Sound101
SPECIFICATIONS
Table Radio with Dock for iPod/Sirius-Ready/AM/FM
Etón has updated the retro glamour of radios past with swooping, curved lines and today’s in-demand technology. This little radio packs a wallop, making
it ideal for home or ofce use.
FEATURES
• AM frequency coverage: 530 -1710 KHz / step 10 KHz
• FM frequency coverage: 87.50 - 108.00 MHz / 0.1 MHz
• Uses Sirius direct connect for home - provides text information on
songs/music
• Memory preset station assignments: 20 AM and 20 FM for total of
40 presets
• Encoder volume control
• Manual scan tuning
• Auto station: locates and locks in on the strongest station
• Auto tune provides a programmed service list
• AM/FM tuner type and circuitry: a high-sensitivity digital Phased-
Locked Loop Tuner (PLL) locks in the frequency and provides excellent
AM/FM reception and selectivity
• LCD type: 128x64 dot-matrix, 88 Segment, 2.87” W x 2.01” H (73mm
W x 51mm H module size)
• Viewing area: 2.68” W x 1.54” H (68mm W x 39mm H), gentle illumina-
tion (will not keep you awake), blue backlight, black characters, displays
time, station, alarm, band and presets
• Clock functions: 12 hours format selectable, alarm (wake up to Radio
or Buzzer), sleep timer (programmable minimum range 15 minutes and
maximum range 60 minutes), snooze (mode duration: 5 minutes, 10
minutes, 15 minutes)
• Auxiliary inputs:
• 3.5mm Aux line-in for MP3/CD connection
• 3.5mm audio line-out
• Input for AC adapter (included), input for earphones (not included)
• External aerial connection socket
• Amplier: single channel, earphone, AB
• Speaker type: the 3” full range, magnetically shielded, high-delity,
front ring, mono speaker driver is capable of producing a wide range
of frequencies and produces incredibly powerful, distortion-free, room
lling sound
• RMS power output: 3 WRMS @ 10% THD, 2 WRMS @ 1% THD
• Frequency response range: 80Hz- 20KHz
• Base port
• Audio output: 5 Watt
• Unit power: 30 Watt
• FM antenna type: pigtail antenna, 360 degree swivel-rotary type
• AM antenna type: built-in loop
• Protection: rubber feet prevent scratching and movement
• Power source: AC adaptor (included); Input voltage: power supply, IN:
100-240V 50HZ, OUT: DC 15V/2A, UL approval
• Battery back-up: stores real time during a power failure (will not hold
station presets and alarm settings during power failure), requires 4 AA
batteries (not included)
• Dimensions: 8.27” x 4.53” x 5.1” (W x H x D) and 21,0 x 11,5 x 13,0 cm
(W x H x D)
• Weight: 2.82 lbs. (3.96 lbs. with adapter) and 1,280 g (1,800 g with
adapter)
• Accessories: owner’s manual, AC adapter, infrared remote control, dock
for iPod, AM loop antenna
MP3
Compatible
Remote
Control
Headphone
Jack
Alarm
Clock
Receives
AM Band
Receives
FM Band
Satellite
Ready
Also available in:
WHITE
