User Guide
May 2022
Eupry 3G Router without Heartbeat
(TL-MR6400)
User Guide: Eupry 3G Router without Heartbeat
Rev. 0.1 - May 2022 Page 1 of 5
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

1 Contents
1 Contents 2
2 Introduction 2
2.1 Intended Purpose 2
2.2 Package Contents 2
3 Front Panel 3
4 Technical Specifications 4
5 Setting up the router 4
5.1 Attach the antennas to the router 4
5.2 Turn on the router 5
6 Support 5
7 Revision history 5
2 Introduction
2.1 Intended Purpose
The router is preconfigured to be set up with any Eupry WiFi Data Loggers that are purchased alongside it. It uses a
3G data connection to provide wireless internet that our Data Loggers can access.
2.2 Package Contents
The package includes one each of the following:
●Eupry router
●2 antennas
●Power Supply
User Guide: Eupry 3G Router without Heartbeat
Rev. 0.1 - May 2022 Page 2 of 5
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

3 Front Panel
The front panel on the router will light up when the router has power.
Name
Status
Indication
On
The system has started up successfully.
Flashing
The system is starting up or firmware is being upgraded. Do
not disconnect or power off your modem router.
Off
Power is off.
Off
The router is connected to the internet.
On
There is no internet connection.
On
The router is connected to the 4G network.
Off
The router is disconnected from the 4G network.
On
The wireless function is enabled.
Off
The wireless function is disabled.
On
At least one LAN port is connected to a powered-on device.
Off
No LAN port is connected to a powered-on device.
On/ Off
This light remains on for 5 minutes when a WPS connection
is established, then turns off.
Flashing
WPS connection is in progress. This may take up to 2 minutes.
On
Indicates the signal strength received from the mobile
internet network. More lit bars indicate a better signal strength.
Off
There is no mobile internet signal.
User Guide: Eupry 3G Router without Heartbeat
Rev. 0.1 - May 2022 Page 3 of 5
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

4 Technical Specifications
General
Wireless Standards
IEEE 802.11b/g/n 2.4GHz
Protocol
TCP/ IP
Interface
3x 10/100Mbps LAN Ports
1x 10/100Mbps LAN/WAN Port
1x Micro SIM Card Slot
Indicators
LEDs
Power
9 V / 0.85 A
Operating Temperature
0 °C - 40 °C
Operating Humidity
10 % RH - 90 % RH Non-condensing
Certificates
CE
RoHS
5 Setting up the router
5.1 Attach the antennas to the router
There are two antennas in the package:
1. The antennas should be firmly attached to the router and pointing upwards (see photo below).
User Guide: Eupry 3G Router without Heartbeat
Rev. 0.1 - May 2022 Page 4 of 5
Eupry ApS | Dortheavej 59, 3rd Floor. | 2400 Copenhagen NV | www.eupry.com | [phone] |[e-mail]

5.2 Turn on the router
It is important to use the cable that is sent together with the router.
Do not use another power supply cable.
Do not insert a cable in the LAN or WAN input.
1. Insert the power cable on the left side of the router
2. Press on the ON/OFF button
3. It takes a few minutes before the router is connected.
6 Support
If you have any problems with setting up the router, please contact Eupry support:
Tel: [phone]
E-mail: [e-mail]
7 Revision history
Revision
Date
Responsible
Change
0.1
17-May 2022
NHP
First revision
