveyor with screw
Circuit
board Function blocks Description
SH-C 0 Boiler SH log boiler
TWIN pellet burner Intheboilersettings,adjusttheinstallationside
of the secondary engines.
SH-C 0 Sys System
Outside temperature sensor
Circuit
board Function blocks Description
GM-C 0 Heating circuit External heating circuit as radiator heating
Heating circuit pump
Heating circuit mixing valve
Digital room sensor
GM-C 0 Heating circuit External heating circuit as underfloor heating
Heating circuit pump
Heating circuit mixing valve
Digital room sensor
Circuit
board Function blocks Description
GM-C 1 Buffer Buffer with fresh water module and stratified
charging module
Temperature sensor for the fresh
water module (1 pump) For the fresh water module
Solar charging For solar charging by stratified charging module
... additional solar charging in buffer
middle Forstratifiedchargingofbufferbystratifiedcharging module
Temp. sensor at buffer middle
Start relief for log boiler
GM-C 1 FWM 1Pump Fresh water module
GM-C 1 Solar panel Solar heating system
Ext. heat exchanger For stratified charging module's heat exchanger
... with stratified charging valve For changeover between bottom and middle of
buffer

18 www.eta.co.at
Example with solar heating system and stratified charging module Examples
Connections
= Type [Heating water]
= Type [SolarMedium]
= Type [Pellets]
= Type [SH-Twin]
Producers Consumers
SH-C 0: Boiler: Flow GM-C 1: Buffer1.1: .
GM-C 1: Buffer1.1: HC/HWT GM-C 0: HC: .
GM-C 0: HC2: .
GM-C 1: Buffer1.1: FWM GM-C 1: FWM1.1: .
GM-C 1: Solar1.1: Tank 1 bottom GM-C 1: Buffer1.1: Solar bottom
GM-C 1: Solar1.1: Tank 2 bottom / Tank 1 top GM-C 1: Buffer1.1: Solar top
PE-C 0: Store: Pellets PE-C 0: Twin: Fuel
PE-C 0: Twin: Flow SH-C 0: Boiler: Twin

Examples Resuming commissioning
19
5.3 Resuming commissioning
Continue heating system commissioning
Continue to commission the heating system and
perform a function test of components such as pumps,
mixing valves, temperature sensors, etc.
Next, make customer-specific adjustments to the
control system such as hot water temperatures, buffer
charging time slots, heating time slots and room tem-
peratures...
The required parameters are listed in Chapter 6 "Con-
figuration parameter".
Making a backup after commissioning
Back up the configuration straight away after you have
adapted the heating system to suit the customer's re-
quirements. See Chapter 4 "Backing up and restoring
a configuration".

20 www.eta.co.at
[TWIN] function block Configuration parameter
6 Configuration parameter
6.1 [TWIN] function block
Parameters to be set
Set or check the following parameters.
Detailed descriptions of the parameters are provided
below.
Explanation of [Start lag]
This parameter is used to set the length of the delay in
operation of the pellet burner after the buffer has
demanded heat.
If there is still a demand from the buffer after this
period, then the pellet burner will begin operation.
Explanation of [MixValve runtime]
This parameter sets the running time for the mixing
valve actuator, the time needed to turn it from the
closed to the fully open position.
Set the running time according to the information
on the mixing valve actuator's type plate.
Explanation of [Start idle time]
This parameter is used to select the time after which
the TWIN pellet burner no longer performs de-ashing.
The log boiler's turbulators are also operated during
this de-ashing.
The duration of this idle time is set by the [Duration idle
time] parameters.
The time and duration are best set to match those
of the log boiler.
Explanation of [Duration idle time]
The [Duration idle time] parameter is used to select the
duration of the de-ashing idle time for TWIN pellet
burner.
The start time for the idle time is set with the [Start idle
time] parameter.
The idle time should be kept as short as possible.
If noise is not expected to be a nuisance, you
should reduce the value to 0 hours.
Explanation of [Empty ash box after]
This parameter adjusts the quantity of pellets used,
after which a reminder to empty the ash box is
displayed on the screen.
If the ash box is then only partially full, this quantity can
be increased. If you set the value to zero, the reminder
will no longer appear.
Boiler
Settings
Start lag
Return
Return riser valve
MixValve runtime
Ash removal
Start idle time
Duration idle time
Empty ash box after
