EURO E410FW User manual

Instruction Manual
Refrigerator-freezer
Please read c ar ef u l l y b efore using o u r p roducts.
Please keep t h i s o peration i n s t r u c t i o n p roperly
for f u t u r e r ef er en c e.
MODEL:E410FW/E410SX

CONTENTS
Safety warnings
Meaning of safety warning symbols ·················2
Related warnings for use ······················2
Electricity related warnings ·····················2
Warnings related to placing items ··················3
Warnings related to disposal ····················3
Proper use of refrigerators
Names of components ·······················4
Ice tray (optional) ··························5
Thermostat ····························5
Illuminating lamp and replacement ··················5
placement ·····························5
Start ·······························5
Maintenance of refrigerators
Cleaning ······························6
Defrost ······························6
Stop using ·····························6
Frequently asked questions
Door install guidelines about swapping left&right
DEAR CUSTOMER:
Thank you for buying this refrigerator-freezer. To ensure that you get the best results from your new
refrigerator-freezer, please take time to read through the simple instructions in this booklet.
Please ensure that the packing material is disposed of in accordance with the current environmental
requirements.
When disposing of any refrigerator-freezer equipment please contact your local waste disposal
department for advice on safe disposal.
This appliance must be only used for its intended purpose.

Safety warnings
Meaning of safety warning symbols
Prohibition symbols
Warning symbols
Note symbols
The symbols indicate prohibited matters, and those
behaviors are forbidden. Non-compliance with the
instructions may result in product damages or endanger
the personal safety of users.
The symbols indicate matters that must be followed, and
those behaviors must be strictly executed in line with the
operation requirements. Non-compliance with the
instructions may result in product damages or endanger
the personal safety of users.
The symbols indicate matters to pay attention to, and
these behaviors shall be specially noted. Due
precautions are needed or minor or moderate injuries
or damages of the product will be caused.
This manual contains lots of important safety information
which shall be observed by the users.
CAUTION :
The appliance is not intended for use by young children or infirm persons without
supervision.
Young children should be supervised to ensure that they do not play with the
appliance.
GENERAL：
This type of refrigerator-freezer is widely used in places such as hotels ,offices,
student dormitories and houses. It is mostly suitable for refrigerating and preserving
foods such as fruits and beverage. It enjoys the advantages of small size, Lightweight,
Low electric consumption and easy use.
1

The refrigerator adopts /50Hz AC power, voltage fluctuations
over the range of 187 ~ 242V will cause malfunction or even damage,
so a 750 W automatic voltage regulator must be installed in concert
with the AC power.
Please turn off the valve of the leaking gas and then open the doors
and windows in case of leakage of gas and other flammable gases.
Do not unplug the refrigerator and other electrical appliances
considering that spark may cause a fire.
220V-240V
To ensure safety, it is not recommended that to place regulators,
rice cookers, microwave ovens and other appliances at the top of the
refrigerator, those recommended by the manufacture are not included.
Do not use electrical appliances in the food pantry.
Safety warnings
Electricity related warnings
Related warnings for use
Authorized demolition or renovation of the refrigerator is not prohibited.
It is forbidden to damage the refrigerant lines and the repair and
maintenance of the refrigerator must be carried out by professionals.
Damaged power cord must be replaced by the manufacturer, its
maintenance department or related professionals in order to avoid
danger.
The surrounding of the appliances around or the embedded structure
shall not be obstructed while good ventilation shall be maintained.
The gaps between refrigerator doors and between doors and refrigerator
body are small, be noted not to put your hand in these areas to prevent
squeezing the finger. Please be gentle when switching off the refrigerator
door to avoid falling articles.
Do not pick foods or containers in the freezing chamber when the
refrigerator is running, especially metal containers in order to avoid frostbite.
10A
Do not pull the power cord when pulling the power plug of the
refrigerator. Please firmly grasp the plug and pull out it from
the socket directly.
Do not damage the power cord under any condition so as to
ensure safety use, do not use when the power cord is damaged
or the plug is worn.
Worn or damaged power cord shall be replaced in
manufacture-authorized maintenance stations.
Please use a dedicated three-hole power socket which is 10A
or more and the power socket shall not be shared with other
electrical appliances.
The power cord should be firmly contacted with the socket or else
fires might be caused. Please ensure that the grounding electrode
of the power socket is equipped with a reliable grounding line.
2

Do not allow children to enter or climb the refrigerator to prevent that
children are sealed in the refrigerator or children are injured by the
falling refrigerator.
Do not spray or wash the refrigerator; do not put the refrigerator in
moist places easy to be splashed with water so as not to affect the
electrical insulation properties of the refrigerator.
Do not place heavy objects on the top of the refrigerator considering
that objectives may fall when switching the door, and accidental
injuries might be caused.
Please pull of the plug in case of power failure or cleaning. Do not
connect the freezer to power supply within five minutes to prevent
damages to the compressor due to successive starts.
Do not put flammable, explosive, volatile and highly corrosive items
in the refrigerator to prevent damages to the product or fire accidents.
Do not place flammable items near the refrigerator to avoid fires.
Do not place items such as bottled or sealed container of fluid such
as bottled beers and beverages in the freezer to prevent bursts and
other losses.
This product is household refrigerators and shall be only suitable for
the storage of foods. According to national standards, household
refrigerators shall not be used for other purposes, such as storage
of blood, drugs or biological products.
Please remove the door of the refrigerator and shelves which shall be properly
placed to avoid accidents of children entering and playing in the refrigerator.
The refrigerator's R600a refrigerant and cyclopentane foam materials are combustible materials
and discarded refrigerators should be isolated from fire sources and can not be burned.
Please transfer the freezer to qualified professional recycling companies for processing to avoid
damages to the environment or other hazards.
Safety warnings
3
Warnings related to disposal
Warnings related to placing items

Proper use of refrigerators
Names of components
The features and accessories of the refrigerator you bought may be not
entirely consistent with the legend, please refer to the packing list.
Refrigerating chamber
Freezing chamber
The low temperature freezing chamber may keep food fresh for a long time and it is mainly used to
store frozen foods and making ice.
The freezing chamber is suitable for storage of meat, fish, shrimp, dumplings, rice balls and other
foods not to be consumed in short term.
Chunks of meat are preferably to be divided into small pieces for easy access. Please be noted food
shall be consumed within the shelf time.
The freezer chamber is suitable for storage of a variety of fruits, vegetables, beverages and
other food consumped in the short term.
Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature.
Foods are recommended to be sealed up before putting into the refrigerator.
The glass shelves can be adjusted up or down for a reasonable amount of storage space and easy use.
4
COOL COOLER
COLD
Mid
Mid
FRZ.
REF.
COLDER
Control knob
Freezer temperature Refrigerator temperature
control knob
Fresh door tray Adjustable foot
Fresh door boottle rack

Placement
Start
The refrigerator is placed in a
well-ventilated indoor place;
the ground shall be flat, and
sturdy (rotate left or right to
adjust the wheel for leveling if
unstable).
The refrigerator shall stay
for half an hour before
connecting 220V/50Hz
power when it is firstly
started.
The refrigerator shall run
2 to 3 hours before loading
fresh or frozen foods; the
refrigerator shall run for
more than 4 hours in
summer in advance
considering that the
ambient temperature is
high.
Ice tray (optional)
Thermostat
Illuminating lamp and replacement
The ice tray is used for making ice. Boiled water
injected to four-fifths of the capacity shall be placed
in the refrigerating chamber for about a few hours
before forming solid ice, twist the ice tray to separate
it from ice.
Do not bend the ice tray to avoid breakage.
Users may adjust the refrigerator according to the actual needs. It is generally recommended
to adjust to the third gear.
Under the same ambient temperature, larger number stands for more robust refrigeration
and lower temperature inside the chamber and vice versa.
On condition that the compressor runs for relative long time or large ice cubes are found in the
refrigerating chamber, adjust the thermostat knob to the direction of smaller numbers.
Knob on the figure represents only gear instead of specific temperature. ＂OFF＂ position of
the thermostat means stop working.
Before using the
refrigerator, remove all
packaging materials
including bottom
cushions and foam pads
and tapes inside the
refrigerator, tear off the
protective film on the door
and the refrigerator body.
Please leave enough space to
ensure feasible opening and
drawer removal.
Dimensions shown are for
reference only.
Keep away from heat and
avoid direct sunlight. Do not
place the freezer in moist or
watery places to prevent rust
or reduction of insulating
effect.
The top space of the refrigerator
shall be greater than 30cm, and
the distances from both sides and
backside shall be more than 10
cm to facilitate the opening and
closing and heat dissipation.
Wipe the refrigerator inside and
outside with warm moist rag (add
a small amount of detergent in the
warm water and wipe clean finally
with clean water).
900mm
545mm
920mm
520mm
Proper use of refrigerators
Illuminating lamp parameter: AC -240 50Hz/10W
Lighting lamps replacement:
Before changing the light bulb,please unplug the refrigerator first,
then pull down the light cover and change the light bulb according
to the picture.
220 V/
5
Water line

Maintenance of refrigerators
Refrigerating chamber
Drainage holes
Cleaning
Defrost
Stop using
Do not use hard brushes, clean steel balls, wire brushes,
abrasives, such as toothpastes, organic solvents (such as
alcohol, acetone, banana oil, etc.), boiling water, acid or
alkaline items clean refrigerator considering that this may
damage the fridge surface and interior.
Do not rinse with water so as not to affect the electrical insulation
properties. Please use a dry cloth when cleaning lighting lamps,
temperature control knob and electrical components.
Manual defrost of freezer is not needed.
The frost on the posterior wall frosting will melt and outflow through the
drainage holes to refrigerator intraday for automatic evaporation.
Freezing chamber shall be manually defrosted.
A layer of frost will be formed on the evaporator plate after a period of
operation. If the frost layer is too thick, the power consumption will be
increased and cooling effect will be impacted; defrost and cleaning are
needed when a thick layer of ice is formed on the evaporator plate. Please
put a bowl of hot water in the freezing chamber to accelerate defrosts, and
the defrosting water shall be dried with dry cloth.
Please unplug the refrigerator for defrost and cleaning.
Do not use metal utensils or electric heater for defrost so as not to damage the appliance. Please
remove the food and put in a cool place when defrosting before removing drawers and other accessories.
Foods can be preserved for a couple of hours even in summer in case of power failure; it is
recommended to reduce the frequency of opening door and do not put fresh foods into the freezer.
Please unplug the refrigerator left unused for a long time for cleaning. Keep the door open to avoid
the bad odor.
Before moving the refrigerator, please emove all items in the refrigerator and fasten the glass
partitions, fruit and vegetable boxes, freezer drawers with taps lest the door opens during
displacement; Do not turn upside, horizontally place or vibrate the refrigerator, the carrying angle can
not be greater than 45 ℃.
Continuous operation is recommended when the refrigerator is started. Please do not move
the refrigerator under normal circumstances so as not to affect the refrigerator's service life.
Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling
effect and energy saving. The interior of the refrigerator should be cleaned regularly to avoid odor.
Soft towels or sponge dipped in water and non-corrosive neutral detergents are suggested for
cleaning. The freezer of shall be finally cleaned with clean water and dry cloth. Open the door for
natural drying before the power is turned on.
6

Frequently asked questions
Inoperation
Odor
Foods in the refrigerating
chamber are frozen
Long-term operation
of compressor
Illuminating light
does not shine
The refrigerator door
can not be properly
closed.
Loud noises
Whether the freezer is plugged and connected to power;
Low voltage;
Failure power or tripping circuit
Odorous foods should closely wrapped;
Whether foods are rotten;
Whether the interior shall be cleaned.
Whether the thermostat is over adjusted;
Whether foods containing water is put in inside the
glass partition.
It is normal that refrigerator operates for longer time in
summer when the ambient temperature is higher;
Do not put too much food in the freezer at one time;
Do not put foods until they are cooled;
Frequent opening of refrigerator door.
Thick frost layer (defrost is needed)
The freezer door is stuck by food packages;
Too much food;
Tilt refrigerator.
Whether the food is leveled, whether the refrigerator is
balanced;
Whether the refrigerator parts are properly placed.
The following simple issues can be handled by the user. Please call the after-sale service
department if the issues are not settled.
Warm tips:
◆The refrigerator enclosure may emit heat during operation specially in summer, this is caused by
the radiation of the condenser, and it is a normal phenomenon.
◆Condensation: condensation phenomenon will be detected on the exterior surface and door
seals of the freezer when the ambient humidity is large, this is a normal phenomenon, and the
condensation can be wiped away with a dry towel.
◆Airflow sound: Refrigerants circulating in the refrigerant lines will produce eruption of sound and
grunts which is normal does not affect the cooling effect.
◆Buzz: Buzz will be generated by running compressor specially when starting up or shutting down.
◆Clatter: The solenoid valve or electric switch valve will clatter which is a normal phenomenon
and does not affect the operation.
◆The refrigerating chamber will periodically frost and defrost (water drops will be generated on the
backside of the refrigerating chamber when defrosting) which are normal.
Whether the refrigerator is connected to power,
whether the illuminating light is damaged.
7

WARNNING
Caution:risk of fire
RECOMMENDATIONS：
1) WARNING Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of
obstruction.
2) WARNING Do not damage the refrigerant circuit.
3) WARNING Do not use electrical appliances inside the food storage compartments of the appliance,
unless they are of the type recommended by the manufacturer.
4) The appliance has to be unplugged after use and before carrying out user maintenance on the
appliance.
5) This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
6) Children should be supervised to ensure that they do not play with the appliance.
7) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
8) Please abandon the refrigerator-freezer according to local regulators for it use flammable blowing gas
and refrigerant.
9）Please according to local regulations regarding disposal of the appliance for its flammable refrigerant
and blowing gas. Before you scrap the appliance, please take off the doors to prevent children trapped.
Correct Disposal of this product：
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.
