Etek Navigation AU-3C-GSM User manual

Dual Band Antenna Series
AU-3C-GSM
User’sManual
VersionA
May 11 2005
© ETEK Navigation, Inc.
E
ET TE EK K N NA AV VI IG GA AT TI IO ON N, ,I IN NC C. .
10F NO. 105 Xicheng Rd., Banqiao City,
Taipei County 220, Taiwan (R.O.C.).
TEL: [phone]
FAX: [phone]
www.etek.com.tw

2
Content
CHAPTER 1 OVERVIEW..................................................................................................3
1.1 PACKAGE CONTENT..................................................................................................... 3
CHAPTER 2 SPECIFICATION..........................................................................................4
CHAPTER 3 WARRANTY.................................................................................................5

3
Chapter 1 Overview
Acombination of both GPS and GSM antennas that is designed mainly to simplify
the need for an AVL or Fleet Management antenna system
This AU-3C-GSM, amember of our mobile antenna series
coming up with dual-band features, is designed to simplify the need
for an AVL or Fleet Management antenna systems. The
combination of a high gain GPS antenna and alow profile and covert
GSM antenna is highly ideal for those applications that requires
durability, small in size, covert installation and ruggedized
construction, such as covering vehicle roof and trunk lid interior deck
or dashboard.
=======================================================
Low Noise Figure/ Fully Weatherproof/ Ultra-high Sensitivity
/Compact Construction/ Excellent Temperature Stability
=======================================================
1.1 Package Content
1. AU-3C-GSM Body (including a
pair of dual-band cables) built in
with a dual-band antenna
2. User Manual
Dual-Band Antenna Series
MODEL: AU-3C-GSM

4
Chapter 2 Specification
SPECIFICATIONS
GPSAntenna GSMAntenna
Features High performance GPS patch
antenna with state-of-the-art low
noise amplifier Dual band GSM 900/1800 MHz
Size 64.5mm(D) x 14mm(H)
Frequency 1575.42 MHz 880~960 & 1710~1880 MHz
Polarization RHCP (right hand circular
polarization)
--
Gain 26 dB typically 1.7 dBi
Noise Figure 1.2 max. -------
Attenuation20dB min. @ F0+/-50MHz ------
Band Width 10 MHz 70 MHz for frequency of 890~960 MHz
170 MHz for frequency of 1710~1880 MHz
VSWR
Impedance 50 ohm 50 ohm
Power Supply Power Consumption: 2.7~5.5
VDC / 13 mA
Power Handling Capacity: 10 W
Cable &
Connector
3m RG-174 FME Connector 3m RG-174 SMA Connector
Operating
Temperature
-40oC ~+85oC-40oC ~+85oC
Storage
Temperature
-45oC ~+100oC-45oC ~+100oC
Welcome custom design for AMPS frequencies!

5
Chapter 3 WARRANTY
LIMITED WARRANTY
ETEK
NAVIGATION, INC. expressly warrants that for a period of one (1) year from the date of
purchase. Our accessories will be free of defects in material (parts) and workmanship (labor). Within the
warranty period, a unit will be tested, repaired, or replaced at our option at no charge.
If your unit is out warranty, we will quote repair charges necessary to bring your unit up to factory
standards.
THIS WARRANTY APPLIES ONLY TO ORIGINAL PURCHASE
Any unit under warranty shou
ld be shipped prepaid to our factory. Warranty replacements will take
approximately ninety (90) days.
WARRANTY EXCLUSION
THE FOREGOING EXPRESS WARRANTY IS MADE IN LIEU OF ALL OTHER PRODUCT
WARRANTIES, EXPRESSED AND IMPLIED, INCLUDING MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE WHICH ARE SPECIFICALLY DISCLAIMED. The
express warranty will not apply to defects or damage due to accidents, neglect, misuse, alternations,
operator error, or failure to properly maintain, clean or repair products.
LIMIT OF LIABILITY
In no event will ETEK
Navigation, Inc. or any seller will be responsible or liable for any injury, loss or
damage, direct or
consequential, arising out of the use or the inability to use the product. Before using,
users shall determine in the suitability
of the product for their intended use, and users assume all risk and
liability whatsoever in connection therewith.
PURCHASER’S DUTIES
The purchaser must return the unit postpaid, with proof of the date of original purchase with the return
address to:
ETEK NAVIGATION, INC.
10F, No. 105, Xicheng Rd., Banqiao City,
Taipei County 220, Taiwan (R.O.C.).
TEL: [phone], FAX: [phone]
www.etek.com.tw
