Euromarc Craftsman C710-7 User manual

WARNING
• These instructions must be read, understood, and followed: improper use or failure to wear the respirator during all times of exposure
may result in severe illness, permanent disability or death.
• Always be sure both mask and filter selection is: appropriate for the application; worn at all times during exposure; filters are replaced
when necessary.
• Refer to information supplied to check suitability or contact Euromarc 0800 278 600.
• Do not use in environments at less than 19.5% oxygen.
• Only use with Euromarc Craftsman filters listed in the table below and only in the stated applications.
• The wearer must be trained in the use of all equipment and in respect of relevant workplace health and safety regulations.
• Beards and facial hair will inhibit the effective sealing of the mask against the user’s skin. Use an alternative mask if a complete
and effective seal is not achievable.
• Do not use in flammable environments.
• Do not use if type, toxicity or concentration of contaminants is unknown. Do not enter hazardous area.
• Leave work area immediately, check integrity of respirator and replace any parts if: a) damage has occurred or is apparent.
b) dizziness, illness or irritation occurs. c) breathing resistance increases. Dispose of all used filters.
• Never modify or alter this product, doing so could jeopardize your safety.
• While materials in this mask do not commonly cause allergic reactions, if you notice any reaction or irritation cease use
and seek medical advice.
• P3 rated protection can only be achieved when using a full-face mask, irrespective of filter choice.
PREPARATION FOR USE
Check that the mask is complete, undamaged and assembled correctly.
Damaged or faulty respirators must be replaced - contact Euromarc 0800 278 600.
INSPECTION
The following points must be checked before use:
1. The material should be soft and pliable to conform to the face. Check the face-piece, valves and diaphragm for
any cracks or tears and ensure the shape of the mask is not distorted.
2. Make sure all seals are correctly positioned. Remove the front plastic piece to check the exhalation diaphragm.
3. Inspect head-straps, clips and harness to ensure an effective seal.
4. Ensure mask is clean. Dust and dirt in the valves or bayonet fittings can impair effective protection.
This product meets the requirements of AS/NZS 1716:2012 and should be used in
combination with a pair of approved Euromarc Craftsman filters to form a filtering
apparatus for respiratory protection.
USER INSTRUCTIONS
Please read these instructions before using the Euromarc Craftsman 710 series
masks and filters.
HALF FACE
RESPIRATOR
A R T. Pcs. SIZES
C710-7 S1
C710-8 M1
C710-9 L1
Euromarc 710 Series Filter
710
AS/NZ 1716 : 2012 Lic 40344
SAI Global

FITTING INSTRUCTIONS
1. The filters have a 3-point locking system - align openings on the back of the filter with
the fitting on the mask, press and turn filter clockwise until it is firmly attached (fig. 9 and
10).
2. With one hand hold the respirator over the mouth sitting it on the bridge of the nose,
then fit head harness over the crown of the head with the other hand, taking care that
the elastic straps are not twisted (fig. 1).
3. Hook the two bottom straps together behind the neck.
4. Firstly, tighten the head harness by pulling on the ends of the straps – ensure
a comfortable but firm and secure fit. Tighten the bottom straps in a similar manner
(fig. 1) (Strap tension may be decreased by pushing out on the back
side of the buckles).
5. For a drop-down suspensed mask, adjust the harness as shown on
(fig.2, 3 to fig. 4) then repeat steps 2, 3 and 4 to fit mask.
FIT CHECK
1. Positive-Pressure test: place the palm of your hand over vent in the exhalation valve
cover and breathe out (fig. 5). If no air leaks are present the mask will bulge out – you
have a good seal.
2. Negative-Pressure test: press your palms firmly over the filters, try and cover as much
area as possible, inhale gently and hold your breath briefly. If no air leaks are present
the face piece will collapse slightly - you have a good seal (fig. 6).
3. If you detect any air leaks in either test try repositioning the respirator on the
face and/or adjust the tension on the elastic straps. You may need to use a different size.
4. Repeat steps 1-3 until you have a good seal.
If you CANNOT achieve a proper fit DO NOT enter the hazardous area. It is recommended
that wearers should be fit tested in accordance with AS/NZS 1715.
MAINTENANCE AND CLEANING
Euromarc recommends cleaning the mask after each use. Use designated respirator
cleaning wipes, and wipe the face seal and internal surfaces. Or remove the filters and
wash in warm clean water (below 50° C).
Leave to air-dry at room temperature in a clean environment (fig. 8).
CAUTION: using cleaners containing oils, detergent or abrasive chemicals can destroy the
integrity of the mask. Masks and filters should be inspected before each use as described
above. Damaged masks should be discarded.
STORAGE
Masks should be stored in their original packaging in dry, clean conditions, between -10 to
+40°C, and away from direct sunlight, high temperature, chemicals and vapours. Masks
have a life-span of 5 years from date of manufacture, including shelf-life and time in-use.
The date of manufacture can be established by examining the date clock on the inside of
the face piece as shown in (fig. 7). After each use and cleaning, masks should be stored in
their original packaging or a sealed container, do not store in contaminated areas.
APPROVALS
These filters comply with Australian/New Zealand Standard
AS/NZS 1716:2012 and have been accredited and certified
as such by SAI Global. AS/NZ 1716 : 2012 Lic 40344
SAI Global

AS/NZ 1716 : 2012 Lic 40344
SAI Global
FITTING INSTRUCTIONS FOR USE
Craftsman Particulate Pre-Filter 713 is used in conjunction with Craftsman Gas/Vapour filter ABEK 719, for protection
against mechanically and thermally generated particles and clogging by sanding, polishing dust, or paint particles.
• To be used with 713R Retainers to connect the 713 filter to the 719 filter.
PARTICULATE
PRE-FILTER P2
For use against
both mechanically
and thermally
generated particulates.
C713 2
Euromarc 710 Series Respirator
When generating dusts
and fumes with sanding,
grinding, cutting, polishing,
or particles from welding
or fabricating.
713
PARTICULATE
PRE-FILTER P2 713
WARNING
• Always be sure that your respirator is: a) suitable for all
expected respiratory hazards in the workplace; b) your
respirator is fitted properly – refer to manufacturer’s
instructions; c) filter is replaced when necessary.
• Do not use for respiratory protection against unknown airborne
contaminants or when concentrations of contaminants are
unknown or as protection against substances immediately
dangerous to life or health.
• Do not modify or alter filters or face-pieces.
• Use with Euromarc 710 series respiratory.
• If in doubt about the correct use or suitability of this device for
any application, consult your supervisor, occupational health
professional or contact Euromarc.
• Always check the filters have not exceeded
the use-by date.
• Provides P3 protection only with full
face-piece espirator, and P2 protection
with half face-piece respirator.
PARTICULATE
FILTER GP3 For use against both
mechanically and thermally
generated particulates.
For use against all particulates
including highly toxic materials.
C718 2
Euromarc 710 Series Respirator
When generating dusts
and fumes with sanding, grinding,
cutting, polishing, or particles
from welding or fabricating.
Working with toxic particulates
such as mould remediation.
718
PARTICULATE
FILTER GP3 718
AS/NZ 1716 : 2012 Lic 40344
SAI Global

WARNING
• Always be sure that your respirator is: a) suitable for all expected respiratory hazards in the workplace; b) fitted properly – refer to
manufacturers instructions; c) filter is replaced when necessary.
• Do not use for respiratory protection against unknown airborne contaminants, when concentrations of contaminants are unknown or
exceed 10x workplace exposure limits, against substances immediately dangerous to life or health.
• Do not modify or alter filters or face-pieces.
• Use with Euromarc 710 series respiratory.
• If in doubt about the correct use or suitability of this device for any application, consult your supervisor, occupational health
professional or contact Euromarc.
• Always check the filters have not exceeded the use-by date.
• Do not use where there may be a deficiency of Oxygen.
718 & 719 FILTER INSTRUCTIONS FOR USE
1. Check identification on the filters to ensure you have the correct filters for the application.
2. a) Align the filter bayonet fitting with the facepiece bayonet fitting. b) Rotate 1/4 turn clockwise to attach (fig 9, 10).
CAUTION: Over rotation will result in damage to the filter and facepiece.
Note: These filters are supplied in pairs of identical classes and type and must be fitted, used and replaced at the same time.
3. Leave work area immediately, check integrity of respirator, and replace any parts if: a) damage has occurred or is apparent b)
dizziness, illness or irritation occurs c) breathing resistance increase. Dispose of all used filters.
STORAGE
Store in original packaging before use. Store between -10 and +35°C and less than 70% humidity. End of Shelf Life is 5 years after date of
manufacture.
APPROVALS
These filters comply with Australian/New Zealand Standard AS/NZS 1716:2012 and have been accredited and certified
as such by SAI Global.
GAS/VAPOUR
FILTER ABEK
Combination filter, for use against
Organic (boiling point >65°C),
Inorganic vapours, and Acid gases,
Ammonia and its derivatives.
C719 2
Euromarc 710 Series Respirator
When working with a variety of
solvents and acid gases such as
chlorine, hydrogen chloride,
sulfur dioxide, hydrogen fluoride,
hydrogen sulphide. Acid cleaning,
de-greasing, paints, thinners and
glues. Ammonia, refrigeration.
719
GAS/VAPOUR
FILTER ABEK 719
AS/NZ 1716 : 2012 Lic 40344
SAI Global
