Etzinger etz-P User manual

GUIDE
Grinder Parts
1 Housing with Turning Knob
2 Lid
3 Adjustment Ring with coneholder & cone burr
4 Magnetically attached catcher (optional)
ETZINGER AG (FL-9492 ESCHEN) - Phone: [phone] - www.etzinger-ag.com - Email: [e-mail]
etz-P®
Technical Data
Burrs: 32mm Diameter (Cone Burr)
Hardened steel (62 HRC)
Weight: 620g (without catch-up cup)
Diameter Housing: 55mm
Catcher: 60mm outside / 55mm opening
Height: 221mm
Material Housing: Anodised Aluminum
Material Adjustment Ring: Fibreglass reinforced plastic (FRP)
1
2
3
4
Thank you for choosing our Pepper Mill etz-P, an innovative pepper grinder facilitating manual grinding not just in regards of handling and adjusting.
Open the box and carefully pull out the grinder. Make sure to check the delivery content before getting your grinder ready for use. To get started,
please follow our instructions and pictures. To clean your grinder, use a soft cloth and/or a brush. Do not clean the burrs with water and avoid to
touch them with wet fingers.
For more information, please visit our Website (for Warranty policy, see „Good to know“).
THANK YOU –ENJOY THE GRIND!!

HOW TO GET STARTED
LID ADJUSTMENT RING CLEANING
GRINDING
etz-P®
Rotate lid to the left
and lift off (Fig. 1).
Fill in peppercorns or
spice corns. (around
60g).
Position lid at opening
and move to the right
until engaged (Crow
and „Pepper“ aligned,
Fig. 2).
The Adjustment Ring (Fig. 3) consists of 88 slightly
stepped increments à 0.02mm, numbered 1-23.
To adjust grind setting, move the black
Adjustment Ring between COARSE (23) and FINE
(1) –beware of marking line.
Recommended settings:
Pepper & Spices
1-3 (super-fine, 60+ Mesh)
9-13 (medium –Table/Restaurant Use)
17-21 (coarse)
23 (extra-coarse, 10-12 Mesh)
To grind, rotate the black Turning
Knob counter-clockwise (CCW, Fig. 3).
Beware of catcher being magnetically
attached.
ATTENTION
Do not grind within the DO-NOT-GRIND section (Fig. 4). Turning the Adjustment Ring beyond, will release the housing.
Do not clean grinder or burrs with water!
Do not grind SALT with this Pepper Mill!
Fig. 1
Fig. 3
Fig. 4 Fig. 5 Fig. 6
Coarse Fine
Fig. 2
Turn the black ring (=Adjustment Ring, Fig. 3/4) to the left (marking to be in line
with arrow, Fig. 4). Pull down and out (if tight, please follow instructions on next
page).
Clean coneholder and cone burr (Fig. 5) as well as ring burr and the inside of the
tube (Fig. 6) with a brush, then reassemble in reverse order before moving
black ring to the right / back to the stepped part or your initial setting.
Please also make sure to read the more detailed instructions on the next page.

Disassembly and Cleaning
etz-P®
3
6
ETZINGER AG
Wirtschaftspark 44
FL-9492 ESCHEN
Phone: [phone]
Website: www.etzinger-ag.com
Email: [e-mail]
6-7
Bottomside
1
Ring Burr
Coneholder
Adjustment
Cone Burr
2
3
Position & Engage
3-4
5
1. Remove magnetically attached Catch-up by gently pulling it down, turn it around
2. Bottomside of Collection Cup may now be used as a tool
3. Fit bottomside of Collection Cup into Adjustment Ring and make sure for it to engage
4. Once engaged, slightly move Collection Cup back and forth to release remains stuck from within
5. Turn Collection Cup with Adjustment Ring to the left (versus COARSE). Make sure for marking to be in line with arrow before pulling Adjustment Ring off
6. Clean coneholder and cone burr with a brush. Brush out ring burr affixed to the grinder body
7. Reposition Adjustment with coneholder and cone burr at indicated arrow (make sure for arrow and marking to be aligned). Groove must engage properly before you can press up Adjustment Ring
and move it to the right, back to the stepped part or your initial setting

etz-P®
3
6-7
SAFETY INSTRUCTIONS
Carefully read the instructions in this guide as well as the information below. It contains important safety information for this grinder. Please keep these instructions for future reference.
✓Only use the grinder for its intended purpose, the grinding of corns and grains.
✓This grinder can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the grinder in a safe way and understand the hazards involved.
✓Improper and negligent handling of packaging elements with sharp edges can lead to injury and may be hazardous. Store packaging elements out of reach of children, persons with limited physical,
mental and/or sensory capacities and pets.
✓Make sure not to have children playing with the handgrinder, its parts or packaging. Children can become entangled or suffocate while playing.
✓Never use inappropriate objetcs (cutlery, scissors, needles, etc.) to clean the handgrinder or remove coffee beans/grounds.
✓Avoid for the burrs to get in contact with water (rust), do not wash burrs or grinder in the dishwasher, use chemicals or aggressive cleaning products to clean the grinder, check for foreign objects
before grinding so to avoid damage to the burrs.
✓Do not grind SALT with this grinder (Pepper Mill).
✓Cleaning and user maintenance shall not be made by childrenwithout supervision by a qualified person. Maintenance and repair work to be carried out by manufacturer, its service agent or
qualified persons only.
✓Safe materials: all materials used for the production and assembly of etzinger® products and getting in contact with corns will not result, directly or indirectly, in their becoming a component of or
otherwise affecting the characteristics of foods.
Warranty Information for EU Countries / Switzerland and Liechtenstein
The warranty for grinders purchased from Etzinger AG covers a period of 24 months (domestic) / 12 months (commercial) from the date of purchase under EU Directives. This warranty covers all damage
to material and processing and shall not apply to improper operation, improper cleaning, misuse, normal wear and tear, inaccuracy when implementingsettings, foreign objects in the beans (stones,
screws, plastic parts, etc.) as well as in the event of use that is inconsistent with the intended use, i.e., the grinding of corns and grains.
In the event of shortcomings within the warranty obligation, please contact your dealer or send us an e-mail at [e-mail] call us on [phone].
International Warranty
Warranty, service, and maintenance in all countries outside of Switzerland, Liechtenstein, and the EU or in countries with authorized Dealers are the responsibility of your authorized Dealer from whom
you purchased the device. To find your nearest Dealer, please contact us by e-mail at [e-mail].
