ETNA EWM247DWIT/E01 User manual

Instructions for Use
Washing machine

452511
Thank you for your confidence in purchasing our washing machine, and congratulations on the
excellent choice.
Your new washing machine meets the requirements of modern treatment of laundry. It is rational in
the consumption of energy, water and washing agents.
Our appliances are friendly to the environment. Some of the materials may be recycled, others
deposited or decomposed. To avoid pollution of environment, once your appliance is no longer
useful, take it to your local authorized waste appliance dealer.
The appliance is intended exclusively for use in households. If the appliance is used for
professional purposes, for profit, or for purposes beyond regular use in a household, or if appliance
is used by a person who is not a consumer, the warranty period equals the shortest warranty period
possible as stipulated by the relevant legislation.
Description of washing machine ..................................3
Cautions ..........................................................................4
Installation and connection...........................................5
Operation.........................................................................8
Tips for washing and energy saving ..........................15
Cleaning and maintenance..........................................16
Troubleshooting ........................................................... 18
Tables ............................................................................22
2

452511
1. Front panel
2. Detergent dispenser
3. Door
4. Filter lid
5. Adjustable legs
6. Water outlet hose
7. Water inlet hose
8. Mains power cable
• Max. load: 7 kg /6 kg / 5,5 kg
Dimensions (w x d x h):
600 mm x 600 mm x 850 mm
Depth with door open: 105 cm
Weight (net): 72 kg
Nominal voltage: 230 V, 50 Hz
Rated power: 2000 W
Power socket: (230 V, 50 Hz, 10 A)
Water pressure: min. 0,05 MPa, max. 0,8 MPa
Fuse: 10 A
• Max. load: 5 kg / 4,5 kg
Dimensions (w x d x h):
600 mm x 440 mm x 850 mm
Depth with door open: 88 cm
Weight (net): 61 kg
Nominal voltage: 230 V, 50 Hz
Rated power: 2000 W
Power socket: (230 V, 50 Hz, 10 A)
Water pressure: min. 0,05 MPa, max. 0,8 MPa
Fuse: 10 A
Rating plate with basic information is located above the opening of
the machine.
3
Description of washing machine
Technical information
(depending on model)

452511
• Be sure to remove transport brackets prior first use of the appliance. Attempted operation of the
blocked machine may result in irreparable damage which is not covered by the manufacturer’s
warranty!
• When connecting your washing machine to water supply, be sure to use brand new water inlet
hose and appropriate sealing gaskets (attached).
• Do not locate the machine in a room with temperature below 0°C. Parts of the machine may be
damaged if frozen.
• Install the washing machine in a perfectly horizontal position, on solid flat concrete floor.
• Follow the instructions for correct installation and water and mains connections.
• Never immerse the end of the drain hose into the draining water.
• Prior starting the washing cycle lock the door by pressing them at the designed spot.
• Door may not be open during the washing cycle.
• We recommend running the self-cleaning program before the first wash in order to remove any
impurities from the washing machine drum (see chapter on” Selecting additional functions”).
• Use only detergents and softeners for machine wash. Manufacturer may not assume
responsibility for any damage and eventual discoloring of gaskets and plastic components as a
consequence of incorrect use of bleach and/or coloring agents.
• For removal of lime residues use such agents with added anti-corrosion agents. Follow the
manufacturer’s instructions. Finish the lime removal by multiple rinsing to remove completely
eventual acid residues.
• Never use detergents containing solvents, since there is a danger of creating toxic gasses which
may damage the machine and result in ignition or explosion.
• This product does not release silver ions during the washing cycle.
• Upon completion of washing operation close the water faucet.
• Before any transport block the machine by inserting at least one transport blocking rod. Prior this
operation disconnect the appliance from the mains power!
• Rating plate with basic information is located above the opening of the machine.
• The warranty shall not apply to consumables (bulbs), minor discoloration or deviations of color,
increased noise level as a consequence of appliance age, which does not affect appliance
functionality, and aesthetical deficiencies which do not affect appliance functionality or safety.
• The appliance is manufactured in compliance with all relevant safety standards; however, it is
recommended that persons with impaired physical, motional, or mental abilities, or persons with
inadequate experience and knowledge, do not use the appliance without due supervision. The
same recommendation applies to minors using the appliance.
Before connecting the appliance read these instructions carefully. Repairing the failure
arising from inappropriate connections or use of the appliance is not covered by the
guarantee.
The symbol on the product or on its packaging indicates that this product may not
be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more
detailed information about recycling of this product, please contact your local city
office, your household waste disposal service or the shop where you purchased the
product.
4
Cautions

452511
In removing the wrapping be careful not to damage the
appliance with a sharp object.
Before connecting the appliance, let it warm up to room
temperature (wait for two hours).
• Our appliances are packed in environmentally friendly
materials which may be recycled, deposited or decomposed
without any threat to the environment.
• To this end all wrappings are marked accordingly.
• Move the pipes.
• Loosen screws (A) at the rear of the machine (Fig. 1).
• Remove the brackets (B) (Fig. 1) and slide them into the
groove on the blocking rod (Fig. 2) - the right one should be
turned around.
• Use the brackets to rotate blocking rods for 90° and pull them
out.
• Close the openings with attached plastic pegs.
Save transport brackets for eventual later use.
Fig. 1 Fig. 2
Be sure to remove the transport brackets prior first use,
otherwise the appliance may be permanently damaged.
In such cases the warranty conditions are void.
• Put the appliance in horizontal position by turning the
adjustable legs. The legs are adjustable up to +/- 1 cm.
After the adjustment tighten the nuts firmly (A) - towards
the bottom of the machine!
Vibrations, moving of the appliance and loud operation
due to incorrect setting of the adjustable feet shall not
be covered by this warranty.
The appliance should be placed on a surface with
concrete base; the surface should be dry and clean in
order to prevent slipping. The adjustable feet should
also be cleaned before installation.
Package removal
Removal of transport
brackets
Leveling the appliance
5
Installation and connection

452511
• If you have a tumble dryer of the same dimensions, you can
place it on top of the washing machine.
To ensure correct operation of the appliance, water
pressure inlet must be between 0,05 and 0,8 MPa.
Minimum water pressure can be established by measuring
the quantity of poured out water. 3 litres of water must be
poured out from completely opened tap in 15 seconds.
• Take the water inlet hose from the drum and attach the inlet hose
angle extension (1) to the washing machine by screwing it onto
the provided thread (certain models only).
• Insert the gasket with a filter net into the straight inlet hose
attachment nut (2) and screw the nut onto the water tap. (With
some models, the gasket with filter net is already fitted and any
additional fitting into the nut on the straight attachment is not
required).
• If your model has connections for both hot and cold water, then
connect one hose to the cold water supply (blue wing nut or blue
mark on the hose) and the other one to the hot water supply (red
wing nut or red mark on the hose), as indicated on the back wall
of the appliance (letters C and H) (C - cold; H – hot).
The inlet hose should be tightened manually, firmly
enough to prevent any leaks. After tightening the hose,
check for any leaks.
Use of pliers, wrenches, or other similar tools is not
allowed when installing the hose, as these tools can
damage the nut thread.
Partial Aqua-stop (water stop system)
In case of damage on the interior pipe, leaking is prevented by
automatic closing system which stops water inlet to the machine. In
such cases display A turns red.
Inlet pipe must be replaced.
Complete Aqua-stop (certain models only)
In case of damage on the interior pipe, leaking is prevented by
automatic closing system which stops water inlet to the machine.
Security system also detects whether there is any water leakage
within the interior of the machine. In such cases washing is
suspended, machine switches on the pump and signals error.
Do not immerse the Aqua-stop system inlet pipe into the
water, because it contains the electric valve!
Water inlet connection
6

452511
• Fix the outlet hose to run into the sink or the bathtub, or
connect it directly to the wall drain outlet (diameter min. 4 cm).
• Wall drain must be installed properly and must enable
occasional cleaning.
• Fasten the outlet hose support with a piece of rope led through
the hose elbow, to prevent the hose from slipping to the floor.
The end of outlet hose should be placed between minimum 60
cm and maximum 100 cm above the floor level.
• Plug the mains power cable to the wall mains socket.
• Required voltage and other information are written on the
rating plate above the door opening of the machine.
The wall socket must be accessible at all times and
must be equipped with an earth lead (in accordance
with the local safety regulations).
The permanent connection must be fitted by an
authorized personnel only.
Damaged mains power cable may be replaced only by
the producer or his authorized personnel.
Never plug the appliance into the electric shaver socket
or hair dryer socket.
Water outlet connection
Connect the appliance to
the mains supply
7

452511
• Open the door of the machine.
• Load the laundry into the drum.
• Close the door.
• Open the water inlet faucet.
• Select the desired program.
• Add washing and treatment agents (detergent and softener).
• Start the operation by pushing the START knob (E).
Washing procedure
A - program selector knob
B - key - selection of spinning speed (rpm)
/ stop pump
C - short program (Quick wash)
D - higher water level (Water plus)
E - START / PAUSE button
F - delayed start
G - display
Signal LED’s:
- washing program stages
• wash + pre-wash
• rinse
• spin
8
Program selector Basic programs Partial programs
Cotton
Pre-wash
Quick program
20°-Tap water + (ECO)
Softening
(Conditioner)
Synthetics
Easy iron Pumping water (Drain)
Delicate Spinning
Wool
Mix
Operation

452511
- Open the door of the machine.
Door is opened by pulling the handle (lever) on the right hand
side of the door towards you.
- Sort the laundry by the type of fabrics.
Do the buttons and zippers, tie the strings and pull out
the pockets.
Very delicate laundry should be put in a special protective
sack.
It is suggested to load the drum with items of different
sizes.
Pay attention to the labels on the clothes, indicating
the recommending washing mode (see table of textile
treatment symbols on the last page of these instructions).
- Load the laundry into the drum.
Check that the drum is empty.
- Close the door of the appliance.
- Open the water inlet faucet.
- Push the ON/OFF button and select washing program.
Program is selected by turning the program selector (A) from
the “0” position to the desired washing program. LED next to
the START key starts flashing. Duration of the selected program
is indicated on the display. The program selector (A) may be
turned in both directions, and the appropriate program selected
according to the type of laundry washed and the required
washing temperature (see Program Chart for help). You may
select basic or partial programs.
Select additional functions by pressing their relevant knobs (E).
- Selection of basic programs ( , , , , )
Basic programs represent integral programs containing all washing
stages, including softening and spinning (see Program Chart). They
are selected by turning the program selector (A) to the appropriate
position.
Cotton: whites/colored
Normally stained cotton and flax bed linen and underwear, table
cloth, bathroom towels, top garments, etc.
To wash heavily soiled laundry that will not discolor, use the program
with a prewash .
For smaller loads (non-delicate cotton, linen, synthetic, and mixed
fabric) and smaller quantities of soiled laundry (laundry refreshment,
laundry wet with perspiration, etc.), we recommend the use of the
quick program. To activate the program, turn the (A) button
to the setting “Cotton 30°C” and then press the “Short Program (C)”
key. You will save both energy and time.
Washing machine
operation
9

452511
The Cotton 15° program is intended for washing less soiled laundry,
using detergents (washing gels) specially designed for washing at
such temperatures.
Using this program will save you both time and power as water
heater will only be engaged if the water inlet temperature is lower
than 15°C.
Synthetics
Normally stained shirts, blouses and other polyester and polyamide
garments, or a mixture of these fabrics with cotton.
If you wish the laundry not to be excessively creased at the end of
washing, use easy ironing program .
Delicate
This is a program for delicate fabrics (dresses, skirts, blouses) and
curtains.
Wool
Special, delicate program for washing woolen products indicated
as appropriate for machine washing, as well as for very delicate
products on which hand washing is indicated as appropriate.
Mix
Special program for washing normally stained colored laundry made
from various resistant fabrics at 40°C.
- Selection of additional function (, , , )
Additional functions alter the basic washing cycle procedure.
Particular function is switched on by pressing the relevant knob.
The selection is confirmed when the LED next to the key lights up. If
certain function is not available for the selected program, signal LED
will not illuminate.
The function is switched off by pressing the same button again -
signal LED goes off.
Select the particular function after the selection of the
basic program, but prior pressing the START button (E).
Display (G)
After setting the basic and partial programs and pressing the START
(E) button, washing time is indicated on the display. After the end of
washing, the display reads END.
During washing, the remaining washing time is indicated in hours
and minutes.
If no program is selected and started and no other action is taken
within five minutes after turning on the machine, the display will be
automatically turned off to save energy.
10

452511
The display will turn on again when you rotate the program selector
dial or press any button.
If no action is taken after the end of the program, the display will also
turn off after five minutes.
Washing stage signal lamps and the START/PAUSE key flash
intermittently.
Low water temperature, low network voltage, and
smaller loads of laundry may extend the washing time;
the time indicated on the display is constantly adjusted
to account for such conditions.
LOW POWER MODE
P o = weighted power in ‘off mode’ [W] 0,10
P l = weighted power in the ‘left on mode’ [W] 0,65
T l = time in ‘left on mode’ [min] 10,0
Delayed start (F)
Press the (F) button; the time “00:00” will be indicated on the
display (G). Each time the button is pressed again, the time on
the display will be increased by one hour (maximum delay is 23
hours). After the time has been selected, the LED over the button
lights up (and remains lit). If no other button is pressed in the
following 5 seconds, program duration is indicated on the display.
The function is activated when the START (E) button is pressed.
Time is decreased by minutes. When the count-down is over, the
washing program starts automatically.
• To interrupt or change the delayed start setting, press the
START / PAUSE button (E).
• To change the delay time, select a new time by pressing the
(F) button. Press START to resume the count-down. To quickly
interrupt the delayed start, press the (F) button and hold it for
three seconds. Press the START button to resume the program.
Spinning speed (rpm) / Pump stop
By pressing the (B) button, you can decrease the spinning speed
(in rounds per minute) to “0”. After pressing the button for the
first time, the optimum rpm setting for the selected program is
indicated. By each subsequent press on the button, the spinning
speed is decreased. The last selection is “pump stop”, which
means that laundry remains soaked in the last rinsing water. Use
this function to prevent creasing when you are not able to take
the laundry out of the washing machine immediately after the
washing cycle is over. This function is particularly appropriate for
synthetics and delicate laundry . Use of this function is not
recommended with wool .
11

452511
Short program (Quick wash) (selection with a button (C))
• energy-saving program
• appropriate for washing lightly soiled laundry or smaller
quantities of clothes
• reduces washing and rinsing time
• reduces water consumption (with some programs)
• by pressing the key quick program on the program Cotton
30°C, activate the program Cotton 30°C-quick
.
Higher water level (Water plus) (selection with a button (D))
• Improves rinsing, which is particularly important if your skin is
oversensitive to detergents.
• For washing heavily soiled laundry.
- Selection of partial programs ( , , )
These are independent programs and may be used when you do
not need the entire washing program. In case you would like to
use more additional programs in a sequence, you must turn off
the appliance prior any new program selection (turn the program
selector (A) to “0” for at least one second).
Softening (Conditioning)
The program is intended for softening, starching, or impregnating
clean clothes.
Softening program can also be used as an independent or
additional rinse program; in this case, however, do not add any
fabric softener or conditioner.
The program is completed by a spinning cycle at 1,000 rpm.
Spinning speed can be decreased.
Pumping the water out (Draining)
Use it when the washing program was interrupted or if pump stop
function was engaged, and you only wish to pump the water out of
the drum, without spinning.
Spinning
Aggressive spinning for non-delicate laundry at high spin RMP.
Spinning rpm can be decreased by pressing the ( ) key - selection
of spinning speed (rpm).
12

452511
- Adding washing and softening agents
(see Tips for washing and energy saving)
• pre-wash compartment
• main wash compartment
• softener compartment
If you do not apply the program which includes the pre-wash
feature, you may add washing detergent directly into the drum,
using the measuring vessel.
When adding softener, be careful to fill the dispenser only
up to the marked level.
Be sure to close the detergent dispenser when opening/
closing the appliance door.
• Push the START button (E). The machine starts operating after
a few seconds. LED indicating the current washing stage lights
up. If the door is not closed after the machine is switched on, the
START LED starts flashing again after a few seconds.
When you close the door, the machine initiates the selected
program. Time remaining until the end of the washing program is
indicated on the display (for LED).
• As each washing stage is completed the relevant washing stage
indicator LED goes off and the subsequent one goes on.
• In case you would like to alter the washing program after the
initiated washing operation, turn the program selector for one
second to the position “0”, followed by the selection of a new
program. Switching the machine off deletes any previously
selected additional functions(i.e. Pump stop), so they have to be
reactivated.
Upon switching OFF, all additional pre-selected functions
are deleted; therefore they must be switched-ON again.
- End of washing program
The end of washing program is signalized by flashing washing
progress LEDs. The message “End” is indicated on the display.
• Washing machine door can be opened.
• Take the laundry out of the drum and remove any remaining
particles or foreign bodies from the door seal.
• Leave the door ajar to let the machine dry.
• Close the water inlet tap.
• Turn off the washing machine by rotating the program selector
knob (A) to position “0”.
Start the operation
13

452511
• After the end of washing program, power supply should be turned
off by pulling the mains cord plug out of the outlet.
• By the user
Selecting PUMP STOP function
If the setting pump stop was selected, the program stops at the
last rinsing cycle and the symbol for pump stop is indicated on
the display. LED next to the START key is flashing. The program
can be completed by pressing the START (E) button; in this case,
the program will finish with a spinning cycle, as defined by the
program. Spinning rpm can be decreased by pressing the ( ) key -
selection of spinning speed (rpm).
The program can also be changed by rotating the program selector
knob (A) to “0” and choosing either spinning or only pumping out the
water between additional programs or cycles.
Manual cancellation
The program is cancelled if the program selector knob (A) is rotated
to position “0”. If there is water in the machine, select one of the
additional programs (pumping , spinning ) to empty the drum
and complete the program.
PAUSE knob
By pressing the PAUSE knob (E) program may be suspended
at any time. After certain time you may open the door if there is
no water in the drum, otherwise this is not possible. Program is
continued by pressing the START knob (E).
• Failures
Program is suspended in case a failure occurs. These are
indicated by the flashing LED-s and sound signal is heard (see cf.
Failures).
• Power failure
At electric cutout the program is interrupted, however, after the
power supply has been re-established, the program operation
automatically proceeds.
If a power failure occurs when the drum is still full of
water, be careful not to open the door before you pump
the water out.
Interruptions
14

452511
• Before washing sort out the laundry according to the type, degree of dirtiness and color resistance.
• Prior selecting the washing program consult the sewn tab with information on a particular piece of
laundry (see Maintenance Chart on the last page).
• Wash separately the new colored textile products for the first time.
• Wash heavily soiled laundry in small quantities and add more detergent.
• Treat stubborn stains with special stain remover, it will save energy.
• With lightly stained laundry select washing program without pre-wash, use short program and
select lower washing temperature. This way you may save up to 50% of energy.
• Avoid washing too little quantities of laundry because of energy saving and for better performances
of the appliance.
• The largest allowed quantity of dry laundry is indicated in the Program chart.
• Before washing empty the pockets, close zip fasteners, and remove any metal fasteners or badges
that might clog the drain or damage the laundry or drum interior.
• Loosen the stacked laundry prior inserting it into the drum.
• Use only detergents for machine wash.
• Add powder or liquid detergents according to the manufacturer’s instructions.
• For different washing temperatures and selected washing programs, please note the
recommendations provided by detergent manufacturers.
• If water hardness in your pipeline exceeds 14°dH, we recommend using water softeners. Any
damage to the heater due to failure to use a water conditioning agent shall not be covered by this
warranty.
• Chlorine-based whitening agents are not recommended, as it can damage the heater.
• To improve your washing results we recommend 2/3 load on Cotton programs.
• If you do not apply the program which includes the pre-wash
feature, you may add washing detergent directly into the drum.
• If you use thick liquid softener it is recommended to dilute
it with water, to prevent clogging of dispenser compartment
ducts.
• Washing machine is equipped with the dispenser partition
gate, so you may pour liquid detergent also into the central
compartment. If you use powder detergent the gate is lifted up,
and in case of liquid detergent it is slid down.
• Liquid detergents are intended for main wash only, without
pre-wash.
• Insert particularly delicate linen (stockings, delicate female
underwear, etc.) into the special bag.
Hardness
scale
Degree of hardness
°dH(°N) m mol/l °fH(°F) p.p.m.
1 - Soft < 8,4 < 1,5 < 15 < 150
2 - Medium 8,4 - 14 1,5 - 2,5 15 - 25 150 - 250
3 - Hard > 14 > 2,5 > 25 > 250
In case of hard water add detergent according to the Chart for
degree and add appropriate quantity of water softener (see
manufacturer’s instructions).
15
Tips for washing and energy saving

452511
• High spin RPM leave less moisture in laundry which dries out
much quicker in the tumble dryer, thereby saving energy.
Do not put clods of detergent into the soap dispenser
as the tube in the washing machine may clog.
Disconnect the washing machine from the mains
before cleaning!
• The casing should be cleaned with soft cloth and mild
detergent.
• The interior of the drum and the door gasket is cleaned by
washing at 60°C without laundry and adding half quantity of
detergent.
• Frequent, or predominant, washing at low temperatures, using
liquid detergents, may result in development of bacteria which
causes odor in the washing machine.
To prevent this, we recommend running the auto-clean
program occasionally (see chapter “OPERATION / selecting
additional functions”).
• If necessary, clean the detergent dispenser. Pull it out from its
casing completely by pressing the flap (see Fig.).
• If necessary, clean the cover of the bung under the running
water.
16
Cleaning and maintenance

452511
• Wash it under running water using a brush, and dry it. Remove
any leftover dried detergent from the bottom of the casing.
• Clean the entire rinsing area of the washing machine with a
brush, especially the nozzles on the upper side of the rinsing
chamber.
• Clean frequently the water inlet hose screen under running
water.
• After each wash wipe the door rubber gasket. This will prolong
its useful life.
• Open the filter lid using flat screwdriver or similar tool.
• Filter needs occasional cleaning, especially following heavily
shaggy or old laundry.
17

452511
Washing machine controls the operation of particular functions during washing. If irregularities
are detected, the fault is signaled by displaying a message (Fx) on the display, and by rhythmical
flashing of the LEDs. The machine signals the fault as soon as it is detected, and the program
progress is paused. If the fault is in the heating system, the machine completes the washing
program, but without the heating function.
If the fault is signaled during washing machine operation, the error code and remaining washing
time are indicated alternately on the display.
The fault is indicated until the washing machine is turned off.
Failures:
2 - Two flashes: door is not correctly closed
3 - Three flashes: inappropriate water intake
7 - Seven flashes: inappropriate water outlet.
In these cases, you will be able to remedy the failure by yourself (See Troubleshooting table).
1 - One flash: temperature sensor failure
4 - Four flashes: spinning sensor failure
5 - Five flashes: motor failure
6 - Six flashes: Heater failure
In these cases, turn off the machine, then turn it back on and repeat the program. If the failure
reoccurs, contact your nearest authorized service center. The LEDs will continue to flash until the
machine is turned off.
• Carefully turn the filter insert in anticlockwise direction and let
the water slowly drain; then remove the filter and clean it under
running water.
• Insert the filter back as shown on the picture, and tighten by
turning it in clockwise direction. To ensure good sealing the
gasket surface (A) must be dirt free.
18
Troubleshooting

452511
Various interferences from the environment (e.g. electric devices) may also cause the machine to
signal faults. In such case:
- turn off the appliance and wait a few seconds;
- turn on the appliance and repeat the washing program.
If the fault reoccurs, call the service center.
The warranty does not cover faults caused by interference from the environment (lightning strike,
electric circuit, natural disasters, etc.).
19
Failure Possible cause Remedy
The machine does not
work (indicator LED’s are
not illuminated).
Machine is not powered. Check if:
• power in the socket,
• the fuse is OK,
• plug is in the socket.
FAILURE 2
Washing program does
not start
• At the beginning of the
washing program: on/off
LED is flashing
• During washing: LEDs
periodically flash twice
Door is not properly closed. Push it towards the machine.
FAILURE 3
Water does not enter the
machine (after approx. 4
min the machine reports
failure - LEDs periodically
flash three times).
Disturbed water inlet. Check if:
• the water tap is open,
• inlet pipe net filter is clean.
Push the START button.
Water is leaking from the
machine.
Filter is not tightly screwed in.
Inlet pipe is not tightly screwed
to the machine or to the water
faucet.
Outlet pipe fell to the floor.
Tighten the filter properly.
Tighten the inlet pipe.
Affix the outlet pipe to the drain.
The machine moves
during operation.
The machine is not properly
leveled.
Transport brackets are not
removed.
Level the machine with the
adjustable legs.
Remove transport brackets.
The machine vibrates
during the spin.
Unevenly distributed laundry,
especially with very small
quantities (for ex. only the
bathrobe).
This is normal, the machine will
reduce the RPM if vibrations are
too strong.
Wash larger quantity of laundry.
Excessive foaming during
washing.
Excessive measure of detergent. Use washing powder according to
the instructions by the producer
and according to the water
hardness and soiled laundry.
Use only detergents for machine
washing.

452511
20
Failure Possible cause Remedy
FAILURE 7
Water is poorly pumped
out or not at all (machine
reports failure - the LEDs
periodically flash seven
times).
Water outlet is clogged Check if:
• the filter is clean,
• outlet pipe is not jammed,
• the drain is clogged,
• outlet pipe is positioned higher
than 1m.
Push START again
Laundry is not properly
spun.
No failure is reported.
The machine switched on the
UKS* function. Because of bad
laundry balance, the machine has
automatically reduced spin RPM.
The machine operates normally.
Wash large and small pieces of
laundry together.
Greasy wads appear on
the laundry.
Too little detergent (laundry was
very greasy).
Wash the laundry again.
Add more detergent for such soiled
laundry, or use liquid detergent.
Laundry is stained after
washing.
You used liquid detergent or
detergent for colored laundry
which does not contain whitener.
Use the detergent containing
whitener.
White powdery residues
on the laundry.
It is not the consequence of bad
rinsing, but because of neo-
phosphate detergents containing
non soluble components
(zeolites) for water softening.
Such substances may be
deposited upon the laundry.
Immediately rinse the laundry once
again.
• Use liquid detergents which do
not contain zeolites.
• Try removing the residues with
the brush.
Detergent residues in the
dispenser.
Low water flow pressure.
Some detergents may stick to the
dispenser rather hard if it is wet.
• Clean the inlet pipe filter net.
• In case of low water pressure
increase water level.
• Wipe the dispenser prior loading
detergent.
Softener is not completely
rinsed, or water is left in
the dispenser dish.
Sucking cover is not correctly
positioned or is clogged.
Clean the dispenser and firmly fix
the cover to its place.
Unpleasant smell in the
washing machine drum.
• Remains of fabrics, washing
agent and softener in the filter.
• Development of germs
• Check whether the filter is clean.
• Run the auto-clean program
(see chapter: selecting additional
functions)
Washing time is longer
than usual.
Time indicated on the
display is corrected during
the washing cycle.
• Low temperature of inlet water.
• Due to unevenly distributed
load, the machine has activated
the UKS*.
• Low mains voltage.
• There has been a failure in the
power supply.
• Washing program time may be up
to 60% longer; however, this does
not imply a fault in the machine.
• Washing time is extended by the
power supply down-time.
