ETCR 001F User manual


CONTENT
Warning ................................................................................................... 1
ⅠIntroduction.......................................................................................... 2
ⅡElectrical symbol................................................................................ 3
Ⅲ Range................................................................................................. 3
Ⅳ Technical specifications.................................................................. 4
ⅤStructure ............................................................................................. 6
ⅥOperating Method ............................................................................ 7
1.Plug connection ..................................................................... 7
2.Switch...................................................................................... 7
3.Stall selection ......................................................................... 7
ⅦBattery replacement........................................................................ 7
Ⅷ Packing List ..................................................................................... 8

1
Warning
Thanks for your purchase of ETCR001F Flexible coil current sensor
(Integrator). For better use of the product, please make sure:
---to read this user manual in details.
---to abide by the safety regulations and precautions strictly.
In any case, use this sensor should pay special attention to safety.
Pay attention to words and symbols stick on the panel.
Keep the pliers clean, maintenance regularly.
Stop using the sensor when there is a rupture or break.
The operator must get strict training and the relevant certification.
Please don’t keep or store the sensor in the spot with high-temperature and
moisture, or condensation, and under direct daylight radiation for a long
time.
For the sensors that need battery power supply, please remove the battery
if you expect not to use the sensor for a long time, and take note of the
polarity when replace the battery.
Replace battery in time when the battery voltage is low.
In case of explosion, please don’t remove or replace the battery in
dangerous places.
For the sensors that need external power supply, please first confirm the
polarity of power supply.
This sensor is only to be used, disassembled, and repaired by qualified
personnel with authorization.
When it may cause hazard by continuous use for the reason of the sensor
itself, it shall immediately stop using it and deposit it at once, leaving it for
disposal by authorized agency.
“ ” in the manual is the safety warning sign, the contents of this manual
must be followed for safe operation.
“ ” and other safety signs, the contents of this manual must be followed
for safe operation.

2
ⅠIntroduction
ETCR001F Flexible coil current sensor (Integrator), Rockwell coil Current
Sensor, using advanced Roche technology, is a non-ferromagnetic material in
the uniform winding of the coil, no hysteresis effect, almost zero phase error,
non-magnetic saturation phenomenon, high linearity. The flexible coil is the
derivative of the current to time. The integrator integrates the output voltage
signal (0 ~ 1V), realizes the measured current and outputs the complete signal
waveform. The measuring current range from 0.1A to tens of thousands
amperes. Mainly used for current, high harmonic current (up to 400 times),
complex waveform current, transient impact current, phase, power, power,
power factor detection. Equipped with integrator can be more easily
integrated into other test equipment, such as power quality analyzer, harmonic
analyzer, power parameter recorder, phase detection analyzer, industrial
control devices, oscilloscopes, high-precision digital multimeter, transient
Impact recorder, distributed measurement system, protection system.
ETCR001F Flexible coil current sensor (Integrator), Coil part without any
exposed metal conductor, non-contact measurement, safe and reliable; Its
small size, light weight, beautiful appearance, soft and flexible, suitable for
narrow environments and cable-intensive places; Wide measurement range,
high accuracy, high reliability, response frequency bandwidth (0.1Hz-1MHz),
the user can customize the length of the coil. Widely used in electricity,
communications, meteorology, railways, oil fields, construction, measurement,
scientific research and teaching units, industrial and mining enterprises and
other fields. Particularly suitable for relay protection, SCR rectifier, frequency
control, semiconductor switches, power electronic conversion equipment,

3
welding and other serious signal distortion of the industrial environment.
ⅡElectrical symbol
Extremely dangerous! Operators shall strictly observe safety
rules; otherwise there would be dangers of electric shock to
cause personal injuries or casualties.
Dangerous! Operators shall strictly observe safety rules;
otherwise there would be dangers of electric shock to cause
personal injuries or casualties.
Warning! Operators shall strictly observe safety rules;
otherwise personal injuries or equipment damages might be
caused.
Double insulation
AC
DC
Ⅲ Range
Range (AC) Output Voltage Coil size
0~300A/3000A 1V/300A,1V/3000A φ100mm
φ200mm
φ300mm
0~6000A 1V/6000A
0~10000A 1V/10000A
Note: Users can choose the range and coil size according to actual needs.

4
Ⅳ Technical specifications
Function
AC current, high harmonic current, complex
waveform current, transient inrush current,
starting current, phase, power, power, power
factor detection
Coil thickness φ7.5mm(Suitable for narrow environments
and cable-intensive places)
power supply 6F22 9VDC Zinc-manganese dry batteries
(external power supply)
Coil length 315mm /650mm/1000mm(Optional)
Coil diameter φ100mm /φ200mm/φ300mm(Optional)
Range AC 300A/3000A/6000A/10000A(Optional)
Signal output AC 0~1V
Resolution 0.1A/1A/2A/3A
Accuracy ±1%FS (50Hz/60Hz;23℃±2℃,Below 70%RH,
the wire is in the center of the coil)
Phase error ≤1°(50Hz/60Hz;23℃±2℃)
Output
Interface 3.5mmAudio frequency plug/BNC plug
(Optional)
Output cable
length 2m
Electric field
interference
No hysteresis effect, no external electric field
interference
Cable position The cable in the center of the coil and the
position error affects ≤±0.5% FS
Current
frequency 45Hz~70Hz (Measured current frequency)
Response
frequency 0.1Hz~1MHz
Line voltage Below AC 600V
Weight 315g/330g/350g(φ100mm/φ200mm/φ300mm)
Integrator size 103mm×65mm×26mm

5
Working
temperature
and humidity -20℃~50℃; Below 80%rh
Storage
temperature
and humidity -10℃~60℃; Below 70%rh
Insulation AC 2000V/rms( both end of the unlocked coil)
Safety
regulations
IEC1010-1, IEC1010-2-032, Pollution degree
2, CAT Ⅲ600V

6
ⅤStructure
1. Integrator signal output
2. Integrator signal ground (shorted shielded)
3. Shielded ground
4. The integrator signal outputs (audio plug)
5. Integrator power indicator
6. Integrator battery voltage low indicator light
7. Power / gear switch
8. Integrator
9. Flexible coil interface
10. Flexible coil
11. Lock (front and rear rotation can lock or open the coil)

7
ⅥOperating Method
Before use, carefully check whether all parts
of the sensor are damaged, there is no
damage to use
Install the battery by manual
1. Plug connection
Put the Audio plug insert to the integrator’s input jack.
2. Switch
Power / gear switch to the right to start the boot, turn off at
OFF, after the boot device power indicator light
3. Stall selection
Optional (AC) Switch position
left intermediate right
0~300A/3000A OFF 1V/300A 1V/3000A
0~6000A OFF 1V/6000A
0~10000A OFF 1V/10000A
Description: If 1V / 300A is measured AC300A current
corresponds to the output AC1V voltage. 6000A /
10000A only one stalls, switch to the middle or right can
be
ⅦBattery replacement
Warning! The battery cover is not covered
when the test is forbidden, otherwise there
is a danger.
Note the polarity of the battery, otherwise
damage the meter.
Can not mix old and new batteries
1. When the battery voltage is lower than 6.8V (± 0.2V),
the battery voltage indicator light is on, indicating that
the battery is low, replace the battery.
2. Make sure the device is in the off state, loosen the
battery cover screws, open the battery cover, replace

8
the battery with a new pass, pay special attention to
the battery specifications polarity, cover the battery
cover, tighten the two screws.
3. Dial the key to the middle or right to check whether the
instrument can boot normally, if not boot, please press
the second step to re-operation.
Ⅷ Packing List
Integrator 1pcs
Flexible coil 1pcs
Box / user manual / warranty card /
certificate
1set


2
Manufactured by
ETCR Electronic Technology Company
Address: F-3F, No.4 Pengshang Zhifu Road, Jiahe, Baiyun
District, Guangzhou, Guangdong, China
Post Code: 510440
Tel: (86-20)62199556
Fax: (86-20)61100822
Website: www.etcr.cc
