Eton Rukus solar User manual

OWNER’S MANUAL
Portable Bluetooth Sound System
with Solar Panel

RUKUS SOLAR OWNER’S MANUAL
2
Thank you for purchasing the Etón Rukus Solar, a portable Bluetooth high-quality
sound system featuring solar charging. The Rukus Solar is powered from the
rechargeable Li-ion battery charged by the solar panel or the AC adapter (included).
Please read this user manual to get a good understanding of how the Rukus Solar
works and how to fully rock out with it!

RUKUS SOLAR OWNER’S MANUAL
3
DISPOSAL
According to the European Directive 2002/96/EC all electrical
and electronic products must be collected separately by a local
collection system.
Please act according to your local rules and do not dispose of
your old products with your normal household waste.
Please dispose of all types of batteries per your Government,
State or Local rules and/or regulations. If you are unsure, please
call the appropriate local authority to find out how to dispose of
them safely and help protect the environment.
NEED HELP? CONTACT US. ENVIRONMENT
Etón Corporation, 1015 Corporation Way, Palo Alto, CA 94303,
USA. 1-800-872-2228 (U.S.); 1-800-637-1648 (Canada);
650-903-3866 (worldwide); M-F, 8:00AM-4:30PM,
Pacific Standard Time; www.etoncorp.com.
WARNING
Do not expose this appliance to rain or moisture.•
Do not submerge or expose for extended period to water.•
Protect from high humidity and rain.•
Only operate within specified temperature range•
(0 °C to 40 °C).
Unplug immediately if liquid has been spilled or any•
object has fallen into the apparatus.
Clean only with a dry cloth. Do not use detergents or•
chemical solvents as this might damage the finish.
Unplug and disconnect external antennas during•
lightning storms.
Do not remove cover [or back].•
Refer servicing to qualified service personnel.•

RUKUS SOLAR OWNER’S MANUAL
4
RUKUS SOLAR FEATURES
FUNCTIONS
1Power ON/OFF button
2Bluetooth button
3USB port
4Battery indicator icon
5USB port icon
6Bluetooth icon
7Solar charging icon
8AUX-in icon
9AUX-in button
10 Bass button
11 Volume up button
12 Volume down button
13 Monocrystal solar panel
14 E Ink display
15 Speakers
16 Integrated carrying handle
17 DC-in jack
18 USB jack
19 AUX-in port
20 Adjustable mobile device storage
1 2 3 4 5 6 7 8 9 10
11
16
17 18 19 20
12
13
14
15

RUKUS SOLAR OWNER’S MANUAL
5
PLUGGING IN THE AC ADAPTER CHARGING THE BUILT-IN BATTERY BY
THE AC POWER/SOLAR ENERGY
Connect one end of the AC adapter to the DC jack of the unit and
the other end to an electrical outlet.
ELECTRICAL
OUTLET
DC JACK
The unit has a built-in Lithium ion battery for portable power
when not using the AC adapter. When the adapter is plugged
in or the unit is exposed under the sunshine, the unit will
start charging. During charging, the indicator on the
display starts blinking.
To fully charge an empty battery:
AC/DC: 3 hours
Solar: 6 hours
BATTERY LIFE (BUILT IN LITHIUM ION BATTERY)
26 - 50 %
51 - 75%
76 - 100%
0 - 25 %
*Charge times may vary depending on solar conditions.
NOTE: To maximize battery life, charge the unit through
the AC adapter for 12 hours prior to first use.

RUKUS SOLAR OWNER’S MANUAL
6
PLAYING BACK VIA AUXPLAYING BACK VIA BLUETOOTH
1. Press the ON/OFF button to turn on the unit.
The power indicator lights up.
2. Press the Bluetooth button to switch the sound source to
Bluetooth mode. The indicator appears on the display.
3. Hold the button for 3 seconds to place the unit in pairing
mode. The indicator starts blinking rapidly. Unit will give off
two short beeps.
NOTE: The indicator turns solid after the unit is successfully
connected. If the indicator starts to blink slowly after
3 minutes, the pair was unsuccessful.
4. Open the Bluetooth settings menu on your Bluetooth-enabled
mobile device or computer. Once it is recognized, “rukus solar”
will appear on the display of the Bluetooth-enabled device.
Select “rukus solar” to pair and connect with your device.
NOTE: On an iPhone or iPad, tap “rukus solar” to select.
If prompted for a password, enter “1234”.
5. Once Bluetooth is connected, seclect the music and press
the button on your device. The unit will playback music
automatically.
NOTE: Playback time on built-in battery is ~8 hours, depending
on music level and other factors.
You can enjoy the sound from an external device such as a
portable digital music player. Be sure to turn off the power of the
external device before making any connections. For details, refer
to the instruction manual of the device to be connected.
1. Connect any device with headphone or line out jack with a
3.5mm line in cable to AUX IN jack on the bottom of the unit.
2. Press the button to turn on the unit.
3. Press the button to switch the sound source to
AUX mode, if the unit is not in AUX mode.
4. Turn on your external device and press button.
5. The unit will play back the music from the external device
automatically.

RUKUS SOLAR OWNER’S MANUAL
7
USB PORT FOR MOBILE DEVICE CHARGING
(5V, 500MAH)
ADJUSTING THE VOLUME LEVEL
BASS BOOST
SWITCHING E INK DISPLAY BACKGROUND COLORS
AUTOMATIC ENERGY SAVING
The USB jack can be used to charge most devices that allow for
USB charging (including many mobile phones, smart phones and
wireless headsets).
1. Connect one end of the USB cord to your device and the other
end to the USB jack of the unit.
2. Press the button to start charging for your device.
Press the button again to stop charging.
NOTE: Use the USB power cord that came with your device
to connect to the unit.
Press the and buttons to adjust the volume levels.
NOTE: During volume adjustments, if the LED indicator
starts to blink, minimum or maximum volume level
has been reached.
Press the button to turn on bass boost.
Press the button again to turn off.
Press and hold the for 5 seconds to toggle between black and
white backgrounds on the E Ink display.
If unit is idle for 10 minutes (no sound output or operation),
the unit will turn off automatically.

RUKUS SOLAR OWNER’S MANUAL
8
WARRANTY REGISTRATION
LIMITED WARRANTY
SERVICE FOR YOUR PRODUCT
WARRANTY
NON-WARRANTY
To ensure full warranty coverage or product updates, registration
of your product should be completed as soon as possible after
purchase or receipt. You may use one of the following options to
register your product:
1. By visiting our website at www.etoncorp.com.
2. Mail in enclosed warranty card.
3. Mail your registration card or information to the following
address; Include your name, full mailing address, phone number,
model purchased, date purchased, retail vendor name and
product serial number (typically located in or near the battery
compartment):
Etón Corporation
1015 Corporation Way
Palo Alto, CA 94303
To obtain service for your product, we recommend
first contacting an Etón service representative at
800-872-2228 US, 800-637-1648 Canada or [phone]
for problem determination and trouble-shooting. If further
service is required, the technical staff will instruct how to
proceed based on whether the radio is still under warranty
or needs non-warranty service.
If your product is still in warranty and the Etón service
representative determines that warranty service is needed, a
return authorization will be issued and instructions for shipment
to an authorized warranty repair facility.
Do not ship your radio back without obtaining the return
authorization number.
If your product is no longer under warranty and requires service
our technical staff will refer you to the nearest repair facility that
will be able to best handle the repair.
For service outside of North America, please refer to the
distributor information included at time of purchase/receipt.
Retain the warranty information from your warranty card with
your proof of purchase or the Limited Warranty information can
also be viewed at www.etoncorp.com.

Etón Corporation
Corporate Headquarters
1015 Corporation Way
Palo Alto, California 94303 USA
tel [phone]
tel [phone]
fax [phone]
Etón Canada
1 Yonge Street, Suite 1801
Toronto, Ontario M5E 1W7
Canada
tel [phone]
www.etoncorp.com
Designed by Etón Corporation and assembled in China. © Copyright 2012 Etón Corporation. All rights reserved. v033012

QUICK GUIDE
2
3
SETIING UP BLUETOOTH PLAYBACK
Connect unit to AC.
PAIR.
Turn unit ON , press and hold Bluetooth button for 3 seconds .
@
ITJ B
~
t * 0) AUX
I AUX II BASS I @
8
CONNECT.
4
PLAY.
0
~II
Connect Bluetooth device to Rukus. Play music from your device.
CHARGING THE BUILT-IN BATIERY BY THE AC POWER/SOLAR ENERGY
Charge internal battery via AC adapter or direct sunlight. Battery charge indicator turns on
when chargin[S. ~
NOTE: To maximize battery life, char[Se the unit throu[Sh AC for l 2 hours prior to first use.
CHARGING SMARTPHONE
l . PIUB Smartphone to USB port.
2. Press the USB ~ button on the unit to char[Se .
CHARGING AND PLAYBACK TIME
SOURCE CHARGING TIME * PLAYBACK TIME*
(i) SOLAR ENERGY
6HOURS B+HOURS
0 AC/DC POWER
4HOURS
00
• Ti mes may va ry de p en d1n gon ba tt ery ca p ao t y. device an d vo lum e se tti ngs, and sunlight int ens ity
Please visit www.etoncorp.com to download the Own e r's Manual.

Et6n Corporation
1 01 5 Corporation Way,
Palo Alto, CA 94303-4305 I USA
1-800-872-22281 us
1-800-637-16481 Canada
1- 650-903-3866 I Worldwide
www.etoncorp.com
Designed by Et6n Corporation and assembled in China.
© Copyright 201 2 Et6n Corporation. All rights reserved.
Con~u par Et6n Corporation et assemble en Chine.
Taus droits reserves.
v030912

et6n
Safety
Information
The
lightning
flash
with
arrowhead
symbol,
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
uninsulated
"dangerous
voltage"
within
the
product's
enclosure
that
may
be
of
sufficient
magnitude
to
constitute
a
risk
of
electric
shock
to
persons.
The
exclamation
point
within
an
equilateral
triangle
is
intended
to
alert
the
user
to
the
presence
of
important
operating
and
maintenance
(servicing)
instructions
in
the
literature
accompanying
the
appliance
.
WARNINGS:
TO
REDUCE
THE
RISK
OF
FIRE
OR
ELECTRIC
SHOCK,
DO
NOT
EXPOSE
THIS
APPLIANCE
TO
RAIN
OR
MOISTURE.
DO
NOT
REMOVE
COVER
or
OPEN
THE
CABINET.
Dangerous
high
voltages
are
present
inside
the
enclosure.
No
user
serviceable
parts
inside.
leave
all
servicing
to
qualified
service
personnel.
IMPORTANT
SAFETY
INSTRUCTIONS
1.
Read
these
instructions.
2.
Keep
these
Instructions.
3.
Heed
all
Warnings.
4.
Follow
all
instructions.
5.
Do
not
use
this
apparatus
near
water.
6.
Clean
only
with
dry
cloth.
7.
Do
not
block
any
ventilation
openings
.
Install
in
accordance
with
the
manufacturer's
instructions.
8.
Do
not
install
near
any
heat
sources
such
as
radiators,
heat
registers,
stoves,
or
other
apparatus
(including
amplifiers)
that
produce
heat.
9.
Do
not
defeat
the
safety
purpose
of
the
polarized
or
grounding-
type
plug.
A
polarized
plug
has
two
blades
with
one
wider
than
the
other.
A
grounding
type
plug
has
two
blades
and
a
third
grounding
prong.
The
wide
blade
or
the
third
prong
is
provided
for
your
safety
.
If
the
provided
plug
does
not
fit
into
your
outlet,
consult
an
electrician
for
replacement
of
the
obsolete
outlet.
10.
Protect
the
power
cord
from
being
walked
on
or
pinched
particularly
at
plugs,
convenience
receptacles,
and
the
point
where
they
exit
from
the
apparatus.
11.
Only
use
attachments/accessories
specified
by
the
manufacturer.
~
12.
Use
only
with
the
cart,
stand,
tripod,
bracket
or
table
specified
by
the
manufacturer,
\Cit
or
sold
with
the
apparatus.
When
a
cart
is
used,
use
caution
when
moving
h I b. .
'd
. . f .
PORTABLECARTWARNING
t e
cart
apparatus
com
mat10n
to
av01
InJury
rom
t1p-over.
tsymbolprovidedbyRETAc)
13.
Unplug
this
apparatus
during
lightning
storms
or
when
unused
for
long
periods
of
time.
14.
Refer
all
servicing
to
qualified
service
personnel.
Servicing
is
required
when
the
apparatus
has
been
damaged
in
any
way,
such
as
power-supply
cord
or
plug
is
damaged,
liquid
has
been
spilled
or
objects
have
fallen
into
the
apparatus,
the
apparatus
has
been
exposed
to
rain
or
moisture,
does
not
operate
normally,
or
has
been
dropped.
15.
Apparatus
shall
not
be
exposed
to
dripping
or
splashing
and
no
objects
filled
with
liquids,
shall
not
be
placed
on
the
apparatus.
16.
The
mains
plug
is
used
as
disconnect
device
and
it
shall
remain
readily
operable
during
intended
use.
In
order
to
disconnect
the
mains
plug
from
the
mains
completely,
the
mains
plug
should
be
disconnected
from
the
mains
socket
outlet
completely.
17.
The
batteries
(battery
pack
&
batteries
installed)
shall
not
be
exposed
to
excessive
heat
such
as
sunshine,
fire
or
the
like.
18.
Do
not
place
any
naked
flame
sources,
such
as
lighted
candles,
on
the
apparatus.
19.
The
battery
used
in
this
product
must
be
properly
recycled
or
disposed
of.
Please
contact
your
local
recycling
center
for
proper
battery
handling
and
disposal
instructions.
For
compatibility
between
the
RK100/RKS100
system
and
another
device
with
Bluetooth
technology,
consult
the
device's
documentation
and
dealer.
In
some
countries,
there
may
be
restrictions
on
using
Bluetooth
devices.
Check
with
your
local
authorities.
Bluetooth
is
a
registered
trademark
of
Bluetooth
SIG,
Inc
WARNING!
Danger
of
explosion
if
battery
is
incorrectly
replaced.
Replace
only
with
the
same
or
equivalent
type.
WARNING!
Changes
or
modifications
to
this
unit
not
expressly
approved
by
the
party
responsible
for
compliance
could
void
the
user's
authority
to
operate
the
equipment.
Please
read
rating
label
at
the
bottom
of
system
for
power
input
and
other
safety
information.
FCC
and
IC
Information:
This
device
complies
with
Part
15
ofthe
FCC
Rules
and
RSS-210
of
the
IC
Rules.
Operation
is
subject
to
the
following
two
conditions:
(
1)
This
device
may
not
cause
harmful
interference,
and
(2)
this
device
must
accept
any
interference
received,
including
interference
that
may
cause
undesired
operation.
Warnings:
The
device
meets
the
exemption
from
the
routine
evaluation
limits
in
section
2.5
of
RSS
102
and
users
can
obtain
Canadian
information
on
RF
exposure
and
compliance
from
the
Canadian
Representative
Burn
port
Holdings
Ltd.
72MT
Belcher
Pis,
East,
Calgary,
Alberta,
T2Z
2G1,
CANADA.
Tel:
403-257-4961

Canada IC statments
Le present appareil est conforme aux CNR d·lndustrie Canada applicables aux appareils radio exempts
de licence. L·exploitation est autorisee aux deux conditions suivantes: (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil do it accepter tout brouillage radioelectrique
subi, meme si le brouillage est susceptible d·en compromettre le fonctionnement.
FCC&IC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment
and meets the exemption from the routine evaluation limits in section 2.5 of RSS 102.
1. This Transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
2. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 20
centimeters from user and bystanders.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determ ined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio TV technician for help.
Information for Users on Disposal of Old Equipment
[European Union]
This symbol indicates that the electrical and electronic equipment should not
be disposed as general household waste at its end-of-life. Instead, the
product should be handed over to the applicable collection point for the
recycling in accordance with your national legislation.
-
Attention:
This symbol is only valid in the
European Union.
By disposing ofthis product correltly, you will help to conserve natural resources and will help prevent
potential negative effects on the environment and human health that could otherwise be caused by
inappropriate waste handling of this product. For more information about collection point and
recycling of this product, please contact your local municipal office, your household waste disposal
service or the shop where you purchased the product.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.
[Other Countries outside the European Union]
If you wish to dispose of this product, please do so in accordance with applicable national legislation
or other rules in your country for the treatment of old electrical and electronic equipment.
CAUTION - Proper Installation
• Install the system in a place which is level, dry and neither too hot nor too cold. The appropriate
temperature is between 5 °C a 11d 35 °C.
• Install the system in a location with adequate ventilation to prevent internal heat from building up
inside the unit.
• Leave sufficient distance between the system and TV.
• Keep the system away from TV' to avoid interference with TV.
CAUTION - Proper Ventilation
To avoid risk of electric shock and fire, and to prevent damage, locate the apparatus as follows:
Front: No obstructions and open )pacing.
Sides I Top I Back: No obstructions should be placed in the areas shown by the dimensions.
Bottom: Place on the level surfa(e. Maintain an adequate air path for ventilation by placing on a stand
with a height of 10 em (3-15/16
11
) or more.
Front View: Side View:
I
1~cm
(5- 1.l ,,6 ")
15cm I if
(5- 1S h6 ") u
n Backside
Front side /r------,-,~~ lScm
I (s- 15 ~,6 ")
lXm 00 II II 0 1Scm
(5-
15
/,."1 ~ ~ (5-
15
/,.")
////////////////////7///#7//////////////
t 1##/#&////fl/#4
10cm (3-
15
h6 ")
QDID:
8019346

Standard
of Quality
Limited
Warranty
and
Product
Registration
USA
Eton
Corporation
Corporate
Headquarters
1
01
5 Corporation
Way
Palo
Alto,
CA
94303
www.etoncorp.com
Canada
Eton
Electronics
Canada
LTD
Toronto Office
1
Yonge
Street, Suite 1801
Toronto, Ontario
MSE
1
W7
www.etoncorp.com

LIMITED WARRANTY
Et6n Corporation (Et6n) offers a limited warranty to the original customer against manufacturing
defects
in material and workmanship on this product This warranty is valid only for the original
purchaser and is not transferable.
TWO (2) YEARS PARTS AND LABOR - Europe
ONE (1) YEAR PARTS AND LABOR - North America
This limited warranty begins on the original date of purchase, and is valid only on products
purchased through an authorized Et6n retailer. Warranty repairs must be performed by Et6n or an
authorized service center. To receive warranty service, the original dated bill of sale, or a copy,
must be presented upon request as proof of purchase. Installation, removal or reinstallation of the
product is not included under this warranty. Shipping to Et6n or the authorized service center is
the responsibility of the purchaser For products purchased in Europe, please return to your dealer
or the distributor of your country, which is listed on a sheet included in the packaging.
Et6n will repair or replace this product, at our option and at no charge, with new or reconditioned
parts if this product is found to be defective during the limited warranty period. To be eligible for
warranty coverage, the product must be returned with shipping charges prepaid no later than 15
days after the expiration of the warranty period to Et6n or the designated service center. Prior to
WARRANTY REGISTRATION
To ensure full warranty coverage or product updates, registration of your
product should be completed as soon as possible after purchase or rr·ceipt.
You may use one of the following options to register your product
1.
By visiting our website at http://www.etoncorp.com.
2. Mail in enclosed warranty card.
3. Mail your registration card or information to following address; include your
name, full mailing address, phone number, email address, model purchased,
date purchased, retail vendor name:
Et6n Corporation
1 01 5 Corporation Way
Palo Alto, CA 94303 USA
LIMITED WARRANTY
Retain the warranty information from your warranty card with your proof of
purchase or the Limited Warranty information can also be viewed at
www.etoncorp.com.
returning any product for warranty service, the purchaser must contact Et6n or the designated
service center for troubleshooting and service procedure instructions. Damaged parts or products
become the property of Et6n. Parts and products replaced by Et6n assume the remaining original
warranty, or ninety (90) days, whichever is longer.
This limited warranty covers manufacturing defects in material and workmanship encountered in
normal, noncommercial use of this product and shall not apply to the following, including, but not
limited to: damage that occurs due to applications and uses for which the product was not
intended; failures or problems that are caused by products or equipment not supplied by Et6n;
accidents, misuse, abuse, neglect, misapplication, fire, water, lightning, or other acts of nature;
incorrect line voltage, fluctuations, or surges; damage caused by improper or faulty installation;
damage caused by acid leakage from improperly installed or defective batteries; product alteration
or modification; or use of unauthorized parts, supplies, accessories, or equipment that damage this
product or result in service problems.
SERVICE INFORMATION
To obtain service for your Et6n product, first contact an Et6n service representative at
1-800-872-2228 US, 1-800-637-1648 Canada or your respective country distributor in Europe
(see enclosed list) for troubleshooting. Many common questions and problems can be resolved
over the phone.
SERVICE FOR YOUR PRODUCT
To obtain service for your product, we recommend first contacting an Et6n
service representative at: 1-800-872-2228 US, 1-800-637-1648 Canada,
[phone] or [email protected] for problem determination
and trouble-shooting. If further service is required, the technical staff will
instruct how to proceed based on whether the radio is still under warranty or
needs non-warranty service.
WARRANTY- If your product is still in warranty and the Et6n service
representative determines warranty service is needed, a return authorization
will be issued and instructions will be given. DO NOT ship your radio back
without obtaining the return authorization.
NON-WARRANTY- If your product is no longer under warranty and requires
service, the Et6n service representative will refer you to the nearest repair
facility that will best handle the repair.
For service outside North America, please refer to the distributor information
included at time of purchase/receipt.

*Denotes Required Field
Et6n Product Registration
Go to: www.etoncorp.com/productregistration, or mail this form today.
Serial number*:
(located in the back of the unit)
Date of purchase*:
Dealers name*:
City*:
Country/Territory*:
Name*:
Address*:
City*:
State/Provice*:
Postal Code/ZIP Code*:
Country/Territory*:
Telephone Number*:
Email*:.
1. Your annual income?
0 Under S14,999
0 S15,000 to $30,000
0 $30,001 to $50,000
0 $50,001 to $75,000
0 $75,001 to $150,000
0 Over S150,001
2. Your age?
0 Under 16
0 16-20
0 21-25
0 26-30
0 31-35
0 36-40
0 41-45
0 46-50
0 51-55
0 56-60
0 61 and over
3. What are your listening interests? (Check all that apply)
0 Satellite Radio
0 Local AM/FM 0 Shortwave/International Broadcast
4. Did you consider another unit before choosing this product?
0 Yes (Please Specify Model): ___________ _
0 No
5. What is your occupation? ____________ _
6. How did you hear about Et6n?
0 Newspaper ad
0 Radio ad
0 Through a retailer
0 Article
0 Web Search
0 Other _________ _
0 Yes! Iwould like Et6n to send me information
on products including special offers, new product
launches, and product updates/information:
0 Email 0 Mail
et6n
EMPOWERED BY NATURE
